Page 1 " Canada www.toyota.ca 2006 TOYOTA MOTOR CORPORATION All rights reserved. This material may not be reproduced or copied, in whole or in part, without the written permission of Toyota Motor Corporation. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 2: Important Information About This Manual
You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your vehicle and its equipment. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 3: Occupant Restraint Systems
None of these systems, either individ- Toyota encourages you and your family to take the time to ually or together, can ensure that there is no injury in the read Section 1−3 of this Owner’s Manual carefully.
Page 4: Event Data Recorder
Toyota recommends you to read the provisions in Section " Engine speed 1−3 carefully and refer to them as needed during your time "...
Page 5 (VSC) system, its Electronic Control Unit (ECU) may con- Toyota will not disclose the data recorded in an EDR to a tain another EDR. There are a variety of driving situations which include activating the VSC under which the VSC third party except when: EDR will record certain information.
Page 6 05 11.29 New vehicle warranty Important health and safety information about your Toyota Your new vehicle is covered by the following Toyota limited warranties: CAUTION " New vehicle warranty " Emission control systems warranty " WARNING: Engine exhaust, some of its constitu- "...
Page 7 Toyota Toyota A wide variety of non−genuine spare parts and accessories The spark ignition system in your Toyota meets all require- for Toyota vehicles are currently available in the market. ments of the Canadian Interference−Causing Equipment You should know that Toyota does not warrant these prod- Standard.
Page 8 Toyota dealer for precau- an accident. Check the tire inflation pressure peri- tionary measures or special instructions regarding installa- odically and be sure to keep the load limits given tion.
Page 9: Driving Tips
In addition, this vehicle shop or by your Toyota dealer before you dispose of your has a higher ground clearance and center of gravity than vehicle.
Page 10 So you may hear sound coming from under- neath the luggage compartment for several minutes. It does not indicate a malfunction. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 11 The Toyota authorized Repair Manual is packed with literally everything you need to know to perform your own maintenance in virtually every area of your new vehicle. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 12 The repair manual outlines exactly what main- The repair manual for FJ CRUISER may be pur- tenance is required and clearly explains how to do the chased from any Toyota dealer or the Material work yourself step−by−step.
Page 13 05 11.29 WE REALLY CARE ABOUT YOU PLEASE BUCKLE UP Toyota has made a special effort to encourage use of seat belts. Toyota belts are: " Comfortable " Easy to use " Convenient We encourage you to use your belts every time you drive.
Page 14: Table Of Contents
ILSAC multigrade engine oil is recommended. See page 293 for detailed information. Tire information: See pages 297 through 304. Tire inflation pressure: See page 320. Publication No. OM35857U Part No. 01999-35857 Printed in Japan 01−0601−00 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 15 ........Indicator symbols on the instrument panel ..... . . 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 16: Instrument Panel Overview
9. Power window switches 10. Automatic transmission selector lever TS11001a 11. Cup holders 12. Parking brake lever 13. Four−wheel drive control lever 14. Tilt steering lock release lever 15. Window lock switch 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 17 9. Power window switches 10. Four−wheel drive control lever 11. Cup holders TS11002a 12. Parking brake lever 13. Manual transmission gear shift lever 14. Tilt steering lock release lever 15. Window lock switch 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 18 16. AUX adapter 17. Intuitive parking assist switch 18. Power outlet main switch 19. “AUTO LSD” switch 20. Ignition switch 21. Cruise control switch 22. Hood lock release lever 23. Clutch start cancel switch 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 19 05 11.29 "Steering switches TS11004b 1. Volume control switch 2. “ ” switch 3. “MODE” switch 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 20: Instrument Cluster Overview
2. Service reminder indicators and 5. Shift position indicator lights 8. Trip meter reset knob indicator lights (automatic transmission only) 9. Odometer and two trip meters 3. Speedometer 6. Engine coolant temperature gauge 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 21 (four−wheel drive models) Engine oil replacement reminder light Unengaged “Park” warning light (for vehicles sold in U.S.A.) (four−wheel drive models) Front passenger occupant classification indicator light Anti−lock brake system warning light 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 22 : If this light flashes, see “Cruise control” on page 135 in Vehicle stability control system off indicator light Section 1−7. Four−wheel drive indicator light (four−wheel drive models) Slip indicator light “AUTO LSD” indicator light (two−wheel drive models) 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 23 ..........2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 24: Keys
If you should lose your keys or if you need additional keys, duplicates can be made by a Toyota dealer using the key number. We recommend writing down the key num- ber and storing it in a safe place. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 25 " Avoid putting it in water. You can use up to 4 wireless remote con- trol transmitters for the same vehicle. TS12007a Contact your Toyota dealer for detailed information. Unlocking operation 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 26 Pushing the switch twice within 3 seconds unlocks all the side doors and back door simultaneously. Each time the “UNLOCK” switch is pushed, two beeps will be heard, and the turn signal lights will flash twice. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 27: Fj Cruiser From Jan. '06 Prod. (Om35857U)
The alarm will last for one minute. To stop alarm midway, push any of the switch on the wireless remote control transmitter. You can also stop the alarm by turning the ignition key from the “LOCK” to “ON” position. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 28 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 29: Fj Cruiser From Jan. '06 Prod. (Om35857U)
Dispose of used batteries according above illustration. to the local laws. NOTICE Replace the transmitter battery by follow- Do not bend the terminals. ing these procedures: 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 30: Side Doors
Water may cause unexpected all the side doors and back door simulta- rust. neously. z Do not touch or move any compo- nents inside the transmitter, or it may interfere with proper operation. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 31 To lock: Push the knob forward. To unlock: Pull the knob backward. The front doors can be opened by pulling the inside handles even if the lock knobs are in the locked position. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 32 It also helps pre- vent the doors from being opened un- intentionally. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 33: Access Doors
Keep the hands, fingers and other parts of sure to follow the above instructions. the bodies of all occupants away from the access door. Otherwise, the closing door may cause serious inju- 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 34: Power Windows
It stops working when either front door is opened. The indicator light (“AUTO”) on the switch tells you the switch can be operated. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 35 Use the window lock switch to TS12018 prevent them from making unex- pected use of the switches. " Be sure to remove the ignition key when you leave your vehicle. Passenger’s side 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 36: Back Window
When you close the back window, be careful not to lock your keys in the ve- hicle. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 37: Back Door
11 and paint or let any other foreign matter “Side doors” on page 16.) on them. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 38: Hood
NOTICE To prevent damage to the damper, en- sure that the damper is unlocked be- fore closing the back door. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 39: Fuel Tank Cap
In order to prevent the fuel filler door spraying out of the filler neck if the from being damaged, do not apply ex- cap is suddenly removed. cessive force. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 40 Make sure the cap is installed se- curely to prevent fuel spillage in the event of an accident. " Use only a genuine Toyota fuel tank cap for replacement. It is designed to regulate fuel tank pressure. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 41 ..........2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 42: Seats
