DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854- 9338/ (818) 854-9339
hereby declare s that the product
Product Name:
Mother Board
Model Number:
GA - 6CX7
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
E r i c L u
Signature:
Date:
Feb. 29, 2000
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection against harmful interference in
residential
installations.
generates,
uses,
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However,
there
interference will not occur in a particular
installation. If this equipment does cause
interference to radio or television equipment
This
and
can
radiate
is
no
guarantee
equipment
radio
that

Advertisement

Table of Contents
loading

Summary of Contents for Gigabyte 6CX7 Series

  • Page 1 FCC Compliance Statement: This equipment has been tested and found to DECLARATION OF CONFORMITY Per FCC Part 2 Section 2. 1077(a) comply with limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These Responsible Party Name: G.B.T. INC. limits are designed to provide reasonable Address: 18305 Valley Blvd., Suite#A LA Puent, CA 91744...
  • Page 2: Declaration Of Conformity

    Declaration of Conformity We, Manufacturer/Importer (full address) G.B.T. Technology Träding GMbH Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board GA-6CX7 is in conformity with (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive EN 55011...
  • Page 3 6CX7 Series 100/133 MHz Pentium II/!!! Socket 370 Processor Motherboard USER'S MANUAL Socket 370 Processor Motherboard REV. 1.2 First Edition R-12-01-000504...
  • Page 5 How This Manual Is Organized This manual is divided into the following sections: Manual revision information 1) Revision History Product item list 2) Item Checklist Product information & specification 3) Features Instructions on setting up the motherboard 4) Hardware Setup Product performance &...
  • Page 7: Table Of Contents

    Table Of Contents Revision History Item Checklist Summary of Features 6CX7 Series Motherboard Layout Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition Performance List P.30 Block Diagram P.31 Suspend to RAM Installation P.32 Dual BIOS Introduction (Optional) P.38 Four Speaker & SPDIF Introduction (Optional) P.45...
  • Page 8: Revision History

    6CX7 Series Motherboard Revision History Revision Revision Note Date Initial release of the 6CX7 Series motherboard user’s Feb.2000 manual. Initial release of the 6CX7 Series motherboard user’s Mar.2000 manual. Second release of the 6CX7 Series motherboard user’s Mar.2000 manual. Initial release of the 6CX7 Series motherboard user’s May.2000...
  • Page 9: Item Checklist

    Item Checklist Item Checklist þThe 6CX7 Series Motherboard þCable for IDE / Floppy device þCD (IUCD) for motherboard utilities oInternal COM B Cable (Optional) oInternal USB Cable (Optional) oCable for SCSI device þ6CX7 Series User’s Manual þCRIMM Module...
  • Page 10: Summary Of Features

    Summary Of Features Form factor 30.5 cm x 20 cm ATX Size form factor, 4 layers PCB. Ÿ Motherboard 6CX7 series includes 6CX7L, 6CX7, 6CX7-1 Ÿ 100/133 MHz Pentium II/!!! Socket 370 Processor Ÿ Intel Pentium !!! 100/133MHz FSB, Coppermine core FC-PGA 2nd cache in CPU (Depend on CPU) Ÿ...
  • Page 11 6CX7 Series Motherboard Layout Licensed AMI BIOS, 4M bit FLASH ROM Ÿ BIOS Support Dual BIOS (Optional) Ÿ On-Board LAN Intel GD 82559(Optional for 6CX7L) Ÿ Alert On LAN*2 ASIC (Optional) Ÿ On-Board Sound Creative CT5880 sound (Optional for 6CX7) Ÿ...
  • Page 12: 6Cx7 Series Motherboard Layout

    6CX7 Series Motherboard 6CX7 Series Motherboard Layout JP16 PS/2 LED1 JP18 JP29 PGA 370 JP17 6CX7 82820 JP11 Intel 82559 JP24 PCI1 82801 AC’97 JP15 PCI 2 BAT1 JP28 PCI 3 JP27 Creative CT5880 JP21 Backup PCI4 JP20 BIOS Main...
  • Page 13: Page Index For Cpu Speed Setup/Connectors/Panel And Jumper Definition

