- Page 1 User Manual 1099-01-1105 - VERSION B ® TATOU UTV 4S Track System Original notice Other languages translation available at www.camoplast.com...
- Page 2 IMPORTANT Please read carefully each part of this document as well as model specific Installation Guidelines prior to assembling, installing and using the track system. are trademarks of Camoplast Inc. All rights reserved. ©2010 Camoplast Inc. ® Printed in Canada.
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..........1 USING THE UTV WITH TRACKS . -
Page 4: Introduction
INTRODUCTION ® Thank you for choosing Tatou UTV 4S, a Camoplast UTV Track System, (hereinafter referred to as the "System"). You have made the right choice. This system will provide you with all the traction, performance and durability you require for recreational or work purposes and allows for year-round operation. - Page 5 USING THE UTV WITH TRACKS Always follow the UTV manufacturer's safety rules and regulations regarding, exemple passengers transportation, maximum loads, ect. It is the driver’s responsibility to follow the recommended schedules maintenance further described in this manual.
-
Page 6: Hints And Tips
HINTS AND TIPS HINTS AND TIPS Before leaving for an excursion, make sure you have the following within arms reach : 12 mm, 14mm, 16 mm, 17 mm, 19mm and 30 mm wrenches, one axe, one shovel, one tow cable, a lifting jack and one adjustable wrench. Generally, the slower you go, the better the traction will be. -
Page 7: Safety
1 866-533-0008 or by email at atvtracksystems@camoplast.com. Camoplast believes that there are certain risks related to the installation and use of the System. Our experience shows that the System is safe. However, the user must be aware of the risks related with driving an UTV with the particularities of this type of System. - Page 8 USER NOTICE AND DISCLAIMER The System consists of many moving parts, including transmission wheels. If an object lodges itself or becomes jammed into the System and blocks the track, it is mandatory to stop the engine and the vehicle and apply the security brake before removing object said.
- Page 9 Excessive speed remains one of the main causes of severe accidents on UTV. Camoplast is proud to offer UTV conversion kits within its wide range of products. UTV Track Systems are not only reliable, but safe. However, there are risks inherent to driving an UTV equipped with the System.
-
Page 10: Dangerous Situations
DANGEROUS SITUATIONS DANGEROUS SITUATIONS When using a vehicle equipped with track systems, it is important to respect the following safety recommendations. It is strongly recommended that the safety guidelines provided below are followed to prevent any accidents and serious malfunctions that could affect the occupants, the vehicle or the track systems from occurring. - Page 11 DANGEROUS SITUATIONS Steep descents WARNING It is not advisable to change direction during steep descents. This can lead to a serious malfunction of the UTV’s steering system and track systems. During a steep descent, it is advisable to keep the handlebar in a forward direction and to begin turning when the UTV is on flat ground, thus to avoid subjecting the components of the vehicle and the system to any high stress.
- Page 12 DANGEROUS SITUATIONS Descending and being stuck in reverse WARNING If the rear track systems get stuck in the snow, avoid moving or towing the vehicle in reverse to ease it from its position , as this could lead to a malfunction of the systems.
- Page 13 DANGEROUS SITUATIONS Towing a vehicle out of the snow WARNING If your vehicle must be towed out of the snow, never tow it in the direction in which it sank. Tow the vehicle in the direction of the trail it left as it became stuck.
- Page 14 DANGEROUS SITUATIONS Driving over an obstacle Driving over a steep ridge WARNING It is not advisable to attempt to drive over an obstacle, such a tree trunk, a big rock or a steep ridge that could lodge itself between the front and the rear track systems and immobilize the vehicle.
- Page 15 DANGEROUS SITUATIONS Exceeding the anti-rotation stroke on rough terrain WARNING Never exceed anti-rotation stroke of the front and rear track systems, system or vehicle faillure may occur. It is recommended to drive on a surface on which the track system is always fully supported.
