Table of Contents
Advertisement
Quick Links
Models:
FG21SP-NG
FG21SP-LP
Decorative Gas Log Set
For Use With The Fogata
Grande only
• Important operating and
maintenance instructions
included.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fire may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas:
- Do not try to light any appliance.
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or
the gas supplier.
CAUTION
DO NOT DISCARD THIS MANUAL
Read, understand and follow
•
these instructions for safe
installation and operation.
• Keep children away.
• CAREFULLY SUPERVISE children around the firepit.
• Alert children and adults to hazards of high
• Keep clothing, furniture, draperies and other
Quadra-Fire • Fogata Grande
Owner's Manual
Installation and Operation
Tested and
Listed by
Leave this manual with
•
party responsible for
use and operation.
WARNING
HOT! DO NOT TOUCH.
SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
Cast iron and other surfaces are hot during
operation and cool down.
temperatures.
combustibles away.
Installation and service of this appliance should be performed
by qualified personnel. Hearth & Home Technologies
suggests NFI certified or factory-trained
professionals, or technicians supervised
by an NFI certified professional.
Beaverton
O-T L
Oregon USA
C
OMNI-Test Laboratories, Inc.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Quadra-Fire FG21SP-NG
Summary of Contents for Quadra-Fire FG21SP-NG
- Page 1 Owner’s Manual Installation and Operation Models: FG21SP-NG FG21SP-LP Tested and Beaverton O-T L Oregon USA Listed by Decorative Gas Log Set For Use With The Fogata OMNI-Test Laboratories, Inc. Grande only CAUTION DO NOT DISCARD THIS MANUAL Read, understand and follow Leave this manual with • Important operating and •...
- Page 2 The information contained in this owner’s manual, unless log set. The Fogata Grande you have selected is designed to noted otherwise, applies to all models and gas control provide the utmost in safety, reliability, and entertainment. systems. As the owner of a Fogata Grande, you’ll want to read and Your new Fogata Grande will give you years of durable use carefully follow all of the instructions contained in this owner’s and trouble-free enjoyment. Welcome to the Quadra-Fire manual. Pay special attention to all cautions and warnings. family of appliance products! This owner’s manual should be retained for future reference. We suggest you keep it with your other important documents and product manuals. We recommend that you record the following pertinent Homeowner Reference Information...
-
Page 3: Table Of Contents
D. High Altitude Installations ..... . . E. LP Gas Supply ....... . Quadra-Fire • Fogata Grande... -
Page 4: Listing And Code Approvals
IAS US requirements for Outdoor Gas Fireplaces, Draft 4-96 and ANSI Z21.58-1995/CGA 1.6-M96 for Cana- da and has been listed by OMNI for installation and opera- tion as described in these installation and operating instruc- tions. The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code ANSI Z223.1 or CAN/CGA-B149.1, National Gas Instal- lation Code or CAN/CGA-B149.2, Propane Installation Code. Quadra-Fire • Fogata Grande... -
Page 5: Getting Started
• Wear protective gloves voided by, the following actions: and safety glasses during installation. • Installation and use of any damaged components. • Modification of the burner or log assemblies. • Installation other than as instructed by Hearth & Home Technologies. • Improper positioning of the gas logs. • Installation and/or use of any component part not approved by Hearth & Home Technologies. Any such action may cause a fire hazard. Quadra-Fire • Fogata Grande... -
Page 6: Inspect The Appliance And Components
Damaged parts may impair safe • Read all of the instructions before starting the operation. installation. Follow these instructions carefully • Do NOT install damaged components. during the installation to ensure maximum safety and • Do NOT install incomplete components. benefit. • Do NOT install substitute components. Report damaged parts to dealer. Burner Assembly Valve Control Box Assembly Quadra-Fire • Fogata Grande... -
Page 7: Framing And Clearances
• Actual installation may vary due to individual design • Around air openings. preference. • For service access. Locate appliance away from traffic areas. A. Select Appliance Location When selecting a location for your appliance it is important to consider the required clearances to all combustibles. B. Clearances Place the Fogata Grande on a flat stable surface. The clear- ance requirements to any combustible material, to any side, is a minimum of 24 inches. Combustible materials are not allowed over the top of the Fogata Grande. Clearances Non-combustible Quadra-Fire • Fogata Grande... -
Page 8: Appliance Set Up
Feed the burner flex line, pilot tube and piezo ignitor wire since the control box will need to be removed in order to down through the center of the screen and grate and through complete the final installation. the oval hole in the side of the bowl The burner will rest flat on the upper tabs on the inside of Once the screws have been installed, remove the valve the bowl. control box in order to assemble the other componenets. Quadra-Fire • Fogata Grande... - Page 9 6) With the valve control box under the edge of the bowl, connect the pilot tube in the hole as shown in picture. The stainless steel flex connector is to be connected to the brass elbow located on the top of the valve control box. The piezo ignitor lead is to be connected to the ignitor lead coming out of the valve control box. Thermopile 8) Replace leg “A” under the Fogata Grande bowl and se- cure the valve control box on the two screws previously in- stalled in step 3 Figure 5 7) Feed the thermopile up through the oval hole in the bowl and insert it into the open hole in the pilot assembly. Ensure that the thermopile snaps into place and is securly in posi- tion to ensure proper connection. 9) With all the gas componets now securly in place, take the lava rock supplied and spread it over the screen so that it covers the sides of the burner but ensure it does not cover the top of the burner in order to ensure proper flame 10) Log Instalation and placement instructions for the log set are provided with the log set Quadra-Fire • Fogata Grande...
