Devio SCX
The Devio SCX is the next generation of Devio processor. Devio SCX combines powerful elements of Biamp's Devio
and Tesira devices in one product for quick and easy integration in medium to large conference spaces.
Devio SCX is designed to be used with Biamp's beam-forming microphones, PoE amplifiers and speakers. A system
including these elements and a UC-room system, display and camera will provide a complete technology solution for a
UC-enabled conference room.
The function of the Devio SCX is to process local Biamp microphone input and speaker output signals in support of
audio-only and audio/video conference calls from dedicated conference rooms.
Devio SCX offers dedicated AEC processing for 4 or 8 mic channels, 1x1 channels of USB connectivity with HID mute
sync, (5) 1G network ports including (4) ports offering PoE+ and support for AVB audio streaming between Devio
SCX and connected Biamp peripheral hardware including Parle mics and amplifiers and the
Bluetooth-capable
expander. The EX-UBT adds an additional 1x1 USB audio connection as well as a 2x1 Bluetooth
connection.
Devio SCX features
Biamp Launch
tuning. Upon completion of the Launch process, a
after optimization and the Biamp hardware manifest is available for viewing via a web browser. The Launch
can also be printed as a pdf.
Devio SCX device discovery and connection is done using the
Models
There are 2 models supporting various densities of AEC processing depending on your requirements. Both are
externally physically identical aside from their model name. The same power supply model is used for both units.
• Devio SCX 400 has 4 channels of AEC, supporting up
to 4 Parlé microphones
• Devio SCX 800 has 8 channels of AEC, supporting up
to 8 Parlé microphones
functionality, allowing for one-touch room hardware discovery, configuration, and
report card
detailing the room's acoustic performance before and
Biamp Discovery
app.
https://support.biamp.com/Devio/Hardware-Software/Devio_SCX
EX-UBT USB and
report card
Updated: Sat, 11 Mar 2023 08:47:04 GMT
Powered by
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Devio SCX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Biamp Devio SCX

Summary of Contents for Biamp Devio SCX

  • Page 1 UC-room system, display and camera will provide a complete technology solution for a UC-enabled conference room. The function of the Devio SCX is to process local Biamp microphone input and speaker output signals in support of audio-only and audio/video conference calls from dedicated conference rooms.

  • Page 2: Auto Configuration

    Launch, Devio SCX features automated system hardware discovery, configuration, and tuning. Upon completion of the auto-configuration process, a report card detailing the room’s acoustic performance before and after optimization plus the Biamp hardware manifest is available for viewing via a web browser and can be printed as a pdf.

  • Page 3: Installation

    Plenum Box 12x12 is a fire-resistant enclosure used to install a variety of Biamp devices in plenum spaces. The Biamp Plenum Box 12x12 is UL2043 compliant and is approved for use in air-handling plenums. This product also meets Chicago Building Code Chapter 14E-3 requirements for use in a plenum space within the city of Chicago.

  • Page 4: Network Connectivity

    Cooling Both models of Devio SCX are actively cooled by a variable speed fan. Air enters the right side and exits the left side of the unit when viewed from the front. When the unit is wall mounted the orientation is not enforced, but best cooling performance (convection plus fan assistance) will happen when the left side is high.

  • Page 5: Web User Interface

    If port 1 is in a common subnet range with ports 2-5 then the discovery and control functions required for peripherals on port 2-5 will be disrupted. • If an HD-1 connected on P2-5 fails to get a configuration ensure that the Devio SCX Control port (P1) is in a https://support.biamp.com/Devio/Hardware-Software/Devio_SCX...
  • Page 6 IP address, independent of the control IP and subnet range, is available for the VoIP interface. Control and VoIP still share a common network port but are now logically separated. 802.1x is supported on the Control interface of the Devio SCX and can be configured in the Network > 802.1x tab of the web UI.
  • Page 7 (provided the HD-1 device ID is at the default "HD-1ID 01"). If an HD-1 fails to get a configuration ensure that the Devio SCX Control port (P1) is in a unique IP subnet range from the media ports. If no DHCP server is present it may be necessary to assign a static IP address to the control port so the HD-1 can communicate via the media subnet.
  • Page 8 ZRTP SRTP-DTLS are supported for media encryption. The media security mechanisms are mutually exclusive. ZRTP and SRTP-DTLS are RTP security mechanisms which are new to Biamp VoIP. In Devio SCX VoIP, SSL/TLS are supported for SIP signaling encryption. TLS 1.2 is supported and is downward https://support.biamp.com/Devio/Hardware-Software/Devio_SCX...
  • Page 9 Mic LED behavior - Launch When Devio SCX is Launch auto-configured using firmware 4.0.x or 4.1.x, the Parle mic LEDs will illuminate in green when idle or when audio streaming is detected, and be solid red when mute is engaged.
  • Page 10 Devio SCX uses dedicated AEC hardware, the same as all Biamp devices, for optimal AEC performance. The number of supported AEC channels is indicated in the model name. The Devio SCX 400 offers 4 AEC channels and the Devio SCX 800 offers 8 AEC channels.
