Genelec 1030A Operating Manual page 4

Figure 5. The curves above show the effect of the 'treble tilt', 'bass
tilt' and 'bass roll-off' controls on the free field response.
SYSTEM SYSTEM SYSTEM SYSTEM SYSTEM
SPECIFICATIONS SPECIFICATIONS
SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS
Lower cut-off frequency, -3 dB: < 52 Hz
Upper cut-off frequency, -3 dB: > 20 kHz
Free field frequency response of system:
55 Hz - 18 kHz (± 2.5 dB)
Maximum short term sine wave acoustic
output on axis in half space, averaged from
100 Hz to 3 kHz:
@ 1m
@ 0.5m
Maximum long term RMS acoustic output in
same conditions with IEC weighted noise
(limited by driver unit protection circuit):
@ 1m
@ 0.5m
Maximum peak acoustic output per pair on
top of console, @ 1 m from the engineer
with music material:
Self generated noise level in
free field @ 1m on axis:
Harmonic distortion at 90 dB SPL @ 1m on
axis:
Freq: 60...150 Hz
> 150 Hz
Drivers: Bass 170 mm
Treble 19 mm
Both drivers are magnetically shielded.
Weight: 7,6 kg (17 lb)
Dimensions:
Height 312 mm
Width 200 mm
Depth 240 mm
Genelec Oy, Olvitie 5
FIN - 74100 IISALMI, FINLAND
Phone: +358 - 17 - 83 881
Fax: +358 - 17 - 812 267
E-mail: genelec@genelec.com
Web: http://www.genelec.com
Bass amplifier output power with a 4 Ohm
load:
Treble amplifier output power with an
8 Ohm load:
Long term output power is limited by
> 105 dB SPL
driver unit protection circuitry.
> 111 dB SPL
Amplifier system distortion at
nominal output:
> 99 dB SPL
> 105 dB SPL
Signal to Noise ratio, referred to full
> 115 dB
output:
< 10 dB
(A-weighted)
Mains voltage:
Voltage operating range:
< 3%
Power consumption:
< 0.5%
(6 1 / ") cone
2
3
( / ") metal
4
dome
1
(12 / ")
4
( 7 7 / ")
8
(9 7 / ")
16
Genelec Inc, 7 Tech Circle
Natick, MA 01760, USA
Phone: +1 - 508/652-0900
Fax: +1 - 508/652-0909
E-mail: genelec.usa@genelec.com
Figure 6. The upper curve group shows the horizontal directivity
characteristics of the 1030A measured at 1m. The lower curve is the
1/3 octave band power response.
AMPLIFIER AMPLIFIER AMPLIFIER AMPLIFIER AMPLIFIER
SECTION SECTION
SECTION SECTION SECTION
Short term 80 W
Short term 50 W
THD < 0.08%
SMPTE-IM < 0.08%
CCIF-IM < 0.08%
DIM 100 < 0.08%
Bass > 95 dB
Treble > 95 dB
100/200 or 115/230 V
±10%
Idle 20 VA
Full output 100 VA
CROSSOVER CROSSOVER CROSSOVER CROSSOVER CROSSOVER
SECTION SECTION
SECTION SECTION SECTION
Input connector: XLR female
Input impedance: 10 kOhm balanced
Input level for 100 dB SPL output @ 1m:
variable from
Input level for maximum short term sine
wave output of 105 dB SPL @ 1m:
variable from +11 to -1 dBu
Subsonic filter below 50 Hz :
Ultrasonic filter above 25 kHz:
Crossover frequency, Bass/Treble: 3.5 kHz
Crossover acoustical slopes:
24 - 32 dB/octave
Treble tilt control operating range in 2 dB
steps: from +2 to -4 dB &MUTE
Bass roll-off control operating range in 2 dB
steps: from 0 to -8 dB @ 50 Hz
Bass tilt control operating range in 2 dB
steps: from 0 to -6 dB @ 100 Hz
& MUTE
The 'CAL' position is with all tone controls
set to 'off' and the input sensitivity control to
maximum (fully clockwise).
Note! All frequency response curves were measured in
a calibrated, 12 m cube, anechoic chamber at 1 m
using grade 1 measuring equipment. Input signal levels
were set at -20 dBu. The anechoic chamber error in the
free field response is less than 0.5 dB down to 60 Hz.
Data Sheet No. DR30001
COPYRIGHT GENELEC OY 6/1999
All data subject to change without prior notice
