Unlocking Your Scanner - Avision AV620CS PLUS User Manual

2.2

UNLOCKING YOUR SCANNER

To protect the scanning unit from damage during
transportation, a lock switch is designed under the scanner
to keep the scanning unit from moving.To unlock the
scanner, please first place the scanner as Fig. 2-1 and
locate the lock switch at the corner and then move the lock
switch to the "Unlock" position as shown in below.
Note: Likewise, if next time you need to transport the scanner, be
sure to move the lock switch to the "Lock" position. Otherwise,
there may be some damage to the scanning unit during
transportation and the manufacturer is therefore not responsible
for this.
2-2
lock
unlock
Figure 2-1 Unlocking the Scanner
AV620CS Plus
