TABLE OF CONTENTS
1
Before driving
2
When driving
Interior
3
features
Maintenance
4
and care
When trouble
5
arises
Vehicle
6
specifications
For U.S.
7
owners
Index
Adjusting and operating features such as door locks,
mirrors, and steering column.
Driving, stopping and safe−driving information.
Air conditioning and audio systems, as well as other in−
terior features for a comfortable driving experience.
Cleaning and protecting your vehicle, performing do−it−
yourself maintenance, and maintenance information.
What to do if the vehicle needs to be towed, gets a flat
tire, or is involved in an accident.
Detailed vehicle information.
Reporting safety defects for U.S. owners
Alphabetical listing of information contained in this
manual.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FJ Cruiser and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toyota FJ Cruiser

Summary of Contents for Toyota FJ Cruiser

  • Page 1 TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. Driving, stopping and safe−driving information. When driving Air conditioning and audio systems, as well as other in− Interior terior features for a comfortable driving experience. features Cleaning and protecting your vehicle, performing do−it−...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Index Theft prevention labels (U.S.A.) ....... 70 Before driving 1−7. Safety information ....71 1−1. Key information ....28 Correct driving posture ..71 Keys ........28 SRS airbags ......73 Front passenger occupant 1−2. Opening, closing and classification system ...
  • Page 3 2−4. Using other driving 3−2. Using the audio system ... 191 Audio system types .... 191 systems ......136 Cruise control ...... 136 Using the radio ....194 Intuitive parking assist..139 Using the CD player ... 200 Four−wheel drive system Playing back MP3 and (4WD models with a manual WMA discs .......
  • Page 4 TABLE OF CONTENTS Index Floor mat ......247 When trouble arises Luggage storage box (vehicles without sub woofer) ..248 Luggage compartment 5−1. Essential information ..322 features ......249 If your vehicle needs to be Compass ......252 towed ........ 322 If you think something is wrong ........

  • Page 5: Index

    6−2. Customization ....386 Customizable features ..386 Items to initialize ....388 For U.S. owners Reporting safety defects for U.S. owners ...... 390 Index Abbreviation list ......392 Alphabetical index ..... 394 What to do if....... 402...
  • Page 6 Pictorial index Exterior Outside rear view mirror illumination lights P. 131 Windshield wipers P. 133 Hood P. 273 Outside rear view mirrors P. 59 Headlights P. 131 Front turn signal/parking and front side marker lights P. 121, 131...
  • Page 7 Stop/tail and rear side marker lights P. 131 Fuel filler door P. 64 Access doors P. 36 Side doors P. 33 Tires lRotation P. 287 lReplacement P. 340 lInflation pressure P. 292 Rear turn signal lights P. 121 lInformation P. 375 : If equipped...
  • Page 8 Pictorial index Exterior Glass hatch P. 41 Rear window wiper P. 135 Rear window defogger P. 190 Back door P. 38 License plate lights P. 131 : If equipped...
  • Page 10 Pictorial index Interior Seat belts P. 51 Head restraints P. 49 SRS driver airbag P. 73 Bottle holders P. 233 Auxiliary box P. 234 SRS front passenger airbag P. 73 Rear seats P. 44 Floor mats P. 247 Cup holders P.
  • Page 11 Sun visors P. 235 Interior lights P. 227 Vanity mirror P. 236 SRS curtain shield airbags P. 73 Anti−glare inside rear view mirror P. 58...
  • Page 12 Pictorial index Interior Inside door lock button P. 33 Door lock switch P. 33 Window lock switch P. 62 Power window switches P. 62...
  • Page 13 Automatic transmission Front−wheel drive control Shift lever P. 117 Cup holders lever P. 146 P. 229 Parking brake lever P. 122 Shift lock override Cup holders P. 229 button P. 351 Manual transmission Four−wheel drive control Shift lever P. 119 lever P.
  • Page 14 Pictorial index Instrument panel Headlight switch P. 131 Turn signal lever P. 121 Gauges and meters P. 124 Windshield wipers and washer switch P. 133 Rear window wiper and washer switch P. 135 Accessory meter P. 130 Glove box P. 228 Cruise control switch P.
  • Page 15 Clock P. 237 Emergency flasher switch Audio system P. 191 Air conditioning Security indicator system P. 184 P. 68 Rear window defogger switch P. 190 : If equipped...
  • Page 16 Pictorial index Instrument panel AUTO LSD switch P. 150 RR DIFF LOCK switch P. 152 A−TRAC switch P. 148 SUB WOOFER switch P. 220 Power outlet P. 239 AUX adapter P. 222 Intuitive parking assist switch P. 139 Power outlet main switch P.
  • Page 17 Engine switch P. 114 : If equipped...
  • Page 18 Pictorial index Instrument panel Audio remote control switches P. 224...
  • Page 19 Instrument panel light control dial P. 125 Tilt steering lock release lever P. 57 CLUTCH START CANCEL switch P. 155 Outside rear view mirror switches P. 59 : If equipped...
  • Page 20 Pictorial index Luggage compartment Child restraint anchor brackets P. 93 Tie−down hooks P. 249...
  • Page 21 Shopping bag hooks P. 251 Cargo net hooks P. 250 Jack Tools P. 340 P. 340 Shopping bag hooks P. 251 Cargo net hooks P. 250 Luggage storage P. 248 Power outlet P. 240 : If equipped : Vehicles without sub woofer...
  • Page 22 Accessories, spare parts and modification of your Toyota A wide variety of non−genuine spare parts and accessories for Toyota vehicles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
  • Page 23 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
  • Page 24 CAUTION General precaution regarding children’s safety Never leave children unattended in the vehicle, and never allow children to have or use the key. Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the cigarette lighter, the windows, or other features of the vehicle.
  • Page 25 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.

  • Page 27: 1−1. Key Information

    Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. ( P. 352)
  • Page 28 1−1. Key information NOTICE To prevent key damage Do not expose the keys to electromagnetic materials or attach any mate− rial that blocks electromagnetic waves to the key surface.

  • Page 29: 1−2. Opening, Closing And

    1−2. Opening, closing and locking the doors Wireless remote control (if equipped) The wireless remote control can be used to lock and unlock the vehi− cle from outside the vehicle. Locks all doors Unlocks all doors Sounds alarm (push and hold) 2−step unlocking function When you push the UNLOCK button, the driver ’s door is unlocked.
  • Page 30 When a wireless key (that emits radio waves) is being used nearby When the wireless key has been left near an electrical appliance such as a personal computer Customization that can be configured at Toyota dealer Settings (e.g. wireless remote control system) can be changed. (Customizable features...
  • Page 31 1−2. Opening, closing and locking the doors Certification for wireless remote control For vehicles sold in U.S.A. NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer− ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 32: Side Doors

    1−2. Opening, closing and locking the doors Side doors The vehicle can be locked/unlocke d using the wireless remote con− trol, key or door lock switch. Wireless remote control (if equipped) P. 3 0 Locks all doors Unlocks all doors Turning the key a single time in the driver’s door unlocks the driver’s door,...
  • Page 33 A buzzer sounds if the driver ’s door is opened, while the engine switch is in the ACC or LOCK position to remind you to remove the key. Customization that can be configured at Toyota dealer Settings (e.g. unlocking function using a key) can be changed.
  • Page 34 1−2. Opening, closing and locking the doors CAUTION To prevent an accident Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. Always use a seat belt.

  • Page 35: Access Doors

    1−2. Opening, closing and locking the doors Access doors The access door (rear door) can be opened using the inside handle. Open the front door widely Pull (from the outside) or push (from the inside) the inside handle of the access door.
  • Page 36 1−2. Opening, closing and locking the doors NOTICE When opening or closing the front door and access door The front door and access door could be damaged if they hit each other when being opened or closed.

  • Page 37: Back Door

    1−2. Opening, closing and locking the doors Back door The back door can be locked/unlo cked using a key, wireless remote control or door lock switch. Wireless remote control (if equipped) P. 3 0 Unlocks the back door Locks the back door Opens the back door When you turn the key clock−...
  • Page 38 1−2. Opening, closing and locking the doors Back door fixing function The back door can be held in the following positions: Half open position Open the back door to the half open position. It cannot be held in this posi− tion when being closed.
  • Page 39 1−2. Opening, closing and locking the doors Rear step bumper For rear end protection and eas− ier step−up loading. To get on the rear step bumper, use the shaded area in the illus− tration. CAUTION Caution while driving Observe the following precautions. Failure to do so may result in death or serious personal injury.

  • Page 40: Glass Hatch

    1−2. Opening, closing and locking the doors Glass hatch The glass hatch can be opened using the key. Turn the key clockwise and hold it for about 1 second. Raise Opening the glass hatch The glass hatch opens slightly, after the back door is locked. When the rear window wiper is working, the wiper returns to the original position and stops working.
  • Page 41 1−2. Opening, closing and locking the doors CAUTION Operating the glass hatch Do not open the glass hatch while the vehicle is moving. Caution while driving Keep the back door and glass hatch closed. This not only keeps the luggage from being thrown out but also prevents exhaust gases from entering the vehicle.

  • Page 42: 1−3. Adjustable Components

    1−3. Adjustable components (seats, mirrors, steering wheel) Front seats Seat position adjustment lever Seat cushion angle adjust− ment knob (driver’s side only) Seat height adjustment lever (driver’s side only) Seatback angle adjustment lever Waterproof and water−repellent seats Waterproof and water−repellent seats are installed in your vehicle; however, the water−repellent effect does not last forever.

  • Page 43: Rear Seats

    1−3. Adjustable components (seats, mirrors, steering wheel) Rear seats The seatbacks of the rear seats can be folded down. Stow the seat belt buckles and remove the head restraints. Swing the bottom cushion up by pulling the lock release strap.
  • Page 44 1−3. Adjustable components (seats, mirrors, steering wheel) Push the lock release button and fold down the seatback. Removing rear seat bottom cushions Loosen the bolts with the wrench at first and turn the dials with hands to remove them. Hexagon head bolt Dial...
  • Page 45 1−3. Adjustable components (seats, mirrors, steering wheel) Separate the bottom cushion from the hinge. Fold the hinge as shown in the illustration.
  • Page 46 1−3. Adjustable components (seats, mirrors, steering wheel) If you cannot raise the seatback Release the seat belt lock by: Pushing on the lower front edge of the seatback to slacken the seat belt. Let the seat belt retract a little. When the bottom cushion is reinstalled Click the claw of the hinge into the hole of the bottom cushion before refastening the...
  • Page 47 Have the hexagon head bolts tightened with a torque wrench to 12.5 ft⋅lbf (17 N⋅m, 1.7 kgf⋅m), or have them tightened by your Toyota dealer. Failure to do so may cause the dials to be loosened and the bottom cush−...

  • Page 48: Head Restraints

    1−3. Adjustable components (seats, mirrors, steering wheel) Head restraints Front seats Vertical adjustment Push and hold the lock release button when lowering the head Lock restraint. release button Removal Pull the head restraint up while pushing the lock release but− ton.
  • Page 49 1−3. Adjustable components (seats, mirrors, steering wheel) Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears. Adjusting the rear seat head restraints Always raise the head restraint one level from the stowed position when using.