    6CX7 Series Motherboard Layout Page Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition CPU Speed Setup Connectors Game & Audio Port COM A / COM B / LPT Port USB & LAN Connector (LAN is optional) P.10 PS/2 Keyboard & PS/2 Mouse Connector P.10...
  • Page 14 6CX7 Series Motherboard JP9 (Top Block Lock) [Optional] P.26 JP10 (FWH Write Protection) [Optional] P.26 JP14 (Internal Buzzer Connector) [Optional] P.27 JP18 (STR Enable) P.27 JP29 (Over Voltage CPU Speed Up)[Optional] P.28 JP1 (Cyrix CPU Turbo Function) [Optional] P.28 JP24 (Onboard LAN Function) [Optional] P.29...
  • Page 15: Cpu Speed Setup

    CPU Speed Setup CPU Speed Setup The CPU bus frequency can be switched at 100MHz and 133MHz by adjusting JP8 & SW 1. The CPU ratio selection is control by BIOS. JP8 / SW1 Select the CPU Speed at 100MHz and 133MHz. AGPCLK 66.6 73.3...
  • Page 16: Connectors

    6CX7 Series Motherboard Connectors Game & Audio Port Game Port Line Out 1 MIC In Line In Line Out 1: Line Out or SPDIF (The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby digital decoder).
  • Page 17: Usb & Lan Connector (Lan Is Optional)

    Connectors USB & LAN Connector (LAN is optional) Pin No. Definition USB V0 USB D0- USB D0+ 1 2 3 4 USB V1 USB D1- 1 – Green LED USB D1+ (LAN Link LED) 2 – Yellow LED (LAN Active LED) PS/2 Keyboard &...
  • Page 18: J1: Cpu Fan

    6CX7 Series Motherboard J1: CPU Fan Pin No. Definition +12V SENSE J17: Power Fan Pin No. Definition +12V SENSE...
  • Page 19: J16: System Fan

    Connectors J16: System Fan Pin No. Definition +12V SENSE ATX Power Pin No. Definition 3,5,7,13, 15-17 1,2,11 3.3V 4,6,19,20 +12V -12V Power Good 5V SB stand by+5V PS-ON(Soft On/Off)
  • Page 20: Ir/Cir (Optional)

    6CX7 Series Motherboard IR/CIR (Optional) Pin No. Definition IRRX IRTX CIRRX Floppy Port Red Line...
  • Page 21: Ide 1(Primary)/ Ide 2(Secondary) Port

    Connectors IDE1 (Primary), IDE2 (Secondary) Port IDE 2 IDE 1 Red Line J8: AUX_IN Pin No. Definition AUX-L AUX-R...
  • Page 22: J6: Cd Audio Line In

    6CX7 Series Motherboard J6: CD Audio Line In Pin No. Definition CD-L CD-R J7: TEL: The connector is for Modem with internal voice connector Pin No. Definition Signal-In Signal -Out...
  • Page 23: J2: Wake On Lan

    Connectors J2: Wake On LAN Pin No. Definition +5V SB Signal J10: Ring Power On Pin No. Definition Signal...
  • Page 24: J15: External Smbus Device Connector

    6CX7 Series Motherboard J15: External SMBUS Device Connector Pin No. Definition SMB CLK SMB DATA JP15: STR LED Connector (Optional) & LED1: RIMM LED RIMM LED STR LED Connector External...
  • Page 25: Cn9: Fp Usb (For Nec)[Optional]

    Connectors CN9: FP USB (For NEC)[Optional] Pin No. Definition 1, 4,5,10 Power 3, 7, 9 USB D1+ USB D1- J12: Front Panel Jumper (For NEC) Pin No. Definition HD LED+ PWR LED+ HD LED- GN LED+/STR LED+ 5,13, 8, 12 9, 16 IRRX 14, 17, 18...
  • Page 26: J18: Aol Ii Connector (For Nec)[Optional]

    6CX7 Series Motherboard J18: AOL II Connector (For NEC)[Optional] Pin No. Definition SMB CLK SMB DATA 3,8,13 ICH-SCL ICH-SDA 6,15,17 THRMO- GPI10 COPEN 3VSB RSMRST- RESET PWROK...
  • Page 27: Panel And Jumper Definition