Move your seat to the rear as far or a collision. as you can while still reaching the pedals comfortably. Waterproof and water−repellent seats are installed in your vehicle; however, the wa- ter−repellent effect does not last forever. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 43 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 44 To change the height of the seat, pull up or push down the lever. 4. SEATBACK ANGLE ADJUSTING LEVER Lean forward and pull the lever up. Then lean back to the desired angle and release the lever. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 45: Rear Seats
NOTICE seatback. To prevent damage to the seat belt buckles, the seat belt buckles must be stowed before you fold the seat- back. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 46 Each seatback can be folded separately 2. Let the seat belt retract a little. and the seat bottom cushions can be re- moved. See “—Removing rear seat bottom cushions” on page 33. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 47 " be stowed before you remove the rear Make sure to arrange the buckles of seat bottom cushion. the seat belts in their proper posi- tion and be ready to use. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 48 4. Fold the hinge as shown in the il- first and turn the dials with hands to the hinge. lustration. remove them. Each bottom cushion can be removed Turn them counterclockwise to loosen. separately. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 49: Head Restraints
Toyota dealer. Fail- ure to do so may cause the dials to be loosened and the bottom cushions to be removed, which may result in death or serious injury. Rear seats 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 50: Armrest
2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 51 In the event of a frontal collision, more the seat is reclined, the great- er the risk of death or personal in- jury. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 52 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 53 Adjust the shoulder anchor position to your size. To raise: Slide the anchor up. To lower: Push in the lock release button and slide the anchor down. After adjustment make sure the anchor is locked in position. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 54 Remember that the extender pro- vided for you may not be safe when used on a different vehicle, another person, or at a different seating position than the one origi- nally intended. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 55 In this case, the driver’s extender. airbag may not activate correctly, causing death or serious injury in the event of collision. Be sure to wear the seat belt with the seat belt extender. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 56 This helps prevent until the seat belt is fixed, because damage to the vehicle interior and extend- it cannot protect an adult occupant er itself. or your child from death or serious injury. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 57 Con- 5. Load sensor sult your Toyota dealer about any re- pair and modification. 6. Seat belt pretensioner assemblies 7. Front passenger’s seat belt buckle switch 8. Airbag sensor assembly 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 58 The light does not come on when the sole ignition key is turned to the “ON” posi- tion or remains on for more than 6 seconds. " The light comes on while driving. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 59: Srs Driver Airbag And Front Passenger Airbag
The driver airbag system consists of the driver seat’s position sensor etc. The front passenger’s airbag system consists of the front passenger occupant classification sensor etc. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 60 For in- structions and precautions concern- ing the seat belt system, see “Seat belts” on page 36 in this Section. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 61 SRS front airbags and the seat belt pretensioners may not activate together. Always wear your seat belts properly. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 62 2. SRS warning light 3. Front passenger occupant classification indicator light 4. Airbag module for front passenger (airbag and inflator) 5. Front passenger occupant classification 6. Load sensor 7. Front passenger’s seat belt buckle switch 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 63 The front passenger sit as far back while still maintaining control of the ve- as possible from the dashboard. hicle. " All vehicle occupants be properly restrained using the available seat belts. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 64 “Child seat, and always use your seat belt should not hold objects in their restraint” on page 65 in this Sec- properly. arms or on their knees. tion. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 65 SRS z Repairs made on or near the front front airbags operation. fenders, front end structure, con- sole, steering column, steering wheel or dashboard near the front passenger airbag 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 66 The pad section of the steering wheel tion or remains on for more than 6 or dashboard (shaded in the illustra- seconds. tion) is scratched, cracked, or other- " wise damaged. The light comes on while driving. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 67: Srs Side Airbags And Curtain Shield Airbags
The SRS curtain shield airbags may acti- vate even when the side airbags are not activated. Always wear your seat belt properly. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 68 “Child restraint” on page of the vehicle. For instructions and 65 in this Section. precautions concerning seat belt system, see “Seat belts” on page 36 in this Section. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 69 4. Front passenger occupant classification Always wear your seat belts properly. 5. Load sensor 6. Side airbag modules (airbag and inflator) 7. Curtain shield airbag sensors 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 70 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 71 Special care should be taken espe- cially when you have a small child cially when you have a small child cially when you have a small child in the vehicle. in the vehicle. in the vehicle. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 72 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 73 It goes off after about 6 seconds. This sole or front seat dangerously interfere with the SRS means the SRS side airbags and curtain side airbags and curtain shield air- shield airbags are operating properly. bags operation. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 74 The light does not come on when the ignition key is turned to the “ON” posi- tion or remains on for more than 6 seconds. " The light comes on while driving. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 75: Front Passenger Occupant Classification System
" sification system operates and judges Do not apply pressure to the front pas- whether to indicate “ON” or “OFF”. senger seat by resting hands or legs on the seatback. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 76 Contact your Toyota dealer as seat, make sure that none of the above soon as possible. occur. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 77 (See “Child restraint” on page 65 in this Section as for installing the child restraint system.) In the event the front passenger does not wear a seat belt. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 78 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 79: Child Restraint
Holding a child in your arms is not a substitute for a child restraint system. In an acci- dent, child can be crushed against the windshield, or between you and the vehicle’s interior. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 80 It is dangerous if the side airbag and/or curtain shield airbag inflate, and the impact could cause death or serious injury to the child. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 81 This will prevent it from in- juring passengers in the event of a sud- den stop or accident. (B) Convertible seat 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 82 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 83 " If the driver’s seat position does not allow sufficient space for safe installation, install child straint system on the rear right seat. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 84 To hold the infant seat securely, make it is secure. Follow all the installation sure the belt is in the lock mode before instructions provided by its manufac- letting the belt retract. turer. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 85 When the belt is then retracted even slightly, it cannot be extended. To hold the seat securely, make sure the belt is in the lock mode before letting the belt retract. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 86 Otherwise, the front passenger occupant classification system can not detect the presence of the child restraint system and the front pas- senger airbag and side airbag on front passenger seat could deploy. