BT CONVERSE 125 User Manual

General information

Your Converse 125 is guaranteed
Pack the unit securely, preferably
for a period of 12 months from the
in the original packaging. All parts
date of purchase.
must be returned. We cannot take
responsibility for goods damaged
Subject to the terms listed below
in transit.
the guarantee will provide for the
repair of, or at BT's or its agent's
discretion the option to replace the
Converse 125, or any component
thereof, which is identified as
faulty or below standard, or fails as
a result of inferior workmanship
or materials. Products over 28 days
All items of telephone equipment
old from the date of purchase
have a Ringer Equivalence Number
may be replaced with a refurbished
(REN), which is used to calculate
or repaired product.
the number of items which may
be connected to any one telephone
line. Your Converse 125 has a REN
of 1. A total REN of 4 is allowed,
• The guarantee shall only apply
if the total REN of 4 is exceeded,
to defects that occur within the
the telephones may not ring. With
12 month guarantee period.
different telephone types there is
no guarantee of ringing, even when
• Proof of purchase is provided.
the REN is less than 4.
• The equipment is returned to
the point of purchase.
• This guarantee does not cover
any faults or defects caused by
accidents, misuse, fair wear and
tear, neglect, tampering with the
This product is intended for use
equipment, or any attempt at
within the UK for connection to
adjustment or repair other than
the public telephone network and
by approved agents.
compatible switchboards, which
support tone dialling and time
• This guarantee does not affect
break recall. If in doubt please
your statutory rights.
consult your service provider.
In the unlikely event of a defect
occurring, please return the
product, with the receipt, to the
For a full range of accessories
place of purchase.
and replacement items for
BT products please call
0870 240 5522, or visit:
If your product needs repair after
the guarantee period has ended,
the repair must meet the approval
requirements for connection to
the telephone network. We
recommend that you contact BT's
approved repair agent, TecLogic
on 01672 564444 or a local
qualified repairer.
Wall-mounting
Rotate the handset hook 180°
Note
so that it protrudes upward.
This holds the handset in place
Before you wall-mount your
when wall-mounted.
Converse 125, check that:
• you are not drilling into any
hidden wiring;
• you do not need the facility of
the data port.
Hang the holes on the back of
the phone over the screwheads
Unplug and remove the
and gently pull the phone
telephone line cord from the
downward to make sure it is
socket on the stand
securely in place.
Hang the handset on the
handset hook.
If you need to leave the phone
DATA LINE
whilst on a call you can hang the
handset on the park at the top
right hand corner of the product.
Unclip the line plug from the
telephone base.
Unclip the stand from the base
of the telephone and remove
the stand. Hereby, TMX, declares that this
Converse 125 is in compliance
with the essential requirements
and other relevant provisions of
Directive 1999/5/EC.
A copy of The Declaration of
Conformance for the Converse 125
is available from TMX, Alpha
Business Park, 28 White House
Road, Ipswich, IP1 5LT.
Reconnect the telephone line
to the line socket on the base of
the phone.
Drill two holes in the wall
60mm vertically apart using an
8mm drill bit.
The telecommunications services described in
this publication are subject to availability and
Wall plug Screw
may be modified from time to time. Services
and equipment are provided subject to British
Telecommunications plc's respective standard
conditions of contract. Nothing in this publication
Wall 60mm
forms any part of any contract.
© British Telecommunications plc 2003.
Registered Office: 81 Newgate Street, London
EC1A 7AJ.
Registered in England No. 1800000.
Insert the wall plugs if
Converse 125 Issue 2 (7/03) 2
Designed by the Art & Design Partnership
necessary, then insert the
Limited.
screws leaving about 5mm
Printed in China
protruding from the wall on
which to hang the phone.
User Guide
BT CONVERSE 125
This product is intended for connection to analogue
public switched telephone networks and private
switchboards in the United Kingdom.