    Panel and Jumper Definition Panel And Jumper Definition J11: For 2x11 Pins Jumper S P K P P P+ GN (Green Switch) Open: Normal Operation Close: Entering Green Mode GD (Green LED/STR LED) Pin 1: GN LED anode(+)/STR LED anode(+) Pin 2: GN LED cathode( )/STR LED cathode( ) HD (IDE Hard Disk Active LED) Pin 1: LED anode(+)
  • Page 28: Jp16: Ps/2 Keyboard Power On

    6CX7 Series Motherboard JP16: PS/2 Keyboard Power On Pin No. Definition 1-2 close PS/2 Keyboard Power on Enabled 2-3 close PS/2 Keyboard Power on Disabled (Default) JP3: Back USB device Wake up Selection (Optional) (USB Connector à CN1) Pin No.
  • Page 29: Jp4: Clear Cmos Function (Optional)

    Panel and Jumper Definition JP4: Clear CMOS Function (Optional) Pin No. Definition 1-2 close Clear CMOS 2-3 close Normal (Default) JP5: Safe mode / Recovery / Normal Pin No. Definition 1-2close Normal (Default) 2-3close Safe mode 1-2-3open Recovery...
  • Page 30: Jp6: Timeout Reboot Function (Optional)

    6CX7 Series Motherboard JP6: Timeout Reboot Function (Optional) Pin No. Definition Open Timeout Reboot Close No Reboot on Timeout JP11: AMR Select (Optional) Pin No. Definition 1-2close AMR Secondary AMR Primary 2-3close AC’97 Disabled (Default) (Disabled Onboard CODEC)
  • Page 31: Jp17: Case Open

    Panel and Jumper Definition JP17: Case Open Pin No. Definition Signal JP20: Onboard Sound Function Selection Pin No. Definition Enabled Onboard sound 1-2 close (Default) 2-3 close Disabled Onboard sound...
  • Page 32: Jp21 (Front Usb Device Wake Up Selection)[Optional]

    6CX7 Series Motherboard JP21: Front USB device Wake up Selection (Optional) (USB Connector à CN9) Pin No. Definition Enabled Front USB Device 1-2 close Wake up Disabled Front USB Device 2-3 close Wake up (Default) (If you want to use “USB KB/MS Wakeup From S3” function, you have to set the BIOS setting “USB KB/MS Wakeup From S3”...
  • Page 33: Jp9: Top Block Lock (Optional)

    Panel and Jumper Definition JP9: Top Block Lock (Optional) Pin No. Definition Open Top Block Lock Close Top Block Unlock (Default) JP10: FWH Write Protection (Optional) Pin No. Definition Open Normal (Default) Close Write Protect M Please set Jumper JP10 to “Open” to enabled BIOS write function when you update new BIOS or new device.
  • Page 34: Jp14: Internal Buzzer Connector (Optional)

    6CX7 Series Motherboard JP14: Internal Buzzer Connector (Optional) Pin No. Definition Open Internal Buzzer Disabled Close Internal Buzzer Enabled (Default) JP18: STR Enable Pin No. Definition Open STR Disabled Close STR Enabled...
  • Page 35: Jp29 (Over Voltage Cpu Speed Up)[Optional]

    Panel and Jumper Definition JP29: Over Voltage CPU Speed Up (Optional) (Magic Booster) (When JP29 set “3-4 close”, CPU Voltage is rising 10%) Pin No. Definition 1-2 close Normal 3-4 close 5-6 close 7-8 close 9-10 close 11-12 close JP1: Cyrix CPU Turbo Function (Optional) Pin No.
  • Page 36: Jp24: Onboard Lan Function (Optional)

    6CX7 Series Motherboard JP24: Onboard LAN Function (Optional) Pin No. Definition 1-2 close Onboard LAN Enabled 2-3 close Onboard LAN Disabled (Default) BAT1: Battery + Danger of explosion if battery is incorrectly replaced. + Replace only with the same or equivalent type recommended by the manufacturer.
  • Page 37: Performance List

    Performance List Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) Intel Pentium !!! 667MHz Socket 370 processor DRAM...
  • Page 38: Block Diagram

    6CX7 Series Motherboard Block Diagram 66 MHz 100 / 133 MHz 16.67MHz RIMM Socket Host Bus RIMM INTEL FW82820 (MCH) 66MHz 33MHz 33MHz INTEL 48MHz 9248BF-77 FW82801 25MHz 66MHz Intel Crystal 82559 Crystal 14.318MHz Game Creative Ports CT5880 AC’97-Link CHIPSET...
  • Page 39: Suspend To Ram Installation

