8 • Completing Your Installation With or Without a Bowl Light Fixture (Continued)
Uninstalling the Light Fixture
8-17. To uninstall the light fixture, first disconnect the plug connectors
between the black wire and the red wire.
8-18. Disconnect the plug connectors between the two white wires.
8-19. Remove the two screws attaching the light kit to the lower
switch housing.
8-20. Remove the light fixture from the lower switch housing, pulling
disconnected wires through the hole in the center of the lower
switch housing.
Note: When removing the wires, pull the thin plug connector
(male) through first, and then pull the other plug connector
(female) through the hole.
8-21. Install the dummy terminals (included in the sack parts) on the
two disconnected wires in the lower switch housing.
8-22. Install the switch housing cap and plug button to the lower
switch housing.
8-23. Once you have uninstalled the light fixture, continue
with step 8-6.
Male Dummy
Female Dummy
Terminal
Terminal
15
42790-01 • 20080925 • Hunter Fan Company
Step 8-19
Cap
Plug Button
Lower Switch
Housing
Screw
Step 8-22
