6. Identify the Left Handrail (71). If there is a wire in
the Left Handrail, remove and discard it.
Hold the Left Handrail (71) near the Left Upright
(75). Insert the wire tie on the Upright Wire (70)
into the bottom of the Left Handrail, and pull it
out of the end of the Left Handrail. Then, pull the
Upright Wire through the Left Handrail.
Attach the Left Handrail (71) to the Left Upright
(75) with two 3/8" x 3 1/2" Screws (9) and two
3/8" Star Washers (5). Make sure not to pinch
the Upright Wire (70). Start both Screws, but
do not tighten them yet.
7. Attach the Right Handrail (72) to the Right
Upright (76) with two 3/8" x 3 1/2" Screws (9)
and two 3/8" Star Washers (5); do not tighten
the Screws yet.
6
70
Wire
Tie
7
11
9
5
71
75
9
5
72
76
