Candy CDB 754 D Instructions For Use Manual page 7

5
4
{
3
1
2
6) KG DETECTOR indicator
Available on Cotton and Synthetic cycles, during the first 4 minutes of the cycle the intelligent
sensor will weigh the laundry and adjust the cycle time, water and electricity consumption
accordingly.
7) DRYING PROGRAMME INDICATORS
The indicators display the type of the drying programme:
Candy washer dryers incorporate an Automatic Sensor Drying function which takes the
guesswork out of setting the drying time. You simply select the degree of dryness you
require and the dryer automatically switches off when that level is reached. For added
flexibility there are 3 Sensor Drying levels to choose from:
= Extra dry programme
= Cupboard dry programme
= Iron dry programme
USEFUL TIPS:
Once the programme option has been selected, press the Start Pause button. The appliance
will then calculate the time to the end of the selected programme based upon a full dry load.
During the cycle the appliance will update the time to suit the actual load size and dampness
of the fabrics.
Timed programmes:
Alternatively you may select a pre-determined time for the drying cycle. The Timed Drying
programmes may be set to the following times:
120 minutes – 90 minutes – 60 minutes – 30 minutes:
Cool down phase :
A 10 minute cool down phase occurs at the end of each drying cycle to ensure clothes are
not too hot to touch when the cycle finishes.
8) STAIN LEVEL
When a programme is selected the relevant indicator will light up to show the minimum
possible Stain Level.
Selecting a greater Stain Level using the special button will cause the corresponding indicator to
light up.
7
6
{
8
12
"STAIN LEVEL" button
By selecting this button (active only on COTTON and MIXED FIBRES programmes) there is
a choice of 3 levels of wash intensity, depending on how much the fabrics are soiled.
Once the programme has been selected the indicator light will automatically show the
minimum level required for that programme. Pressing the button increases the duration of the
wash cycle, and adjusts the wash settings accordingly. For example: Using this button on
the Rapid Wash cycle will enable you to select either a 14, 30 or 44 minute wash cycle.
PROGRAMME selector with "OFF" position
When the programme selector is turned
the display lights up to show the settings
for the programme selected.
N.B. To switch the machine off, turn the
programme selector to the "OFF"
position.
Today, most detergents have been improved to wash
efficiently at lower temperatures, therefore we have set the
default temperature settings of each programme to a lower
level, saving electricity and reducing the carbon footprint of
your machine.
You can select an high temperature by pressing the
temperature button.
Please refer to the programme guide for the maximum
temperature to which each programme can be set.
Press the "Start/Pause" button to start the selected cycle.
Once a programme is selected the programme selector remains stationary on the selected
programme till cycle ends.
Switch off the washing machine by turning the selector to "OFF".
Note:
The programme selector must be returned to the "OFF" position
at the end of each cycle or when starting a subsequent wash
cycle prior to the next programme being selected and started.
Buttons indicator light
These light up when the relevant buttons are pressed.
If an option is selected that is not compatible with the selected programme then the light on
the button first flashes and then goes off.
13
M
N
O