  • Page 50: Seat Belts

    1−3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv− ing the vehicle. Correct use of the seat belts l Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoul−...
  • Page 51 1−3. Adjustable components (seats, mirrors, steering wheel) Adjusting the height of the belt (front seats) Move the height adjuster up as needed until you hear a click. Down Push the lock release button and slide the height adjuster down. Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu−...
  • Page 52 1−3. Adjustable components (seats, mirrors, steering wheel) Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
  • Page 53 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system.
  • Page 54 Ensure that the belt and tab are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
  • Page 55 1−3. Adjustable components (seats, mirrors, steering wheel) NOTICE When using a seat belt extender When releasing the seat belt, press on the buckle release button on the extender, not on the seat belt. This helps prevent damage to the vehicle interior and the extender itself.

  • Page 56: Steering Wheel

    1−3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and pull the lever. Adjust to the ideal position by moving the steering wheel verti− cally. Release the lever. CAUTION Caution while driving Do not adjust the steering wheel while driving.

  • Page 57: Anti−Glare Inside Rear View Mirror

    1−3. Adjustable components (seats, mirrors, steering wheel) Anti−glare inside rear view mirror Glare from the headlights of veh icles behind can be reduced by using the following functions. Normal position Anti−glare position CAUTION Caution while driving Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and an accident, resulting in death or serious injury.

  • Page 58: Outside Rear View Mirrors

    1−3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted Power−adjustable type Select a mirror to adjust. (L: left or R: right) Adjust the mirror up, down, in or out using the switch. Manually adjustable type Adjust the mirror up, down, in or out by pushing the mirror surface.
  • Page 59 1−3. Adjustable components (seats, mirrors, steering wheel) Folding back the mirrors Push backward to fold the mir− rors. Mirror operating conditions (with power−adjustable type only) The engine switch is in the ACC or ON position. CAUTION When driving the vehicle Observe the following precautions while driving.
  • Page 60 1−3. Adjustable components (seats, mirrors, steering wheel) NOTICE If ice should jam the mirror Do not operate the control or scrape the mirror face. Use a spray de−icer to free the mirror.

  • Page 61: 1−4. Opening And Closing The

    1−4. Opening and closing the windows Power windows The power windows can be opened/closed using the following switches. Driver ’s power window switches Closing Opening One−touch opening (driver’s window only) Pressing the switch in the opposite direction will stop win− dow travel partway.
  • Page 62 1−4. Opening and closing the windows The power windows can be operated when The engine switch is in the ON position. Operating the power windows after turning the engine switch off The power windows can be operated for approximately 45 seconds even after the engine switch is turned off.

  • Page 63: 1−5. Refueling

    1−5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. Before refueling the vehicle Turn the engine switch off and ensure that all the doors, win− dows and glass hatch are closed. Opening the fuel tank cap Open the fuel filler door.
  • Page 64 1−5. Refueling Hang the tether as shown in the illustration. Closing the fuel tank cap When replacing the fuel tank cap, turn it until a clicking sound is heard. After releasing your hand, the cap will turn slightly to the opposite direction.
  • Page 65 This may cause static electricity to build up, resulting in a possible engine hazard. When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
  • Page 66 1−5. Refueling NOTICE Refueling Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the exhaust systems to operate abnormally or damaging fuel system components or the vehicle’s painted surface. To prevent damage to the fuel filler door Do not apply excessive force.

  • Page 67: 1−6. Theft Deterrent System

    1−6. Theft deterrent system Engine immobilizer system The vehicle’s keys have built−in tr ansponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle’s on−board computer. Never leave the keys inside the vehicle when you leave the vehicle. The indicator light flashes after the key has been removed from the engine switch to indi−...
  • Page 68 1−6. Theft deterrent system For vehicles sold in Canada This device complies with RSS−210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

  • Page 69: Theft Prevention Labels (U.s.a.)

    1−6. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto− len vehicles. Do not remove under penalty of law.

  • Page 70: 1−7. Safety Information

    1−7. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. ( P. 4 3 ) Adjust the position of the seat forward or backward to ensure the pedals can be reached and easily depressed to the extent required.
  • Page 71 1−7. Safety information CAUTION While driving Do not adjust the position of the driver’s seat while driving. Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.

  • Page 72: Srs Airbags

    1−7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and ches t of the driver and front pas−...
  • Page 73 1−7. Safety information Airbag system components Front passenger airbag Side and curtain shield air− bag sensors Curtain shield airbags Driver airbag Side airbags Driver ’s seat position sen− Occupant detection system (ECU and sensors) Driver ’s seat belt buckle Front passenger’s seat belt switch buckle switch AIR BAG ON and AIR BAG...
  • Page 74 1−7. Safety information Your vehicle is equipped with ADVANCED AIRBAGS designed based on US motor vehicle safety standards (FMVSS208). The airbag sys− tem controls airbag deployment po wer for the driver and front pas− senger. The driver airbag system consists of the driver seat’s position sensor etc.
  • Page 75 1−7. Safety information Operating conditions (front airbags) The SRS front airbags will deploy if the severity of the frontal impact is above the designed threshold level, comparable to an approximate 15 mph (25 km/h) collision when the vehicle impacts straight into a fixed bar− rier that does not move or deform.
  • Page 76 1−7. Safety information Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. Hitting a curb, edge of pavement or hard surface Falling into or jumping over a deep hole...
  • Page 77 1−7. Safety information Types of collisions that may not deploy the SRS airbag (side airbags and curtain shield airbags) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli− sion to the side of the vehicle body other than the passenger compartment.
  • Page 78 1−7. Safety information When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. Do not disconnect the battery cables before contacting your Toyota dealer. Any of the SRS airbags have been inflated.
  • Page 79 1−7. Safety information CAUTION SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts. The SRS driver airbag deploys with considerable force, and can cause death or serious injury especially if the driver is very close to the airbag.
  • Page 80 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys− tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are...
  • Page 81 1−7. Safety information CAUTION SRS airbag precautions Do not sit on the edge of the seat or lean against the dashboard. Do not allow a child to sit on the knees of a front passenger while the vehicle is moving. Do not drive the vehicle while the driver or passenger has items resting on their knees.
  • Page 82 Wash off any residue as soon as possible to prevent skin irritation. If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer.
  • Page 83 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.

  • Page 84: Front Passenger Occupant Classification System

    1−7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica− tion system. This system detects the conditions of the front passen− ger seat and activates or deactivates the devices for front passenger. SRS warning light Front passenger ’s seat belt reminder light AIR BAG ON indicator light...
  • Page 85 1−7. Safety information Condition and operation in the front passenger occupant classification system Adult AIR BAG ON and AIR BAG OFF indicator AIR BAG ON lights Indicator/ SRS warning light warning light Front passenger ’s seat belt reminder light Flashing Front passenger airbag Side airbag on the front passenger seat Devices...
  • Page 86 1−7. Safety information There is a malfunction in the system AIR BAG ON and AIR BAG OFF indicator AIR BAG lights Indicator/ warning light SRS warning light Front passenger ’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Devices Curtain shield airbag in the front passenger side...
  • Page 87 1−7. Safety information CAUTION Front passenger occupant classification system precautions Observe the following precautions r egarding front passenger occupant clas− sification system. Failure to do so may cause death or serious injury. Wear the seat belt properly. Make sure the front passenger ’s seat belt tab has not been left inserted into the buckle before someone sits in the front passenger seat.
  • Page 88 Do not kick the front passenger seat or subject it to severe impact. Other− wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. Child restraint systems installed on the rear seat should not contact the...

  • Page 89: Child Restraint Systems

    1−7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop− erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
  • Page 90 1−7. Safety information Convertible seat Booster seat When the child restraint system is not in use Leave the child restraint system properly secured on the seat. Do not store the restraint loosely on a passenger seat or in the luggage compartment. Selecting an appropriate child restraint system Get an appropriate child restraint system for the child.
  • Page 91 CAUTION Child restraint precautions Toyota strongly urges the use of a proper child restraint system that con− forms to the size of the child, installed on the rear seat. According to acci− dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.

  • Page 92: Installing Child Restraints

    1−7. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the outside rear seats using a seat belt or a child restraint lower anchor belt. Attach the top strap when installing a child restraint. Seat belts equipped with a child restraint locking mecha−...
  • Page 93 1−7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing child seat Infant seat/convertible seat Place the child seat on the rear seat facing the rear of the vehi− cle. Run the seat belt through the child seat and insert the plate into the buckle.
  • Page 94 1−7. Safety information While pushing the child seat down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
  • Page 95 1−7. Safety information While pushing the child seat into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended Booster seat Place the booster seat on the...
  • Page 96 1−7. Safety information Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Installation with child restraint lower anchorages Type A Widen the gap between the seat cushion and seatback slightly. Latch the hooks of the lower straps onto the anchorages and tighten...
  • Page 97 1−7. Safety information Type B Widen the gap between the seat cushion and seatback slightly. Latch the buckles onto the anchorages. If the child restraint has a top strap, the top strap should be latched onto the anchorages. For owners in Canada: The symbol on a child restraint system indicates the presence of a lower connector system.
  • Page 98 1−7. Safety information Raise the anchor bracket, latch the hook onto the anchor bracket and tighten the top strap. Make sure the top strap is securely latched. Reinstall the head restraint. Laws and regulations pertaining to anchorages Anchorages conform to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifica−...
  • Page 99 1−7. Safety information When the anchor bracket is not in use Lower the anchor bracket. The anchor bracket is only designed to secure the top strap. Do not use the anchor bracket for any other purpose. CAUTION When installing a booster seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode.
  • Page 100 1−7. Safety information CAUTION When installing a child restraint system Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child may be seriously injured or even killed in the event of sudden braking or an accident.
  • Page 101 1−7. Safety information CAUTION Do not use a seat belt extender If a seat belt extender is used when installing a child restraint system, the seat belt will not securely hold the child restraint system, which could cause death or serious injury to the child or other passengers in the event of a colli− sion.

  • Page 102: 2−1. Driving Procedures

    2−1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv− ing. Starting the engine ( P. 11 4 ) Driving Automatic transmission With the brake pedal depressed, shift the shift lever to D. ( P. 117) Release the parking brake.
  • Page 103 2−1. Driving procedures Parking the vehicle Automatic transmission With the shift lever in D, depress the brake pedal. Set the parking brake. ( P. 122) Shift the shift lever to P. ( P. 117) When parking on a hill, if necessary, block the wheels. Turn the engine switch off to stop the engine.
  • Page 104 Your vehicle has a drum−in−disc type parking brake system. This type of brake system needs bedding−down of the brake shoes periodically or when− ever the parking brake shoes and/or drum are replaced. Have your Toyota dealer perform the bedding down.
  • Page 105 Have the vehicle inspected by your Toyota dealer immediately. Do not under any circumstances shift the shift lever to P, R or N (automatic transmission) or R (manual transmission) while the vehicle is moving.
  • Page 106 2−1. Driving procedures CAUTION When driving the vehicle Do not shift the shift lever to N while the vehicle is moving. Doing so may cause the engine brake to not operate properly and lead to an accident. Do not turn the engine off while driving. The power steering and brake booster systems will not operate properly if the engine is not running.
  • Page 107 2−1. Driving procedures CAUTION When driving on slippery road surfaces Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle, resulting in an accident. Sudden changes in engine speed, such as engine braking caused by up− shifting or down−shifting, may cause the vehicle to skid, resulting in an accident.
  • Page 108 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in...
  • Page 109 2−1. Driving procedures CAUTION When taking a nap in the vehicle Always turn the engine off. Otherwise, you may accidentally move the shift lever or depress the accelerator pedal, which could cause an accident or fire due to engine overheating. Additionally, if the vehicle is parked in a poorly ventilated area, exhaust gases may collect and enter the vehicle, leading to death or a serious health hazard.
  • Page 110 If you hear a squealing or scraping noise while driving (brake pad wear limit indicators) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. The rotor damage can result if the pads are not replaced when needed.
  • Page 111 Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following. Brake function Changes in quantity and quality of oil and fluid used for the engine, trans−...

