All rights reserved. Reproduction by any means, electronic
or mechanical including photocopying, recording or by any
information storage and retrieval system or translation in
whole or part is not permitted without written
authorization from Ford Motor Company. Ford may change
the contents without notice and without incurring
obligation.
Copyright © 2002 Ford Motor Company
Table of contents
2
5
7
9
10
11
14
14
14
23
23
23
24
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ford SVT Mustang Cobra
Summary of Contents for Ford SVT Mustang Cobra
- Page 1 Ford Motor Company. Ford may change the contents without notice and without incurring obligation.
-
Page 2: Introduction
Introduction INTRODUCTION Congratulations on your decision to purchase or lease a Ford SVT Mustang Cobra. If you’ve owned or leased an SVT product in the past, we’re glad you’re back. If this is your first SVT vehicle, welcome to the... - Page 3 Introduction SVT HISTORY The Ford Special Vehicle Team (SVT) was established in 1991 to “Polish the Ford Oval” by creating low-volume, factory-produced vehicles designed for those select few whose idea of driving is a high-powered, passionate experience — not just a means of getting from point A to point B.
- Page 4 • SVT Info. Center: Have a question or want more information about your new SVT vehicle? Call the SVT Info. Center at 1–800–FORD-SVT. We’ll handle your request or get you in touch with someone who can. The SVT Info Center is open from 8:30 a.m.
-
Page 5: Cobra Unique Standard Features
Cobra unique standard features • 4.6L DOHC 32V Supercharged V–8 Engine with Intercooler — 390 horsepower, 390 lb-ft torque • T56 6 speed transmission • Aluminum flywheel • Engine oil cooler • Power steering cooler • Anti-lock Brake System with Traction Control •... - Page 6 Cobra unique standard features SPORT INSTRUMENT CLUSTER Upshift (if equipped) Illuminates when it is best to shift to the next highest manual transmission gear for the maximum fuel economy.
-
Page 7: Engine/Transmission
Engine/Transmission 4.6L DOHC SUPERCHARGED V–8 ENGINE 1. Engine oil filler cap 2. Brake fluid reservoir 3. Engine oil dipstick 4. Power distribution box 5. Windshield washer fluid reservoir 6. Battery 7. Power steering fluid reservoir 8. Engine coolant reservoir 9. Intercooler reservoir 10. - Page 8 Engine/Transmission Item Description Longitudinally mounted, Configuration 90-degree V8, cast iron cylinder block and cast aluminum cylinder heads Bore x Stroke 90.2 x 90.0 mm (3.55 x 3.54 Displacement 4601 cc/280 cid Compression ratio 8.5:1 239 kW @ 6000 rpm (390 HP Horsepower @ 6000 rpm) Torque...
-
Page 9: Drivetrain
Drivetrain DRIVETRAIN Item Description Rear axle 8.8 inch limited-slip differential with Independent Rear Suspension Driveshaft Aluminum with hardened yoke Transmission T56 6-speed manual with integral clutch housing Gear ratios Gear Ratio 2.66 1.78 1.30 1.00 0.80 Reverse 2.90... -
Page 10: Chassis
Chassis WHEELS AND TIRES P275/40ZR17 Goodyear Tires Eagle F1 performance tire Wheels SVT-Signature style, 17 in x 9.0 in aluminum 5-spoke wheel, 26 mm offset SUSPENSION • Retuned Independent Rear Suspension (IRS) with improved geometry and unique bushing rates • Limited slip axle •... -
Page 11: Seating And Energy Management
Seating and energy management 4–WAY HEAD RESTRAINTS Your vehicle’s seats are equipped with four-way adjustable head restraints. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible. - Page 12 Seating and energy management Lumbar and adjustable bolster controls The lumbar and adjustable bolster controls are located on the front right corner of the driver seat. The power lumbar feature creates lower back support for the driver and may be adjusted to increase or decrease the support.
- Page 13 Seating and energy management ENERGY MANAGEMENT FEATURE • This vehicle has a seat belt system with an energy management feature at the front outboard seating positions to help further reduce the risk of injury in the event of a head-on collision. •...
-
Page 14: Maintenance
PCV valve EV-153 Spark plugs* AGSF-12FM1 * Refer to Vehicle Emissions Control Information (VECI) decal for spark plug gap information. REFILL CAPACITIES Fluid Ford Part Name Capacity Brake fluid Motorcraft High Fill to line on Performance DOT reservoir 3 Motor Vehicle... - Page 15 6 mm to 14 mm (1/4 inch to 9/16 inch) below bottom of fill hole. Add 118 ml (4 oz.) of Additive Friction Modifier C8AZ-19B546-A or equivalent meeting Ford specification EST-M2C118–A for complete refill of Traction-Lok axles. The TTC T56 6 Speed transmission on your SVT Mustang Cobra uses automatic transmission fluid.
- Page 16 Maintenance OCTANE RECOMMENDATIONS Your vehicle is designed to use “Premium” unleaded gasoline with (R+M)/2 METHOD an (R+M)/2 octane rating of 91 or higher for optimum performance. The use of gasolines with lower octane ratings may degrade performance. We do not recommend the use of gasolines labeled as “Premium”...
- Page 17 Maintenance • an accurate temperature readout from the engine coolant gauge. When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “cold fill level” as listed on the engine coolant reservoir. •...
- Page 18 The cooling system in your vehicle is filled with either green-colored Motorcraft Premium Engine Coolant meeting Ford specification ESE-M97B44–A or yellow-colored Motorcraft Premium Gold Engine Coolant meeting Ford Specification WSS-M97B51–A1. To determine your vehicle’s coolant type (color), check your coolant reservoir.
- Page 19 • Do not mix with recycled coolant unless from a Ford-approved recycling process (see Use of Recycled Engine Coolant section). To avoid personal injury, make sure the engine is cool before unscrewing the coolant pressure relief cap.
- Page 20 Maintenance 3. Reinstall the pressure relief cap. 4. Start and idle the engine until the upper radiator hose is warm (this indicates the thermostat is open and coolant is flowing through the entire system). 5. Shut the engine off and let it cool. 6.
- Page 21 Maintenance fittings must be lubricated at regular maintenance intervals as indicated in the Scheduled Maintenance Guide using Ford recommended ESA M1C 92A grease to ensure proper function and extended service life. • location of the front tie rod • location of the rear tie...
- Page 22 • Only radial ply winter tires may be installed. • For a recommended wheel and tire package, ask your SVT dealer or call the SVT Info. Center at (800) FORD-SVT. • Winter tires of the same size and type must be mounted on all four wheel positions.
-
Page 23: Roadside Emergencies
4x4 blocks must be used when loading/unloading your vehicle. Do not tow with a wheel lift or a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. If the vehicle is towed by other means or incorrectly, vehicle damage may occur. -
Page 24: A Word About Warranty Coverage
Vehicle Limited Warranty as other Ford Mustang models. This information is covered in its entirety in the Ford Motor Company Warranty Guide. Warranty service for the SVT Mustang Cobra or any SVT vehicle can be obtained at any Ford Lincoln Mercury dealer nationwide. - Page 25 Making these noted modifications and subjecting your SVT Mustang Cobra to competition conditions will render repairs non-reimbursable under the New Vehicle Limited Warranty.
