Summary of Contents for Maxon GMRS-50
- Page 1 GMRS-50 eneral obile adio ervice Two-Way Radio Owner's Manual...
-
Page 2: Table Of Contents
Table of Contents About Your GMRS-50 Radio............Package Contents................About Maxon / Topaz3..............Safety Information................. FCC Licensing Information............FCC Forms and Information..........Radio Controls / Functions............Battery Charging and Care............Installing and Removing the Battery Pack ........ Antenna Installation..............Attaching and Removing the Belt Clip........ -
Page 3: About Your Gmrs-50 Radio
About Your GMRS-50 Radio Congratulations, you now own the Maxon GMRS-50 two-way radio. Featuring 16 channel, 5 Watt operation, the GMRS-50 provides superior performance and reliability. Operation and functions for your radio are described in this instruction manual. We urge you to thoroughly read this manual before operating the radio. -
Page 4: Safety Information
Federal law prohibits unauthorized use or adjustments of this radio. FCC Licensing Information Before using your Maxon GMRS-50, you must obtain / possess a radio license issued by the Federal Communications Commission (FCC). It is illegal to transmit without the appropriate license. -
Page 5: Fcc Forms And Information
FCC Licensing Information, Continued FCC Forms and Information To obtain a FCC license to operate your GMRS-50 radio, you must submit FCC Form 574 directly to the FCC at this address: Federal Communications Commission General Mobile Radio Service P.O. Box 358230... -
Page 6: Radio Controls / Functions
Radio Controls / Functions A Antenna Receptacle Channel Selector Knob C Busy/TX/BT Indicator D On/Off - Volume Control Accessory Jacks Speaker G Microphone H Battery Push-To-Talk (P-T-T) Monitor Button Not shown: Belt Clip (on back) Battery Charge Contacts (on back) Battery Latch (on bottom) B C D... -
Page 7: Battery Charging And Care
Proper care and charging will allow maximum performance and life from your battery pack. The GMRS-50 comes standard with a desktop charger. Turn radio off and insert into charger. The charging cycle with this charger is overnight (12-16 hours). -
Page 8: Antenna Installation
GMRS-50 Series Operations Power On - Volume - Power Off Turn the radio on by rotating the on /off - volume control clockwise until you hear a click and a single tone. -
Page 9: To Receive
When you have finished transmitting, release the P-T-T bar to receive. Status Indicators and Audible Alert Tones Your GMRS-50 radio has a sophisticated microprocessor control which provides a series of audible alert tones. Upon initial power up, a single tone indicates that the self-test of the microprocessor functions has been completed satisfactorily. -
Page 10: Accessories
Red, flashing Double beep, repeat Filtering Error Red, flashing Triple beep, repeat Accessories The Maxon GMRS-50 radio is designed to work with a variety of accessory products, including: QPA-1200G* 1200 mAh Ni-Cad Battery Pack CA-1410C AC/DC Wall Trickle Charger QPA-1130... -
Page 11: Pre-Programmed Frequencies
Pre-Programed Frequencies Your GMRS-50 radio comes pre-programmed on the following frequencies: 462.5500 GMRS Channel 1 462.5750 GMRS Channel 2 462.6000 GMRS Channel 3 462.6250 GMRS Channel 4 462.6500 GMRS Channel 5 462.6750 GMRS Channel 6 462.7000 GMRS Channel 7 462.7250 GMRS Channel 8 462.5625... -
Page 12: Scan Mode
Programmable Features, Continued Scan Mode The GMRS-50 allows for a channel scan function programmed onto Channel 16 only, (making the radio a 15 channel radio with scan). No channel frequency may be programmed onto Channel 16 with scan. The scan function will scan all programmed channels (Channel 1 - 15). -
Page 13: Radio Maintenance /Service
800#: 800-548-8797 Fax: 714- 441-0857 Radio Maintenance /Service Your GMRS-50 Series radio is designed to be maintenance free. To keep your radio in good working condition: Clean external surfaces with a clean cloth dampened in a solution of dishwasher detergent diluted in water. Apply the solution sparingly to avoid any moisture leaking into cracks and crevices. -
Page 14: Software Copyrights
Software Copyrights The Maxon product(s) described in these operating instructions may include copyrighted Maxon software programs stored in semi- conductor memories or other media. Laws in the United States and other countries preserve for Maxon certain exclusive rights for copyrighted software programs, including the exclusive right to copy or reproduce in any form the copyrighted software program. -
Page 15: Product Warranty
Product Warranty Topaz3 warrants that the Products and included accessories sold herein will be free from defects in workmanship or materials under normal use and service for a period of one (1) year from the date of purchase by the original end user, provided that the buyer has complied with the requirements stated herein. - Page 16 For more information, contact: Topaz3, LLC 10828 NW Air World Drive Kansas City, Missouri 64153 (Within USA) Phone: 1-800-821-7848, Ext. 399 (Outside USA) Phone: 1-816-891-6320, Ext. 399 Fax: 816/891-8815 Explore our website: www.topaz3.com Printed in Thailand U.S. P/N: 680-090-0159...