  • Page 112: Engine (Ignition) Switch

    2−1. Driving procedures Engine (ignition) switch Engine switch LOCK The steering wheel is locked and the key can be removed. Some electrical components such as the audio system can be used. All electrical components can be used. START For starting the engine. Starting the engine Automatic transmission Check that the parking brake is set.
  • Page 113 2−1. Driving procedures Turning the key from ACC to LOCK Shift the shift lever to P (auto− matic transmission) or N (man− ual transmission). ( P. 11 7 119) Push in the key and turn to the LOCK position. Steering lock release When starting the engine, the engine switch may seem stuck in the LOCK posi−...
  • Page 114 2−1. Driving procedures CAUTION Caution while driving Do not turn the engine switch to the LOCK position. If in an emergency, you must turn the engine off while the vehicle is moving, turn the engine switch only to the ACC position. NOTICE To prevent battery discharge Do not leave the engine switch in the ACC or ON position for long periods if...
  • Page 115 2−1. Driving procedures Automatic Transmission (if equipped) Select a shift position appropriate for the driving conditions. Shifting the shift lever While the engine switch is on, depress the brake pedal and move the shift lever. Shift position uses Shift position Function Parking the vehicle or starting the engine Reversing...
  • Page 116 2−1. Driving procedures Downshifting restrictions The shift lever cannot be downshifted if the following speeds are exceeded. 2WD models Maximum speed Downshifting mph (km/h) 86 (140) 59 (95) 25 (41) 4WD models Maximum speed Downshifting Transfer position mph (km/h) H2 and H4 86 (140) 33 (54) H2 and H4...

  • Page 117: Manual Transmission

    2−1. Driving procedures Manual Transmission (if equipped) Fully depress the clutch pedal before operating the shift lever, and then release it slowly.
  • Page 118 2−1. Driving procedures Maximum allowable speed Observe the following maximum allowable speeds in each gear when maxi− mum acceleration is necessary. Maximum speed Shift position Transfer position mph (km/h) H or HL 30 (48) 11 (18) H or HL 58 (93) 22 (35) H or HL 86 (138)

  • Page 119: Turn Signal Lever

    2−1. Driving procedures Turn signal lever Left turn Right turn Move and hold the lever partway to signal a lane change. The left hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change. The right hand signal will flash until you release the lever.

  • Page 120: Parking Brake

    2−1. Driving procedures Parking brake Set the parking brake Fully set the parking brake while depressing the brake pedal. At this time, the indicator will come on. Release the parking brake Slightly raise the lever Press the button Lower it completely...
  • Page 121 2−1. Driving procedures NOTICE Before driving Fully release the parking brake. Driving the vehicle with the parking brake set will lead to brake components overheating, which may affect braking performance and increase brake wear.

  • Page 122: 2−2. Instrument Cluster

    2−2. Instrument cluster Gauges and meters The following gauges, meters and displays illuminate when the engine switch is in the ON position. Tachometer Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed. Voltmeter Displays the charge state. Engine coolant temperature gauge Displays the engine coolant temperature.
  • Page 123 2−2. Instrument cluster Odometer/trip meter Odometer: Displays the total distance the vehicle has been driven. Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display differ− ent distances independently.
  • Page 124 2−2. Instrument cluster NOTICE To prevent damage to the engine and its components Do not let the indicator needle of the tachometer enter the red zone, which indicates the maximum engine speed. The engine may be overheating if the temperature gauge is in the red zone (H).

  • Page 125: Indicators And Warning Lights

    2−2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen− ter panel inform the driver of the status of the vehicle’s various sys− tems. Instrument cluster Center panel...
  • Page 126 2−2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Active traction control Turn signal indicator system indicator ( P. ( P. 121) 148) (if equipped) Headlight high beam AUTO LSD indicator indicator ( P.
  • Page 127 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer.

  • Page 128: Accessory Meter

    2−2. Instrument cluster Accessory meter (if equipped) Compass Displays the direction that the vehicle is heading. ( P. 252) Outside temperature Displays the outside air temperature. ( P. 238) Clinometer Displays the longitudinal and lateral inclination of the vehicle. SET button This button is used to calibrate the compass.

  • Page 129: 2−3. Operating The Lights And

    2−3. Operating the lights and wipers Headlight switch The headlights can be operated manually. The side marker, parking, tail, license plate, outside rear view mirror illumination (if equipped) and instrument panel lights turn on. The headlights and all lights listed above turn on. Turning on the high beam headlights With the headlights on, push the lever forward to turn on the...
  • Page 130 To turn the lights on again, turn the engine switch to the ON position, or turn the headlight switch off once and then back to the position. Customization that can be configured at Toyota dealer Settings (automatic light off system) can be changed. (Customizable features P.

  • Page 131: Windshield Wipers And Washer

    2−3. Operating the lights and wipers Windshield wipers and washer Wiper intervals can be adjusted fo r intermittent operation (when INT is selected.) Intermittent wiper interval adjustment (increase) Intermittent wiper interval adjustment (decrease) Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation...
  • Page 132 2−3. Operating the lights and wipers The windshield wiper and washer can be operated when The engine switch must be in the ON position. If no windshield washer fluid sprays Check that the washer nozzles are not blocked and if there is washer fluid in the windshield washer fluid reservoir.

  • Page 133: Rear Window Wiper And Washer

    2−3. Operating the lights and wipers Rear window wiper and washer (if equipped) Intermittent window wiper operation. The wiper operates 3 times at normal speed and then moves to intermittent mode. Normal window wiper oper− ation Washer/wiper dual opera− tion Washer/wiper dual opera−...

  • Page 134: 2−4. Using Other Driving

    2−4. Using other driving systems Cruise control (if equipped) Use cruise control to maintain a set speed without using the acceler− ator. Set the vehicle speed Press the ON−OFF button to turn the cruise control on. At this time, the cruise control indicator will come on.
  • Page 135 2−4. Using other driving systems Canceling and resuming regular acceleration Cancel Pull the lever towards you to cancel cruise control. The speed setting is also can− celed when the brakes are applied or the clutch depressed (manual transmis− sion). Resume To resume cruise control and return to the set speed, push the lever up.
  • Page 136 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. CAUTION To avoid operating the cruise control by mistake Keep the ON−OFF button off when not in use.

  • Page 137: Intuitive Parking Assist

    2−4. Using other driving systems Intuitive parking assist (if equipped) The distance to obstacles measured by the sensors is communi− cated via the buzzer when parallel parking or maneuvering into a garage. Always check the surrounding area when using this system. This system works when the engine switch is in the ON position and the shift lever is in R.
  • Page 138 2−4. Using other driving systems Intuitive parking assist switch ON/OFF When on, the buzzer sounds to inform the driver that the system is operational. At this time, the indicator light will come on. Press the button to switch the ON/OFF mode. The distance and buzzer When a sensor detects an obstacle, the buzzer sounds.
  • Page 139 2−4. Using other driving systems Sensors that operate and detection range The following diagrams show the se nsor detection range. Note that sensors may not be able to detect obstacles that are extremely close to the vehicle. Detection range of the sensors Approx.
  • Page 140 S A towing hitch is mounted to the vehicle. S A non−genuine Toyota suspension (lowered suspension etc.) is installed. In addition to the examples above, there are instances in which, because of their shapes, signs and other objects may be judged by a sensor to be closer than they are.
  • Page 141 2−4. Using other driving systems Certification (Canada only) This ISM device compiles with Canadian ICES−001. CAUTION Caution when using the intuitive parking assist Observe the following precautions. Failure to do so may result in the vehicle being unable to be driven safely and possibly cause an accident.

  • Page 142: Four−Wheel Drive System (4Wd Models With A Manual Transmission)

    2−4. Using other driving systems Four−wheel drive system (4WD models with a manual transmission) Use the four−wheel drive control lever to select the following transfer modes. The center differential lock indicator comes on when the LL or HL mode is selected.
  • Page 143 2−4. Using other driving systems Shifting between H and HL You need not to depress the clutch pedal. If the center differential lock indicator does not come on when you shift from H to HL, drive straight ahead while accelerating or decelerating. If the center differential lock indicator does not go off when you shift from HL to H, drive straight ahead while accelerating or decelerating, or drive in reverse.

  • Page 144: Four−Wheel Drive System (4Wd Models With An Automatic Transmission)

    2−4. Using other driving systems Four−wheel drive system (4WD models with an automatic transmission) Use the front−wheel drive control le ver to select the following trans− fer modes. The four−wheel drive indicator comes on when the H4, N or L4 mode is selected.
  • Page 145 2−4. Using other driving systems Shifting between H2 and H4 Reduce your speed to less than 50 mph (80 km/h) and shift the front− wheel drive control lever from H2 to H4. If you have trouble shifting in cold weather, reduce your speed or stop the vehicle.

  • Page 146: Active Traction Control System

    2−4. Using other driving systems Active traction control system (if equipped) The active traction control system automatically helps prevent the spinning of 4 wheels when the veh icle is started or accelerated on slippery road surfaces. System operation Vehicles with an automatic transmission: Shift the front−wheel drive control lever into L4.
  • Page 147 2−4. Using other driving systems When the rear differential is locked(vehicles with the rear differential lock system) The active traction control system is activated only when the vehicle speed is less than 4 mph (6 km/h). Sounds and vibrations caused by the active traction control system A sound may be heard from the engine compartment when the engine is started or just after the vehicle begins to move.

  • Page 148: Auto Lsd System (2Wd Models)

    2−4. Using other driving systems AUTO LSD system (2WD models) The AUTO LSD system aids tractio n by using the traction control system to control engine performance and braking when one of the rear wheels begins to spin. The system should be used only wh en wheel spinning occurs in a ditch or rough surface.
  • Page 149 2−4. Using other driving systems If the brake system overheats The system will cease operation and a buzzer will sound to alert the driver. Stop the vehicle in a safe place. (There is no problem with continuing normal driving.) CAUTION To avoid an accident Do not use the AUTO LSD system in conditions other than the above.

  • Page 150: Rear Differential Lock System

    2−4. Using other driving systems Rear differential lock system (if equipped) The rear differential lock system is provided for use only when wheel spinning occurs in a ditch or on a slippery or ragged surface. The rear differential lock system is effective in case one of the rear wheels is spinning.
  • Page 151 2−4. Using other driving systems Manual transmission Before using the rear differential lock system. Shift the four−wheel drive control lever into LL to see if this is sufficient. If this has no effect, additionally use the rear differ− ential lock system. Be sure to stop the wheels.
  • Page 152 2−4. Using other driving systems CAUTION To avoid an accident Do not use the rear differential lock system except when wheel spinning occurs in a ditch or on a slippery or ragged surface. Large steering effort and careful cornering control will be required. Do not lock the rear differential until the wheels have stopped spinning.

  • Page 153: Clutch Start Cancel Switch (Vehicles With A Manual Transmission)

    2−4. Using other driving systems Clutch star t cancel switch (vehicles with a manual transmission) The switch allows the vehicle to be driven out of difficult situations by cranking the engine with the clutch engaged. Never use the switch for normal engine starting. Be sure to follow the starting procedure.

