The
Pioneer
EX is an
easy to use detector. The most difficult
aspects of metal detecting have been
automated.
However if you are new to the hobby, we strongly
recommend that you:
1) Adjust the Sensitivity to a low setting in the
event of false signals. The detector powers on a
3/4 sensitivity; increase to full sensitivity after you have
become familiar with the detector.
2) Do not use indoors. This detector is for outdoor use only. Many
household appliances emit electromagnetic energy, which can
interfere with the detector. If conducting an indoor demonstration,
turn the sensitivity down and keep the searchcoil away from
appliances such as computers, televisions and microwave ovens.
If your detector beeps erratically, turn off appliances and lights.
Also keep the searchcoil away from objects containing metal, such as
floors and walls.
3) Read this manual. Most importantly, review the Quick-Start Demo
(p.6) and Basic Operation (p. 8-10).
4) Use 9-volt ALKALINE batteries only.
Do not use Heavy Duty or ordinary Zinc-carbon Batteries.
OWNER'S MANUAL
Advertisement
Table of Contents
Related Manuals for Bounty Hunter Pioneer EX
Summary of Contents for Bounty Hunter Pioneer EX
- Page 1 OWNER’S MANUAL Pioneer EX is an easy to use detector. The most difficult aspects of metal detecting have been automated. However if you are new to the hobby, we strongly recommend that you: 1) Adjust the Sensitivity to a low setting in the event of false signals.
-
Page 2: Table Of Contents
Accessories .....Back Cover The BOUNTY HUNTER PIONEER series of metal detectors is not associated or connected in any way with Pioneer Corporation or its... -
Page 3: Terminology
TERMINOLOGY The following terms are used throughout the manual, and are standard terminology among detectorists. ELIMINATION Reference to a metal being "eliminated" means that the detector will not emit a tone, nor light up an indicator, when a specified object passes through the coil’s detection field. -
Page 4: Assembly
ASSEMBLY Assembly is easy and requires no tools. Loosen both Locking Collars by rotating 100% counterclockwise. Insert the Upper Stem into the S-Rod and click Silver Button into hole. Position the Lower Stem with the Silver Button toward the back. Using the Bolt and Knurled Knob, attach the Searchcoil to the Lower Stem. -
Page 5: Batteries
You may notice erratic beeping if using with LOW BATTERY illuminated. IMPORTANT: Your Pioneer EX metal detector requires two 9-Volt ALKALINE batteries. Follow these steps to install the batteries. Carefully remove the battery compartment door by pressing the release clip on the right side of the door. -
Page 6: Quick-Start Demo
Q UICK-START DEMONSTRATION I. Supplies Needed • A Medium-Size Nail • A Quarter • A Nickel • A Zinc Penny (dated after 1982) II. Position the Detector a. Place the detector on a table, with the searchcoil hanging over the edge. (or better, have a friend hold the detector, with the coil off the ground) - Page 7 Q UICK-START DEMONSTRATION (continued) V. Press the TARGET REJECT touchpad a. An “X” will appear under the IRON segment. b. The “X” tell us that Iron has been eliminated from detection. VI. Wave the Nail over the Searchcoil a. The Nail will not be detected. b.
-
Page 8: Basic Operation
BASIC OPERATION POWERING UP Press the ON touch pad. All display indicators will illuminate momentarily The inverted-pyramid depth-selection indicator on the right of the display will stay illuminated. UNDERSTANDING THE DISPLAY DEPTH SELECT The detector default to 3/4 sensitivity, indicated by two illuminated segments. - Page 9 BASIC OPERATION (continued) indication. The detector will begin to beep erratically and operate unreliably if continuing use with discharged batteries. To save on batteries, check each battery individually, as the two batteries can discharge at different rates. When LOW BATTERY illuminates, it is possible that only one of the batteries requires replacement.
- Page 10 BASIC OPERATION (continued) Commonly found objects are classified into the four categories as follows: IRON ------------------------------------------------ Ferrous objects Metals composed mostly or entirely of iron Most very small metals objects Small foil pieces; small gold pieces. AL ZN ------------------------------------------------ Post-1982 pennies (are made of zinc, some zinc pennies will register as coins within 1”...
-
Page 11: The Display
OPERATING CONTROLS The Pioneer EX is the most automated, easy-to-operate, professional metal detector ever designed. It is designed for those who are new to the hobby providing maximum basic target discrimination, while requiring minimal operator adjustment. DEPTH SELECT With each press of the DEPTH... -
Page 12: Environmental Conditions
If you receive constant false signals, reduce the sensitivity or move to another area. SAND: Dry beach sands are no problem for the Pioneer EX. if the sand is damp with saltwater, however, follow the precautions outlined under saltwater above. -
Page 13: Audio Target-Identification
AUDIO TARGET IDENTIFICATION While the LCD (Liquid Crystal Display) is very accurate in identifying buried objects, the user in the field does not always maintain the display screen in his field of vision. Therefore, we have incorporated an audio feedback mechanism to alert the user to the nature of buried objects. This audio feedback system first alerts the user to the presence and classification of objects, whose nature and location can be confirmed using the LCD display. -
Page 14: Depth Select (Sensitivity Adjustment)
SEVERE GROUND CONDITIONS A secondary use for the Sensitivity Control is to reduce false detection signals caused by severe ground conditions. While your Pioneer EX contains circuitry to eliminate the signals caused by most naturally occurring ground minerals, 100% of all ground conditions cannot be anticipated. -
Page 15: In The Field Techniques
IN THE FIELD TECHNIQUES PINPOINTING COIL MOVEMENT Accurate pinpointing takes practice When swinging the coil, be and is best accomplished by careful to keep it level with the “X-ing” the target area. ground about 1/2 inch from the surface. Never swing the coil like a pendulum. - Page 16 IN THE FIELD TECHNIQUES (continued) Swing searchcoil slowly, practice in the field, you will learn to overlapping each sweep as you move better discern the nature of buried forward. It is important to sweep the objects by the nature of the detector’s coil at a consistent speed over the response.
-
Page 17: Metal Detecting Applications
METAL DETECTING APPLICATIONS COIN SHOOTING: The most popular metal detecting activity. Find coins where people congregate frequently. Many detectorists revisit the same areas again and again to find a never-ending treasure trove as people continue to lose valuables every day. Parks, fairgrounds, and play areas are good choices. -
Page 18: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING GUIDE SYMPTOM CAUSE SOLUTION Detector chatters • Using detector • Use detector or beeps erratically indoors outdoors only • Using detector near • Move away power lines from power lines • Using 2 detectors in • Keep 2 detectors close proximity at least 30’... -
Page 19: Treasure Hunter's Code Of Ethics
Copyright© 2011 by First Texas Products, L.L.C. All rights reserved, including the right to reproduce this book, or parts thereof, in any form. Published by First Texas Products, L.L.C. Bounty Hunter ® is a registered trademark of First Texas Products, L.L.C. www.detecting.com MADE IN USA... -
Page 20: Accessories
Pouch & Digger Combo Pouch with 2 large pockets & 9” heavy duty digging tool. TP-KIT-W Stereo Headphones Use with Bounty Hunter metal detectors. Lightweight and adjustable with true stereo sound, adjustable volume, 1/8” jack with 1/4” adaptor, 4’ cable. HEAD-W Pinpointer Pinpoints the exact location of buried metal objects.
