Your Pioneer 202 is an advanced technology metal detector which incorporates
patented microprocessor-controlled technology, designed for a variety of
applications including coinshooting, relic hunting, and general purpose detecting.
The Pioneer 202 is a motion detector; movement over an object is required in
order for the machine to detect the object and emit a tone. Alternatively, you can
sweep a metal object over a motionless searchcoil.
Before using your Pioneer 202, it is important to read these instructions. This
manual's description of detection concepts and types of metals is necessary to
avoid frustration if you are new to the hobby of metal detecting.
THIS METAL DETECTOR HAS TWO TYPES OF OPERATING MODES:
1. ALL METAL DETECTION
All metals will be detected.
2. DISCRIMINATE, NOTCH, and AUTO NOTCH modes
In any of these three detection modes, the detector will emit different
tones, depending upon the type of metal present. The characteristics are
adjustable. Depending on the detector control settings, some metals will
also be eliminated from detection.
DISCRIMINATE:
DISC/NOTCH knob.
NOTCH:
Provides an adjustable rejection "window" to eliminate undesirable
metals from detection. Move the rejection "window" with the
DISC/NOTCH knob.
AUTO NOTCH:
eliminating most pull-tabs and trash items from detection.
CAUTION:
• Do not test the detector by placing coins or metal objects on the floor.
Most floors contain metal, which will cause interference.
• Use 9-VOLT ALKALINE batteries only.
DO NOT USE INDOORS. LIGHTS AND HOUSEHOLD APPLIANCES EMIT
ELECTROMAGNETIC FIELDS WHICH INTERFERE WITH THE DETECTOR'S OPERATION
OWNER'S MANUAL
Eliminates iron and trash items with the use of the
Provides a pre-set rejection "window", automatically
Advertisement
Related Manuals for Bounty Hunter P202
Summary of Contents for Bounty Hunter P202
- Page 1 OWNER’S MANUAL Your Pioneer 202 is an advanced technology metal detector which incorporates patented microprocessor-controlled technology, designed for a variety of applications including coinshooting, relic hunting, and general purpose detecting. The Pioneer 202 is a motion detector; movement over an object is required in order for the machine to detect the object and emit a tone.
- Page 2 ACCESSORIES ....... .BACK COVER The BOUNTY HUNTER PIONEER series of metal detectors is not associated or connected in any way with Pioneer Corporation or its PIONEER brand audio and video products or other products.
- Page 3 TERMINOLOGY The following terms are used throughout the manual, and are standard terminology among detectorists. ELIMINATION Reference to a metal being "eliminated" means that the detector will not emit a tone, nor light up an LCD indicator, when a specified object passes through the coil’s detection field.
- Page 4 ASSEMBLY Adjusting the Arm Rest The arm rest may be moved forward backwards removing the single screw and nut, and then repositioning the 2-piece arm rest. Users with shorter arms may find the arm rest more comfortable in the forward position. In order to move the arm rest backwards, plastic...
- Page 5 ASSEMBLY Assembly is easy and requires no tools. Position detector upright. LOCKING Rotate LOCKING COLLAR INTERNAL COLLAR fully in a counter CAM LOCK clockwise direction. SILVER BUTTON Insert your finger inside the MIDDLE STEM tube and make sure the INTERNAL CAM LOCK is S-ROD flush with the inside of the tube.
- Page 6 BATTERIES IMPORTANT: Always use ALKALINE batteries only. Do not use heavy duty batteries. Always remove the batteries for prolonged storage. CHECK THE BATTERIES if your detector exhibits any of the following symptoms: The unit does not turn on. Low speaker volume. Unit beeps continuously or erratically.
- Page 7 PIONEER 202 DEMONSTRATION Here is a quick way to demonstrate the basic features of your PIONEER 202. I. Supplies Needed • A quarter (25¢) • A penny (1¢) • A dime (10¢) • A nickel (5¢) • Small piece of aluminum foil •...