- Page 16 DANGEROUS SITUATIONS Sharp turns in locked 4x4 mode WARNING Never do sharp turns in locked diffential 4x4 mode on a sticky terrain without lubrification. The track system is designed to slip into the drive system, keeping the vehicle from being overloaded. NOTE: Somes vehicles don’t have unlocked 4x4 mode on the rear differential, for those vehicles avoid the current situation, take wider turns instead.
-
Page 17: Installation, Removal And Re-Installation
INSTALLATION, REMOVAL AND RE-INSTALLATION INSTALLATION, REMOVAL AND RE-INSTALLATION WARNING Never place body parts under the vehicle unless it is securely placed on appropriate stands. Severe injuries could occur if the vehicle collapses or moves. Do not use a lifting device as a secure stand. Always follow good shop practices. - Page 18 INSTALLATION, REMOVAL AND RE-INSTALLATION WARNING To avoid any injury to your hands during the manipulation of the systems, we recommend you to manipulate the systems at places indicated in following figure (near to hub and near to the anchoring of the anti-pivot). Installation Execute all tasks described in Installation Guidelines of the vehicle model.
- Page 19 INSTALLATION, REMOVAL AND RE-INSTALLATION At the front: • Remove the anti-rotation bracket cover but keep the anchor bracket attached to the anti-rotation device on the track system. Figure 1 Leave anchor bracket attached to the stabilizing rod. • Remove track systems. •...
- Page 20 INSTALLATION, REMOVAL AND RE-INSTALLATION Re-installation Always clean wheel hubs on the UTV before installing wheels or track systems. Figure 2 Clean wheel hubs. • Re-install track systems at the rear and secure stabilizing rod to anchor bracket for rigid axle. •...
-
Page 21: Adjustments
ADJUSTMENTS ADJUSTMENTS Angle of attack for front tracks systems NOTE: Before adjusting your kit, make sure the vehicle is on a hard and flat surface like concrete. No lifting device should be installed. To obtain the correct angle of attack on front tracks systems, perform the following : •... - Page 22 ADJUSTMENTS Figure 4 • Set the nut (2) shown on Figure 5 until the flat bar reaches 315 ± 5 mm above the ground. For right hand side, rotating the wrench towards A makes the system rotate towards C while rotating the wrench towards B makes the system rotate towards D (reverse for left hand side).
- Page 23 ADJUSTMENTS • Turn the nut (1) until it comes in contact with the spring, then compress the spring by turning this nut 1.5 turns (refer to Figure 6). Figure 6 NOTE: In certain rare cases, where the adjustment of the nut (article 1 on Figure 6) compressing the spring, is close to the end of the threaded rod, lengthen the assembly by loosening the locknut (article 3 on Fig-...
- Page 24 ADJUSTMENTS Figure 7 Basic Tuning (front track systems): • An adjustment of more than 315 mm measured with the flat bar, gives easier steering with wobbling effect at high speed. • An adjustment of less than 315 mm measured with the flat bar, gives harder steering and more stability at high speed.
- Page 25 ADJUSTMENTS Angle of attack for rear track systems To obtain the correct angle of attack on rear tracks systems, perform the following : Vehicles with rigid axle or trailing arm suspension • Loosen the nut (1) compressing the spring of the stabilizing rod (see Figure 8).
- Page 26 ADJUSTMENTS Vehicles with independent suspension • Loosen the nut (1) compressing the spring of the stabilizing rod (refer to Figure 9). • Turn the nut (2) until it comes in contact with both rubber damper and bracket (3). Then, compress the rubber damper by turning the nut (2) one turn.
- Page 27 ADJUSTMENTS NOTE: In some rare cases where the adjustment of the nut (1) compressing the spring is near the end of the threaded rod, extend the rod by unlocking the jam nut (item 3 on Figure 10) and unscrew the rod to obtain 19 mm max.
- Page 28 ADJUSTMENTS Alignment It is required to align the tracks when the vehicle is placed on the ground. Before the measurements, move the vehicle for- wards on a distance of approximately 3 meters. Use a tape for the following measurements. Measure A: Measure the distance which separates the external plastic wheels of the front axle on the front track systems.
