READ AND SAVE THESE INSTRUCTIONS
"Derby" Series
Model No.
F2100AB02
F2100BS02
F2100PB02
F2100WW02
Net Weight:
Derby & Amphora Series
Ceiling Fan Owner's Manual
Part No. F40BP71880005
21.5
Lbs.
"Amphora" Series
Model No.
F2200HTW02
F2200S02
F2200TG02
F2200OB02
21.7
Net Weight:
®
Lbs.
Form No. BP7188-5
Advertisement
Table of Contents
Related Manuals for Emerson Derby F2100AB02
Summary of Contents for Emerson Derby F2100AB02
- Page 1 READ AND SAVE THESE INSTRUCTIONS “Derby” Series “Amphora” Series Model No. Model No. F2100AB02 F2200HTW02 F2100BS02 F2200S02 F2100PB02 F2200TG02 F2100WW02 F2200OB02 21.5 21.7 Net Weight: Lbs. Net Weight: Lbs. ® Derby & Amphora Series Ceiling Fan Owner's Manual Part No. F40BP71880005...
-
Page 2: Table Of Contents
WARNING WARNING: To avoid fire, shock, and serious personal injury, follow these instructions. Safety Instructions 1. Read your owner’s manual carefully and keep it for future reference. 2. Before servicing or cleaning unit, switch power off at service panel and lock service panel disconnecting means to prevent power from being switched on accidentally. -
Page 3: Tools Needed For Assembly
This Manual Is Designed to Make it as Easy as Possible for You to Assemble, Install, Operate and Maintain Your Ceiling Fan Tools Needed for Assembly Installed Wire Length Wire Size A.W.G. Up to 50 ft. One Phillips head screwdriver One stepladder 50-100 ft. -
Page 4: Assembly Instructions
Assembly Instructions 1. Remove the fan motor and housing assembly from 5.Remove the hanger ball by loosening the setscrew styrofoam packaging and position it so that the top in the hanger ball until the ball falls freely down the of the motor is facing you. downrod. -
Page 5: Electrical Requirements
9. The fan comes with blue, black and white leads Electrical Requirements that are 80” long. Before installing fan, measure up Your new ceiling fan will require a grounded electrical approximately 6 to 9-inches above the ball/ supply line of 120 volts AC, 60 Hz, 15 amp circuit. downrod assembly. -
Page 6: How To Wire Your Ceiling Fan
1. Securely attach the hanger bracket to the outlet How to Wire Your box using the two screws supplied with the outlet Ceiling Fan box. (Figure 2). If you feel that you do not have enough electrical WARNING wiring knowledge or experience, have your fan installed by a licensed electrician. -
Page 7: Using Your Ceiling Fan
3. Screw the two 1-1/4” threaded studs (provided) into Using Your Ceiling Fan the tapped holes in the hanger bracket. 1. Restore electrical power to the outlet box by turning 4. Lift the ceiling cover up to the threaded studs and the electricity on at the main fuse box. -
Page 8: Trouble Shooting
WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN. Trouble Shooting TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fan will not start. 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or circuit breakers. -
Page 9: Repair Parts
Repair Parts WARNING THE USE OF ANY OTHER CONTROL NOT SPECIFI- CALLY APPROVED FOR THIS FAN COULD RESULT IN FIRE, SHOCK, AND PERSONAL INJURY. WARNING THIS PRODUCT IS DESIGNED TO USE ONLY THOSE PARTS SUPPLIED WITH THIS PRODUCT AND/OR ANY ACCESSORIES DESIGNATED SPECIFICALLY FOR USE WITH THIS PRODUCT BY EMERSON ELEC- TRIC. - Page 11 NOTES...
-
Page 12: Warranty
LIMITED WARRANTY What The Warranty Covers: This warranty covers the motor and the other components and accessories of your Emerson ceiling fan against all defects in workmanship and materials. You must be the original purchaser or user of the product to be covered. What The Period Of Coverage Is: As it applies to the motor, this warranty will last for the lifetime of your ceiling fan.