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 87 Otherwise, the child may be rious injury to the child if the rear− killed or seriously injured. facing child restraint system installed on front passenger seat. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 88 " If the driver’s seat position does not allow sufficient space for safe installation, install child straint system on the rear right seat. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 89 To hold the convertible seat securely, it is secure. Follow all the installation make sure the belt is in the lock mode instructions provided by its manufac- before letting the belt retract. turer. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 90 “OFF”, because the front passenger airbag could in- flate with considerable speed and force. Otherwise, the child may be killed or seriously injured. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 91 See “Seat belts” on " Do not insert coins, clips, etc. in page 36 in this Section for details. the buckle as this may prevent your child from properly latching the tab and buckle. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 92 2. To remove the booster seat, press the Follow the procedure below for a child buckle release button and allow the restraint system that requires the use belt to retract. of a top strap. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 93 2. Raise the anchor bracket. seatbacks to attach the top strap. 1. Remove the head restraint. Anchor brackets are installed for each rear seating position. This symbol indicates the locations of the anchor brackets. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 94 Do not use the anchor bracket for any other purpose. For instructions to install the child re- straint system, see “Child restraint” on page 65 in this Section. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 95 CMVSS213 specification can be fixed to these anchorages. In this case, it is not necessary to fix the child restraint system with a seat belt on the Canada only vehicle. Type A 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 96 “—Using den braking or a collision. a top strap” on page 78 in this Section.) For installation details, refer to the instruc- tion manual equipped with each product. Canada only Type B 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 97 ..........2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 98 ........2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 99: Headlights And Turn Signals
The lights automatically turn off when the charged, do not leave the lights on driver’s door is opened with the ignition for a long period when the engine is key in the “ACC” or “LOCK” position. not running. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 100: Emergency Flashers
“OFF”. lights) on the instrument panel flash faster than normal, a front or rear turn signal bulb is burned out. See “Replacing light bulbs” on page 309 in Section 7−3. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 101: Instrument Panel Light Control
“DOOR”—Turns the light on when any of the side doors, back door and back win- dow is opened. The light goes off when all the side doors, back door and back window are closed. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 102: Luggage Compartment Light
The light goes off when the wireless remote control transmitter, the all the side doors, back door and back light will come on and remain on for about window are closed. 15 seconds before fading out. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 103: Windshield Wipers And Washer
(position 1). Twist the band upward to increase the time be- The following adjustments can be made in tween sweeps, and downward to decrease this system. For details, contact your Toyota dealer. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 104: Back Window Wiper And Washer
The back window wip- object. The nozzle will be damaged. er operates while the washer squirts. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 105: Back Window Defogger
An indicator light will illuminate to indicate the defogger is operating. Push the switch once again to turn the defoggers off. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 106 ....... . Service reminder indicators and warning buzzers ....2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 107: Fuel Gauge
Driving up a long hill on a hot day. fuel level warning light comes on, fill the " fuel tank as soon as possible. Reducing speed or stopping after high speed driving. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 108: Voltmeter
Remember, in most cases the slower the engine speed, the greater However, it is normal for the needle to the fuel economy. drop below the normal range during en- gine starting. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 109 You can use one trip meter to calculate the fuel economy and the other to measure the distance on each trip. All trip meter data is cancelled if the elec- trical power source is disconnected. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 110 05 11.29 Service reminder indicators and warning buzzers If the indicator or buzzer comes on... Do this. If parking brake is off, stop immediately and contact Toyota dealer. (indicator and buzzer) Fasten driver’s seat belt. (indicator and buzzer) Fasten front passenger’s seat belt.
Page 111 If the indicator or buzzer comes on... Do this. Replace engine oil. Take vehicle to Toyota dealer. If brake system warning light is also on, stop immediately and contact Toyota dealer. Take vehicle to Toyota dealer. Close all side doors, back door and back window.
Page 112 05 11.29 If the indicator or buzzer comes on... Do this. Key reminder buzzer Remove key. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 113 This is a pump pulsating and your stopping distance will be- sound of the brake system, and it is come longer. Depress brake not a malfunction. pedal firmly and bring the vehicle to an immediate stop. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 114: Odometer And Two Trip Meters
10 seconds or the buzzer to sound. ignition key is turned to the “OFF” position. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 115: If A Service Reminder Indicator Or Warning Buzzer Comes On
It may ruin the engine. operated for more than 10 seconds or the ignition key is turned to the “OFF” position. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 116 " There is a problem somewhere in the engine, emission control system, elec- tronic throttle control system, automatic transmission electrical system or warn- ing light system itself. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 117 Thereafter, if either of the systems malfunctions, the light comes on again. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 118 It is normal if they vehicle will become extremely unsta- (four−wheel drive models with rear dif- go out after a few seconds. ble during braking. ferential lock) " “AUTO LSD” system (two−wheel drive models) 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 119 " The light does not come on when the ignition key is turned to the “ON” posi- tion or remains on for more than 6 seconds. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 120 “ABS” warning light " “VSC TRAC” warning light " “AUTO LSD” indicator light (two−wheel drive models) " “VSC OFF” indicator light (four−wheel drive models, and vehicles with rear differential lock) " Slip indicator light 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 121 05 11.29 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 122 05 11.29 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 123 Any object lock release lever. seen in a convex mirror will look smaller and farther away than when seen in a flat mirror. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 124 Push the switch to “L” (left) or “R” (right). 2. Control switch—To move the mirror Push the switch in the desired direc- tion. Mirrors can be adjusted when the key is in the “ACC” or “ON” position. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 125 Night driving—Lever at position 2 before driving. Remember that by reducing glare you also lose some rear view clarity. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 126 05 11.29 Vanity mirror TS14007 To use the vanity mirror, swing down the sun visor. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 127 ........2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 128: Ignition Switch
Never remove the key when the ve- door, a buzzer will remind you to remove hicle is moving, as this will lock the the key. steering wheel and result in loss of steering control. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 129: Automatic Transmission
