Warnings - Built-under ovens
It is most important that the instruction book should be retained with the appliance for future
reference. Should the appliance be sold or transferred to another owner, or should you move
house and leave the appliance, always ensure that the book is supplied with the appliance in
order that the new owner can be acquainted with the functioning of the appliance and the
relevant warnings. These warnings are provided in the interest of safety. You must read them
carefully before installing or using the appliance.
Installation
Any installation work must be undertaken
by a qualified electrician or competent
person.
Installation and initial adjustment of your
oven MUST be carried out by qualified
personnel in compliance with current
regulations.
instructions for the installer are given in this
booklet.
During use
This appliance has been designed for
cooking edible foodstuffs only, and must
not be used for any other purposes.
Always stand back from the oven when
opening the oven door during cooking or
at the end of it to allow any build up of
steam or heat to release.
It is dangerous to alter the specifications
or modify the product in any way.
Appliances become very hot with use, and
retain their heat for a long period after use.
Care should be taken to avoid touching
heating elements inside the oven.
Always ensure that the control knobs are
in the "off" position when not in use.
Using a gas cooking appliance will produ-
ce heat and moisture in the room which it
has been installed in. Ensure a continuous
air supply, keeping the air vents in good
conditions or installing a cooker hood
with discharge tube.
In case of intensive or long time use of the
appliance, make the ventilation more
efficient, by opening a window or
increasing the electric exhaust fan power.
English
Specific
installation
For hygiene and safety reasons, this
appliance should be kept clean at all times.
A build-up of fats or foodstuffs could result
in a fire.
Never line any part of the oven with
aluminium foil.
Never use steam or steam machines to
clean the appliance.
Before any maintenance or cleaning work
is carried out on the appliance, always turn
off the isolator switch at the cooker point,
and allow to cool.
Ensure that the shelves are put in place in
the correct way.
This oven (even if it is linked to an electrical
cooking table) is made to function at 230 V
monophase with neutral.
Child safety
This appliance is designed to be operated
by adults. Children should not be allowed
to tamper with the controls or play with the
product.
Children should be supervised at all times
and should not be allowed to touch the hot
surfaces or be in the vicinity when in use or
until the appliance has cooled after use.
During oven cooking and grilling, the
appliance door and the surrounding parts
are warmed up to a very high temperature.
Be careful and keep children away from
the appliance while you are using it. When
you connect other appliances to a plug near
the oven, check carefully that the wire does
not touch warm parts of the oven and does
not get taken in the oven door.
31
Advertisement
Table of Contents
Related Manuals for Electrolux EON6701FXP
Summary of Contents for Electrolux EON6701FXP
-
Page 1: Child Safety
English Warnings - Built-under ovens It is most important that the instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings. -
Page 2: Technical Assistance
Safety Instructions you purchased the product. Step by step instructions for an MANUFACTURER: ELECTROLUX HOME PRODUCTS ITALY S.p.A. operation Viale Bologna, 298 47100 FORLÌ (Italy) Hints and Tips When the oven is first installed... -
Page 3: Description Of The Appliance
Description of the appliance 1. Control panel 8. Operating control light 2. Control knob for right rear burner 9. Oven thermostat control light 3. Control knob for right front burner 10. Electronic programmer 4. Control knob for left front burner 11. -
Page 4: Lighting The Burners
Gas Hob Hob Burner Control Knobs The hob burners control knobs are situated on the front panel (Fig. 2). The symbols on the knobs mean that : there is no gas supply there is maximum gas supply there is minimum gas supply Fig. - Page 5 Using the hob correctly To ensure maximum burner efficiency, it is strongly recommended that you use only pots and pans with a bottom fitting the size of the burner used, so that flame will not spread beyond the bottom of the vessel (see table).
-
Page 6: Electric Oven
Electric oven Oven Function (Fig. 4) and Thermostat (Fig. 5) control knobs They enable to select the most appropriate type of heating for the different cooking requirements by appropriately connecting the heating elements and adjusting temperature to the required level. The oven is OFF. - Page 7 Operating control light It indicates that one or more of the heating elements are turned on. Oven thermostat control light This light goes off when the oven heats up to the temperature set and comes on again every time the thermostat cuts in to stabilize temperature.
-
Page 8: Electronic Programmer
Electronic programmer 1. Push button for selecting a function 2. Decreasing control button “ ” 3. Increasing control button “ ” 4. Display 5. “Cooking Duration” pilot lamp 6. “End of cooking” pilot lamp 7. “Minute minder” pilot lamp 8. “Time of day” pilot lamp The oven will work only if the time of day has been set. - Page 9 lamp will start flashing. Then, proceed as follows: To set the duration time: 1. press button “ ” or “ ”. 2. After the setting is carried out, wait for 5 seconds: the "Cooking Duration" pilot lamp will come on and the display will revert to the time of day.
- Page 10 To cancel the End of cooking time: 1. Press button repeatedly to select the “End of cooking” function. The relevant pilot lamp will flash and the display will show the programmed End of cooking time. 2. Press button “ ” until the display shows the current time of day.
- Page 11 How to switch off the display 1. Press two or three programmer push buttons simoultaneously and keep them pressed for about 5 seconds. The display will switch off. 2. To switch on the display, press any button. The display can be switched off only if no other functions have been set.
