V i s uA L P e R F o R M A n C e
V P 1 0 S U B, V P 1 0 S U B A M P
Product Family Overview
From the company that invented the category, comes the
best sounding, best looking and most complete range of
in-wall and in-ceiling speakers ever. Visual Performance

Features and Benefits

VP10sub in-Wall subwoofer combines elegant, modern
visual design with uncompromised bass performance for
home theaters and multimedia solutions. the integrated
cabinet design is only 3 7/8" (98mm) deep allowing it to be
mounted directly into a 15" x 15" (381mm x 381mm) cutout in
a standard 2 x 4 stud bay.
• VP10SUB design allows to fit directly into a drywall cutout or
recess in a concrete or brick wall
• VP10SUB features an innovative low profile driver with an ultra
low distortion motor, 4" diameter voice coil and dual spiders to
optimize the performance of the laminated carbon fiber
honeycomb woofer
Subwoofer Features
• Low profile driver
• 1.5" of peak to peak travel
• Ultra low distortion motor
• 4" diameter voice coil
• Dual spiders
• Laminated carbon fiber honeycomb cone
• Die-cast basket
• Visual Performance grille
• Integrated Cabinet

Specifications

Width: 15" (381mm)
Height: 15" (381mm)
Depth: 3 7/8" (98mm)
Cut Out Width: 12 3/4" (324mm)
Cut Out Height: 12 3/4" (324mm)
Series
®
V P 1 0 S U B
Cut Out
12.56 [319.0]
Height
15.00 [381.0]
s e R i e s
®
comes in various shapes and sizes to compliment down lights and
décor and a complete range that allows you to enjoy a consistent
aesthetic for any application in any room.
V P 1 0 S U B A M P
• The VP10SUB extends down to 34Hz using the matching
VP10SUB Amplifier and is capable of producing 105dB of output
at one meter with one subwoofer and 110dB of output at one
meter with two subwoofers
• The outboard VP10SUB amplifier features a Class D output
stage, line, and speaker level high pass filtering and is designed
specifically to the VP10SUB. Each amplifier is capable
of driving up to two subwoofers
Sonance Digital Amplifier
• Capable of driving two subwoofers
• Class D output stage
• Line and speaker level high pass filtering
• Designed specifically for the VP10SUB
Width
12.56 [319.0] 12.56 [319.0]
Height
12.56 [319.0] [365.6] 14.39
Cut Out
[365.6] 14.39 [365.6] 14.39
Width
15.00 [381.0]
[365.6] 14.39
Depth
3.81 [96.9] 3.81 [96.9]