  • Page 154: Driving Assist Systems

    2−4. Using other driving systems Driving assist systems To help enhance driving safety a nd performance, the following sys− tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ABS (Anti−lock Brake System) Restrains the vehicle from slipping when driving on slick road surfaces or in the event of sudden braking.
  • Page 155 2−4. Using other driving systems To disable VSC If the vehicle gets stuck in fresh snow or mud, VSC may reduce power from the engine to the wheels. You may need to turn the sys− tem off to enable you to rock the vehicle in order to free it. Vehicles with rear differential lock system Press the RR DIFF LOCK switch.
  • Page 156 2−4. Using other driving systems Sounds and vibrations caused by the ABS, TRAC, VSC and brake assist system A sound may be heard from the engine compartment when the engine is started or just after the vehicle begins to move. This sound does not indi− cate that a malfunction has occurred in any of these systems.
  • Page 157 The ABS and VSC will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. Handling of tires and suspension Using tires with any kind of problem or modifying the suspension will affect...

  • Page 158: 2−5. Driving Information

    2−5. Driving information Off−road precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off−road applications.
  • Page 159 2−5. Driving information CAUTION Off−road vehicle precautions Always observe the following precautions to minimize the risk of serious per− sonal injury or damage to your vehicle: In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt. Therefore, the driver and all passengers should fasten their seat belts whenever the vehicle is moving.
  • Page 160 2−5. Driving information Off−road driving When driving your vehicle off−road, please observe the following pre− cautions to ensure your driving enjoyment and to help prevent the closure of areas to off−road vehicles. l Drive your vehicle only in areas where off−road vehicles are permit− ted to travel.
  • Page 161 2−5. Driving information CAUTION Off−road driving precautions Always observe the following precautions to minimize the risk of serious per− sonal injury or damage to your vehicle: Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places. Do not grip the steering wheel spokes when driving off−road.
  • Page 162 2−5. Driving information NOTICE To prevent the water damage Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. Water entering the engine air intake will cause severe engine damage. Water entering the automatic transmission will cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ulti−...

  • Page 163: Cargo And Luggage

    2−5. Driving information Cargo and luggage Take notice of the following information about storage precau− tions, cargo capacity and load. l Stow cargo and luggage in the luggage compartment whenever possible. l Be sure all items are secured in place. l Be careful to keep the vehicle level.
  • Page 164 2−5. Driving information (6) If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. Example on your vehicle Cargo capacity Total load capacity...
  • Page 165 2−5. Driving information CAUTION Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compart− ment. Receptacles containing gasoline Aerosol cans Storage precautions Do not stack anything in the luggage compartment higher than the seatbacks.

  • Page 166: Vehicle Load Limits

    2−5. Driving information Vehicle load limits Vehicle load limits include total load capacity, seating capacity, towing capacity and cargo capacity. Total load capacity: 1190 lb. (540 kg) Total load capacity means the combined weight of occupants, cargo and luggage. Seating capacity: 5 occupants (Front 2, Rear 3) Seating capacity means the ma ximum number of occupants whose estimated average weight is 150 lb.

  • Page 167: Winter Driving Tips

    2−5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri− ate to the prevailing weather conditions. Pre−winter preparations l Use fluids that are appropriate to the prevailing outside tem− peratures.
  • Page 168 2−5. Driving information When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suit− able to road conditions. When parking the vehicle Park the vehicle and move the shift lever to P (automatic trans− mission) or to 1 or R (manual transmission) without setting the parking brake.
  • Page 169 NOTICE Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the opera− tion of the tire pressure warning valves and transmitters.

  • Page 170: Trailer Towing

    For your safety and the safety of others, do not overload the vehicle or trailer. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Weight limits Confirm the total trailer weight, gross vehicle weight, gross axle weight and trailer tongue load are all within the limits.
  • Page 171 Total trailer weight Tongue load Towing a trailer Consult your Toyota dealer for further information about additional requirements such as a towing kits, etc. Hitch and tow hitch receiver Hitch Trailer hitch assemblies have different weight capacities estab−...
  • Page 172 2−5. Driving information Selecting trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer coupler. Most couplers are stamped with the required trailer ball size.
  • Page 173 Break−in schedule Toyota recommends that you do not use a new vehicle or a vehicle with any new power train components (engine, transmission, differential, wheel bearings, etc.) to tow a trailer for the first 500 miles (800 km) of driving.
  • Page 174 The tow hitch receiver installed on your vehicle must never be used on another vehicle. Hitches If you wish to install a trailer hitch, your Toyota dealer should be consulted. Use only a hitch that conforms to the total trailer weight requirement. Follow the directions supplied by the hitch manufacturer.
  • Page 175 NOTICE When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. Brakes Toyota recommends trailers with brakes that conform to any applicable fed−...
  • Page 176 2−5. Driving information Trailer towing tips Your vehicle will handle differently when towing a trailer. The three main causes of vehicle−trailer ac cidents are driver error, excessive speed and improper trailer loading. Keep these in mind when towing. l Before starting out, check the trailer’s light and the vehicle−trailer connections.
  • Page 177 2−5. Driving information l Note that when making a turn, the trailer wheels will be closer than the vehicle wheels to the inside of the turn. Compensate by making a larger than normal turning radius. l Crosswinds and rough roads will adversely affect handling of your vehicle and trailer, causing sway .
  • Page 178 2−5. Driving information l Always place wheel blocks under both the vehicle and the trailer wheels when parking. Apply the parking brake firmly, and put the transmission in P (automatic transmission) or in 1 or R (manual transmission). Avoid parking on a slope, but if unavoidable, do so only after performing the following: Apply the brakes and keep them applied.
  • Page 179 2−5. Driving information CAUTION To avoid an accident Do not exceed 45 mph (72 km/h) or posted towing speed limit, whichever is lower. As instability (swaying) of the towing vehicle−trailer combination increases as speed increases, exceeding 45 mph (72 km/h) may cause loss of control.

  • Page 180: Dinghy Towing

    2−5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground.

  • Page 181: 3−1. Using The Air Conditioning System And Defogger

    3−1. Using the air conditioning system and defogger Air conditioning system Outside air or recirculated Air conditioning air mode switch ON/OFF switch Fan speed control dial Temperature control dial Air outlet selection dial Adjusting the settings Adjusting the temperature setting Turn the temperature control dial clockwise (warm) or counter−...
  • Page 182 3−1. Using the air conditioning system and defogger Adjusting the fan speed Turn the fan speed control dial clockwise (increase) or counter− clockwise (decrease). Set the dial to OFF to turn the fan off. Selecting the air outlets Set the air outlet selection dial to an appropriate position. The positions between the air outlet selections shown below can also be selected for more detailed adjustment.
  • Page 183 3−1. Using the air conditioning system and defogger When the dial is set to , air flows to the feet and the wind− shield defogger operates. The air intake selector is automat− ically set to outside air mode. To return the recirculated air mode, press When the dial is set to , air...
  • Page 184 3−1. Using the air conditioning system and defogger If the ambient temperature drops while using the recirculated air mode The air intake mode automatically changes from recirculated air mode to outside air mode after a few minutes. To cancel this function: Press and hold for longer than 2 seconds.
  • Page 185 3−1. Using the air conditioning system and defogger Right and left side outlets Direct air flow to the left or right, up or down. Opening and closing the right and left side outlets Open the vent. Close the vent.
  • Page 186 3−1. Using the air conditioning system and defogger Using the system in recirculated air mode The windows will fog up more easily if the recirculated air mode is used for an extended period. When outside air temperature approaches 325F (05C) The air conditioning system may not operate even when is pressed.

  • Page 187: Rear Window Defogger

    3−1. Using the air conditioning system and defogger Rear window defogger Clear the rear window using the defogger. ON/OFF Press the button to turn on the rear window defogger. The indicator light will come on. The defogger will automatically turn off after 15 to 240 minutes. The operation time changes according to the ambient tem−...

  • Page 188: 3−2. Using The Audio System

    3−2. Using the audio system Audio system types Type A: CD player with external CD changer controller and AM/FM radio Type B: CD player with changer and AM/FM radio Type A Type B...
  • Page 189 Using the steering wheel audio switches P. 224 Welcome function (type B only) When you turn the engine switch to the ACC or ON position, “FJ CRUISER” will appear scrolling on the display. A nd then “FJammer” will appear for 6 seconds.
  • Page 190 3−2. Using the audio system CAUTION For vehicles sold in U.S.A. and Canada Part 15 of the FCC Rules FCC Warning: Any unauthorized changes or modifications to this equipment will void the user ’s authority to operate this device. Laser products S Do not take this unit apart or attempt to make any changes yourself.

  • Page 191: Using The Radio

    3−2. Using the audio system Using the radio Type A Power Volume Adjusting the Station selector frequency Scanning for receivable stations AM/FM mode buttons Seeking the frequency Type B Adjusting the frequency Power Volume (AM, FM mode) or channel (SAT mode) AM⋅SAT/FM mode buttons Scanning for receivable stations Display text message...
  • Page 192 3−2. Using the audio system ® Setting station presets (excluding XM Satellite Radio) Search for desired stations by turning pressing “ ” or “ ” on Press and hold the button (from to or ) that the station is to be set to until you hear a beep. ®...
  • Page 193 3−2. Using the audio system Turn to select the desired channel in the all categories or press “ ” or “ ” on to select the desired channel in the current category. ® Satellite Radio channel presets Setting XM Select the desired channel. Press and hold the button (from ) that the channel is to be set to until you hear a beep.
  • Page 194 3−2. Using the audio system When the battery is disconnected Stations presets are erased. Reception sensitivity Maintaining perfect radio reception at all times is difficult due to the con− tinually changing position of the antenna, differences in signal strength and surrounding objects, such as trains, transmitters, etc. The radio antenna is mounted on the right−side front fender.
  • Page 195 XM antenna cable is attached securely. ANTENNA There is a short−circuit in the antenna or the sur− rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to the XM Satellite Radio. The radio is being updated with the latest ®...
  • Page 196 3−2. Using the audio system The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to −−− the previous channel or “CH001”. If it does not change automatically, select another channel. ® Contact the XM Listener Care Center at 1−800−967−2346 (U.S.A.) or 1−877−438−9677 (Canada).

  • Page 197: Using The Cd Player

    3−2. Using the audio system Using the CD player Type A Power Volume CD selection (with external CD changer only) Fast−forward CD eject Reverse Search playback Repeat play Display text message Random playback Track selection Playback Type B Power Volume Playback CD selection Fast−forward...
  • Page 198 3−2. Using the audio system Loading CDs Loading a CD (type A) Insert a CD. Loading a CD (type B) Press . “WAIT” is shown on the display. Insert a CD when the indicator on the slot turns from amber to green.
  • Page 199 3−2. Using the audio system Ejecting all the CDs (type B only) Press and hold until you hear a beep, and then remove the CDs. Selecting and scanning a track Selecting a track Press “ ” to move up or “ ” to move down using until the desired track number is displayed.
  • Page 200 3−2. Using the audio system Repeat play Repeating a track Press (RPT) or (RPT). Repeating all of the tracks on a CD (with CD changer only) Press and hold (RPT) or (RPT) until you hear a beep. Random playback Current CD Press (RAND) or (RAND).
  • Page 201 Canceling repeat play Press (RPT) or (RPT) again. Error messages Refer to the following table and take the appropriate measures. If the prob− lem is not rectified, take the vehicle to your Toyota dealer. Correction Message Cause Procedures S The disc may be dirty...
  • Page 202 3−2. Using the audio system Correction Message Cause Procedures There is no disc in the NO DISC Insert a disc CD changer Discs that can be used Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc fea− tures, or due to scratches, dirt or deterioration.
  • Page 203 3−2. Using the audio system NOTICE CDs and adapters that cannot be used Do not use the following types of CDs or 3 in. (8 cm) CD adapters or Dual Disc. Doing so may damage the CD player and/or the CD insert/eject function. CDs that have a diameter that is not 4.7 in.
  • Page 204 3−2. Using the audio system NOTICE CD player precautions Failure to follow the precautions below may result in serious damage to the CDs or the player itself. Do not insert anything other than CDs into the CD slot. Do not apply oil to the CD player. Store CDs away from direct sunlight.

