Vocia
®
VI-6
Operation Manual
Biamp Systems, 10074 S.W. Arctic Drive, Beaverton, Oregon 97005 U.S.A. (503) 641-7287 www.biamp.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VOCIA VI-6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Biamp VOCIA VI-6

Summary of Contents for Biamp VOCIA VI-6

  • Page 1 Vocia ® VI-6 Operation Manual Biamp Systems, 10074 S.W. Arctic Drive, Beaverton, Oregon 97005 U.S.A. (503) 641-7287 www.biamp.com...

  • Page 2: Table Of Contents

    table Of cOntents VOcIa InPUt 6 (VI-6) featUres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . frOnt Panel .

  • Page 3: Vocia Input 6 (Vi-6) Features

    • Rotary switches for unit identification • CobraNet audio/control with dynamic use of available bundles, plus power over single Ethernet cable • Status LEDs to indicate signal and clip •  marked and RoHS compliant • Covered by BIAmp Systems’ warranty...

  • Page 4: Front Panel

    VI-6 frOnt Panel Setup and Use The Vocia software provides an intuitive interface for configuration, DSP equalization, and programming of the VI-6. The information supplied by this manual relates to physical connections and assignment. For more details on software setup, please consult the Vocia Help File. Power/ Network Input 6...

  • Page 5: Rear Panel Controls

    VI-6 rear Panel cOntrOls Control Inputs Inputs BIAMP SYSTEMS Input 1 Input 3 Designed in Australia N24138 Assembled in USA Input 5 Model VI-6 YEL:in use/conductor Control Inputs Paging Ports GRN:link/act Device ID Control Outputs CobraNet ® PoE IEEE 802.3af...
  • Page 6 If other network traffic shares an Ethernet switch with the Vocia network, a managed switch should be used with separate VLANs. All Ethernet wiring is to be done using shielded CAT5, CAT5e, CAT6, or CAT7 cable. VI-6 BIAMP SYSTEMS Input 1 Input 3...

  • Page 7: Control Outputs

    VI-6 rear Panel cOntrOls Control Outputs The Control Outputs, labeled 1 through 4, are isolated, voltage-free, software-configurable relay outputs. The individual pins are labeled as follows: 1. (C): the common/ground pin 2. (NC): normally closed (connected to C when relay is not energized) 3.

  • Page 8: Installation

    VI-6 InstallatIOn Installation The VI-6 requires one 1.75 inch (44.45mm) high and 19 inch wide (483mm) rack space with 10 inch (254mm) depth. Mounting the unit using four screws with washers will prevent marring of the front panel. pVC or nylon washers are appropriate. Please install the unit away from heat sources, such as vents and radiators, and in rooms with adequate ventilation.

  • Page 9: Specifications & Block Diagram

    VI-6 sPecIfIcatIOns Vocia Input 6 SPECIFICATIONS Control Inputs Frequency Response Line Inputs: + or – 1dB, 20Hz-20kHz Type: Digital, variable threshold Mic/Line Inputs: + or – 1dB 35Hz to Max Input Threshold: 20kHz Max Input Voltage: Min Input Threshold: 150mV Input Impedance: 100kΩ...

  • Page 10: Warranty

    9. BIAmp Systems shall not be liable for special, indirect, incidental, or consequential damages, including lost profits or loss of use arising out of the purchase, sale, or use of the products, even if BIAmp Systems was advised of the possibility of such damages.
  • Page 11 cOMPlIance...
