Part 2
INFORMATION

BEFORE DRIVING

YOUR TOYOTA
D

Break- in period

D

Fuel

D
D
D
D
Facts about engine oil
consumption
D
Twin ground electrode spark
plugs
D
D
D
D
Your Toyota's identification
D
D
D
Break- in period
Drive gently and avoid high speeds.
Your vehicle does not need an elaborate
break- in. But following a few simple tips
for the first 1600 km (1000 miles) can add
to the future economy and long life of
your vehicle:
D
Do not drive over 88 km/h (55 mph).
D
Run the engine at moderate speed be-
tween 2000 and 4000 rpm.
D
Avoid full- throttle starts.
D
Try to avoid hard stops during the first
300 km (200 miles).
D
Do not drive slowly with the manual
transmission in a high gear.
D
Do not drive for a long time at any
single speed, either fast or slow.
D
Do not tow a trailer during the first 800
km (500 miles).
I n f o r ma t i o n P r o v i d e d b y :
C orolla (U)
Fuel
FUEL TYPE
Your new vehicle must use only un-
leaded gasoline.
To help prevent gas station mix- ups, your
Toyota has a new smaller fuel tank open-
ing. The special nozzle on pumps with
unleaded fuel will fit it, but the larger
standard nozzle on pumps with leaded gas
will not.
At a minimum,
the gasoline you use
should
meet
of
ASTM
D4814 in the U.S.A. and CGSB 3.5- M93
in Canada.
NOTICE
Do not use leaded gasoline. Use of
leaded gasoline will cause the three-
way catalytic converter to lose its ef-
fectiveness and the emission control
system to function improperly. Also,
this can increase maintenance costs.
OCTANE NUMBER
Select Octane Rating 87 (Research Oc-
tane Number 91) or higher.
Use of unleaded fuel with an octane num-
ber or rating lower than stated above will
cause persistent heavy knocking. If se-
vere, this will lead to engine damage.
129