-
Page 10: Gas Information
(In Fittings and connections may have loosened the Commonwealth of Massachusetts installation must be during shipping and handling. performed by a licensed plumber or gas fitter.) Note: A listed (and Commonwealth of Massachusetts approved) 1/2 in. (13 mm) T-handle manual shut-off valve and flexible gas connector are connected to the 1/2 in. (13 mm) control valve inlet. • If substituting for these components, please consult local codes for compliance. Quadra-Fire • Fogata Grande... - Page 11 Fittings and connections may have loosened during shipping and handling. WARNING Fire Risk Explosion Risk Do NOT change the valve settings. • This valve has been preset at the factory. • Changing valve settings may result in fire hazard or bodily injury. WARNING Shock Risk Explosion Risk Do NOT wire 110V to valve. Quadra-Fire • Fogata Grande...
-
Page 12: High Altitude Installations
E. High Altitude Installations OMNI gas appliances are tested and approved without re- quiring changes for elevations from 0 to 2000 ft in the USA and Canada. When installing this appliance at an elevation above 2000 ft, it may be necessary to decrease the input rating by chang- ing the existing burner orifice to a smaller size. Input rate should be reduced by 4% for each 1000 ft above a 2000 ft elevation in the U.S.A., or 10% for elevations between 2000 and 4500 ft in Canada. If the heating value of the gas has been reduced, these rules do not apply. To identify the prop- er orifice size, check with the local gas utility. If installing this appliance at an elevation above 4500 ft (in Canada), check with local authorities. Quadra-Fire • Fogata Grande... -
Page 13: Operating Instructions
• Keep clothing, furniture, draperies and other combustibles away. Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to the owner’s information manual provided with this appliance. For assistance or additional information consult a qualified installer, service agency or the gas supplier. Piezo Valve Control Knob On/Off Switch WARNING The lighting instructions and operation of the unit are described on the following instructional page and MUST be followed to ensure the safe operation of this appliance. Quadra-Fire • Fogata Grande... -
Page 14: To Turn Off Gas To Appliance
• If the pilot will not stay lit after several tries, turn the gas control handle to “OFF” and call your service technician or gas supplier. Turn gas control handle counterclockwise to “ON”. TO TURN OFF GAS TO APPLIANCE Turn gas control handle clockwise to “OFF” position. Do not force. Control Knob (Shown in “Pilot” Position) Thermocouple Pilot Burner Assembly Quadra-Fire • Fogata Grande... -
Page 15: After The Appliance Is Lit
• Do NOT use gasoline, lantern fuel, Note: This appliance should be run three to four hours on kerosene, charcoal lighter fluid or similar the initial start-up. Turn it off and let it cool completely. This liquids in this appliance. will help cure the products used in the paint and logs. Combustible materials may ignite. WARNING Fire Risk High Temperatures Keep combustible household items away from appliance. • Do NOT obstruct combustion and ventilation air. • Do NOT place combustible items on top of or near appliance. • Keep furniture, draperies away from appliance. Quadra-Fire • Fogata Grande... -
Page 16: Troubleshooting