  • Page 205: Playing Back Mp3 And Wma Discs

    3−2. Using the audio system Playing back MP3 and WMA discs Type A Power Volume File selection Disc eject Fast−forward Folder selection Reverse File selection Repeat play Display text message Search playback Playback Random playback Type B Power Volume File selection Disc selection Playback Disc eject...
  • Page 206 3−2. Using the audio system Loading MP3 and WMA discs Loading a disc (type A) Insert a disc. Loading a disc (type B) Press . “WAIT” is shown on the display. Insert a disc when the indicator on the slot turns from amber to green.
  • Page 207 3−2. Using the audio system Ejecting all the discs (type B only) Press and hold until you hear a beep, and then remove the discs. Selecting a disc (type B only) Selecting the desired disc ( ). Press ( ) or Selecting a folder Selecting folders one at a time To select the desired folder, press “...
  • Page 208 3−2. Using the audio system Selecting the desired file by cueing the files in the folder Press or . The first 10 seconds of all files in the folder will be played. When the desired file is reached, press the switch once again. Fast−forwarding and reversing files To fast−forward or reverse.
  • Page 209 Press (RPT) or (RPT) again. Error messages Refer to the following table and take the appropriate measures. If the prob− lem is not rectified, take the vehicle to your Toyota dealer. Correction Message Cause Procedures S The disc may be dirty...
  • Page 210 3−2. Using the audio system Correction Message Cause Procedures This indicates that no playable data is NO MUSIC Eject the disc included in the disc Discs that can be used Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc fea− tures, or due to scratches, dirt or deterioration.
  • Page 211 3−2. Using the audio system S Compatible sampling frequencies MPEG1 LAYER3: 32, 44.1, 48 (kHz) MPEG2 LSF LAYER3: 16, 22.05, 24 (kHz) S Compatible bit rates (compatible with VBR) MPEG1 LAYER3: 64, 80, 96, 112, 128, 160, 192, 224, 256, 320 (kbps) S MPEG2 LSF LAYER3: 64, 80, 96, 112, 128, 144, 160 (kbps) S Compatible channel modes: stereo, joint stereo, dual channel and monaural...
  • Page 212 3−2. Using the audio system File names The only files that can be recogniz ed as MP3/WMA and played are those with the extension .mp3 or .wma. Multi−sessions As the audio system is compatible with multi−sessions, it is possible to play discs that contain MP3 and WMA files.
  • Page 213 3−2. Using the audio system S There is a wide variety of freeware and other encoding software for MP3 and WMA files on the market, and depending on the status of the encoding and the file format, poor sound quality or noise at the start of playback may result.

  • Page 214: Optimal Use Of The Audio System

    3−2. Using the audio system Optimal use of the audio system Type A Displays the current mode Changes the following set− ting Sound quality and volume balance ( P. 218) The sound quality and bal− ance setting can be changed to produce the best sound.
  • Page 215 3−2. Using the audio system Adjusting sound quality Turning or adjusts the level. Sound qual− Mode Turn to the Turn to the Level ity mode displayed left right Bass −5 to 5 High Treble −5 to 5 Front/rear Shifts to volume F7 to R7 Shifts to rear...
  • Page 216 3−2. Using the audio system Trademark owned by New Transducers Limited This vehicle incorporates NXT flat panel speaker technology by New Transducers Limited, UK. is a registered trademarks of New Transducers Limited.

  • Page 217: Operating The Sub Woofer

    3−2. Using the audio system Operating the sub woofer (if equipped) Pressing the switch, to oper− ate the sub woofer. To stop it, press the switch again.

  • Page 218: Changing Display Color (Type B Only)

    3−2. Using the audio system Changing display color (type B only) Display color can be changed by following the procedure below. Select the function of which you want to change the display color. Turn the audio system off by pressing Push for more than 5 seconds.

  • Page 219: Using The Aux Adapter

    3−2. Using the audio system Using the AUX adapter This adapter can be used to connect a portable audio device and lis− ten to it through the vehicle’s speakers. Connect the portable audio device. Type A Press .
  • Page 220 3−2. Using the audio system Type B Press . Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle’s audio controls. All other adjustments must be made on the portable audio device itself. When using a portable audio device connected to the power outlet or cigarette lighter Noise may occur during playback.

  • Page 221: Using The Steering Wheel Audio Switches

    3−2. Using the audio system Using the steering wheel audio switches (if equipped) Some audio features can be contro lled using the switches on the steering wheel. Volume Radio: Select radio stations CD: Select tracks, files (MP3 and WMA) and discs Power on, select audio source Turning on the power...
  • Page 222 3−2. Using the audio system Selecting a radio station Press to select the radio mode. Press “ ” or “ ” on to select a preset station. To scan for receivable stations, press and hold the switch until you hear a beep. Selecting a track/file Press to select the CD mode.

  • Page 223: 3−3. Using The Interior Lights

    If the interior light remains on when the door is not fully closed and the inte− rior light switch is in the DOOR position, the light will go off automatically after 30 minutes. Customization that can be configured at Toyota dealer Settings (e.g. The time elapsed before lights turn off) can be changed. (Customizable features...

  • Page 224: S Interior Lights

    3−3. Using the interior lights Interior lights Interior lights Front DOOR position Rear DOOR position...

  • Page 225: 3−4. Using The Storage

    3−4. Using the storage features List of storage features Glove box Auxiliary box Glove box Bottle holders Cup holders Glove box Pull up the lever.

  • Page 226: S Cup Holders (Front)

    3−4. Using the storage features Glove box and Cup holders (front) CAUTION Caution while driving Keep the glove box closed. Injuries may result in the event of an accident or sudden braking. Cup holders (front) Vehicles with an automatic transmission...
  • Page 227 3−4. Using the storage features Cup holders (front) Vehicles with a manual transmission Holding large cups Vehicles with an automatic transmission Remove the adapter.
  • Page 228 3−4. Using the storage features Cup holders (front) Vehicles with a manual transmission Remove the adapter. CAUTION Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.

  • Page 229: S Cup Holders (Rear)

    3−4. Using the storage features Cup holders (rear) Cup holders (rear) Removing the mat Pull up. CAUTION Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.

  • Page 230: S Bottle Holders

    3−4. Using the storage features Bottle holders Bottle holders Bottle holders Depending on their size or shape, some bottles may not fit in the holders. NOTICE Items that should not be stowed in the bottle holders Put the cap on before stowing a bottle. Do not place open bottles in the bot− tle holders, or glasses and paper cups containing liquid.

  • Page 231: S Auxiliary Box

    3−4. Using the storage features Auxiliary box Auxiliary box Push the button. Pull up the lid. CAUTION Items that should not be left in the auxiliary box Do not leave anything flammable or deformable, such as a lighter or glasses in the box.

  • Page 232: 3−5. Other Interior Features

    3−5. Other interior features Sun visors Front Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side Flip down.

  • Page 233: Vanity Mirror

    3−5. Other interior features Vanity mirror Flip down.

  • Page 234: Clock

    3−5. Other interior features Clock Adjusts the hours Adjusts the minutes The clock is displayed when The engine switch is in the ACC or ON position. When disconnecting and reconnecting battery terminals The time display will automatically be set to 1:00.

  • Page 235: Outside Temperature Display

    English/U.S. Cus− tomary System and metric. When – –5C or – –5F is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. The outside air temperature is displayed when The engine switch is in the ON position.

  • Page 236: Power Outlet (12V Dc)

    3−5. Other interior features Power outlet (12V DC) The power outlet can be used for 12 V accessories that run on less than 10A. The power outlet can be used when The engine switch is in the ACC or ON position. NOTICE To avoid damaging the power outlet Close the power outlet lid when not in use.

  • Page 237: Power Outlet (If 115V Ac Equipped)

    3−5. Other interior features Power outlet (if 115V AC equipped) The power outlet can be used for electrical appliances. Operation Main switch To use the power outlet, turn on the main switch. The power supply starts a few seconds after the main switch is pressed.
  • Page 238 3−5. Other interior features The maximum capacity is 115V AC/400W when the following condition applies: Vehicles with an automatic transmission: The shift lever is in P or N. Vehicles with a manual transmission: The shift lever is in N and the clutch pedal is not depressed. A maximum capacity of 400W can only be restored by turning the power outlet main switch off and then on again under con−...
  • Page 239 When the cabin temperature is high, open the windows to cool the tempera− ture down. Once it reaches the normal temperature, turn the power outlet main switch on again. If the power supply is not resumed even after performing the above proce− dure, have the vehicle inspected by a Toyota dealer.
  • Page 240 Do not modify, disassemble or repair the power outlet or its inverter, in any way. Doing so may result in unexpected malfunctions or accidents, which could cause serious damage or injuries. Contact a Toyota dealer for any necessary repairs. To prevent injuries and accidents, secu rely fix all electric appliances before use and do not use any appl iances that may do any of the fol−...
  • Page 241 3−5. Other interior features NOTICE To avoid damaging the power outlet and the plug Close the power outlet lid when not in use. Foreign objects or liquids that enter the power outlet may cause a short circuit. Do not use plug adaptors to connect too many plugs to the power outlet. After inserting a plug, gently close the power outlet lid.
  • Page 242 If the power outlet is loose when an electrical appliance plug is con− nected Replace the outlet. Contact a Toyota dealer for any necessary replacements. If the power outlet gets dirty Turn the main switch off and use a soft, clean cloth to wipe it gently.

  • Page 243: Armrest

    3−5. Other interior features Armrest Adjusting to the desired angle: Lower the armrest from the highest position to the lowest position. Raise the armrest to the desired angle. Unlock the armrest: Lift the armrest to raise it to the highest position. NOTICE To prevent damage to the armrest Do not place too much strain on the armrest.

  • Page 244: Floor Mat

    3−5. Other interior features Floor mat Securely place a mat that matches the size of the space on the car− pet. Secure the front floor mat using the hooks provided. CAUTION When inserting the floor mat Make sure the floor mat is properly placed on the vehicle carpet and the cor− rect side face upward.

  • Page 245: Luggage Storage Box (Vehicles Without Sub Woofer)

    3−5. Other interior features Luggage storage box (vehicles without sub woofer) Push the lid down and pull it towards you. CAUTION Caution while driving Keep the luggage storage box closed. Injuries may result in the event of an accident or sudden braking.

  • Page 246: Luggage Compartment Features

    3−5. Other interior features Luggage compartment features Tie−down hooks Tie−down hooks are provided for securing loose items.
  • Page 247 3−5. Other interior features Cargo net hooks To hang the cargo net, use the cargo net hooks and tie−down hooks. The cargo net itself is not included as an original equip− ment.
  • Page 248 3−5. Other interior features Shopping bag hooks To hang the shopping bag, use the cargo net hooks. CAUTION When the tie−down hooks and cargo net hooks are not in use To avoid injury, always return the tie−down hooks and cargo net hooks to their positions when they are not in use.