4: Engine braking (shifting into overdrive not possible) 3, 2: Stronger engine braking L: Maximum engine braking With the brake pedal depressed (The ignition switch must be in “ON” position.) Shift normally 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 130 “D” position. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 131 140 km/h (87 mph) Two−wheel drive models strong engine braking as described pre- Four−wheel drive models 41 km/h (25 mph) viously. Four−wheel drive control lever at “H2” and “H4” 140 km/h (87 mph) 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 132 “P” posi- “2” ..38 km/h (24 mph) tion. “L” ..22 km/h (14 mph) 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 133: Manual Transmission
2 to 3 23 (14) when stopped on an uphill grade–use the 3 to 4 40 (25) parking brake. 4 to 5 55 (34) 5 to 6 66 (41) 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 134: Four−Wheel Drive System
“N” (neutral position): Lever at “N” " No power is delivered to the wheels. The When towing a trailer, in order to main- tain engine braking efficiency, do not vehicle must be stopped. use sixth gear. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 135 You need not depress the clutch pedal. If the indicator light does not go off when shift transfer into “H”, drive straight ahead while accelerating or decel- erating, or drive in reverse. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 136 Use this for normal driving on wet, icy or snow−covered roads. This position pro- vides greater traction than two−wheel drive. “N” (neutral position): Lever at “N” No power is delivered to the wheels. The vehicle must be stopped. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 137: Traction Control System
Always drive at an ap- When the traction control system is oper- propriate and cautious speed for the “N” and move the front drive control lever. ating, the following conditions occur: present road conditions. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 138 “ON”, the “VSC buzzer sound changes from intermittent to TRAC” warning light will come on and will continuous. (The continuous buzzer go off after a few seconds. sounds for about 3 seconds.) 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 139: Active Traction Control System
The warning light comes on while driv- speed for the present road condi- control system indicator light will come ing. tions. To cancel the system, push the active traction control switch once again. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 140 When the active traction control system is operating, the following conditions occur: " The system controls the spinning of the 4 wheels. At this time, the slip indica- tor light blinks. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 141: Auto Lsd" System
It is not a malfunction that the “VSC TRAC” warning light may stay on for 60 seconds after the ignition key is turned to “ON”. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 142 If the engine is turned off while the ignition key is turned to “ON”, contact “AUTO LSD” indicator light is on and then your Toyota dealer. restarted, the indicator light will turn off automatically. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 143 TRAC” warning light will come on and will go off after a few seconds. It is not a malfunction that the warning light may stay on for 60 seconds after the ignition key is turned to “ON”. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 144: Vehicle Stability Control System
The slip indicator light comes on for a few seconds when the ignition key is turned to “ON”. If the indicator light does not come on when the ignition is turned on, contact your Toyota dealer. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 145 The transfer is set into “H4” or “L4” " position. (part−time four−wheel drive “AUTO LSD” system models) (two−wheel drive models) " The rear differential is locked. (vehicles with rear differential lock) 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 146: Rear Differential Lock System
" The warning light comes on while driv- lever into “LL” to see if this is sufficient. ing. If this has no effect, additionally use the rear differential lock system. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 147 Wait a few seconds for the system to complete operation. Af- ter the differential is locked, the light will stop blinking and remain on. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 148: Parking Brake
CAUTION release the parking brake. Do not keep driving with the differen- tial lock switch on. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 149: Cruise Control
When the system is turned off, cruising cruise control then downshift the speed must be reset when the cruise con- transmission to use engine braking trol is turned on again. to slow down. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 150 Pulling the lever in the “CANCEL” di- direction. the accelerator pedal. rection and releasing it " Vehicle speed must be above 40 km/h (25 Depressing the brake pedal mph). " Depressing the clutch pedal 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 151: Clutch Start Cancel Switch
If you use the brake pedal, cruise The switch allows the vehicle to be driven control is cancelled. out of difficult situations by cranking the engine with the clutch engaged. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 152 05 11.29 Never use the switch for normal engine starting. Be sure to follow the starting procedure instructed in “How to start the engine” on page 232 in Section 3. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 153 ....... . 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 154: Reference
“PWR·VOL”. To turn on the compact disc player, a compact disc must be loaded in the player. You can turn on the compact disc player by inserting a compact disc. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 155: Satellite Radio Broadcast
XM satellite radio service is also ready; the radio ID can be found by tun- necessary. ing to “channel 000” on the radio. For details, see “Displaying the radio ID” be- low. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 156 In fact, differ- ent kinds of music and vocal programs usually sound better with different mixes of treble and bass. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 157 Then it will play from track pact disc into the slot. 1 of the next disc. The player is intended for use with 12 cm (4.7 in.) discs only. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 158 —Controls and features "Type 1 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 159 FAD: Adjusts the sound balance between the front and rear speakers. The display ranges from F7 to R7. BAL: Adjusts the sound balance between the right and left speakers. The display ranges from L7 to R7. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 160 “ERROR 3”: There is a problem inside the system. Eject the disc or magazine. Set the disc or magazine again. “ERROR 4”: Over−current. your Toyota dealer to inspect. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 161 To turn off the repeat perform all the tracks on all the discs in feature, push this button again. the magazine in random order. To turn off random feature, push this button again. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 162 To stop scanning, push this button again. If the player has scanned all the discs, it will stop scan- ning. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 163 “NO TITLE” will appear on the appears on the display. If you want to display. return to the beginning of the current file, push the “ ” side of the button one time, quickly. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 164 “NO TITLE” will appear on the display. If the entire text data is not displayed, push and hold it until you hear a beep. The rest of the text data will appear. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 165 "Type 2 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 166 The preset but- pushing the button will be ejected first. If ton number will appear on the display. the ejected disc is not removed for a long time, the eject function will be cancelled. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 167 Toyota certified dealer. not broadcasting any programming. Select ranges from F7 to R7. another channel. BAL: Adjusts the sound balance between the right and left speakers. The display ranges from L7 to R7. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 168 Insert a disc. tions, two for each of the preset button. “ERROR 3”: There is a problem inside the system. Eject the disc or magazine. Set the disc or magazine again. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 169 ” will appear on the display and the player will perform all the tracks on all the discs in the magazine in random order. To turn off random feature, push this button again. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 170 To turn off the repeat You can either scan the currently selected feature, push this button again. channel category or scan only the preset channels for that band. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 171 “SCAN” again. After all the folders have push this button again. If the player has been scanned in one pass, normal play scanned all the discs, it will stop scan- resumes. ning. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 172 : Text Information includes, Channel If the signal becomes extremely weak, the Name, (Artist) Name, (Song) Title and radio switches from stereo to mono recep- Category Name. tion. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 173 “ ” or “ ” side of the “TYPE” but- ton to switch to the next or previous cate- gory. : Use of satellite radio requires XM tuner and service. Contact your Toyota dealer for details. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 174: Display Color Change Function
