- Page 1 METRO ® Model No. MG481KA322P—Serial No. 312000000 and Up Picture below may not reflect actual product. Part No. 4500-942 Rev. A...
- Page 2 PRH: phillips round head Touch Up Paint Exmark black touch up spray paint – gloss black. Exmark red touch up paint (spray paint – P/N 1-850337 - .6 oz liquid bottle – P/N 103-9140). © 2011—Exmark Mfg. Co., Inc. Contact us at www.Exmark.com.
-
Page 3: Table Of Contents
If your Exmark dealer does not have the Exmark part in stock, Exmark will get the parts to the dealer the next business day or the part will be FREE Guaranteed!! (Some restrictions apply. See your participating Exmark Dealer for details.) -
Page 4: Mower Deck Assembly
Mower Deck Assembly 4500-942A... - Page 5 ● Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on threads. ■ Requires installation of mulch kit for proper mulching. See your Exmark dealer for details. ▲ Apply Mobil HTS grease (P/N 103-5217 1.5 oz packet) (or a food-grade anti-seize). See operator s manual for locations.
-
Page 6: Engine Deck Assembly
Engine Deck Assembly 4500-942A... - Page 7 Engine Deck Assembly (continued) Ref. Part Number Qty. Description Ref. Part Number Qty. Description 116-6131 Rear Deck (116-6084-01) 1-633453 Spacer-Clutch W/Decals 1-603610 Washer-Spring Disc 7/16 1-323500 Transmission 9264964 Bolt-HWH 5/16-18 X 3/4 Tap 1-324340 Asm, Coupling, W/Guard 1-303186 Bellcrank And Zerk 1-323278 Sheave-Transmission ●...
-
Page 8: Engine Deck Assembly (Cont.)
Engine Deck Assembly (cont.) 4500-942A... - Page 9 Engine Deck Assembly (cont.) (continued) Ref. Part Number Qty. Description Ref. Part Number Qty. Description 103-1611-03 Arm-Brake 323-39 Screw-HH 3/8-16 X 5 302-19 Zerk-1/4-28 Str 1-523157 Washer ● 1-322141-03 Axle 1-543436 Washer-Spacer ● 2412-104 Clamp-R 98-5975 Washer-Spring Disc 3/8 103-1615-03 Arm-Idler, LH 1-323307 Pin-Clevis 1/2 X 1...
-
Page 10: Pistol Grip Upper Handle And Controls
Pistol Grip Upper Handle and Controls 4500-942A... - Page 11 1-303097 Grip-Handle 1-403121 Switch-Key 1-324279 LH Thumb Latch ASM ● 31:1 1-603511 Key-Ignition 1-303019 Grip-Latch 31:2 103-2106 Key-Exmark Logo 1-302006 Drive Lever ASM 1-303363 Spring-Extension 1-303021 Grip-Lever, Drive 33094-00 Washer 1-324280 RH Thumb Latch ASM 103-1796 Cable-Choke 1-323229 Clip-Loom 3/8...
-
Page 12: Fuel Tank Assembly
Fuel Tank Assembly Ref. Part Number Qty. Description Ref. Part Number Qty. Description 2412-98 116-3656 Asm-Fuel Tank Clamp-Hose 114-0284 1-603770 Valve-Fuel Grommet 103-2605 Fitting-Fuel Bulkhead 120-2235 Filter-Air W/Strainer ▲ 322-10 Screw-HH 5/16-18 X 2 104-8300 Nut-Nyloc 5/16-18 Flg 3256-3 Washer-5/16 Std 107-4543 Clamp 116-4346... -
Page 13: Decals
Decals Ref. Part Number Qty. Description Ref. Part Number Qty. Description 103-1798 Decal, Throttle 1-323550 Decal, Neutral/Brake 103-2882 Decal,Exmark Logo 116-4769 Decal-Filter, Emissions 117-2718 Decal-Arrester, Spark 103-2920 Decal, Metro Model 103-2076 Decal-Caution 1-303508 Decal-Warning, Discharge 1-323427 Decal, Belt Routing 1-403005... - Page 14 Notes:...
- Page 15 Synthetic formulation. Gas & Diesel compatible. Anti-corrosion additives. API 'SL' and JASO rated with wet clutch compatibility for other machines. Available from your local Exmark dealer. Find your closest dealer at exmark.com...
- Page 16 Pack) or Fill in Below Engine Model No. and Spec. No. Model No. Engine Serial No. (E/No) Serial No. © 2011 Exmark Mfg. Co., Inc. Part No. 4500-942 Rev. A Industrial Park Box 808 (402) 223-6300 Beatrice, NE 68310 Fax (402) 223-5489 All Rights Reserved Printed in the USA.