    Suspend to RAM Installation Suspend To RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 40 6CX7 Series Motherboard Step 2: (If you want to use STR Function, please set jumper JP18 Closed.) Pin No. Definition Open STR Disabled Close STR Enabled Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup.
  • Page 41 Suspend to RAM Installation A.3 How to put your system into STR mode? There are two ways to accomplish this: Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down” B.
  • Page 42 6CX7 Series Motherboard Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 43 Suspend to RAM Installation C. Select the “Advanced” tab and “Standby” mode in Power Buttons. Step 4: Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button.. A.4 How to recover from the STR sleep mode? There are seven ways to “wake up”...
  • Page 44 6CX7 Series Motherboard A.5 Notices: In order for STR to function properly, several hardware and software requirements must be satisfied: A. Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current).
  • Page 45: Dual Bios Introduction (Optional)

    Dual BIOS Introduction Dual BIOS Introduction (Optional) What is Dual BIOS Technology? Dual BIOS means that there are two system BIOS (ROM) on the motherboard, one is the Main BIOS and the other is Backup BIOS. Under the normal circumstances, the system works on the Main BIOS.
  • Page 46 6CX7 Series Motherboard b. AMI Dual BIOS Flash ROM Programming U tility AMI Dual BIOS Flash ROM Programming Utility Boot From……………………….. Main BIOS Main ROM Type………………… Intel N82802AB Backup Intel N82802AB Type……………… Wide Range Protection Disable Boot From Main BIOS...
  • Page 47 Dual BIOS Introduction Boot From : Main BIOS (Default), Backup BIOS Status 1: The user can set to boot from main BIOS or Backup BIOS. Auto Recovery : Enabled(Default), Disabled When one of the Main BIOS or Backup BIOS occurs checksum failure, the working BIOS will automatically recover the BIOS of checksum failure.
  • Page 48 DualBIOS Technology FAQ GIGABYTE Technology is pleased to introduce DualBIOS technology, a hot spare for your system BIOS. This newness “Value-added” feature, in a long series of innovations from GIGABYTE, is available on GA-6CX7 Series motherboard. Future GIGABYTE motherboards will also incorporate this innovation.
  • Page 49 Dual BIOS Introduction I. Q: What is DualBIOS technology? Answer: DualBIOS technology is a patented technology from Giga-Byte Technology. The concept of this technology is based on the redundancy and fault tolerance theory. DualBIOS technology simply means there are two system BIOSes (ROM) integrated onto the motherboard. One is a main BIOS, and the other is a backup BIOS.
  • Page 50 6CX7 Series Motherboard III. Q: How does DualBIOS technology work? Answer: 1. DualBIOS technology provides a wide range of protection during the boot up procedure. It protects your BIOS during system POST, ESCD update, and even all the way to PNP detection/assignment.
  • Page 51 Dual BIOS Introduction 2. During or after a BIOS upgrade, if DualBIOS detects that the main BIOS is corrupt, the backup BIOS will take over the boot-up process automatically. Moreover, it will verify the main and backup BIOS checksums when booting-up. DualBIOS technology examines the checksum of the main and backup BIOS while the system is powered on to guarantee your BIOS operates properly.
  • Page 52: Four Speaker & Spdif Introduction (Optional)

    6CX7 Series Motherboard Four Speaker & SPDIF Introduction (Optional) Four Speaker Introduction What is Four Speaker? The Creative CT5880 audio chip can support 4 speaker output, if you select “Four speaker” out, Line in will be change to another line out.
  • Page 53 Four Speaker & SPDIF Introduction c. Two speaker (Default) d. Click “Four speaker” item. Four Speaker Application The four speaker function will only support in application software that use Microsoft DirectX and Creative EAX. For example, the game titles, software DVD player and MP3 player. Those software support Microsoft DirectX, so they can support four speaker output.
  • Page 54 6CX7 Series Motherboard SPDIF Introduction What is SPDIF? The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby digital decoder. How to use SPDIF? a. Press your mouse right button in “My Computer” and then select the “Properties” item.
  • Page 55 Four Speaker & SPDIF Introduction c. Press “Sound, video and game controllers” item and then select the “Creative Sound Blaster PCI128” item. d. Press “Settings” item and then select the “Output Mode” item.
  • Page 56 6CX7 Series Motherboard e. Click “Digital” item, Line Out will be change to SPDIF Out. f. Recommend you to select “Autosense”, it will auto detect the audio jack you plug in to Line Out is mono or stereo, and then change to SPDIF Out or Speaker out automatically.
  • Page 57: Memory Installation

