Telematrix Marquis 9000MWD User Manual

Single line cordless hotel telephone
Hide thumbs
Table of Contents

Advertisement

Quick Links

MARQUIS 9000MWD
SINGLE LINE CORDLESS
HOTEL TELEPHONE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Marquis 9000MWD and is the answer not in the manual?

Questions and answers

Related Manuals for Telematrix Marquis 9000MWD

Summary of Contents for Telematrix Marquis 9000MWD

  • Page 1 MARQUIS 9000MWD SINGLE LINE CORDLESS HOTEL TELEPHONE...

  • Page 2: Features

    TeleMatrix has designed the telephone to be simple to install and easy to use. Cordless performance provides convenience and mobility for all your guest rooms. Your 9000MWD telephone is a precision electronic device that requires minimum maintenance. Please be sure to read the contents set forth in the user’s guide to become familiar with the...
  • Page 3 To reduce the risk of fire or injury, read and follow these instructions: Use only the designated battery pack for cordless handset and power adapter for the base. Do not dispose of the battery(ies)in a fire. The cell may explode. Check with the local codes for possible special disposal instructions.

  • Page 4: Controls

    IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product. 3.
  • Page 5 FCC Part 15 Compliance Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to Part 15 of the FCC Rules, These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 6 DOC - NOTICE AND LOAD NUMBER STATEMENT NOTICE: The Canadian Department of Communications label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. The Department does not guarantee the equipment will operate to the user's satisfaction.
  • Page 7 NOTIFICATION TO THE TELEPHONE COMPANY Before you may connect your telephone you must notify the telephone company of particular line(s) to which such connections is to be made, and provided to the telephone company the FCC registration number and ringer equivalence number of the registered protective circuitry. The customer shall give notice to the telephone company upon final disconnection of such equipment or circuitry from the particular line(s).

  • Page 8: Consumer Information

    Consumer Information: This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the bot- tom of this equipment is a label that contains, among other information, a product identifier in the format US:2N3WI29B95339 If requested, this number must be provided to the telephone company.

  • Page 9: Table Of Contents

    Features ...…………………... Controls ...…...…………………... Installation …………………... Wall Mounting ...…...…………………... 16 Battery Preparation ...…………………... Switch Settings .…………………..…... Programming ...…...…………………... Operation ...…...…………………. Service ...…...…………………... Warranty ...…...…………………... Spare Part List ……………………………………………...…………………...
  • Page 10 One Line Operation Cordless Handset, 900 Mhz Operation, with Handshake Technology Long Life Rechargeable NiCd Battery Speakerphone with volume control 10 Guest Service Keys (Speed Dial Locations)  M essage Waiting Indicator/Retrieval Feature TouchLite Convenient Data Port “Soft-Key” Volume Control (Handset -- 8 step/ADA Compliant) HI/Low Ringer Volume Controls (Handset) Speaker Volume Control Rocker Switch Line Status Indicators (In-Use/Hold/Mute/Ringing)

  • Page 11: Top View

    TOP VIEW (14) (13) (11) (10) NEON STORE FLASH FOR MESSAGES PRESS HERE REDIAL PQRS WXYZ MUTE SPEAKER (12)

  • Page 12: Charge Led

    Handset ...……………………..…...…...…... Charge LED …….……………………………….. In-Use / Ringer Indicator ………………………... Mute Key ………………………………………… Speaker Key ……………………………………… Speakerphone Volume Control Rocker Switch ….. Locate Key ………………………...……………... Pause/Redial Key ...………...………….….… TouchLite One Touch Message Retrieval Key… 10. Flash Key ...…….…...…………………. 11. Store Key ...……….…………...…...…. 12.
  • Page 13 TOP VIEW OF HANDSET (10) ON/OFF HOLD WXYZ PQRS REDIAL VOLUME FLASH...

  • Page 14: Handset Unit

    Handset ...…………...……………... Hearing aid compatible, low profile styling. ON/OFF Line Key ...……………..…... Used to activate line or hold. Hold Key ...……………...…... Numeric Dialing Keypad ……………………. Used to dial numbers. Redial Key ………………………….……….. Used to dial the last number dialed. Handset Volume Control ………………….… Used to increase or decrease volume Flash Key ...………...……………...

  • Page 15: Left Side

    TOP SIDE LEFT SIDE...

  • Page 16: Data Port

    1. Telephone Jack …………... 2. Data Port …………..………...…... Modular receptacle for plugging in telephone line. Convenient port to connect a computer modem, fax or answering device.
  • Page 17 Use caution when installing or modifying telephone lines. Parts Check List The following parts are included with the 9000MWD: 1. Stationary Base Unit. 2. Mobile Handset Unit. 3. 15’ Modular Telephone Line Cord.

