- Page 1 SoundWorks Radio 705 ® User Manual High Performance AM/FM Table Radio With Stereo Headphone Output Auxiliary Input SWR705UserManual_v3.indd 1 10/3/06 4:57:33 PM...
- Page 2 The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The excalmation point within an equilateral triangle is intended to alert the user to the presence...
- Page 3 15 of the FCC rules. These limits are designed to provide reasonable protection agains harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment...
-
Page 4: Radio Features
Radio Features SWR705UserManual_v3.indd 4 10/3/06 4:57:35 PM... -
Page 5: Operation
Setup Connect AC Power Cord. Operation Press Power Button. Green Light is ON. SLEEP DELAY: From OFF, press Power Button until Amber Light appears. SWR705UserManual_v3.indd 5 Select Source (FM, AM or Auxiliary). Tune Radio and adjust Volume. Adjust TONE as desired. FM only FM and AM FM only 10/3/06 4:57:36 PM... -
Page 6: Additional Information
Additional Information 1) Use a 3.5 mm plug with the Auxiliary Input. 2) Connect headphones to the " " jack. SWR705UserManual_v3.indd 6 3) The internal FM antenna (INT) is sensitive enough for all local stations. For weak or distant stations, an external antenna can be connected as shown. Set switch to EXT. 10/3/06 4:57:36 PM... -
Page 7: Specifications
Specifications Dimensions 5.125 in ..Height ... 130 mm 8.75 in ..Wide ... 212 mm 6.25 in ..Depth w/ knobs ..160 mm Weight 4.5 lbs ..2.0 kg Sensitivity Usable (30 dB S/N) ...18 dBf 50 dB S/N ..27 dBf Image Rejection ..46 dB IF Rejection ..61 dB AM Rejection ... 55 dB Selectivity (+/ ) ... - Page 8 Rev 1b English SWR705UserManual_v3.indd 8 10/3/06 4:57:37 PM...