    Memory Installation Memory Installation The motherboard has Rambus In-line Memory Module (RIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the RIMM Slot .The RIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
  • Page 58 6CX7 Series Motherboard Introduce RIMM (Rambus In-line Memory Module) Direct Rambus Memory Controller Directly support a single Direct Rambus * Channel Supports 300&400 / 356&400 MHz Direct Rambus * Channel @ 100/133MHz host Ÿ bus frequency. Maximum memory array size up to 256MB using 64Mb/72Mb, 512MB using Ÿ...
  • Page 59: Page Index For Bios Setup

    BIOS Setup $ Page Index for BIOS Setup Page The Main Menu P.54 Standard CMOS Setup P.57 BIOS Features Setup P.60 Chipset Features Setup P.62 Power Management Setup P.64 PNP/ PCI Configuration P.68 Load BIOS Defaults P.70 Load Setup Defaults P.71 Integrated Peripherals P.72...
  • Page 60: Control Keys

    6CX7 Series Motherboard BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off.
  • Page 61: Getting Help

    BIOS Setup GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Opt ion Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 62 6CX7 Series Motherboard Standard CMOS Setup This setup page includes all the items in standard compatible BIOS. BIOS Features Setup This setup page includes all the items of AMI special enhanced features. Chipset Features Setup This setup page includes all the items of chipset special features.
  • Page 63 BIOS Setup Save & Exit Setup Save CMOS value settings to CMOS and exit setup. Exit Without Saving Abandon all CMOS value changes and exit setup.
  • Page 64: Standard Cmos Setup

    6CX7 Series Motherboard Standard CMOS Setup The items in Standard CMOS Setup Menu (Figure 2) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item.
  • Page 65 BIOS Setup Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer. There are two types: auto type, and user definable type. User type is user-definable;...
  • Page 66 6CX7 Series Motherboard Boot Sector Virus Protection If it is set to enable, the category will flash on the screen when there is any attempt to write to the boot sector or partition table of the hard disk drive. The system will halt and the following error message will appear in the mean time.
  • Page 67: Bios Features Setup

    BIOS Setup BIOS Features Setup AMIBIOS SETUP – BIOS FEATURES SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved 1st Boot Device Floppy 2nd Boot Device IDE-0 3rd Boot Device CDROM S.M.A.R.T. for Hard Disks Disabled BootUp Num-Lock Floppy Drive Seek Disabled Password Check...
  • Page 68 6CX7 Series Motherboard Floppy Drive Seek During POST, BIOS will determine if the floppy disk drive installed is 40 or 80 tracks. 360 type is 40 tracks while 720, 1.2 and 1.44 are all 80 tracks. Enabled BIOS searches for floppy disk drive to determine if it is 40 or 80 tracks.
  • Page 69: Chipset Features Setup

    BIOS Setup Chipset Features Setup AMIBIOS SETUP – CHIPSET FEATURES SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Direct Rambus Clock Auto DRAM Integrity Mode Non-ECC ICH Delayed Transaction Enabled ICH DCB Enable Disabled Graphics Aperture Size 64 MB CPU Ratio Selection 3.0x...
  • Page 70 6CX7 Series Motherboard Graphics Aperture Size 4 MB Display Graphics Aperture Size is 4MB. 8 MB Display Graphics Aperture Size is 8MB. 16 MB Display Graphics Aperture Size is 16MB. 32 MB Display Graphics Aperture Size is 32MB. 64 MB Display Graphics Aperture Size is 64MB.
  • Page 71: Power Management Setup