If you want to set that display color for all the function displays, push the knob for 2 seconds. “ALL CHANGE” will ap- pear on the display. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 175 If you want to return to the beginning of the current file, push the “ ” side of the switch once, quickly. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 176: Aux Adapter
To adjust the volume, turn the “PWR·VOL” knob. If you install an audio system other than a genuine audio system, you will not be able to use the AUX adapter. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 177 Static—AM is easily affected by external in a particular installation. loss of reception. sources of electrical noise, such as high tension power lines, lightening, or electri- cal motors. This results in static. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 178 Compact disc players use an invisible Copy−protected CD laser beam which could cause hazard- CD−R (CD−Recordable) radiation exposure directed CD−RW (CD−Re−writable) outside the unit. Be sure to operate CD−ROM the player correctly. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 179 This system is not designed for use of dual discs. Do not use dual discs because it may cause damage to the player or changer. Special shaped discs Low quality discs Z17058 Z17037 Transparent/translucent discs Labeled discs 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 180 MP3/WMA files. Remove discs from the compact disc player when you are not playing them. Store them in their plastic cases away from moisture, heat, and direct sun- light. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 181 VBR (Variable Bit Rate) files, the play time will not be correctly displayed if fast−forward or reverse operations are used. It is not possible to check folders that do not include MP3/WMA files. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 182 Titles and other text information re- Folder 8 corded on a CD−R/CD−RW disc may not be displayed by the MP3/WMA player (in the case of audio data (CD− DA)). : MP3/WMA file 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 183 Disc Digital Audio. It refers to the uncom- English capital letters and half−byte nu- pressed format of regular CDs. merals and the “−” sign, with a file exten- sion of three characters.) 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 184 3. It is an audio compression standard set by a working group (MPEG) of the ISO (International Standards Organization). MP3 is able to compress audio data to about 1/10 the level of a conventional disc. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 185 ........2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 186: Controls
05 11.29 Controls 1. Air intake selector 2. “A/C” button 3. Air flow selector 4. Temperature selector 5. Fan speed selector TS19001 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 187 4. Floor/Windshield—Air flows mainly from the floor vents and windshield vents. Turning the air flow selector to the floor/windshield position turns on the defogging/defrosting function with the purpose of clearing the windshield. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 188 To prevent fogging up of the windshield, the air intake mode may change automati- cally to FRESH depending on the condi- tion of the air conditioning system. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 189: Air Flow Selector Settings
FRESH and the fan speed selector to any setting except “OFF”. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 190 Air conditioning For best results, set controls to: Fan speed—Any setting except “OFF” Temperature—Towards COLD (blue zone) Air intake—FRESH (outside air) Air flow—PANEL Air conditioning—ON 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 191 Turning the air flow selector to the wind- shield or floor/windshield position turns on the defrosting function with the purpose of clearing the windshield. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 192: Side Vents
The air conditioning filter prevents dust from entering the vehicle through the air conditioning vent. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 193 1. Open the glove box, and slide off 2. Push in each side of the glove box nance Guide” or “Owner’s Manual Supple- the damper as shown. to disconnect the claws. ment”.) 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 194 Position the filter case so that the “ UP” mark is pointing up and install it in the vehicle. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 195 ..........2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 196: Accessory Meter
05 11.29 Accessory meter— 1. Compass 2. Outside temperature display 3. Clinometer 4. “SET” button 5. “E/M” button TS10019 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 197 “ON”. initial mode. “SET” button This button is used to calibrate the compass For details, see “—Compass” on page 184 in this Section. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 198: Compass
There may be a case that “−−_C” (“−−_F”) appears momentarily when the ignition is the accessory meter.) " quickly turned to “ON”. It is normal if it The battery has been disconnected. goes out soon. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 199 2 seconds. The zone number ap- pears on the outside temperature display. Select the zone number by pushing the “E/M” button, referring to the following map to determine where the vehicle is. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 200 CAUTION Do not adjust the display while the vehicle is moving. Be sure to adjust the display only when the vehicle is stopped. LS10048 Zone numbers 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 201 2. Push the “SET” button. “−−” will start moving. If you want to cancel the calibration be- fore it is complete, push the “SET” button for about 2 seconds. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 202: Clock
The key must be in the “ACC” or “ON” position. If the electrical power source has been disconnected from the clock, the time dis- play will automatically be set to 1:00 (one o’clock). 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 203: Intuitive Parking Assist
The sensors work only when the transmis- tion. Approximately Continuous sion is in the “R” position. 500 (19.7) If the buzzer keeps sounding intermittently with nothing close to the sensors, have your Toyota dealer check the system. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 204 Therefore, always ob- serve the area around the vehicle and do not rely solely on the sys- tem. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 205: Power Outlet
When a radio antenna or fender pole " When the buzzer keeps sounding inter- is mounted on your vehicle. mittently even though nothing is close " When a towing hitch is mounted on to the sensors. your vehicle. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 206 115 VAC/100W. When the vehicle is stationary, the maximum capacity of the power outlet varies depending on the fol- lowing conditions (a) or (b): 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 207 When the power outlet 2. Check and ensure the following condi- is not in use, make sure that the main tions: switch is off and that the indicator light is not illuminated. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 208 Emit steam, while the windows of play with the power outlet. the cabin are closed. " Be careful not to get any part of your body caught in the power out- let lid. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 209 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 210: Glove Box
Do not leave anything flammable or deformable such as a lighter, glasses, CAUTION etc. inside. To reduce the chance of injury in case of an accident or a sudden stop, always keep glove door closed while driving. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 211: Cup Holders
Type A (instrument panel) TS10018a TS10013 Type B (right side of luggage compart- Type A (vehicles with automatic transmis- ment) sion) 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 212 Type A and B cup holders are equipped with a detachable adapter each holder. When you remove the adapter, a bigger cup can be held in the holder. TS10029 Type C TS10027a Type B (vehicles with manual transmis- sion) 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 213: Bottle Holder
Inappropriately sized shaped objects may be thrown about in the compartment and possibly in- jure people in the vehicle during a sudden braking or an accident. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 214: Tie−Down Hooks