  • Page 249: Compass

    3−5. Other interior features Compass (if equipped) The compass indicates the direction that the vehicle is heading. Operation The compass points north for about 3 seconds after the engine switch is turned to the ON position, and then indi− cates the actual direction the vehicle facing.
  • Page 250 3−5. Other interior features Calibrating the compass Samoa: 5 Guam: 8 Saipan: 8 The direction display deviates fr om the true direction determined by the earth’s magnetic field. The amoun t of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will deviate.
  • Page 251 3−5. Other interior features After calibration, leave the syst em for 6 seconds or press the SET button for about 2 seconds. If the display returns to the outside temperature display, the calibra− tion is complete. Circling calibration Stop the vehicle where it is safe to drive in a circle. Press the SET button until the zone number appears on the outside...
  • Page 252 3−5. Other interior features Conditions unfavorable to correct operation The compass may not show the correct direction in the following conditions: The vehicle is stopped immediately after turning. The compass does not adjust while the vehicle is stopped. The engine switch is turned off immediately after turning. The vehicle is on an inclined surface.
  • Page 253 3−5. Other interior features NOTICE To avoid the compass malfunctions Do not place magnets or any metal objects on or near the accessory meter. Doing this may cause a malfunction of the compass sensor. To ensure normal operation of the compass Do not perform circling calibration of the compass in a place where the earth’s magnetic field is subject to interference by artificial magnetic fields.

  • Page 254: 4−1. Maintenance And Care

    4−1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. l Working from top to bottom, liber ally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
  • Page 255 4−1. Maintenance and care Aluminum wheels (if equipped) Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical cleaners. Use the same mild detergent and wax as used on the point. Bumpers and side moldings Do not scrub with abrasive cleaners.

  • Page 256: Cleaning And Protecting The Vehicle Interior

    Wipe the window in strokes running parallel to the heater wires. Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. Shampooing the carpets There are several commercial foaming−type cleaners available.
  • Page 257 4−1. Maintenance and care Seat belts Clean with mild soap and lukewarm water using a cloth or sponge. Also check the belts periodically for excessive wear, fraying or cuts. CAUTION Water in the vehicle Be careful not to splash or spill liquid on the floor. Do not get any of the SRS components or wiring in the vehicle interior wet.
  • Page 258 4−1. Maintenance and care NOTICE Cleaning the inside of the rear window Be careful not to scratch or damage the heater wires.

  • Page 259: 4−2. Maintenance

    It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non−Toyota parts are used in replacement or if a repair shop other than Toyota deal er performs repairs, confirm the war− ranty coverage.
  • Page 260 4−2. Maintenance Allow inspection and repairs to be performed by a Toyota dealer Toyota technicians are well−trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.

  • Page 261: General Maintenance

    “Scheduled Maintenance Guide” or “Owner ’s Manual Supp lement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items Check points Battery Maintenance−free.
  • Page 262 4−2. Maintenance Vehicle interior Items Check points S Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? S Can the vehicle be hold securely Automatic transmission “Park” on an incline with the shift lever in mechanism S Moves smoothly? S Does it have appropriate clear−...
  • Page 263 4−2. Maintenance Items Check points S Moves smoothly? S Has correct free play? Steering wheel S No strange noises? Vehicle exterior Items Check points Door S Operate smoothly? Engine hood S The lock system works properly? S Is there any leakage after park− Fluid leaks ing? S Inflation pressure is correct?

  • Page 264: Emission Inspection And Maintenance (I/M) Programs

    The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test:...

  • Page 265: Do−It−Yourself Service Precautions

    Brake fluid level ( P. 280) S Rag or paper towel S Funnel (used only for adding brake fluid) S “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non−silicate, non− amine, non−nitrite and non−borate coolant with long−life hybrid organic acid technology.
  • Page 266 4−3. Do−it−yourself maintenance Items Parts and tools S Bulb with same number and watt− age rating as original Light bulbs ( P. 314) S Phillips−head screwdriver S Automatic transmission fluid ® II or III DEXRON Power steering fluid level S Rag or paper towel ( P.
  • Page 267 4−3. Do−it−yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury observe the following precautions. When working on the engine compartment Keep hands, clothing, and tools away from the moving fan and engine drive belt.
  • Page 268 4−3. Do−it−yourself maintenance NOTICE If you remove the air cleaner Driving with the air cleaner removed may cause excessive engine wear due to dirt in the air. Also a backfire could cause a fire in the engine compart− ment. If the fluid level is low or high It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high.

  • Page 269: Hood

    4−3. Do−it−yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. The hood will pop up slightly. Pull up the hood catch lever and lift the hood. CAUTION Pre−driving check Check that the hood is fully closed and locked.

  • Page 270: Engine Compartment

    4−3. Do−it−yourself maintenance Engine compartment Washer fluid tank ( P. 286) Engine oil filler cap ( P. 275) Power steering fluid reservoir ( P. 282) Brake fluid reservoir ( P. 280) Radiator cap Fuse box ( P. 303) Engine oil level dipstick ( P.
  • Page 271 4−3. Do−it−yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil Park the vehicle on level gro und. After turning off the engine, wait a few minutes for the oil to drain back into the bottom of the engine.
  • Page 272 4−3. Do−it−yourself maintenance Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
  • Page 273 Oil consumption: Max. 1.1 qt./600 miles, 0.9 lmp.qt./600 miles (1.0 L per 1000 km) If you consume more than 1.1 qt. (1.0 L, 0.9 lmp.qt.) every 600 miles (1000 km), contact your Toyota dealer.
  • Page 274 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
  • Page 275 If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system. Coolant selection Only use “Toyota Super Long Life Coolant”...
  • Page 276 Check the radiator and condenser and clear any foreign objects. If either of the above parts are ex tremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION When the engine is hot Do not touch the radiator or condenser as they may be hot and may cause burns.
  • Page 277 4−3. Do−it−yourself maintenance Adding fluid Make sure to check the fluid type and prepare the necessary items. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items Clean funnel Turn the engine switch off. Depress the brake pedal 20 times or more. Remove the reservoir cap.
  • Page 278 4−3. Do−it−yourself maintenance Power steering fluid Fluid level The fluid level should be within the appropriate range. Full (when cold) Add fluid (when cold) Full (when hot) Add fluid (when hot) Hot: Vehicle has been driven around 50 mph (80 km/h) for 20 minutes, or slightly longer in frigid temperatures.
  • Page 279 4−3. Do−it−yourself maintenance CAUTION Checking the fluid level Take care, as the reservoir may be hot. NOTICE When adding fluid Avoid overfilling, or the power steering may be damaged. After replacing the reservoir cap Check the steering box case, vane pump and hose connections for leaks or damage.
  • Page 280 Checking battery condition Check the battery condition using the indicator color. Blue: Good condition White: Charging is necessary. Have the vehicle inspected by your Toyota dealer. Red: Not working properly, have the battery checked by your Toyota dealer. Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive.
  • Page 281 4−3. Do−it−yourself maintenance CAUTION Where to safety charge the battery Always charge the battery in an open area. Do not charge the battery in a garage or closed room where there is not sufficient ventilation. How to recharge the battery Only perform a slow charge (5A or less).
  • Page 282 4−3. Do−it−yourself maintenance Washer fluid If any washer does not work, the washer tank may be empty. Open the lid. Add washer fluid. NOTICE Do not use any fluid other than washer fluid Do not use soapy water or engine antifreeze instead of washer fluid. Doing so may cause streaking on the vehicle’s painted surfaces.

  • Page 283: Tires

    The tire pressure warning system Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. ( P. 334)
  • Page 284 A tire goes flat repeatedly or c annot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. Tire life Any tire over 6 years old must be checked by a qualified technician even if they have seldom or never been used or damage is not obvious.
  • Page 285 4−3. Do−it−yourself maintenance Routine tire inflation pressure checks The tire pressure warning system doe s not replace routine tire inflation pressure checks. Make su re to check tire inflation pressure as part of your routine of daily vehicle checks. Maximum load of tire Check that the maximum load of the re placed tire is greater than 1/2 of the Gross Axle Weight Ratings (GAWR) of either the front axle or the rear axle, whichever is greater.
  • Page 286 4−3. Do−it−yourself maintenance Tire pressure warning system certification For vehicles sold in U.S.A. NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 287 Do not mix tires of different makes, models, tread patterns or tread− wear. Do not use tire sizes other than those recommended by Toyota. Do not mix radial, bias−belted, or bias−ply tires. Do not mix summer, all season and winter tires.

  • Page 288: Tire Inflation Pressure

    4−3. Do−it−yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis− played on the tire and loading information label. ( P. 370)
  • Page 289 Driving with incorrect tire inflation pressure may result in the following: Reduced fuel efficiency Reduced driving comfort and tire life Reduced safety Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer.
  • Page 290 4−3. Do−it−yourself maintenance Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: Check only when the tires are cold. If your vehicle has been parked for at least 3 hours and has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
  • Page 291 4−3. Do−it−yourself maintenance NOTICE When inspecting and adjusting tire inflation pressure Be sure to reinstall the tire valve caps. Without the valve caps, dirt or mo isture could get into the valve and cause air leakage, which could result in an accident. If the caps have been lost, replace them as soon as possible.

  • Page 292: Wheels

    When replacing wheels The wheels of your Toyota are equipped with sensors that allow the tire pressure warning system sensors to provide advanced warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, the tire pressure warning valve and transmitter must be switched over from the old wheels.
  • Page 293 Because tire repair or replacement may affect the tire pressure warn− ing valves and transmitters, make su re to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.

  • Page 294: Air Conditioning Filter

    4−3. Do−it−yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. Removal method Turn the engine switch off. Open the glove box. Slide off the damper. Push in each side of the glove box to disconnect the claws.
  • Page 295 2 minutes at 72 psi (500 kPa, 5.0 kgf/cm or bar). If it is not available, have the filter cleaned by your Toyota dealer. Replacement method Remove the air conditioning filter and replace it with a new one. The “ UP” marks shown on the...
  • Page 296 4−3. Do−it−yourself maintenance Checking interval Inspect, clean and replace the air conditioning filter according to the mainte− nance schedule. In dusty areas or areas with heavy traffic flow, more fre− quent cleaning or early replacement may be required. (For scheduled maintenance information, please refer to the “Scheduled Maintenance Guide”...

  • Page 297: Key Battery

    4−3. Do−it−yourself maintenance Key battery Replace the battery with a new one if it is discharged. You will need the following items: l Small Phillips−head screwdriver l Lithium battery CR1616 Replacing the battery Remove the screw and cover. Push the cover in the arrow direction.
  • Page 298 The wireless remote control will not function properly. The operational range is reduced. Use a CR1616 lithium battery Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. Replace only with the same or equivalent type recommended by your Toyota dealer.

