Overload cut-out

The appliance is equipped with an
overload cut-out, which switches the
appliance off if it starts to overheat,
protecting the unit from damage.
When this happens, the overload cut-
out reset button (Fig. 1/N) jumps out.
If this happens, proceed as follows.
1
Failure to follow this procedure can
result in damage to the appliance,
which is not covered by the guarantee.
0 Allow the appliance to cool down for
at least 15 seconds.
0 Turn the speed selector (Fig. 1/I) left to
"0" position (Fig. 16/①).
0 Remove the mix container or all-pur-
pose bowl (Fig. 16/② and ③), as descri-
bed at the relevant point in these
operating instructions.
0 Remove the mains plug from the
socket (Fig. 17/①).
0 Lay the appliance on its back to gain
access to the bottom (Fig. 17/②).
0 Press the overload cut-out reset button
(Fig. 1/N) on the bottom of the appli-
ance. If the appliance has cooled down
sufficiently, the button will engage
(Fig. 17/③). If it jumps back out, allow
the appliance to cool down a little lon-
ger, then repeat the process.
0 Once the reset button has engaged,
put the appliance back to its normal
working position (Fig. 18/①).
0 Plug the power lead back into the
mains socket (Fig. 18/②).
0 Replace the mix container or all-pur-
pose bowl (Fig. 18/③ and ④), as descri-
bed at the relevant point in these
operating instructions.
0 The appliance is now ready for use
again. Turn the speed selector to the
right to the required position (Fig.
18/⑤) and continue with the function
that was interrupted.
Mixer
The mixer is used to prepare a wide
range of mixed drinks, to crush ice,
reduce fruit and vegetables, etc.
Preparing mixer
In order to fit the mix container, the
safety cover for the mixer drive (figs.
1/T and 4) must be removed.
0 Turn the safety cover clockwise and
remove.
– The red warning lamp (fig. 4/a)
flashes.
0 Place the mix container (figs. 1/B and
2) on the mixer drive (arrow
arrow ) and turn counter-clock-
wise to the stop. The mix container is
heard to engage. The two black arrows
must coincide.
– The red warning lamp (fig. 4/a)
extinguishes.
0 Only KM 850: Place mixer cover (figs.
1/C and 3) on mix container and turn
until the nose of the cover is directly
above the handle. The cover can be
heard to engage.
The mixer can only be switched on
3
when the container and cover are fit-
ted correctly.
0 Only KM 880: Place mixer cover on
mix container.
The mixer can only be switched on
3
when the container is fitted correctly.
0 Fit closing cover (fig. 1/D) and lock.
Operating mixer
0 Open cover (fig. 1/C) and fill all ingre-
dients required in the container.
Caution: Do not exceed maximum fill-
ing volume of 1.5 litres!
During operation further ingredients
3
can be added through the filling inlet.
The sealing cover (fig. 1/D) can also be
used as a filling beaker for this pur-
pose. Close the filling inlet again