    BIOS Setup Power Management Setup AMIBIOS SETUP – POWER MANAGEMENT SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Sleep Type S1/POS Resume by Alarm Disabled USB KB/MS Wakeup From S3 Disabled RTC Alarm Date Every Day HDD Power Down Disabled RTC Alarm Hour...
  • Page 72 6CX7 Series Motherboard Suspend Mode (Minute) Disabled Disabled Suspend Mode Function. (Default Value) Enabled Suspend Mode after 1min. Enabled Suspend Mode after 2min. Enabled Suspend Mode after 4min. Enabled Suspend Mode after 8min. Enabled Suspend Mode after 10min. Enabled Suspend Mode after 20min.
  • Page 73 BIOS Setup PIRQ[A] IRQ Active Monitor Monitor PIRQ[A] IRQ Active. Ignore Ignore PIRQ[A] IRQ Active. (Default Value) PIRQ[B] IRQ Active Monitor Monitor PIRQ[B] IRQ Active. Ignore Ignore PIRQ[B] IRQ Active. (Default Value) PIRQ[C] IRQ Active Monitor Monitor PIRQ[C] IRQ Active. Ignore Ignore PIRQ[C] IRQ Active.
  • Page 74 6CX7 Series Motherboard PME Event Wake Up Disabled Disabled PME Event Wake Up. Enabled Enabled PME Event Wake Up. (Default Value) Resume by Alarm You can set “Resume by Alarm” item to Enabled and key in date/time to power on system.
  • Page 75: Pnp/Pci Configuration

    BIOS Setup PNP/PCI Configuration AMIBIOS SETUP – PNP / PCI CONFIGURATION ( C ) 1999 American Megatrends, Inc. All Rights Reserved PnP OS Installed Reset Configuration Data Disabled VGA Boot From PCI/VGA Palette Snoop Disabled DMA-0 DMA-1 DMA-3 DMA-5 DMA-6 DMA-7 IRQ-3 PCI/PnP...
  • Page 76 6CX7 Series Motherboard DMA ( 0,1,3,5,6,7 ) ISA/ EISA The resource is used by Legacy ISA device. The resource is used by PnP device. IRQ ( 3,4,5,7,9,10,11 ) ISA/ EISA The resource is used by Legacy ISA device. PCI / PnP...
  • Page 77: Load Bios Defaults

    BIOS Setup Load BIOS Defaults AMIBIOS SIMPLE SETUP UTILITY -VERSION 1.21 ( C ) 1999 American Megatrends, Inc . All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP USER PASSWORD Load BIOS Defaults (Y/N)? PNP/PCI CONFIGURATION...
  • Page 78: Load Setup Defaults

    6CX7 Series Motherboard Load Setup Defaults AMIBIOS SIMPLE SETUP UTILITY -VERSION 1.21 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP...
  • Page 79: Integrated Peripherals

    BIOS Setup Integrated Peripherals AMIBIOS SETUP – INTEGRATED PERIPHERALS ( C ) 1999 American Megatrends, Inc. All Rights Reserved On-Chip PCI IDE Both Mouse PowerOn Function Disabled AC97 Audio Auto AC97 Modem Auto OnBoard FDC Controller Auto OnBoard Serial Port A Auto OnBoard Serial Port B Auto...
  • Page 80 6CX7 Series Motherboard OnBoard FDC Controller Auto Set OnBoard FDC Controller is Auto. (Default Value) Disabled Disabled OnBoard FDC Controller. Enabled Enabled OnBoard FDC Controller. OnBoard Serial Port A Auto BIOS will automatically setup the port A address. (Default Value) 3F8/COM1 Enable OnBoard Serial port A and address is 3F8.
  • Page 81 BIOS Setup OnBoard CIR port Disabled Disabled OnBoard CIR port. (Default Value) Enabled Enabled OnBoard CIR port. CIR IRQ Select IRQ 3 / 4 / 9 / 10 (Default Value) / 11 OnBoard Parallel port Enable OnBoard LPT port and address is 378. Enable OnBoard LPT port and address is 278.
  • Page 82 6CX7 Series Motherboard Midi IRQ Select IRQ 9 / 5 / 7/ 10 (Default Value) OnBoard Game Port Disabled Disabled OnBoard Game Port. Set OnBoard Game Port is 201. (Default Value) Set OnBoard Game Port is 209. Keyboard Power On Function Disabled Disable this function.
  • Page 83: Hardware Monitor Setup

