- Page 1 VI-6 OPERATION MANUAL May 2019 585.0247.90C...
- Page 2 VI-6 Product Description The VI-6 is a networked audio input expansion device allowing the user to add six channels of background music or user-defined audio to a Vocia system. As part of the Vocia system, the VI-6 meets paging requirements for facilities of all sizes.
- Page 3 The Vocia software provides an intuitive interface for configuration, DSP equalization, and programming of the VI-6. The information supplied by this manual relates to physical connections and assignment. For more details on software setup, please consult the Vocia Help File.
- Page 4 VI-6 Front Power Indicator LED The Unit features one power indication LED on the front panel: 1. Not illuminated: The device is not powered. 2. Flashing green: The unit is receiving power but not data, or the unit has not been configured correctly.
-
Page 5: Network Connection
VI-6 Rear Ground Screw This screw provides a connection point to ground the chassis of the device. The power supply to the unit is sourced from PoE, which may have no connection to ground. The chassis of the unit should be connected to a safety ground (main power supply ground) using the grounding screw. - Page 6 3. Ground Paging Ports The VI-6 has four Paging Ports on the rear of the unit which facilitate connection of either a Vocia Paging Stations Interface 1 (VPSI-1) or a Vocia Auxiliary Microphone 1 (VAM-1), or a combination of both. The Paging Ports when used in conjunction with these devices allow a balanced audio input, external Push-to- Talk and LED feedback of Zone and Paging states.