-
Page 12: Hints And Tips For Using The Oven
Hints and tips for using the oven The possibility of cooking on several shelf Always cook with the oven door heights means that you can cook several closed. different dishes at the same time and up to The oven is supplied with an exclusive system three tins of biscuits and mini pizzas to be which produces a natural circulation of air eaten immediately or subsequently deep... -
Page 13: Cooking Times
Some hints fairly pink in color, cooking times must be For baking cakes short. Cakes require a moderate temperature The meat can be cooked in a baking pan or (normally between 150 and 200 °C). In else directly on the shelf - in this case a addition, the oven must be heated up dripping pan must obviously be placed beforehand - for about 10 minutes. -
Page 14: Cooking Tables
Cooking Tables Traditional cooking and fan ducted cooking Traditional Cooking Fan Oven Cooking time TYPE OF DISH NOTES Level Level temp. temp. °C °C minutes CAKES Whipped up kneading 2 (1 and 3)* 45 ~ 60 In cake mould Shortbread dough 2 (1 and 3)* 20 ~ 30 In cake mould... - Page 15 Grilling Cooking time Grilling Quantity (minutes) TYPE OF DISH Weight Lower Upper °C Pieces temp. Level side side Fillet steaks 12 ~ 15 12 ~ 14 Beef-steaks 10 ~ 12 6 ~ 8 Sausages — 12 ~ 15 10 ~ 12 Pork chops 12 ~ 16 12 ~ 14...
-
Page 16: Cleaning And Maintenance
Cleaning and Maintenance Oven door cleaning Before any cleaning switch the oven off and let it cool down. For a better cleansing of the oven door, you Never use steam or steam are suggested to remove it from the appliance machines to clean the appliance. -
Page 17: Replacing The Oven Light
Replacing the oven light Disconnect the appliance from its power supply point. Push in and unscrew the glass cap (Fig. 8). Unscrew the light bulb and replace it with a new heat-proof bulb (300 °C) having the following features: - Operative tension: 230 V (50 Hz);... -
Page 18: What Happens If Something Goes Wrong
What happens if something goes wrong If the appliance is not working correctly, please carry out the following checks, before contacting your local Service Centre. SYMPTOM SOLUTION The oven does not come on Check that both a cooking function and a tem- perature have been selected Check the appliance is wired in properly, and the socket switch or the switch from the... -
Page 19: Service And Spare Parts
Service and Spare Parts If after the checks listed in the previous chapter, the appliance still does not work correctly, contact your local Service Centre, specifying type malfunctioning, the appliance model (Mod.), the product number (Prod. No.) and the serial number (Ser. No.) marked on the identification plate. -
Page 20: Technical Data
Technical Data Dimension of the oven This appliance complies with the following E.E.C. Directives: recess 73/23 - 90/683 (Low Voltage Directive); 89/336 (Electromagnetical Compatibility Height 593 mm Directive); Width 560 mm 90/396 (Gas Directive); Depth 550 mm 93/68 (General Directives) and subsequent modifications. -
Page 21: Building-In
Building-in Safety information for the installator • The surround or cabinet into which the oven will be built must whithstand temperatures over 75°C. Should the furniture unit not comply with this requirement, it may be subject to warping. • Wood panels may be used as protection between the burners and the adjacent walls, provided that the minimum clearances which are given in the relevant... -
Page 22: Gas Connection
Gas connection General warnings • This gas appliance must be installed by qualified personnel only, according to the manufacturer's instructions and the rules in force. • This appliance is supplied with a gas connection R 1/2" located on the rear side (Fig. - Page 23 FO 2191 Fig. 15 Recess for the oven • The opening for the oven must comply with the dimensions given in the diagram (Fig. 15). • If the furniture unit is closed on the rear side, an additional opening shall be obtained onto the rear panel to allow the gas and electrical connections and a proper ventilation.
- Page 24 Gas hob installation The gas burner support and the relevant hardware comes as one assembly together with the built-in oven directly from the factory, and it is secured onto the upper panel of the oven to avoid damage during transport. Procedure •...
- Page 25 • Place the sealing gasket which supplied with the appliance onto the front, left and right borders of the opening for the gas hob, as shown in Fig. 19. Take care that the edges meet precisely without overlapping. • The earth connection between the hob top and the built-in oven is obtained by means of the green/yellow wire.
-
Page 26: Instructions For The Installer
Instructions for the installer The instructions given below are should be 2-3 cm. longer than the other designed specifically for a qualified cables. The supply cable must in all cases installer and should aid him or her to be laid out in such a way as to ensure that perform all installation, adjustment, it does not reach at any given point a and maintenance operations with... -
Page 27: Adaptation To Different Types Of Gas
Adaptation to different types of gas Injector replacement • Remove the pan supports. • Remove the burner's caps and crowns. • With a socket spanner 7 unscrew and remove the injectors (Fig. 24), and replace them with the ones required for the type of gas in use (see the table below). - Page 28 Adjustment of minimum level To adjust the minimum level of the burners, proceed as follows: • Light the burner. • Turn the knob on the minimum position. • Remove the knob. Fig. 26 • With a thin screwdriver, adjust the by- pass screw.
- Page 29 EON6701FXP 0,79 kWh 0,78 kWh 53,0 43 min. 41 min. 1130 cm²...
- Page 30 From the Electrolux Group. The world’s No.1 choice. The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
