Page 1: Table Of Contents
Table of Contents TABLE OF CONTENTS INTRODUCTION 1.1. PREFACE......................1-1 1.2. KEY FEATURES ....................1-1 1.3. PERFORMANCE LIST..................1-2 1.4. BLOCK DIAGRAM....................1-3 1.5. INTRODUCE THE Pentium II Processor ............1-4 1.6. What is AGP ...................... 1-6 SPECIFICATION 2.1. HARDWARE ....................... 2-1 2.2. - Page 2 686LX4 3.10. IDE & ATAPI DEVICE INSTALLATION ............3-9 3.11. PERIPHERAL DEVICE INSTALLATION ............3-8 3.12. KEYBOARD & PS/2 MOUSE INSTALLATION..........3-8 BIOS CONFIGURATION 4.1. ENTERING SETUP..................... 4-1 4.2. CONTROL KEYS ....................4-2 4.3. GETTING HELP ....................4-2 4.3.1. Main Menu ....................4-2 4.3.2.
-
Page 3: Introduction
Introduction 1. INTRODUCTION 1.1. PREFACE Welcome to use the 686LX4 motherboard. It is a Pentium II / Celeron Processor based PC / AT compatible system with AGP / PCI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want. -
Page 4: Performance List
686LX4 1.3. PERFORMANCE LIST The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware &... -
Page 5: Block Diagram
Introduction 1.4. BLOCK DIAGRAM 66MHz 14.318MHz 3.3V EDO/SDRAM SLOT DIMM Sockets Host Bus 82432LX 66MHZ AGP Bus CHIPSET DRAM Bus 66MHz 33MHz 52C64-25 33MHz 24MHz Ultra DMA/33 IDE Ports 52C64-06 PCI Bus 33MHz PIIX4 48MHz 82371AB USB Ports 14.318MHz IDE Bus CHIPSET USB Bus COM Ports... -
Page 6: Introduce The Pentium Ii Processor
686LX4 1.5. INTRODUCE THE Pentium II Processor Figure 1:Retention Mechanism & attach Mount Figure 2:OEM Pentium II Processor... - Page 7 Introduction Figure 3:Heatsink / FAN & Heat sink support for OEM Pentium II Processor Figure 4:Boxed Pentium II Processor & Heat sink support...
-
Page 8: What Is Agp
686LX4 1.6 What is AGP The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory. The AGP port can be used either as fast PCI port (32-bits at 66MHz vs. 32- bits at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and side band addressing. -
Page 9: Specification
Specification 2. SPECIFICATION 2.1. HARDWARE Pentium II / Celeron processor 233 – 633 MHz. 242 pins 66MHz slot1 on board. 66 MHz system speed. SPEED 66 MHz AGP bus speed. (2Xmode 133MHz) 33 MHz PCI-Bus speed. 8 MHz AT bus speed. 4 banks 168 pins DIMM module sockets on board. -
Page 10: Software
686LX4 Suspend mode support. GREEN FUNCTION Green switch & ACPI LED support. IDE & Display power down support. Monitor all IRQ / DMA / Display / I/O events. 2M bits FLASH ROM. BIOS Supports Plug & Play, DMI, ACPI Function. -
Page 11: Hardware Installation
BIOS Configuration HARDWARE INSTALLATION 3.1. UNPACKING The mainboard package should contain the following: The 686LX4 mainboard. The Retention Mechanism & Attach Mount USER'S MANUAL for mainboard. Cable set for IDE, Floppy. Diskette or CD for Mainboard Utility. The mainboard contains sensitive electric components, which can be easily damaged by static electricity, so the mainboard should be left in its original packing until it is installed. -
Page 12: Mainboard Layout
686LX4 3.2. MAINBOARD LAYOUT PCB Rev:2.0 COMA COMB PS/2 BAT1 BIOS KB Power On CPU 1 CPU Fan INTEL 440LX BANK 0 BANK 1 PIIX4 BANK 2 BANK 3 IDE2 ATX Power IDE1 FLOPPY ×Figure 3.1Ø PCB Rev: 2.2 COMA... -
Page 13: Quick Reference For Jumpers & Connectors
BIOS Configuration 3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS I/O Ports Connector USB port. IDE 1 For Primary IDE port. IDE 2 For Secondary IDE port. PS/2 For PS/2 Keyboard/ Mouse port. Floppy For Floppy port COM B For Serial port2 (COM B).[Support Modem Ring on] COM A For Serial port1 (COM A).[Support Modem Ring on] For LPT port. - Page 14 686LX4 Signal Wake on LAN Connector Pin No. Function +5VSB CTRL-Signal JP1 : Keyboard Power On Selection Pin No. Function Enabled Keyboard power on. Disabled Keyboard power on.(Default) J16 : System After Ac Back (Only for PCB 2.0 use) Pin No.
- Page 15 BIOS Configuration +5V SB...
- Page 16 686LX4 JP7: For 2X11 PINs Jumper PWR P+P P HD Soft PWR: Soft Power Connector Open: Normal Operation Short: Power On/Off RES: Reset Switch Open: Normal Operation Short: For Hardware Reset System P+P P : Power LED PIN 1 : anode (+)
-
Page 17: Dram Installation
BIOS Configuration GN: Green Function Switch Open : Normal operation Short : Entering Green Mode GD: Green LED PIN 1 : LED anode (+) PIN 2 : LED cathode ( ) 3.4. DRAM INSTALLATION The mainboard can be installed with 8 / 16 / 32 / 64 / 128 / 256 MB 168 pins DIMM module DRAM, and the DRAM speed must be 50 or 60 ns for EDO &... -
Page 18: Cmos Rtc & Isa Cfg Cmos Sram
686LX4 DIP SWITCH (SW) REQ. EXT.CLK INT.CLK CPU Type RATIO . MHz . MHz Pentium II 233 MHz (Celeron 233MHz) Pentium II 266 MHz (Celeron 266MHz) Pentium II 300 MHz (Celeron 300MHz) Pentium II 333 MHz (Celeron 333MHz) Pentium II 366 MHz (Celeron 366MHz) JP2, JP3, JP4 (Select the system speed¡... -
Page 19: Speaker Connector Installation
BIOS Configuration internal battery is 5 years, the user can change a new Battery to replace old one after it cannot work. M Danger of explosion if battery is incorrectly replaced. M Replace only with the same or equivalent type recommended by the manufacturer.