To avoid personal injury, keep the tie− down hooks folded in place on the floor when not in use. NOTICE Do not use the seat anchors instead Cargo net hooks of the tie−down hooks. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 215: Floor Mat
Lock floor mat slips and interferes with the the clips into the holes in the vehicle movement of the pedals during driv- carpet. ing, it may cause an accident. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 216 05 11.29 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 217 ..........2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 218: Off−Road Vehicle Precautions
Avoid high speeds, sudden starts, sharp turns, sudden braking or abrupt maneu- vers, otherwise it may result in loss of control or vehicle rollover due to failure to operate this vehicle cor- rectly. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 219: Tips For Driving During Break−In Period
(or any similar off−road ve- system to function improperly. Also, hicle) can tip over sideways much this can increase maintenance costs. more easily than forward or back- ward. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 220 If mance, reduce vehicle emissions, and im- continue to have unacceptable driveability, prove air quality. try changing gasoline brands. If this does not rectify your problem, then consult your Toyota dealer. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 221: Fuel Pump Shut Off System
FUEL TANK CAPACITY ground, it is the fuel system has been damaged and it is in need of 72 L (19.0 gal., 15.8 Imp. gal.) repair. In this case, do not restart the engine. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 222: Three−Way Catalytic Converters
The exhaust gas is very hot. " Do not idle or park your vehicle over anything that might burn easi- ly such as grass, leaves, paper or rags. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 223: Engine Exhaust Cautions
High tem- vehicle. perature exhaust gases also burn the oil used to lubricate the exhaust valve stems. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 224: Brake System
“ON” position. appear that oil is excessively consumed after driving at high speeds. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 225 " At the end of the anti−lock brake sys- approximately 5 km/h (3 mph). tem activation, the brake pedal may move a little forward. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 226 Compared with vehicles without an anti−lock brake system, your vehicle may require a longer stopping dis- tance in the following cases: " Driving on rough, gravel or snow− Type B covered roads. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 227 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 228: Brake Pad Wear Limit Indicators
The brake assist system becomes opera- replaced when necessary. tive after the vehicle has accelerated to a speed in excess of approximately 10 km/h (6 mph). It stops operating when the vehicle stops. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 229: Rear Step Bumper
Do not allow more than one person to get on the rear step bumper at a time. It is designed for only one person. " Never drive the vehicle with anyone on the rear step bumper. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 230: Theft Prevention Labels
NOTICE The engine number is stamped on the You should not attempt to remove the engine block as shown. theft prevention labels as it may vio- late certain state or federal laws. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 231: Tire Information
6. Radial tires or bias−ply tires—A radial tire has “RADIAL” on the sidewall. A tire not marked with “RADIAL” is a bias−ply tire. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 232 “M+S” is a summer 5. Manufacturer’s optional tire type tire. For details, see “Types of code (3 or 4 letters) tires” on page 228. 6. Manufacturing week 7. Manufacturing year 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 233 4. Tire construction code (R=Radial, 8. Carcass D=Diagonal) 9. Rim lines 5. Wheel diameter (in inches) 10.Bead wires 6. Load index (2 digits or 3 digits) 11. Chafer 7. Speed symbol (alphabet with one letter) 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 234 Quality grades can be found where appli- cable on the tire sidewall between tread shoulder and maximum sec- tion width. For example: Treadwear 200 Traction AA Temperature A 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 235 Excessive speed, underinfla- tion, or excessive loading, either sep- arately or in combination, can cause heat buildup and possible tire failure. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 236 (c) vehicle capacity weight; and (d) production options weight i ht 68 kg (150 lb.) times the number of occupants specified in the second Normal occupant weight column of Table 1 that follows 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 237 Vehicle maximum load on the tire its share of the maximum loaded vehicle weight and dividing by two 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 238 Vehicle normal load, number of Occupant distribution in a normally number of occupants occupants loaded vehicle 2 through 4 2 in front 5 through 10 2 in front, 1 in second seat 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 239: Vehicle Load Limits
Total load capacity means combined pants are within the seating ca- weight of occupants, cargo and lug- pacity, do not exceed the total gage. Tongue load is included when load capacity. trailer towing. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 240: Cargo And Luggage
Keep cargo and luggage low, vehicle. In an accident they as close to the floor as pos- may injure the vehicle occu- sible. pants. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 241 540 kg – 166 kg = 374 kg. cargo and luggage load capacity (1190 lb. – 366 lb. = 824 lb.) of your vehicle. For details about trailer towing, see page 237. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 242: Types Of Tires
For details about total load capacity, conditions, as well as for use all year see “Vehicle load limits” on page 225. round. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 243 " Do not use tire other than the manufacturer’s designated tires, and never mix tires or wheels of the sizes different from the originals. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 244 05 11.29 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 245 ..........How to save fuel and make your vehicle last longer ... . . 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 246: How To Start The Engine
Simply restart it, using the correct proce- the floor until driving off. dure given in normal starting. If the engine will not start... See “If your vehicle will not start” on page 248 in Section 4. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 247: Tips For Driving In Various Conditions
Part−time four−wheel drive models—In the wheels. cold temperatures, noise may occur when driving in two−wheel drive before the transfer is warmed up. Therefore, first drive in four−wheel drive until the transfer is warmed up. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 248: Off−Road Driving Precautions
" State and Local Parks and Recreation Departments " State Motor Vehicle Bureau 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 249 You the differentials, transmission are also risking expensive damage and transfer case, reducing the gear to your vehicle’s suspension and oil’s lubricating qualities. chassis. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 250: Winter Driving Tips
Use a washer fluid containing an anti- (−44_F). freeze solution. NOTICE This product is available at your Toyota dealer and most auto parts stores. Follow Do not use plain water alone. manufacturer’s directions much to mix with water. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 251: Dinghy Towing
Some of the things you might put in the vehicle are tire chains, window scraper, bag of sand or salt, flares, small shovel, jumper cables, etc. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 252 Exceeding the maximum weight rating set by the trailer hitch manufacturer can cause an accident resulting in seri- ous personal injuries. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 253 About 60% of the trailer load should be in the front half of the trailer and the remaining 40% in the rear. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 254 2 threads. The trailer ball shank must be matched to the ball mount hole diameter size. 1 Coupler 2 Trailer ball 3 Ball mount attachment 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 255 For correct safety chain procedures, follow the hitch or trailer manufacturer’s recommenda- tions. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 256 Direct splicing may Make sure the trailer cargo is securely loaded so that it cannot shift. damage your vehicle’s electrical system and cause a malfunction of your lights. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 257 4. Apply the parking brake firmly. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 258: How To Save Fuel And Make Your Vehicle Last Longer
