Seat

To remove the seat
1. Insert the key into the seat lock,
and then turn it clockwise.
1. Seat lock
2. Unlock.
2. Pull the seat off.
To install the seat
1. Insert the projections into the seat
holders as shown.
INSTRUMENT AND CONTROL FUNCTIONS
EAU36692
1. Seat holder
2. Projection
2. Push the center of the seat down
to lock it in place.
3. Remove the key.
NOTE:
Make sure that the seat is properly se-
cured before riding.

Adjusting the front fork

This front fork is equipped with spring
preload adjusting bolts, rebound damp-
ing force adjusting screws and com-
pression damping force adjusting bolts.
Always adjust both fork legs equal-
ly, otherwise poor handling and loss
of stability may result.
Spring preload
1. Spring preload adjusting bolt
To increase the spring preload and
thereby harden the suspension, turn
the adjusting bolt on each fork leg in di-
rection (a). To decrease the spring pre-
3-15