  • Page 18: Wall Mounting

    Wall Mounting Your Telephone* The 9000MWD is designed to be conveniently wall mounted. Note: A 9000MWD wall mounting kit must be used (not included) Follow these easy steps: 1. The handset retaining clip must be engaged to secure the handset when hanging up.
  • Page 19 Power Adapter “LINE” Connection The power adapter “LINE” connection is used to connect the telephone lines from the wall jack to the telephone. Using the 15’ modular telephone line cord provided, connect one end of the cord to the RJ14 telephone jack on the wall or base board.

  • Page 20: Install The Handset Battery

    Install the Handset Battery To install the handset battery; 1. Open the battery cover as shown, 2. Insert the battery pack. Match the polarity marks from the battery to the case (+ to 3. When properly installed, the battery will slide into position.

  • Page 21: Message Waiting Lamp

    To turn ON, slide the switch to the “LED” or “NEON” position. The switch is located underneath the overlay and faceplate on the top of the base. Note: The 9000MWD is factory preset to the “Neon” setting. *NOTE: Voice Mail will ONLY operate if you subscribe to...

  • Page 22: Speed Dial Memory

    Guest Service Keys (Speed Dial Memory) The 9000MWD has 10 one-touch speed dial memory locations that are used as a ience for dialing frequently used Each speed dial memory location can store up to 32 digits. Step: Procedure: Press the Speakerphone ON/OFF key to activate the phone.

  • Page 23: Programming

    TouchLite the guest to the message center or the front desk. Note: The TouchLite key adds an additional memory location to your 9000MWD telephone. Programming The TouchLite See “Programming: Guest Service Keys (speed dial memory)” connects...
  • Page 24 Programming A Flash Into Memory The “Flash” key is a storable function into memory that is used to provide a 600mS timed line break. This function may be required for accessing line features provided by your telephone system or local telephone company. For example, many times the “Flash”...
  • Page 25 Placing A Call Using The Handset Follow the instructions below for placing a call using the handset. Lift the handset from the base and press the ON/OFF key to activate the line. Dial out by using the numeric dial pad on the handset.
  • Page 26 BASE UNIT DIALING Placing A Call Using The Base Unit Follow the instructions below for placing a call using the base unit. 1. The handset can either be on or off the base cradle when dialing from the base unit. 2.

  • Page 27: Locating The Handset

    Locating The Handset The 9000MWD is equipped with a handset locator feature key located on the base. Simply press the “LOCATE” button on the base unit. The handset will beep for about 15 seconds. Once the handset is located, simply press the ON/OFF key to activate your handset.
  • Page 28 Using The Handset Volume Control A convenient handset volume control is provided. This volume control will adjust the loudness of the handset. The loudness can be adjusted in seven (8) steps up or down. Using The Speakerphone Volume Control A rocker volume switch is provided to adjust the loudness of the speakerphone.
  • Page 29 Line Status Indicators (Base Unit) The 9000MWD has visual LED indicators located on the base unit that indicates the status of the telephone. Ringing of Line The in use LED blinks rapidly GREEN to show ring. Line In-Use The in use LED shows a steady GREEN color when base in off-hook.
  • Page 30 Using The Data Port The 9000MWD is equipped with a convenient port on the right side of the base unit. This modular receptacle is used to plug in any standard telephone device such as a computer modem, answering machine or fax machine.

  • Page 31: Using The Mute Feature

    Using The Hold Feature (on Handset) The “Hold” key is used to place a caller on hold. To use, simply press the “Hold” key on the handset. The LED light on the handset will indicate that the line is on hold and the base unit LED will blink rapidly Green.
  • Page 32 Redial (On Handset) The “Redial” key is used to automatically redial the last number that was manually dialed from the numeric dial pad of the spe- cific handset or base unit. To use (handset): Lift the handset Press ON/OFF key. Press the “Redial”...
  • Page 33 When problems arise during installation or service that cannot be resolved using this or related documents, contact the TeleMatrix Technical Service department 8:30a.m. - 4:30p.m. MST: Toll Free: 1-800-462-9446 Direct: 719-638-8821 Fax: 719-638-8815 Web Site: http://www.telematrixusa.com Many times a problem is either installation or user related. Please contact TeleMatrix PRIOR to sending a telephone to our service center for repair.

  • Page 34: Operation

    STATEMENT OF LIMITED WARRANTY TeleMatrix, Inc. and TeleMatrix Equipment, LLC (TMX) warrants to its [original end customer] [purchaser] that Spectrum, Spectrum Plus and Marquis branded products manufactured by TMX are free from defects in materials and workmanship for five (5) years after the date of purchase, and Regency branded products manufactured by TMX are free from defects in materials and workmanship for three (3) years, other than the following products for which the warranty period shall be one (1) year: handset batteries, either NiCd or NiMH, used in TMX cordless products.

  • Page 35: Spare Part List

    Spare Parts List The following 9000MW accessories and spare parts are available from TeleMatrix or Associate Distributors. Description Complete Handset Unit (light ash) Complete Handset Unit. (black) Handset Battery Pack—NiCd 12V DC Power Supply Adapter (light ash) 12V DC Power Supply Adapter (black) 15’...