" Accelerate slowly smoothly. trailer combination usually Avoid jackrabbit starts. Get into high creases as the speed increases, ex- gear as quickly as possible. ceeding 72 km/h mph) cause loss of control. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 259 Supplement”.) " Maintain a moderate speed on high- ways. The faster you drive, the greater the fuel consumption. By reducing your speed, you will cut down on fuel con- sumption. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 260 05 11.29 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 261: In Case Of An Emergency
........If you lose your wireless remote control transmitter ... . . 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 262: If Your Vehicle Will Not Start
3. If the engine still will not start, it needs conds at a time. This may overheat shop. adjustment or repair. Call a Toyota the starter and wiring systems. dealer or qualified repair shop. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 263 Then get immediate medical attention. If possible, continue to apply water with a sponge or cloth while en route to the medical office. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 264 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 265: If Your Engine Stalls While Driving
If another attempt is not successful, the battery may be depleted. Have it checked at your Toyota dealer. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 266: If Your Vehicle Overheats
Fill it about half full. For the coolant type, see “Coolant type selection” on page 294 in Section 7−2. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 267: If You Have A Flat Tire
(manual). Block the wheel diag- of or underneath the jack. onally opposite to the one be- " Raise the vehicle only high ing changed if necessary. enough to remove and change the tire. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 268 When storing the tool bag, make sure it is securely held by the tightening strap. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 269 When blocking the wheel, place a flying forward during a collision or wheel block in front of one of the front sudden braking. wheels or behind one of the rear wheels. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 270 Be careful that the wrench does not slip off the nut. Do not remove the nuts yet—just un- screw them about one−half turn. Steel wheel 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 271: Positioning The Jack
Make sure the jack is positioned on a level and solid place. 1. Jack handle end 2. Jack handle extensions JACK POINTS: 3. Jack handle Front—Under the frame side rail Rear—Under the rear axle housing 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 272: Raising
Tighten the square head bolt dle. securely. Otherwise, the exten- sion may come off and it may damage the paint or vehicle body. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 273 Then lift up the wheel and get while driving. at least the top bolt started through its hole. Wiggle the tire and press it back over the other bolts. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 274 Make sure the wrench is securely en- gaged over the nut. Tighten each nut a little at a time in the order shown. Repeat the process until all the nuts are tight. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 275 NOTICE Steel wheel: To prevent damage TS40015 to the wheel ornament, do not attach it to the wheel on the back door. Steel wheel 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 276: If Your Vehicle Becomes Stuck
During the technician repair the flat tire. rocking operation the vehicle may suddenly move forward or backward as it becomes unstuck, causing injury or damage to nearby people or ob- jects. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 277: If Your Vehicle Needs To Be Towed
If your vehicle remains stuck after rocking the vehicle several times, consider other ways such as tow- ing. (b) Using flat bed truck (b) Using flat bed truck Two−wheel drive models Four−wheel drive models 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 278 The wheels and axle on the ground must be in good condition. If they are damaged, use a towing dolly. (b) Using flat bed truck 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 279 (c) Towing with sling type truck (b) Using flat bed truck NOTICE Do not tow with sling type truck, ei- ther from the front or rear. This may cause body damage. TS40021 Rear 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 280 Securely fasten the cable or chain to ground. This may cause serious the towing eyelet provided. damage to the transmission. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 281 Contact your Toyota dealer or a commercial tow truck service for assistance. " Tow the vehicle as straight ahead as possible. " Keep away from the vehicle during towing. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 282: If You Cannot Shift Automatic Transmission Selector Lever
6. Start the engine. For your safety, 2. Pry up the cover with a flathead keep the brake pedal depressed. screwdriver or equivalent. Be sure to have the system checked by your Toyota dealer as soon as possible. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 283: If You Lose Your Wireless Remote Control Transmitter
At the same time, you must bring all of the remaining transmitters to have them registered again as well. You can use the wireless remote control system with the new transmitter. Contact your Toyota dealer for detailed information. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 284 05 11.29 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 285: Corrosion Prevention And Appearance Care
........2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 286 " you should hose off the undercarriage High humidity accelerates corrosion es- at least once a month to minimize cor- pecially when temperatures range just rosion. above the freezing point. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 287 Even if your vent, you may experience trouble with re- garage is heated, a wet vehicle can cor- fueling or rough engine idling. rode if the ventilation is poor. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 288 Toyota through an automatic the paint. object. The nozzle will be damaged. car wash. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 289 NOTICE der the floor carpet (or mat) and Do not use solvent, thinner, gasoline cause a malfunction; and it may or window cleaner on the interior. cause body corrosion. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 290 Remove dirt using a soft cloth dampened warm water then lightly wipe off dirt. with 5% solution of neutral detergent for wool. Then thoroughly wipe off all traces of detergent with a clean damp cloth. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 291 Try to keep your upholstery always clean. z Long exposure to direct sunlight may cause the leather surface to harden and shrink. Keep your ve- hicle in a shaded area, especially in the summer. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 292 05 11.29 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 293 ......Emissions Inspection and Maintenance (I/M) programs ..For scheduled maintenance information, please refer to the “Sched- uled Maintenance Guide” or “Owner’s Manual Supplement”. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 294: Maintenance Requirements
Simple instructions for how to per- or if you prefer, your Toyota dealer will be dating this warranty. See “Owner’s War- form them are presented on page 285 in pleased to do them at a nominal cost.
Page 295: General Maintenance
Make sure there is sufficient fluid in the on a level spot. See page 292 in Section tank. See page 309 in Section 7−3 for 7−2 for additional information. additional information. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 296 Check that it has the specified free play. Be alert for changes in steering condition, such as hard steering or strange noise. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 297: Does Your Vehicle Need Repairing
" Loss of brake effectiveness; spongy feeling brake or clutch pedal; pedal al- most touches floor; vehicle pulls to one side when braking " Engine coolant temperature continually higher than normal 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 298: Emissions Inspection And Maintenance (I/M) Programs
Also, if the malfunction indicator lamp had come on recently due to temporary mal- function such as a loose fuel tank cap, your vehicle may not pass the I/M test. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 299 ..........2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 300: Engine Compartment Overview
2. Power steering fluid reservoir 3. Engine oil level dipstick 4. Engine coolant reservoir 5. Engine oil filler cap 6. Brake fluid reservoir 7. Fuse blocks 8. Battery 9. Condenser 10. Radiator TS71001 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 301: Fuse Locations
