2006
C H R Y S L E R 3 0 0 C S R T 8
SPECIFICATIONS
Dimensions are in inches (millimeters) unless otherwise noted.
GENERAL INFORMATION
Body Style _________________________________________________________________ Four-door sedan
Assembly Plant _____________________________________________________Brampton, Ontario, Canada
EPA Vehicle Class _________________________________________________________________ Large car
Introduction Date ________________________________________________________ April 2005, MY 2006
ENGINE: 6.1-LITER, HEMI
®
V-8
Availability _______________________________________________________________________ Standard
Type and Description ____________________________________________ 90-degree V-type, liquid-cooled
Displacement _______________________________________________________ 370 cu. in. (6059 cu. cm)
Bore x Stroke _______________________________________________________4.06 x 3.58 (103.0 x 90.9)
Valve System _______________________________________ Pushrod-operated overhead valves, 16 valves,
sixteen conventional hydraulic lifters, all with roller followers
Fuel Injection _______________________________________ Sequential, multi-port, electronic, returnless
Construction _________________________Deep-skirt cast-iron block with cross-bolted main bearing caps,
aluminum alloy heads with hemispherical combustion chambers
Compression Ratio ___________________________________________________________________ 10.3:1
Power (estimated SAE net) _____________________________ 425 bhp (318 kW) @ 6,000 rpm (69.8 bhp/L)
Torque (estimated SAE net) ____________________________________ 420 lb.-ft. (569 N•m) @ 4,800 rpm
Max. Engine Speed _____________________________________________6,400 rpm (electronically limited)
Fuel Requirement ____________________________________ Premium 91 octane (R+M)/2—recommended,
Oil Capacity _____________________________________________________________________ 7 qt. (6.6L)
Factory Oil Fill ________________________________________________________ Mobil 10W-40 Synthetic
Coolant Capacity _____________________________________________________________ 14 qt. (13.25L)
Emission Controls ______________________________ Dual close-coupled three-way catalytic converters,
quad heated oxygen sensors and internal engine features
Max. Gross Trailer Weight ______________________________________________ Not rated for trailer tow
EPA Fuel Economy (mpg City/Hwy) ______________________________________________________ 14/20
TRANSMISSION: W5A580 FIVE-SPEED AUTOMATIC
Availability _______________________________________________________________________ Standard
Description ______________________________________ Adaptive electronic control, Performance tuned
AutoStick
driver-interactive manual control and
®
electronically modulated torque converter clutch
continued
Chrysler Brand Product Information
10
