blue sky ProDesk™ SAT 5 Active Satellite & SUB 8 Active Subwoofer
Owners Manual for 2.1 (Stereo) Applications Issue 1, rev 4
9.

Technical Information

As mentioned in the introduction of this manual, Blue Sky International's high
performance to cost ratio is based on a philosophy that says that inexpensive
products should NOT be made from "inferior" components. This counter
intuitive attitude means that the highest quality components and manufacturing
techniques available are used in all aspects of the development and production
of this reference quality monitoring system. The specifications say it all, these
speakers are not toys - they are tools. We hope this new set of tools serves you
for a long time and that all the components, engineering and manufacturing
resources that have been used to make them shines through in every day use.
This next section outlines the components, specifications and performance
data that make this product such a uniquely high value.
In order to continually improve all of its products Blue Sky reserves the right to
change these specifications without notice.
SAT 5 Active Satellite
Enclosure
* Solid .75" MDF construction with 1" front and rear
baffle
* M6 X 12mm inserts for attachment of OmniMount type 30 brackets
(formerly known as the 75 series).
* Dimensions are 10.88" H x 6.62" W x 10.23" D (11.88" with
heatsink and tweeter wave guide)
* Weight 24lbs. / 11kg
.75" Tweeter
* Dual concentric diaphragm with integral wave guide
* High power ferrite magnet assembly
* Fully video shielded
5.25" Hemispherical Woofer
* Cast aluminum frame
* 1.5" voice coil
* Copper shorting ring
* Aluminum alloy cone
* Fully video shielded
* Vented motor structure
Satellite Amplifier
* Dual 60 Watts into 4-Ohm
* .01% THD + noise at rated power @ 1 kHz
* XLR balanced input
* Adjustable gain control
* B00® optimized crossover
* 80Hz filter bypass switch
General Specifications
Input Impedance
Common Mode Rejection Ratio 40dB typical 60Hz
Voltage Sensitivity
Maximum Input Level
Frequency Response
Low Frequency Cutoff
Internal High Pass Filter
Internal Crossover
Page 12
40k Ohms balanced
200mV = 90dB SPL @ 1M
+18dBu balanced
+/- 1.5dB 200Hz to 10kHz
+/- 3.0dB 80Hz to 20kHz
80Hz
80Hz 2nd order (selectable)
1.8kHz
SUB 8 - 8" Active Subwoofer
Enclosure
* .75" MDF with 1" front and rear baffle
* Isolation feet include
* Dimensions: 13" H x 16" W x 13.37" D (15.76" with heatsink and grill)
* Weight 48.5lbs / 22kg
8" Hemispherical Woofer
* 8-inch high excursion woofer
* Vented motor structure
* Cast aluminum frame
* 2.0 " voice coil
* Aluminum alloy cone
Amplifier
* Discrete symmetrical bipolar design
* 100 Watts RMS into 4-Ohm
* 01% THD + noise at rated power @ 100 Hz
* XLR balanced input
* Adjustable gain control
* B00® optimized crossover
* Voltage Sensitivity
* Frequency Response (direct IN - anechoic) 0 to 200Hz
* Typical in room response (direct IN )
Bass-Management
* Input impedance
* Common mode rejection
* Maximum Input Level
* Output Impedance
* Nominal gain
* High Pass filter
* Low Pass filter
* Direct In low pass filter
100mv=90dB SPL@1m
35Hz to 200Hz
(1500 cubic feet)
20K balanced
40dB typical @ 60Hz
+18dBu balanced
200 Ohms balanced
0dB
None (built into SAT 5)
80Hz 4th order
None