    BIOS Setup Hardware Monitor Setup AMIBIOS SETUP – HARDWARE MONITOR SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Battery 3.088V ACPI Shut Down Temp. 75 C/167 F CPU Temp. Alarm +5V SB 4.896V 70 C/158 F CPU Fan Fail Alarm Power Fan Fail Alarm System Fan Fail Alarm Reset Case Open Status...
  • Page 84 6CX7 Series Motherboard CPU Temp. Alarm 60 C / 140 F Monitor CPU Temp. at 60 C / 140 F. 65 C / 149 F Monitor CPU Temp. at 65 C / 149 F. 70 C / 158 F Monitor CPU Temp. at 70 C / 158 F. (Default Value) 75 C / 167 F Monitor CPU Temp.
  • Page 85: Supervisor / User Password

    BIOS Setup Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. AMIBIOS SIMPLE SETUP UTILITY -VERSION 1.21 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP...
  • Page 86: Ide Hdd Auto Detection

    6CX7 Series Motherboard IDE HDD Auto Detection AMIBIOS SETUP – STANDARD CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Date (mm/dd/yyyy) : Tue Jan 18, 2000 Time (hh/mm/ss) : 10:36:24 TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE...
  • Page 87: Save & Exit Setup

    BIOS Setup Save & Exit Setup AMIBIOS SIMPLE SETUP UTILITY -VERSION 1.21 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP USER PASSWORD SAVE to CMOS and EXIT(Y/N)? Y PNP/PCI CONFIGURATION...
  • Page 88: Exit Without Saving

    6CX7 Series Motherboard Exit Without Saving AMIBIOS SIMPLE SETUP UTILITY -VERSION 1.21 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP...
  • Page 89: Appendix

    Appendix Appendix Appendix A: Intel 820 Chipset Driver Installation A. Windows 9x INF Update Utility Insert the support CD that came with your motherboard into your CD-ROM drive or double-cl i c k the CD drive icon in My Computer to bring up the setup screen. 1.Click “Windows 9x INF Update Utility”...
  • Page 90 6CX7 Series Motherboard B. Intel ICH IDE ATA66 Driver Installation Insert the support CD that came with your motherboard into your CD-ROM drive or double-cl i c k the CD drive icon in My Computer to bring up the setup screen.
  • Page 91 Appendix 7.Click “Finish” to restart computer.
  • Page 92 6CX7 Series Motherboard Appendix B: Intel 8255x Lan Driver Installation Insert the support CD that came with your motherboard into your CD-ROM drive or double-cl i c k the CD drive icon in My Computer to bring up the setup screen.
  • Page 93 Appendix Appendix C: Creative Sound Driver Installation Insert the support CD that came with your motherboard into your CD-ROM drive or double-cl i c k the CD drive icon in My Computer to bring up the setup screen. 1.Click here. 2.Click ”Creative 5880 Sound Driver”...
  • Page 94 6CX7 Series Motherboard 7.Click”Yes” item. 8.We recommend you to click this item. 9.Click “Finish” to restart. (10)
  • Page 95 C:\utility \ AWDFlash or AMIFlash <filename of the BIOS binary file intended for flashing> ü Once the process is finished, reboot the system MNote: Please download the newest BIOS from our website (www.gigabyte.com.tw) or contact your local dealer for the file.
  • Page 96 6CX7 Series Motherboard Appendix E: Introduce The Alert on LAN The primary functions of the Alert on LAN *2 ASIC are to provide an interface to the 82559 and to the system monitoring critical system parameters and conditions, such as supply voltage detected, cover tamper, over temperature, link loss, and processor missing intrusion.
  • Page 97 Appendix Appendix F: Acronyms Acor. Meaning ACPI Advanced Configuration and Power Interface POST Power-On Self Test Local Area Network Extended Capabilities Port Advanced Power Management Direct Memory Access Megahertz ESCD Extended System Configuration Data Central Processing Unit Symmetric Multi-Processing Universal Serial Bus Operating System Error Checking and Correcting Integrated Dual Channel Enhanced...
  • Page 98 6CX7 Series Motherboard Acor. Meaning Peripheral Component Interconnect RIMM Rambus in -line Memory Module Dual Retention Mechanism Industry Standard Architecture Memory Translator Hub CRIMM Continuity RIMM...