05 11.29 Fuse locations Spare fuses TS71003 TS71005 Vehicles with power outlet (115 VAC) only TS71002a TS71004 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 302: Do−It−Yourself Service Precautions
It contains poi- Do not get under your vehicle with serve: sonous and corrosive sulfuric acid. just the body jack supporting it. Al- ways use automotive jack stands or other solid supports. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 303: Parts And Tools
“Toyota Super Long Life Coolant” is a cause engine damage, loss of per- mixture of 50% coolant and 50% deion- formance or radio noise. ized water (for the U.S.A.) or 55% coolant and 45% deionized water (for Canada). 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 304 309 in " Funnel (only for adding fluid) Section 7−3.) CHECKING BATTERY CONDITION Tools: Tools: " Screwdriver " Warm water " Baking soda " Grease " Conventional wrench (for terminal clamp bolts) 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 305 ....... . 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 306: Checking The Engine Oil Level
4. Pull the dipstick out and look at the oil level while holding a rag under the end. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 307 Mark is added to some oil con- tainers to help you select the oil you should use. Outside temperature SAE 5W−30 is the best choice for good fuel economy and good starting in cold weather. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 308: Checking The Engine Coolant Level
“Toyota Genuine vides protection down to about −35_C cock and water pump. (−31_F). Motor Oil” is available, which has been If you can find no leak, have your Toyota specifically tested and approved for all Canada—“Toyota Super Long...
Page 309: Checking The Radiator And Condenser
Please contact your Toyota dealer for lem. further details. If the level is low, add SAE J1703 or FMVSS No.116 DOT 3 brake fluid to the brake reservoir. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 310: Checking Power Steering Fluid
(about room temperature, ately. If you still feel uncomfortable 10_C—30_C or 50_F—85_F) if the engine with your hands or eyes, go to the has not been run for about five hours. doctor. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 311: Checking Tire Inflation Pressure
1.5 Avoid overfilling, or the power steer- km or 1 mile since, you will get ing could be damaged. an accurate cold tire inflation pres- sure reading. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 312 In case of applying too If a tire frequently needs refilling, much air, press the center of the have it checked by your Toyota deal- valve and release the air to adjust. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 313: Checking And Replacing Tires
" Wheel deformation and/or tire shown by the “TWI” or “ ” marks, separation etc., molded on the sidewall of " A greater possibility of tire each tire. damage from road hazards 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 314 Toyota dealer. pressure mentioned on the sidewall of the tire, and as for the Gross Axle Weight Ratings (GAWR), see the Cer- tification Label. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 315: Rotating Tires
See “If you have a flat tire” on page 253 in Section 4 for tire change proce- dure. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 316: Installing Snow Tires And Chains
" Never drive over 120 km/h (75 mph) handling characteristics resulting in with any type of snow tires. loss of control. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 317: Replacing Wheels
Do not exceed 50 km/h (30 mph) or chain manufacturer’s recom- mended speed limit, whichever is lower. " Drive carefully avoiding bumps, holes, and sharp turns, which may cause the vehicle to bounce. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 318: Aluminum Wheel Precautions
If loss of control. damaged, replace immediately. " Four−wheel drive models: wheels different brands, sizes and types, as this cause dangerous handling characteristics resulting in loss of control. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 319 ........2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 320: Checking Battery Condition
Overtightening may damage the cal office. battery case. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 321: Battery Recharging Precautions
NOTICE Toyota dealer. Never recharge the battery while the Clear or Have battery engine is running. Also, be sure all light checked by your accessories are turned off. yellow Toyota dealer. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 322: Checking And Replacing Fuses
See Good Blown hicle for emergencies. page 321 in Section 8 for the functions controlled by each circuit. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 323: Adding Washer Fluid
Hold a bulb only by its plastic or metal case. Do not touch the glass part of a bulb with bare hands. NOTICE Only use a bulb of the listed type. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 324 License plate — lights Interior light — Luggage compart- — ment light A: HB2 halogen B: Single end bulbs C: Wedge base bulbs D: Wedge base bulbs (amber) E: Double end bulbs 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 325 Aiming is not necessary after replacing the bulb. When aiming adjustment is nec- TS73007 essary, contact your Toyota dealer. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 326 You may damage the ve- hicle. flathead screwdriver which a: Back−up light wrapped with a cloth. b: Tail/stop and rear side marker lights c: Rear turn signal light TS73009 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 327 05 11.29 —License plate lights TS73011 Use a Phillips−head screwdriver. TS73012 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 328 05 11.29 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 329 ........... . . 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 330: Dimensions And Weights
Vehicle capacity weight (occupants + luggage) kg (lb.) 540 (1190) Towing capacity (trailer weight + cargo weight) kg (lb.) 2268 (5000) : Unladen vehicle : Two−wheel drive models : Four−wheel drive models 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 331: Service Specifications
“Toyota Genuine Motor Oil” or equivalent Do not use plain water alone. satisfy following grade Please contact your Toyota dealer for viscosity. further details. Oil grade: ILSAC multigrade engine oil Recommended oil viscosity: SAE 5W−30 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 332 Rear mission of your vehicle. Without rear differential lock Please contact your Toyota dealer for fur- 3.0 (3.2, 2.6) ther details. With rear differential lock 2.9 (3.1, 2.6) 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 333 Lithium base chassis grease, NLGI No.2 Power steering fluid type: Automatic transmission fluid DEXRON_II Slide yokes or III Molybdenum−disulfide lithium base chassis grease, NLGI No.2 or lithium base multipurpose grease, NLGI No.2 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 334: Tires
NOTE: For a complete information on tires (e.g. replacing tires or replacing wheels), see “Checking tire inflation pres- sure” through “Aluminum wheel precautions”, pages 297 through 304 in Section 7−2. Wheel nut torque, N·m (kgf·m, ft·lbf): 113 (11.5, 85) 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 335: Fuses
16. DOME 10 A: Interior light, luggage light (high beam) system compartment light, clock, accessory meter, meter and gauge 6. AUX LP 15 A: Driving lamp 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 336 27. RADIO NO.2 20 A: Audio system shift lock system, multiplex communica- 41. ABS MTR 40 A: Anti−lock brake sys- tion system tem, vehicle stability control system, traction control system, active traction control system, “AUTO LSD” system 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 337 45. AC 115V 80 A: Power outlet Fuses (type C) 46. ALT “AM1”, “AC 115V”, “DEFOG”, “DEFOG NO.2”, “STOP”, “OBD”, “J/B”, “TOWING TAIL”, “AUX LP” and “OFFROAD LP” fuses 47. HEATER 60 A: Air conditioning system 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 338 05 11.29 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 339 Reporting safety defects for U.S. owners Reporting safety defects for U.S. owners ..... . 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)
Page 340 However, NHTSA cannot be- come involved in individual problems be- tween you, your dealer, or Toyota Motor Sales, U.S.A., Inc. 2007 FJ CRUISER from Jan. ’06 Prod. (OM35857U)

This manual is also suitable for:

2007 fj cruiser

Toyota FJ Cruiser User Manual

Table of Contents

1 2 Section −

1 3 Section −

1 5 Section −

1 6 Section −

1 7 Section −

1 8 Section −

1 9 Section −

1 10 Section −

2 Section

3 Section

4 Section

6 Section

7 1 Section −

7 2 Section −

Quick Links

Chapters

Need help?

Questions and answers

Related Manuals for Toyota FJ Cruiser

Summary of Contents for Toyota FJ Cruiser

This manual is also suitable for:

Table of Contents
