- Page 1 2402646 SERIES MD’s Medium Temperature Merchandisers PLEASE READ THIS MANUAL BEFORE USING THE PRODUCT Installation & Operation Manual P/N 2402646A MD-10, MD-14 Agust 2005 HUSSMANN - CORPORATION 1331 Seamist Drive Houston TX 77008 Phone (713) 861-9171...
-
Page 2: Table Of Contents
2402646 TABLE OF CONTENTS PAGE INTRODUCTION, INSPECTION, LOCATION and CLEARANCE SKID, LEVELING and SEALING DRAINS SERIAL PLATE AIR DISTRIBUTION and PRODUCT LOADING POWER REQUIREMENTS ELECTRICAL BOX, POWER SWITCH, TIME CLOCK CONNECTIONS SPECIFICATIONS, DIMENSIONS, BTU CAPACITY SHELVING, TEMPERATURE CONTROL, CONDENSING UNIT THERMOMETER LIGHTING, LAMP SWITCH, BALLAST NIGHT COVER, CLEANING EXTERIOR... -
Page 3: Introduction, Inspection, Location And Clearance
NSF approved material DRAINS such as General Electric RTV -102 silicone sealant or equivalent. Hussmann MD model cabinets offer maximum versatility in the display of medium temperature DRAINS - prechillded products such as prepared salads, pizzas, fresh entrees, and dairy products. -
Page 4: Electrical Box, Power Switch, Time Clock
2402646 local codes. Separate circuits are recommended for MODEL Length Width Height each cabinet in order to prevent product loss due circuit MD-10 39" 33" 5/8 77" overloading of malfunction of other equipment, which may be on the same circuit. For proper operation of the MD-14 52"... -
Page 5: Condensing Unit
2402646 bulb located under the top header. The bulb is sleeved to maintain proper heat around the bulb for maximum light intensity and to protect the product in case of breakage. The bulb can be replaced without removing shelves or product .To replace the bulb, twist the bulb and slide the prongs clear of the lamp holder. -
Page 6: Refrigeration
2402646 proper operating temperature before reloading product. REFRIGERATION - The MD models employ a refrigeration system using a hermetic compressor, with refrigerant flow being controlled through the use of a capillary tube. In the event the capillary tube may become partially or fully restricted, replace the entire tube. -
Page 7: Trouble Shooting Charts
2402646 TROUBLE SHOOTING CHARTS TROUBLE PROBABLE CAUSE SOLUTION Compressor will not start no 1. Power disconnected 1. Check service cord or noise wiring connection. 2. Blown fuse or breaker 2. Replace fuse or reset breaker 3. Defective or broken wiring 3. -
Page 8: Lighting Troubleshooting
Quality Control Department. Contact your Hussmann Distributor for instructions on returning in-warranty parts. Warranty parts must be returned to the factory within 30 days of date of failure to assure proper disposition. -
Page 9: Warranty
Hussmann Corporation SHALL NOT BE LIABLE: A) For any repairs or replacements made by buyer without the written consent of Hussmann or when equipment is installed or operated in a manner contrary to the printed instructions covering installation and service which accompanied.
