2. Scanner Installation

2.1 Unlocking your scanner

To protect the scanning unit from damage during transportation,
a lock switch is designed to keep the scanning unit from
moving. To unlock the scanner, move the lock switch to the
unlock position as shown in Fig. 2-1.
Scanning unit at
this position
before locking the
scanner
Figure 2-2 Home position
Note: If the scanning unit is not located at the front of the
scanner before transporting the scanner, be sure to do the
follows:
1. Turn on the scanner. The scanning unit should move to
the front of the scanner.
2. Press the lock switch down to the "Lock position".
3. The scanner is now ready to transport.
Figure 2-1 Unlocking the Scanner
