—Positioning the jack

Front
Adapter
5. Position the jack at the correct jack
point as shown.
When replacing front wheels,
adapter in the tool bag and install it on
the jack. Make sure the protruded edge at
the bottom of the adapter is securely fit
in the cutout at the top of the jack.
JACK POINTS:
Front—Under the frame side rail
Rear—Under the rear axle housing
When jacking up the rear tires, do not
install the adapter on the jack.
CAUTION
Make sure of the secure installation
of the adapter and the jack positioned
Rear
on a level and solid surface.
Make sure the jack is positioned on a
level and solid place.
get an
New L/C100(U)
Put a jack handle, jack handle extensions,
and jack handle end together as shown in
the illustration.
1 Jack handle end
2 Jack handle extensions
3 Jack handle
191
