S E E P A G E S 8 - 9 F O R Q U I C K R E F E R E N C E G U I D E
SoundWorks Radio 730
User Manual
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SoundWorks Radio 730 and is the answer not in the manual?

Questions and answers

Related Manuals for Cambridge SoundWorks SoundWorks Radio 730

Summary of Contents for Cambridge SoundWorks SoundWorks Radio 730

  • Page 1 S E E P A G E S 8 - 9 F O R Q U I C K R E F E R E N C E G U I D E SoundWorks Radio 730 User Manual ®...

  • Page 2: Do Not Open

    The lightning flash with arrowhead, The exclamation point within an equilat- within an equilateral triangle, is intended eral triangle is intended to alert the user to alert the user to the presence of to the presence of important operating uninsulated “dangerous voltage” within and maintenance (servicing) instructions the product’s enclosure that may be of in the literature accompanying this...
  • Page 3 8 AM station presets. The large 32-character display and full-function remote makes radio operation easy from across the room. The SoundWorks Radio 730 will also display Radio Data Service (RDS) FM station text. An automatic dimmer function reduces display bright- ness in dark rooms while maintaining good legibility in bright light.

  • Page 4: Getting Started

    GETTING STARTED Remove the SoundWorks Radio (See A) from its pro- tective polybag and place it in your preferred location. The Radio’s Tone alarm and Subwoofer outputs will be reduced if the Radio is placed on a compliant, soft surface. Connect the AM antenna (See B): To prepare the antenna (1), fold the base (2) and snap it into place (3).
  • Page 5 GETTING STARTED Setting the Clock You can adjust the current time whether the Radio is in Standby or On. Just press the time adjust buttons STEREO WIDE MONO 9 : 43AM (by the symbol) on the right hand side of the AUX-F TUNE display (See E).
  • Page 6 GETTING STARTED Tuning Stations • Autotune Method 1: Press the SEEK button (remote or radio face) to automatically find the next STEREO WIDE MONO FM2 P1 88 . 1 9 : 43AM listenable station of higher frequency (See I). AUX-F TUNE PRESETS •...

  • Page 7: Connecting An External Audio Source

    CONNECTING AN EXTERNAL AUDIO SOURCE Listening To External Sound sources FM ANTENNA INPUT MIXING ANTENNA INPUT If you have an external audio source you always want RECORD INPUT INPUT OUTPUT 75 OHMS to keep connected to the SoundWorks Radio, like a desktop cassette player, connect it to the AUX input on the rear panel (See L).

  • Page 8: Quick Reference Guide

    QUICK REFERENCE GUIDE NORMAL OPERATION: PRESS TO MUTE SOUND. DURING WAKEUP: PRESS TO TO ACTIVATE SNOOZE FEATURE. INDICATES ALARM STATUS MUSIC WAKEUP TONE WAKEUP TAP TO ACTIVATE ALARM PRESS AND HOLD TO ADJUST ALARM PRESETS RADIO STATION PRESET BUTTONS: PRESS AND HOLD TO STORE CURRENT STATION TAP TO PLAY STORED STATION HEADPHONES...
  • Page 9 SELECTS FM BAND FM: TAP TO MANUAL TUNE, PRESS AND HOLD PRESS AGAIN TO SWITCH TO SEEK NEXT STATION. ALARM SET: TAP TO SET WAKEUP TIME. BETWEEN PRESET BANK 1 OR 2 TAP TO AUTOMATICALLY SEEK THE NEXT STATION UP THE BAND. ADJUSTS VOLUME DURING NORMAL OPERATION ADJUSTS SETTINGS IN JOG BUTTON OPERATION SELECTS AM BAND (ONE PRESET BANK)

  • Page 10: Convenience Features

    CONVENIENCE FEATURES Mute To mute the SoundWorks Radio: Press the SNOOZE/MUTE bar or the SNOOZE/MUTE button on the Remote Control (See P). Mute is cancelled if the Radio enters Standby. Sleep Delay To make the Radio automatically turn off after a specific period of time: •...
  • Page 11 JOG FUNCTIONS JOG button operation: Press the JOG button on the Radio or on the remote control to access JOG functions (See S). Press the JOG button again to select additional STEREO WIDE MONO FM2 P1 JOG functions. 88 . 1 09 : 43 AUX-F TUNE...

  • Page 12: Wakeup Functions

    WAKEUP FUNCTIONS Adjusting The Wakeup Settings 1. MUSIC WAKEUP Adjustment, First screen During Wakeup Settings adjustment, you select Wakeup time and the Music Wakeup Source and Volume. The STEREO WIDE MONO WAKEUP T I ME 7 : 57 AM choice of Tone or Music Wakeup is selected when the AUX-F TUNE PRESETS...
  • Page 13 WAKEUP FUNCTIONS Adjusting The Wakeup Settings 4. WAKEUP Time adjustment 4) Adjust the Wakeup time by using the Time adjust- ment on the front panel of the TUNE adjustment on STEREO WIDE MONO FM WAKEUP 7 : 57 AM the remote control. AUX-F TUNE PRESETS...

  • Page 14: Snooze Function

    WAKEUP FUNCTIONS Activating the Wakeup Feature While in Standby or normal operation, tap either Alarm STEREO WIDE MONO ALARM 1 MUS I C WAKEUP button to cycle between AUX-F TUNE PRESETS 6) Music Wakeup VOLUME FM 1/2 SEEK POWER 7) Tone Wakeup TUNE WAKEUP TIME...
  • Page 15 RADIO DATA SERVICE (RDS) Some FM radio stations transmit Radio Data Service RADIO DATA Service display (RDS) text along with their programs. This text general- STEREO WIDE MONO UP NEXT: BORN I N ly shows the current program or music titles and may FM 1 0 1 .7 2 : 1 7 PM include information about upcoming programs or music.

  • Page 16: Specifications

    SPECIFICATIONS Internal audio sources: FM stereo tuner with display of Radio Data Sevice text from supporting FM stations. AM tuner. Inputs: One rear panel AUX IN 3.5 mm stereo minijack One rear panel MIXING INPUT (combined with REC OUT) 3.5 mm stereo minijack One rear panel AM Antenna 3.5 mm stereo minijack Antenna stereo mini plug wiring configuration sleeve –...
