Pro-Form 720 Zle Elliptical User Manual page 16

21. While a second person holds the Console (33)
near the Handlebar (10), connect the console
wires to the Upright Wire (60), to the Extension
Wire (121), and to the Pulse Wire (79).
Insert the excess wire into the Handlebar (10).
Tip: Avoid pinching the wires. Attach the
Console (33) to the Handlebar (10) with four M4
x 16mm Screws (93).
22. Attach the Console Cover (11) to the Console
(33) with two M4 x 16mm Screws (93).
23. Plug the Power Adapter (59) into the receptacle
on the frame of the elliptical.
Note: To plug the Power Adapter (59) into an
outlet, see HOW TO PLUG IN THE POWER
ADAPTER on page 18.
24. Make sure that all parts of the elliptical are properly tightened. Note: Extra parts may be included. To
protect the floor or carpet from damage, place a mat under the elliptical.
21
33
22
33
23
16
Avoid pinching
the wires
121
79
10
60
93
11
59
93