- Page 29 ADJUSTMENTS Measure B: Measure the distance which separates the exter- nal plastic wheels of the rear axle on the front track systems. See Figures 13 and 14. Figure 13 ( Distance between the rear plastic wheels) Figure 14 ( Distance between the rear plastic wheels) The distance between the outside wheels of the front axle (Measure A) and the rear axle (Measure B) should be equal.
- Page 30 ADJUSTMENTS Figure 15 (Steering Mechanism) NOTE: Everytime you verify the measurements, move the vehicle back and forth on a distance of approximately 3 meters. Method of ajustment To adjust the UTV, first unscrew the nut (1) of the coupling rod of the vehicle's direction system (2), screw or unscrew the cou- pling rod of an equal number of revolutions on the both sides of the vehicle.
- Page 31 ADJUSTMENTS Rubber track tension Adjust the tension the rubber track by turning the adjusting nuts of the track tensioner. Adjust track tension. Figure 16 NOTE: The two nuts are screwed on against the other to clamp the tension adjustment. Free the two nuts on against the other and then loosen the track adjustment.
- Page 32 ADJUSTMENTS The following table indicates the force (1) applied and the deflection (2) which must occur according to the conditions of use. Season Track Force Deflection Front 15 kg 19 mm Summer Rear 15 kg 19 mm Front 11 kg 19 mm Winter (snow) Rear...
-
Page 33: Installation Of A Rubber Track
INSTALLATION OF A RUBBER TRACK INSTALLATION OF A RUBBER TRACK If possible, position the vehicle on a flat and level surface (or on a suitable lift device). Turn off the engine. Proceed as follows : • Set rubber track tension to the minimum (refer to Figure 18). - Page 34 INSTALLATION OF A RUBBER TRACK Figure 19 • Install the rubber track NOTE: Compare with the other rubber tracks to find the correct orientation. • Re-install 255 mm wheels. • Adjust track tension. Refer to ‘’Rubber track tension’’ on page 28.
-
Page 35: Break-In Period
BREAK-IN PERIOD BREAK-IN PERIOD A break-in period is necessary in order to allow the components of the system to match themselves to each others. During the break-in period (4 hours or 80 kilometers), follow these recommendations : • Avoid running under dry and clean conditions. (For example: asphalts, hay or straw field, etc). -
Page 36: Replacement Of A Wheel With Extractor
REPLACEMENT OF A WHEEL WITH EXTRACTOR REPLACEMENT OF A WHEEL WITH EXTRACTOR WARNING Do not use air tools to remove the wheels. Use Tatou extractor # 2000-00-1050 (article 1, figure 20), and the following procedure to make the replacement: Figure 20 •... - Page 37 REPLACEMENT OF A WHEEL WITH EXTRACTOR • Place the extractor under the wheel as shown on figure • Then screw the threaded rod to remove the wheel.. Figure 21 • Insert the new wheel on the shaft until it reaches the shoulder.
-
Page 38: Maintenance Schedule
MAINTENANCE SCHEDULE MAINTENANCE SCHEDULE WARNING Do not insert hands nor feet into or near the system unless the engine is off, and the vehicle is stopped with the security brake engaged. For optimum performance and maximum durability, please refer to the following maintenance grid : NOTE: Phillips screwdriver. -
Page 39: Torque Table
TORQUE TABLE TORQUE TABLE Bolt M8 - 8.8 M10 - 8.8 M10 - 10.9 M12 - 10.9 STORAGE The best way to store the System is to lay down each frame on its side, away from direct sunlight. -
Page 40: Wear
WEAR WEAR Wheel Verify the wear of the wheels especially on the interior guidance strip (figure 22). The wheel must be replaced if the inner sur- face (article 1, figure 22) is perforated or when the thickness of the wheel rolling band reaches a thickness of 45 mm. A wheel that is excessively worn will not offer enough support for the track's guidance. - Page 41 WEAR Figure 23 Track Verify the wear of the track by inspecting the rolling path, the driving lug, the profile and the internal and external condition of the track's carcass. Make sure that the track’s internal structure are not visible at cuts or worn area. Too much wear could cause damage to the wheels and to the track's guide.
