The
Pioneer
EX is an
easy to use detector. The most difficult
aspects of metal detecting have been
automated.
However if you are new to the hobby, we strongly
recommend that you:
1) Adjust the Sensitivity to a low setting in the
event of false signals. The detector powers on a
3/4 sensitivity; increase to full sensitivity after you have
become familiar with the detector.
2) Do not use indoors. This detector is for outdoor use only. Many
household appliances emit electromagnetic energy, which can
interfere with the detector. If conducting an indoor demonstration,
turn the sensitivity down and keep the search coil away from
appliances such as computers, televisions and microwave ovens.
If your detector beeps erratically, turn off appliances and lights.
Also keep the search coil away from objects containing metal, such as
floors and walls.
3) Read this manual. Most importantly, review the Quick-Start Demo
(p.6) and Basic Operation (p. 8-12).
4) Use 9-volt ALKALINE batteries only.
Do not use Heavy Duty or ordinary Zinc-carbon Batteries.
OWNER'S MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Bounty Hunter PIONEER EX

Summary of Contents for Bounty Hunter PIONEER EX

  • Page 1 OWNER’S MANUAL Pioneer EX is an easy to use detector. The most difficult aspects of metal detecting have been automated. However if you are new to the hobby, we strongly recommend that you: 1) Adjust the Sensitivity to a low setting in the event of false signals.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Terminology ......3 Assembly ......4 Batteries .

  • Page 3: Terminology

    TERMINOLOGY The following terms are used throughout the manual, and are standard terminology among detectorists. ELIMINATION Reference to a metal being "eliminated" means that the detector will not emit a tone, nor light up an indicator, when a specified object passes through the coil’s detection field.

  • Page 4: Assembly

    ASSEMBLY Assembly is easy and requires no tools. Position the lower stem (the straight tube) with the silver button toward the back. Using the bolt and knurled knob, attach the search coil to the plastic extension protruding from the lower stem. Press the button on the upper end of the lower stem,...

  • Page 5: Batteries

    BATTERIES IMPORTANT: Always use ALKALINE batteries only. Do not use heavy duty batteries. Always remove the batteries for prolonged storage. CHECK THE BATTERIES if your detector exhibits any of the following symptoms: The unit does not turn on. Low speaker volume. Unit beeps continuously or erratically.

  • Page 6: Quick-Start Demo

    Q UICK-START DEMONSTRATION I. Supplies Needed • A Medium-Size Nail • A Quarter • A Nickel • A Zinc Penny (dated after 1982) II. Position the Detector a. Place the detector on a table, with the search coil hanging over the edge. (or better, have a friend hold the detector, with the coil off the ground)
  • Page 7 Q UICK-START DEMONSTRATION (continued) V. Press the TARGET REJECT touchpad a. An “X” will appear under the IRON segment. b. The “X” tell us that Iron has been eliminated from detection. VI. Wave the Nail over the Search Coil a. The Nail will not be detected. b.

  • Page 8: Basic Operation

    BASIC OPERATION POWERING UP Press the ON touch pad. All display indicators will illuminate momentarily The inverted-pyramid depth-selection indicator on the right of the display will stay illuminated. UNDERSTANDING THE DISPLAY DEPTH SELECT The detector default to 3/4 sensitivity, indicated by two illuminated segments.
  • Page 9 BASIC OPERATION continued will begin to beep erratically and operate unreliably if continuing use with discharged batteries. To save on batteries, check each battery individually, as the two batteries can discharge at different rates. When LOW BATTERY illuminates, it is possible that only one of the batteries requires replacement.
  • Page 10 BASIC OPERATION continued Commonly-found object are classified into the four categories as follows: IRON ------------------------------------------------ Ferrous objects Metals composed mostly or entirely of iron Most very small metals objects Small foil pieces; small gold pieces. AL ZN ------------------------------------------------ Post-1982 pennies (are made of zinc, some zinc pennies will register as coins within 1”...

  • Page 11: The Display

    BASIC OPERATION continued OPERATING CONTROLS The Pioneer EX is the most automated, easy-to-operate, professional metal detector ever designed. It is designed for those who are new to the hobby providing maximum basic target discrimination, while requiring minimal operator adjustment. DEPTH SELECT...

  • Page 12: Environmental Conditions

    If you receive constant false signals, reduce the sensitivity or move to another area. SAND: Dry beach sands are no problem for the Pioneer EX. if the sand is damp with saltwater, however, follow the precautions outlined under saltwater above.

  • Page 13: Audio Target Identification

    AUDIO TARGET IDENTIFICATION While the LCD (Liquid Crystal Display) is very accurate in identifying buried objects, the user in the field does not always maintain the display screen in his field of vision. Therefore, we have incorporated an audio feedback mechanism to alert the user to the nature of buried objects. This audio feedback system first alerts the user to the presence and classification of objects, whose nature and location can be confirmed using the LCD display.

  • Page 14: Depth Select (Sensitivity Adjustment)

    SEVERE GROUND CONDITIONS A secondary use for the Sensitivity Control is to reduce false detection signals caused by severe ground conditions. While your Pioneer EX contains circuitry to eliminate the signals caused by most naturally occurring ground minerals, 100% of all ground conditions cannot be anticipated.

  • Page 15: In The Field Techniques

    IN THE FIELD TECHNIQUES PINPOINTING COIL MOVEMENT Accurate pinpointing takes practice When swinging the coil, be and is best accomplished by careful to keep it level with the “X-ing” the target area. ground about 1/2 inch from the surface. Never swing the coil like a pendulum.
  • Page 16 IN THE FIELD TECHNIQUES (continued) Swing the search coil slowly, respond with a repeatable tone. overlapping each sweep as you If the signal does not repeat move forward. It is important after sweeping the coil directly to sweep the coil at a consistent over the suspected target a few speed over the ground as you times, it is more than likely...

  • Page 17: In The Field Techniques

    To make detector’s response. searching easier in very trashy areas, consider purchasing the You may encounter some false Bounty Hunter 4-inch Search signals as you proceed. False Coil. The 4-inch coil’s narrower signals occur when the detector detection field...

  • Page 18: Trouble Shooting

    TROUBLE SHOOTING TROUBLE SHOOTING GUIDE SYMPTOM CAUSE SOLUTION Detector chatters • Using detector • Use detector or beeps erratically indoors outdoors only • Using detector near • Move away power lines from power lines • Using 2 detectors in • Keep 2 detectors close proximity at least 20’...

  • Page 19: Metal Detecting Applications

    METAL DETECTING APPLICATIONS COIN SHOOTING: The most popular metal detecting activity. Find coins where people congregate frequently. Many detectorists revisit the same areas again and again to find a never-ending treasure trove as people continue to lose valuables every day. Parks, fairgrounds, and play ares are good choices.

  • Page 20: Treasure Hunter's Code Of Ethics

    Copyright© 2003 by First Texas Products, L.P. All rights reserved, including the right to reproduce this book, or parts thereof, in any form. Published by First Texas Products, L.P. Bounty Hunter ® is a registered trademark of First Texas Products, L.P. www.detecting.com First Texas Products, LP...