  • Page 299: Checking And Replacing Fuses

    4−3. Do−it−yourself maintenance Checking and replacing fuses If any of the electrical componen ts do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the engine switch off. The fuses are located in the following places. To check the fuses, follow the instructions below.
  • Page 300 4−3. Do−it−yourself maintenance Under the instrument panel Remove the lid. After a system failure, see “Fuse layout and amperage rat− ings” ( P. 307) for details about which fuse to check.
  • Page 301 4−3. Do−it−yourself maintenance Remove the fuse with the pull− out tool. Check if the fuse has blown.
  • Page 302 4−3. Do−it−yourself maintenance Type A Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type B Normal fuse Blown fuse Replace it with one of an appropriate amperage rating.
  • Page 303 4−3. Do−it−yourself maintenance Fuse layout and amperage ratings Engine compartment Type A 16 17 18 22 23 Type B (if equipped)
  • Page 304 4−3. Do−it−yourself maintenance Fuse Ampere Circuit SPARE 10 A Spare fuse SPARE 15 A Spare fuse TOWING TAIL 15 A Trailer lights OFFROAD LP 15 A Offroad lamp Stop lights, high mounted stop− light, anti−lock brake system, trac− tion control system, active traction control system, vehicle stability STOP 10 A...
  • Page 305 4−3. Do−it−yourself maintenance Fuse Ampere Circuit RADIO NO.1 20 A Audio system Air conditioning system, multiplex communication system, SRS air− ECU−B 10 A bag system, front passenger occu− pant classification system ALT−S 7.5 A Charging system HORN 10 A Horn Multiport fuel injection system/ sequential multiport fuel injection A/F HEATER...
  • Page 306 4−3. Do−it−yourself maintenance Fuse Ampere Circuit IGN and GAUGE, multiport fuel injection system/sequential multi− 30 A port fuel injection system, starting system Anti−lock brake system, vehicle sta− bility control system, traction con− ABS SOL 30 A trol system, active traction control system, AUTO LSD system AM1, AC 115V, DEFOG, DEFOG 120 A...
  • Page 307 4−3. Do−it−yourself maintenance Under the instrument panel 5678 91011 Fuse Ampere Circuit Multiport fuel injection system/ sequential multiport fuel injection system, anti−lock brake system, vehicle stability control system, 10 A traction control system, active trac− tion control system, AUTO LSD system, SRS airbag system, front passenger occupant classification system...
  • Page 308 4−3. Do−it−yourself maintenance Fuse Ampere Circuit Anti−lock brake system, vehicle sta− bility control system, traction con− trol system, active traction control system, AUTO LSD system, multi− ECU−IG 10 A port fuel injection system/sequen− tial multiport fuel injection system, cruise control system, back door lock system, shift lock system, mul−...
  • Page 309 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix.

  • Page 310: Light Bulbs

    You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
  • Page 311 4−3. Do−it−yourself maintenance Rear bulb locations Stop/tail and rear side marker lights Back−up lights Rear turn signal lights License plate lights Replacing light bulbs Headlights Unplug the connector.
  • Page 312 4−3. Do−it−yourself maintenance Remove the rubber cover. Release the bulb retaining spring. Remove the bulb. To install a new bulb, align the tabs of the bulb with the cutouts of the mounting hole.
  • Page 313 4−3. Do−it−yourself maintenance Front turn signal/parking and front side marker lights Turn the bulb base counterclock− wise. Remove the light bulb.
  • Page 314 4−3. Do−it−yourself maintenance Back−up lights, stop/tail and rear side marker lights and rear turn signal lights Open the back door and remove the cover. Using a flathead screwdriver which is wrapped with a cloth. Turn the bulb bases counter− clockwise. Back−up light Stop/tail and rear side marker lights...
  • Page 315 Remove the screws and cover. Remove the light bulb. Lights other than the above If any of the lights listed below has burnt out, have it replaced by your Toyota dealer. Outside rear view mirror illumination lights High mounted stoplight...
  • Page 316 Water has built up inside the headlight. LED high mounted stoplight The high mounted stoplight consists of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. CAUTION Replacing light bulbs Turn off the headlights.

  • Page 317: 5−1. Essential Information

    If your vehicle needs to be towed If towing is necessary, we recommen d having your vehicle towed by your Toyota dealer or a commerci al towing service, using a lift−type truck or a flat bed truck. Use a safety chain system for all to wing, and abide by all state/pro−...
  • Page 318 5−1. Essential information Emergency towing procedure The engine switch must be in the ACC (engine off) or the ON (engine running) position. 4WD models with an automatic transmission: Shift the front−wheel drive control lever in H2. 4WD models with a manual transmission: Unlock the center differ− ential.
  • Page 319 5−1. Essential information Towing with a sling−type truck NOTICE To prevent body damage Do not tow with a sling−type truck, either from the front or rear. Towing with a wheel lift−type truck from the front Use a towing dolly under the rear wheels.
  • Page 320 5−1. Essential information Towing with a wheel lift−type truck from the rear 2WD models Turn the engine switch to the ACC position. 4WD models Vehicles with a manual transmis− sion: Use a towing dolly under the front wheels. Vehicles with an automatic trans− mission: When not using a tow−...
  • Page 321 5−1. Essential information Using a flat bed truck If your Toyota is transported by a Front flat bed truck, it should be tied down at the locations shown in the illustration. If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45 .

  • Page 322: If You Think Something Is Wrong

    5−1. Essential information If you think something is wrong If you notice any of the followin g symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms l Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)

  • Page 323: Fuel Pump Shut Off System

    5−1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an air− bag inflates upon collision, the fuel pump shut off system stops sup− plying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.

  • Page 324: Event Data Recorder

    SRS airbag deployment data l SRS airbag system diagnostic data Your Toyota’s Electronic Contro l Unit (ECU) may contain another EDR. There are a variety of driving situations which include activating the VSC under which the VSC EDR will record certain information.
  • Page 325 EDR does not record sound data such as conversation between passengers. Disclosure of the data Toyota will not disclose the data re corded in an EDR to a third party except when: l An agreement from the vehicle’s ow n er (or the leasing company for...

  • Page 326: If A Warning Light Turns On Or A Warning Buzzer Sounds

    Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys− tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details...
  • Page 327 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light/Details Warning light Malfunction indicator lamp Indicates a malfunction in: S The electronic engine control system;...
  • Page 328 5−2. Steps to take in an emergency Warning light Warning light/Details ABS warning light (U.S.A.) Indicates a malfunction in: S The ABS; or S The brake assist system. (Canada) VSC/TRAC warning light Indicates a malfunction in: S The vehicle stability control system; S The traction control system;...
  • Page 329 Indicates low tire inflation inflation pressure. pressure. (including spare tire) S When the light stays on Have the system after blinking for 1 checked by your minute: Indicates a mal− Toyota dealer. function in the tire pres− sure warning system.
  • Page 330 5−2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Low fuel level warning Refuel the vehicle. light Low level of fuel. Engine oil replacement reminder light S Illuminates for about 3 Check the engine oil, seconds and then flashes and change if neces−...
  • Page 331 If it is, tighten it securely. The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. Front passenger detection sensor and passenger seat belt reminder If luggage or other load is placed on the front passenger seat, depending on its weight, the reminder light to flash and buzzer to sound.
  • Page 332 Toyota dealer. After changing the engine oil (U.S.A. only) Make sure to reset the oil maintenance data. ( P. 278) Customization that can be configured at Toyota dealer The vehicle speed linked seat belt reminder buzzer can be disabled. (Customizable features...
  • Page 333 5−2. Steps to take in an emergency CAUTION Maintenance of the tire Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
  • Page 334 Check the tires. If the tire is flat, change to the spare tire and have the flat tire repaired by the nearest Toyota dealer. Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose control of the steering wheel or the brakes.

  • Page 335: If You Have A Flat Tire

    5−2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. Before jacking up the vehicle l Stop the vehicle on a hard, flat surface. l Set the parking brake. l Shift the shift lever to P (automatic transmission) or R (manual transmission).
  • Page 336 5−2. Steps to take in an emergency Taking out the jack and tool bag Remove the cover and loosen the strap. Tighten Loosen Taking out the spare tire Vehicles with an aluminum wheel, remove the wheel orna− ment. To protect the wheel and wheel ornament, place a rag between the wrench and the wheel orna−...
  • Page 337 5−2. Steps to take in an emergency Turn the hold−down nuts counter− clockwise with the wheel nut wrench and remove them. Replacing a flat tire Chock the tires. Wheel Flat tire chock positions Behind the Left− rear right− hand hand side side tire Front...
  • Page 338 5−2. Steps to take in an emergency Aluminum wheel Remove the wheel ornament using the wheel nut wrench as shown. To protect the wheel and wheel ornament, place a rag between the wrench and the wheel orna− ment, as shown in the illustra− tion.
  • Page 339 5−2. Steps to take in an emergency Position the jack at the correct jack point as shown. Front Front Rear Make sure the jack is positioned on a level and solid place. Assemble the jack handle exten− sion as shown. Be sure to tighten each bolt securely.
  • Page 340 5−2. Steps to take in an emergency Installing the tire Remove any dirt or foreign mat− ter from the wheel contact sur− face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
  • Page 341 5−2. Steps to take in an emergency Lower the vehicle. Firmly tighten each nut two or three times in the order shown in the illustration. Tightening torque: 85 ft⋅lbf (113 N⋅m, 11.5 kgf⋅m) Reinstall the wheel ornament. Aluminum wheel...
  • Page 342 5−2. Steps to take in an emergency Steel wheel Stowing the flat tire, jack and all tools Install the flat tire in the reverse order of removal. Tightening torque: 65 ft⋅lbf (88 N⋅m, 8.9 kgf⋅m) Stow the tools and jack securely. CAUTION Using the jack Improper use of the jack may lead to death or injuries due to the vehicle...
  • Page 343 5−2. Steps to take in an emergency CAUTION Using the jack Use a jack stand if it is necessary to get under the vehicle. Take particular care when lowering the vehicle to ensure that no one working on or near the vehicle will be injured. Using the jack handle Tighten all the square head bolts securely to prevent the extension parts from coming apart unexpectedly.
  • Page 344 When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled cor− rectly.

  • Page 345: If The Engine Will Not Start

    One of the following may be the cause of the problem. l One or both of the battery terminals may be disconnected. l The battery may be discharged. ( P. 353) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown.

  • Page 346: If The Shift Lever Cannot Be Shifted From P

    (a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.

  • Page 347: If You Lose Your Keys

    5−2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using one of the master keys and the key number stamped on your key number plate. ( P. 28) If you lose all your master keys.

  • Page 348: If The Vehicle Battery Is Discharged

    You can call your Toyota dealer, Roadside Assistance or Toyota Customer Service Assistance. If you have a set of jumper (or boo ster) cables and a second vehi− cle with a 12−volt battery, you can jump start your Toyota following the steps below. Connecting the jumper cables If required, remove all vent plugs from the booster and dis−...
  • Page 349 If removed, replace all the battery vent plugs. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. Avoiding a discharged battery Turn off the headlights and the audio system while the engine is turned off.
  • Page 350 5−2. Steps to take in an emergency CAUTION Battery precautions The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre− cautions when handling the battery. When working with the battery, always wear safety glasses and take care not to allow any battery fluids (acid) to come into contact with skin, clothing or the vehicle body.

  • Page 351: If Your Vehicle Overheats

    If the fan is operating: Wait until the temperature of the engine (shown on the instrument cluster) begins to fall and then stop the engine. If the fan is not operating: Stop the engine immediately and call your local Toyota dealer.
  • Page 352 Note that water draining from the air conditioning is normal if it has been used. Add engine coolant if required. Water can be used in an emer− gency if engine coolant is unavailable. ( P. 366) Have the vehicle checked at your nearest Toyota dealer as soon as possible.
  • Page 353 5−2. Steps to take in an emergency Overheating If you observe the following, your vehicle may be overheating. The engine coolant temperature gauge enters the red zone or a loss of power is experienced. Steam is coming from under the hood. CAUTION To prevent an accident or injury when inspecting under the hood of your vehicle...