- Page 8 BASIC OPERATION TURNING ON YOUR DETECTOR Turn the left knob (SENSITIVITY) to the right. As the knob clicks to the "On" position, the detector sounds three beeps, the LCD arrows appear momentarily, and the unit pre-sets to the DISC/ALL METAL mode of operation. SET THE MODE 1.
- Page 9 LCD TARGET DISPLAY READING THE DISPLAY IRON/FOIL: All sizes of iron and aluminum objects will register on the The Liquid Crystal Display (LCD) shows far-left side of the scale. This could the PROBABLE identification of the indicate a worthless item such as a nail, targeted metal, as well as the PROBABLE or a more valuable historic iron relic.
- Page 10 BATTERY & DEPTH INDICATORS The LOW BATT indicator will flash as display. Repeated indication at the the unit is powered on. If the indicator same depth level indicates an accurate comes on and stays on, replace the target detector. If the depth indication batteries.
- Page 11 MODES OF OPERATION tones, depending on the type of metal detected. As you turn the Disc Knob clockwise, you will progressively “discriminate out,” or eliminate from detection, different types of metals. Refer to the illustration below as a ALL METAL TOUCHPAD reference for the levels required to ALL METAL MODE: discriminate out different objects.
- Page 12 MODES OF OPERATION NOTCH then gives the user a variable customized hunt. rejection window. In this mode, you can eliminate items in the middle of the metallic spectrum, but still detect items to the left of the scale, as follows: SELECTIVELY “NOTCH OUT”...
- Page 13 AUDIO TARGET ID Depending on the operating mode PULL TABS: and Disc/Notch control setting, the Pull tabs are the most bothersome Pioneer 202 emits three distinct tones trash items for detectorist. Most will which classify metal objects into induce a medium tone. Most will be categories.
- Page 14 IN THE FIELD TECHNIQUES PINPOINTING COIL MOVEMENT Accurate pinpointing takes practice When swinging the coil, be and is best accomplished by careful to keep it level with the “X-ing” the target area. ground about one inch from the surface. Never swing the coil like 1.
- Page 15 IN THE FIELD TECHNIQUES After selecting your operating mode, objects. These signals are easily swing the searchcoil gently side-to- recognized by their often broken or side, slightly overlapping each sweep non-repeatable nature. as you move forward. Make sure you The Pioneer 202 is a very sensitive keep your searchcoil approximately 1 and deep-seeking detector.
- Page 16 METAL DETECTING APPLICATIONS COINSHOOTING: The most popular metal detecting application. When coinshooting, you want to discriminate out pull tabs, screw caps, and iron objects. Beware that highly oxidized steel may also be detected. Control settings required. 1) Press DISC/ALL METAL touch pad. 2) Turn the Disc/Notch Knob to the 3:00 position.
- Page 17 TROUBLESHOOTING TROUBLE SHOOTING GUIDE SYMPTOM CAUSE SOLUTION Detector chatters • Using detector • Use detector or beeps erratically indoors outdoors only • Using detector near • Move away power lines from power lines • Using 2 detectors in • Keep 2 detectors close proximity at least 30’...
- Page 18 CARE AND MAINTENANCE Your Pioneer 202 Metal Detector is an example of superior design and craftsmanship. The following suggestions will help you care for your metal detector so you can enjoy it for years to come. Handle the metal detector carefully. Dropping it can damage circuit boards and cases.
- Page 19 Bounty Hunter® is a registered trademark of First Texas Products, L.L.C. The BOUNTY HUNTER PIONEER series of metal detectors is not associated or connected in any way with Pioneer Corporation or its PIONEER brand audio and video products or other products.
- Page 20 Pouch & Digger Combo Pouch with 2 large pockets & 9” heavy duty digging tool. TP-KIT-W Bounty Hunter Stereo Headphones Use with Bounty Hunter metal detectors. Lightweight and adjustable with true stereo sound, adjustable volume, 1/8 jack with 1/4 adaptor, 4’ cable. HEAD-W Pin Pointer Pinpoints the exact location of buried metal objects.