D. The pilot orifice is plugged, 1. This repair requires tools and some degree of not allowing gas to flow. experience. Call a qualified service technician. E. There is no gas supply to 1. Check the plumbing to ensure the fireplace has been the fireplace. hooked up the gas supply line. 2. The propane tank is empty. 2. The pilot lights, but A. There is a weak pilot flame 1. The pilot flame must engulf the thermocouple. will not stay lit after Clean and/or adjust the pilot for maximum flame carefully following lighting impingement on the thermocouple. instructions. 3. The pilot is on, but there is A. A blockage is preventing 1. Inspect the burner orifice for obstruction. Call a no gas to the main burner; gas flow. qualified service technician. the valve knob is on. B. Defective valve. 1. Replace the gas valve. Call a qualified service technician. Quadra-Fire • Fogata Grande... -
Page 17: Maintaining And Servicing The Appliance
• Ensure appliance is completely cooled. • Gas connections and fittings. Risk of: • Fire • Delayed ignition or explosion • Exposure to combustion fumes • Odors Maintenance and Service Tasks: Inspect Maintenance Tasks Burner Assembly Remove logs and examine burner. Vacuum and wipe out dust, cobwebs, debris or pet hair. Use caution when cleaning these areas. Screw tips that have penetrated the sheet metal are sharp and should be avoided. Remove any foreign objects Inspect for paint condition, warpage, corrosion. Sand and repaint as necessary. Verify unobstructed air circulation. Logs Inspect for broken, damaged or missing logs. Replace as necessary. Verify correct log placement and no flame impingement causing sooting. Correct as necessary. Verify logs are clean and carbon (soot) free. Logs may be cleaned with a dry bristle brush or dry cloth. Handle logs with care as they are fragile and easily damaged. Burner ignition and operation Verify all gas connections are tight and leak-free. Clean off burner top corrosion or deterioration. Replace burner if necessary. Check for smooth lighting and ignition carryover to all ports. Verify there is no ignition delay. Inspect for lifting or other flame problems. Inspect orifice for soot, dirt or corrosion. Verify manifold and inlet pressures. Adjust regulator as required. Quadra-Fire • Fogata Grande... -
Page 18: Reference Materials
Reference Materials A. Service Parts List FOGATA GRANDE Service Parts Description of Part Part Number Qty. Valve Assembly Complete Thermopile Burner Assembly Complete Pilot Assembly (without Thermopile) Quadra-Fire • Fogata Grande... - Page 19 FOGATA GRANDE Service Parts B. Logs Log 3 Log 2 Log 1 Log 4 Log 6 Log 5 Log 7 Log 8 Log 9 Description of Part Part Number Qty. Log Log Log 3 Log 4 Log Log Log Log 8 Log Quadra-Fire • Fogata Grande...
- Page 20 FOGATA GRANDE Service Parts B. Logs (continued) Log 12 Log 11 Log 10 Log 15 Log 13 Log 14 Log 17 Log 16 Description of Part Part Number Qty. Log 10 Log Log Log 13 Log 14 Log Log Log Quadra-Fire • Fogata Grande...
-
Page 21: Limited Lifetime Warranty
WARRANTY IS LIMITED TO THE DURATION OF THE WARRANTY SPECIFIED ABOVE. IN NO EVENT SHALL HEARTH & HOME TECHNOLOGIES BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY DEFECTS IN THE PRODUCT. Some states do not allow limitations on how long an implied warranty lasts, or do not allow exclusion or limitation of incidental or consequential damages, so these limitations may not apply to you. To obtain service under this warranty, you must: 1. Send written notice of the claimed condition to: The Technical Services Department, Hearth & Home Technologies Inc., Mt. Pleasant, 1915 W. Saunders St., Mt. Pleasant, IA 52641 (phone: 1-800-927-6841). 2. Affirm that you are the original owner of the Product. 3. Provide Hearth & Home Technologies reasonable opportunity to investigate the claim, including reasonable opportunity to inspect the Product prior to any repair or replacement work and before the Product or any component of the Product has been removed. 4. Obtain Hearth & Home Technologies’ consent to any warranty work before the work is done. © 2004 Hearth & Home Technologies Inc. 803-905 8/04 Quadra-Fire • Fogata Grande...
