- Page 1 DS-60...
- Page 2 DS-60 The DS-60 is a precision, 3-axis Doppler Sonar While retaining the measurement accuracy of the DS-30, designed to output the required information for berthing the DS-60 provides a greatly downsized transducer unit.
- Page 3 Full compliance with IMO MSC.36(63), MSC.96(72), A.694(17) and A.824(19), required for the vessels of 50,000 GT and greater Delivers high precision measurement required for berthing and docking maneuvers 3-beam transmission reduces the effects of vessel’s pitch and roll in order to output precision measurements Ground-tracking speed measurement range of up to 200 m Workload for installation has been greatly reduced thanks to its compact transducer unit 8.4-inch color LCD display gives high-legibility, real-time information in both graphics and alphanumerics...
- Page 4 NAV Data Status of echoes in last 3 minutes. Speed tracking mode Green: ground tracking -Ground Blue: water tracking -Water (Auto) Background color: no echo Position Heading source/value GPS measured Doppler SOG/COG SOG/COG Depth (selectable from echo sounder or doppler) Current speed/direction Drift angle...
-
Page 5: Specifications
SPECIFICATIONS PRODUCT NAME DOPPLER SONAR ENVIRONMENT Temperature MEASUREMENT RANGE OF SHIP'S SPEED Main Display -25˚C to +55˚C Fore-Aft -10.0 to 40.0 kn Other Units -15˚C to +55˚C Port-Starboard -9.9 to 9.9 kn Waterproofing MEASUREMENT DEPTH Main Display Front: IP56 Back: IP22 Speed over ground 1 to 200 m below hull bottom Distribution Box... -
Page 6: Distribution Box
310 12.2" All brand and product names are registered trademarks, trademarks or service marks of their respective holders. SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE FURUNO ELECTRIC CO., LTD. FURUNO FINLAND OY FURUNO DEUTSCHLAND GmbH FURUNO ESPAÑA S.A. 1112PDF Printed in Japan...