  • Page 354: If The Vehicle Becomes Stuck

    5−2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the engine. Set the parking brake and put the shift lever in P (vehicles with an automatic transmission) or N (vehicles with a manual transmission).
  • Page 355 5−2. Steps to take in an emergency CAUTION When attempting to free a stuck vehicle If you choose to rock the vehicle back and forth to free it, make sure the sur− rounding area is clear, to avoid striki ng other vehicles, objects or persons. The vehicle may also lunge forward or lunge back suddenly as it becomes free.

  • Page 356: 6−1. Specifications

    6−1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 183.9 in. (4670 mm) Overall width 75.0 in. (1905 mm) 2WD models 71.3 in. (1810 mm) Overall height* 4WD models 72.0 in. (1830 mm) Wheelbase 105.9 in. (2690 mm) Front tread 63.2 in.
  • Page 357 Vehicle identification number The vehicle identificati on number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
  • Page 358 6−1. Specifications Engine Model 1GR−FE Type 6−cylinder V type, 4−cycle, gasoline Bore and stroke 3.70 3.74 in. (94.0 95.0 mm) Displacement 241.4 cu.in.(3956 cm Drive belt tension Automatic adjustment Fuel Fuel type Unleaded gasoline only Octane rating 91 (Research octane number 96) or higher Fuel tank capacity 19.0 gal.
  • Page 359 5.5 qt. (5.2 L, 4.6 Imp.qt.) Without filter 5.2 qt. (4.9 L, 4.3 Imp.qt.) Oil grade ILSAC multigrade engine oil Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the grade and viscosity shown below. Recommended oil viscosity Outside temperature *: 5W−30 is an oil that provides optimal levels of fuel efficiency.
  • Page 360 Capacity Vehicles with a manual transmission 9.9 qt. (9.4 L, 8.3 Imp. qt.) Use either of the following. S “Toyota Super Long Life Coolant” S Similar high−quality ethylene glycol−based non−silicate, non−amine, non−nitrite, and Coolant type non−borate coolant with long−life hybrid organic acid technology Do not use plain water alone.
  • Page 361 Toyota dealer. NOTICE Automatic transmission fluid type Using automatic transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the automatic transmission of your vehicle.
  • Page 362 6−1. Specifications Manual transmission Gear oil capacity (Reference) 1.9 qt. (1.8 L, 1.6 Imp.qt.) Gear oil type Gear oil API GL−4 or GL−5 Recommended gear oil viscosity SAE 75W−90 Clutch Clutch free play 0.6 in. (5 15 mm) Fluid type FMVSS No.
  • Page 363 6−1. Specifications Brakes Pedal clearance 2.1 in. (54 mm) Min. Pedal free play 0.04 0.24 in. (1 6 mm) Brake pad wear limit 0.04 in. (1.0 mm) Parking brake lining wear limit 0.04 in. (1.0 mm) Parking brake lever travel 5 —...
  • Page 364 6−1. Specifications Tires and wheels Tire size P265/75R16 114T, P265/70R17 113S Front tires: 32 psi (220 kPa, 2.2 kgf/cm or bar) Tire inflation pressure Rear tires: (Recommended cold tire 32 psi (220 kPa, 2.2 kgf/cm or bar) inflation pressure) Spare tire: 32 psi (220 kPa, 2.2 kgf/cm or bar) Wheel size...
  • Page 365 6−1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights — 60/55 Front turn signal/ parking and front side — 21/5 marker lights Outside rear view mirror illumination —5 C Exterior lights Rear turn signal lights 5674 Stop/tail and rear side 7443 21/5 marker lights...

  • Page 366: Fuel Information

    ASTM D4814 in the U.S.A. and CGSB3.5−M93 in Canada. Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. If premium gasoline is not available If 91 rating gasoline cannot be obtained, you may use unleaded gasoline with an octane rating as low as 87 (Research Octane Number 91).
  • Page 367 Toyota allows the use of oxygenate blended gasoline where the oxygenate content is up to 10% ethanol or 15% MTBE. If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 91. Toyota does not recommend the use of gasoline containing methanol.
  • Page 368 6−1. Specifications NOTICE Notice on gasoline quality Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s three−way catalytic converters causing the emission control system to malfunction. Do not use gasohol other than that stated here. Other gasohol may cause fuel system damage or vehicle performance problems.

  • Page 369: Tire Information

    6−1. Specifications Tire information Typical tire symbols 5 / 70 R17 11 3 S M P 2 6 Tire size ( P. 377) DOT and Tire Identification Number (TIN) ( P. 376) Location of treadwear indicators ( P. 378) Tire ply composition and materials Plies are layers of rubber−coated parallel cords.
  • Page 370 6−1. Specifications Radial tires or bias−ply tires A radial tire has RADIAL on the sidewall. A tire not marked RADIAL is a bias−ply tire. Summer tire or all season tire ( P. 289) An all season tire has M+S on the sidewall. A tire not marked M+S is a summer tire.
  • Page 371 6−1. Specifications Tire size Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol...
  • Page 372 U.S.A. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answ er any questions you may have as you read this information. DOT quality grades...
  • Page 373 6−1. Specifications Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested und er controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and a half (1 − 1/2) times as well on the government course as a tire graded 100.
  • Page 374 6−1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure. Glossary of tire terminology Tire related term Meaning...
  • Page 375 6−1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as Occupant distribution specified in the third column of Table 1 below The combined weight of installed regular production options weighing over 5 lb.
  • Page 376 6−1. Specifications Tire related term Meaning The surface area of the rim not covered by the Weather side inflated tire The part of the tire that is made of steel wires, wrapped or reinforced by ply cords and that is Bead shaped to fit the rim A breakdown of the bond between components...
  • Page 377 6−1. Specifications Tire related term Meaning The parting of the innerliner from cord material Innerliner separation in the carcass (a)The sidewall that cont a ins a whitewall, bears white lettering, or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same molding on Intended outboard the other sidewall of the tire, or...
  • Page 378 6−1. Specifications Tire related term Meaning A layer of rubber−coated parallel cords A parting of rubber compound between Ply separation adjacent plies A mechanical device made of rubber, chemicals, fabric and steel or other materials, that, when mounted on an automotive wheel, Pneumatic tire provides the traction and contains the gas or fluid that sustains the load...
  • Page 379 6−1. Specifications Tire related term Meaning That portion of a tire that comes into contact Tread with the road A tread section running circumferentially Tread rib around a tire Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear designed to give a visual indication of the...

  • Page 380: 6−2. Customization

    Programming these preferences requires specialized equipment and may be performed by an autho− rized Toyota dealership. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customized Item Function Default setting...
  • Page 381 6−2. Customization Customized Item Function Default setting setting Driver ’s door unlocked in All doors Door lock one step, all Unlocking using a key unlocked in ( P. 33) doors one step unlocked in two steps Automatic Time elapsed before 0 seconds light off sys−...

  • Page 382: Items To Initialize

    6−2. Customization Items to initialize The following items must be init ialized for normal system operation in cases such as after the battery is reconnected, or maintenance is performed on the vehicle. Item When to initialize Reference Engine oil maintenance After changing engine oil P.

  • Page 383: Reporting Safety Defects For U.s. Owners

    National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll−free: 1−800−331−4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defec t exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 384: Abbreviation List

    Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Two Wheel Drive Four Wheel Drive Anti−Lock Brake System Accessory AI−SHIFT Artificial Intelligence shifting Automatic Locking Retractor A−TRAC Active Traction Control AUTO LSD Automatic Limited Slip Differential Child Restraint System English/U.S. Customary System and metric Electronic Control Unit Event Data Recorder Emergency Locking Retractor...
  • Page 385 ABBREVIATIONS MEANING TPMS Tire Pressure Warning System TRAC Traction Control Treadwear indicators Vehicle Identification Number Vehicle Stability Control...

  • Page 386: Alphabetical Index

    Alphabetical index Alphabetical index MP3/WMA disc ..... 208 A/C ..........184 Optimal use ......217 ABS ........... 156 Portable music player ... 222 Access doors ......36 Radio........194 Accessory meter ...... 130 Type ........191 Active traction control system ........148 AUTO LSD system ....
  • Page 387 Alphabetical index Seat belts ......261 Care Exterior ......... 258 Clinometer ........ 130 Interior ........260 Clock ........237 Seat belts ......261 Clutch start cancel switch..155 Cargo capacity ......165 Compass ......130, 252 Cargo net hook ......250 Condenser ........
  • Page 388 Alphabetical index Preparing and checking before Emergency, in case of Blown fuse......303 winter ........169 If the engine will not start ..350 Warning light ....332, 334 If the shift lever cannot be Engine oil maintenance shifted from P...... 351 data .........
  • Page 389 Alphabetical index Fuel door ........64 Jack Positioning the jack ....342 Fuel filler door ......64 Replacing the wheel ....340 Fuel pump shut off system ..328 Fuses Jack handle ......342 Fuses........303 Locations ...... 307, 311 Keyless entry......
  • Page 390 Alphabetical index Maintenance Parking assist ......139 Do−it−yourself maintenance ... 269 Parking brake ......122 General maintenance .... 265 Parking lights Maintenance data....362 Replacing light bulbs ..... 317 Maintenance requirements..263 Switch ........131 Vehicle exterior ..... 258 Wattage......... 371 Vehicle interior ......
  • Page 391 Alphabetical index Seat belts Shift lock system ..... 351 Adjustment ......51 Side airbags........ 73 ALR ........53 Side doors ........33 Automatic Locking Retractor .. 53 Side marker lights Child restraint system Replacing light bulbs ..317, 318 installation ......93 Switch........
  • Page 392 Alphabetical index Intuitive parking assist Tools ......... 340 switch ........139 Total load capacity ....168 Headlights switch ....131 Towing Light switch ......131 Dinghy towing ....... 182 Power door lock switch ... 33 Emergency towing ....322 Power window switch ....62 Trailer towing ......
  • Page 393 Alphabetical index Low fuel level......334 Low tire inflation pressure ..334 Malfunction indicator lamp..332 Open door ......334 Seat belt ....... 334 Seat belt pretensioner system........ 332 SRS ........332 SRS airbag system....332 Tire pressure ......334 Tire pressure warning system........

  • Page 394: What To Do If

    What to do if... What to do if... A tire punctures If you have a flat tire P. 340 P. 350 If the engine will not start The engine does not start Engine immobilizer system P. 6 8 If the battery is discharged P.
  • Page 395 What to do if... Instrument cluster Center panel...
  • Page 396 What to do if... nWarning lights Unengaged Park warning Brake system warning light light P. 331 P. 333 Charging system warning VSC/TRAC warning light light P. 332 P. 333 Tire pressure warning Low engine oil pressure light warning light P. 332 P.
  • Page 397 Memo...
  • Page 398 Memo...
  • Page 399 Memo...
  • Page 400 (L, Imp.qt.) Engine oil capacity With filter 5.5 (5.2, 4.6) (Drain and refill) Without filter 5.2 (4.9, 4.3) Toyota Genuine Motor Oil or equivalent Oil grade: P. 365 ILSAC multigrade engine oil Engine oil type Recommended oil viscosity: SAE 5W−30...

Table of Contents

Save PDF