- Page 42 WEAR Figure 24 Anti-rotation Verify the wear of anti-rotation system, mainly at the ball joint (figure 25) to make sure that it is not seized or extremely loose. Ball joint damage could harm the performance of the track sys- tem. Figure 25...
-
Page 43: Warranty
(original receipt or sale contract) and work or repairs must be performed by an authorized Camoplast dealer. All claims not previously approved and authorized by Camoplast will be rejected. The following situations and items are not under any... - Page 44 (12) months from the date of original System purchase. In all cases, the warranty is limited to a maximum of the original purchase price or the fair market value of the System. Camoplast will have final authority in determining the fair market value of a used System.
-
Page 45: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING TROUBLE SHOOTING Problem Potential cause Correction to do Abnormal vibration Presence of debris in the system. Remove any debris which could prevent the proper operation of the system Severe and localized wear of a wheel ( Replace the part flat spot) Sprocket or wheel frozen Remove the ice/snow build up. -
Page 46: Serial Number Location
SERIAL NUMBER LOCATION SERIAL NUMBER LOCATION The following pictures show the location of the serial numbers on the track system frame and rubber track. Figure 26 Figure 27... -
Page 47: Technical Support
TECHNICAL SUPPORT TECHNICAL SUPPORT If your dealer or distributor is unable to solve a problem related with the System, you may contact the Camoplast support team from Monday to Friday. Camoplast Inc. 1701, 3 Avenue Grand-Mère, (Québec) J1X 0E6 CANADA E-maill : atvtracksystems@camoplast.com... -
Page 48: Ce" Declaration Of Conformity
PHONE : (819) 533-0008 PHONE : (819) 533-0008 FAX : (819) 533-5532 FAX : (819) 533-5532 WEB SITE : www.camoplast.com WEB SITE : www.camoplast.com HEREBY SOLE RESPONSABILITY THE CONFORMITY OF THE PRODUCT SERIES HEREBY SOLE RESPONSABILITY THE CONFORMITY OF THE PRODUCT SERIES... - Page 49 This page is left intentionally blank.
- Page 51 Item # Part # Description TATOU UTV4S - MY2011 FRONT LEFT & RIGHT 1001-00-7005 STABILIZING ROD ASS'Y, 370 LBS/IN 1008-77-0010 MULTI HUB SPACER 1-1/8" ASS'Y (METRIC) 1008-77-0020 MULTI HUB SPACER 2" ASS'Y (METRIC) 1009-00-7115 INJ SPROCKET, 15 TEETH 1009-00-7116 INJ SPROCKET, 16 TEETH 1009-00-7117 INJ SPROCKET, 17 TEETH 1009-00-7118...
- Page 53 Item # Part # Description TATOU UTV4S - MY2011 REAR LEFT & RIGHT 1008-77-0010 MULTI HUB SPACER 1-1/8" ASS'Y (METRIC) 1008-77-0020 MULTI HUB SPACER 2" ASS'Y (METRIC) 1008-77-0040 MULTI HUB SPACER 4" ASS'Y (METRIC) 1009-00-7115 INJ SPROCKET, 15 TEETH 1009-00-7116 INJ SPROCKET, 16 TEETH 1009-00-7117 INJ SPROCKET, 17 TEETH...
- Page 55 Item # Part # Description TATOU UTV4S - MY2011 INDEPENDENT SUSPENSION (IS) OPTION 1000-00-8002 THREADED ROD, LONG 1001-00-8005 STABILIZING ROD ASS'Y, 480 LBS/IN 1015-00-7026 BACK PLATE 1015-00-8005 BRACKET ANTI-ROT, UTV (IS) 1015-05-7005 SPACER 5/8", ANTI-ROTATION BRACKET 1033-10-1080 HEX SCR , ISO 4014 (DIN 931), 10.9, YZN / M10x1.5x80 1033-10-2025 HEX SCR W/WASH 25x2, 8.8, YZN, TL 9S-1026 / M10x1.5x25 1033-10-2045...
