SECTION
Contact Information........................................................................................................................................................2
Product Specifications...................................................................................................................................................2
Safety Instructions .........................................................................................................................................................3
Grounding Instructions..................................................................................................................................................5
Specific Safety Instructions for Bench Grinders ........................................................................................................6
Carton Contents .............................................................................................................................................................7
Assembly Instructions ...................................................................................................................................................8
Operating the Bench Grinder ......................................................................................................................................10
Maintenance ..................................................................................................................................................................13
Troubleshooting Guide ................................................................................................................................................13
Parts List .......................................................................................................................................................................14
Warranty.........................................................................................................................................................Back Cover
If you are unable to solve a problem using this manual, please contact us for advice.
Exclusive USA Agent: Colovos Company, 4444 West Ohio Street, Chicago, IL 60624, Tel.: (773) 533-4444
Repairs must be carried out only by qualified technical staff; and must follow the instructions and guidelines given in
this manual. Should technical assistance be required, contact Colovos Company at (773) 533-4444.
Colovos Company is not liable for, nor do they guarantee against, damage or operating malfunctions resulting from
alteration, abuse, and lack of maintenance or this product's use for other than its intended purpose. Failure to read and
follow the operating manual is not covered.
For repairs only use proper and suitable tools and parts purchased from an authorized agent.
Motor
Continuous Duty HP
Volts
Amps
Hertz
RPM
Grinding Wheel Size
Grinding Wheel Grit
Lamp
Tool Rests
Eye Shield Assemblies
Spark Arrestors
Quench tray

TABLE OF CONTENTS

CONTACT INFORMATION

PRODUCT SPECIFICATIONS

1/2
120
5.0
60
2000 R.P.M. to 3450 R.P.M.
(no load speed)
8" x 1", 5/8" bore
36 and 60
120V, 40 watt or less Track
Light Bulb, Type R20,
medium base or equivalent
(Not included)
Left and Right
Clear Lexan Left and Right
Left and Right
3.4" x 2.8" x 0.63"
WARNING
To avoid electrical shock to yourself and damage to the
Bench Grinder, use proper circuit protection.
The Bench Grinder is factory wired for 120V, 60 Hz,
operation. Connect to a 120V, 15 amp branch circuit
and use a 15 amp time delay fuse or circuit breaker.
The electrical circuit cannot have any wire size less
than #14. To avoid shock or fire, replace power cord
immediately if it is damaged in any way.
2
