Westerbeke 4.5 BCGTC Specifications

WESTERBEKE
The All New
Westerbeke BCGTC Series
Continuous Quality Power
Combining innovative technology and simplicity
of design, Westerbeke has managed, once again, to
set the standard in power generation with its new line
of gasoline powered generators, the BCGTC Series.
This new line of gasoline generators is powered
by an industrial three-cylinder gas engine. Like most
Westerbeke gensets, this series incorporates true
one-side servicing for complete access to all
serviceable components.
Like all Westerbeke gensets, these gasoline
generators feature fresh-water cooling and are fitted
with flexible mounts to prevent the transfer of
vibration. Fuel is supplied via a down draft style
carburetor for a smooth and precise fuel flow which
results in an extremely economical and durable
engine.
Perfect for smaller boats with limited space and
heavy electrical loads, the BCGTC Series, along with
its sister product, the EFI Series, are the smallest
gasoline generators Westerbeke has produced. They
have been designed with the boater in mind. All
Westerbeke generators are backed by a five year
limited warranty and by a worldwide network of
master distributors and dealers.
Many features are
standard equipment
Fresh water cooling
Vibration mounts
90° water injected elbow
Coolant recovery tank
Battery charging
Safety stop switch
Drip tray
Belt guard
Belt-driven sea water pump
Lube oil drain hose
Safety shut-downs — hi-coolant temperature, low oil
pressure,hi-exhaust temperature
Operator's manual and parts list
"CE" Mark
A.C. Circuit Breaker
CARB certified
EPA certified
Unit Dimensions
Length
Width
Height
Dry Weight 280 lbs. (127.0 kg
See other side for more dimension information
Photographs may show optional equipment
WESTERBEKE
W
Engines & Generators
GASOLINE
GENERATOR
4.5 BCGTC
Gasoline Generator
25.6" (650.2 mm)
14.3" (363.2 mm)
21.5" (546.1 mm)
)
4.5 BCGTC
Gasoline Generator
Optional Sound Guard enclosure
provides optimum silencing for the
generator. Ruggedly constructed
with all panels removable for easy
servicing and maintenance.
Length - 35.48in (901.19mm)
Width - 17.45in (443.23mm)
Height - 23.23 in (590.04mm)
Weight - 40 lbs.(18.14kg)
TM TM
4.5
BCGTC
60Hz
3.75
BCGTC
50Hz
W
