Axis 540+ User Manual page 92

AXIS 540/640 User's Manual
Setting Parameters
Example:
Important:
In AppleTalk, you can change a limited number of the parameters of
the AXIS 540+/542+. You can:
• enable and disable binary data transfers for your printing
• select the type of binary transfer protocol to use
• specify the AppleTalk printer type
• set the IP address
However, by assigning an IP address to your AXIS 540+/542+, you
have access to all of print server's parameters via any standard Web
browser or via FTP. Refer to Section 9 Management & Configuration,
on page 108 for more information.
The following example describes the how you set the AXIS 540+/542+
parameters in AppleTalk.
DO NOT use the parameter values from this example when
configuring your AXIS 540+/542+. You should select values that are
appropriate for your printers and network settings.
Follow the instructions below:
1. Open the Chooser.
2. Select a network printer driver, any LaserWriter will do.
3. Select the printer port which name ends with "_CFG".
4. Close the Chooser.
5. Open a text editor, e.g. SimpleText.
Section 7: Setting Up - Macintosh
91
