QUICK REFERENCE GUIDE

INDICATES ALARM STATUS
=
MUSIC WAKEUP
=
TONE WAKEUP
TAP TO ACTIVATE ALARM
PRESS AND HOLD TO ADJUST ALARM
RADIO STATION PRESET BUTTONS:
PRESS AND HOLD TO STORE
CURRENT STATION
TAP TO PLAY STORED STATION
INSERT HEADPHONES WITH 3.5mm STEREO MINIPLUG HERE FOR PRIVATE LISTENING
3.5mm STEREO MINIJACK FIXED LEVEL AUDIO
OUTPUT, ALSO FUNCTIONS AS A MIXING INPUT
PRESETS
INSERT AUDIO PLAYER WITH 3.5mm STEREO MINIPLUG HERE:
ADJUSTS VOLUME DURING NORMAL OPERATION: ADJUSTS SETTINGS IN JOG BUTTON OPERATION.
AM ANTENNA
INPUT MINIJACK
REAR 3.5mm STEREO
MINIJACK AUXILIARY INPUT
8
NORMAL OPERATION: PRESS TO MUTE SOUND.
DURING WAKEUP: PRESS TO TO ACTIVATE SNOOZE FEATURE.
HEADPHONES
MIXING AM
INPUT AUX ANTENNA
RECORD INPUT INPUT
OUTPUT
AUX-F
SELECT
PRESS
REPEATED
BASS _ +4 TO
TREBLE _ +4
STEREO, W
LOUDNESS
FM ANTENNA INPUT
EXT
INT
75 OHMS
INTERNAL / EXTERNAL
FM ANTENNA SELECTOR
