Connecting your video through extra equipment
Connecting your video to the satellite system
Before you start, unplug all the equipment from the mains supply
3
Make sure the satellite receiver is switched to Sky One.
Connecting your video to the hi-fi system - Option 1
Before you start, unplug all the equipment from the mains supply.
4
You can also use a scart lead to improve picture and sound quality from your video.
Connecting your video to the hi-fi system - Option 2
Before you start, unplug all the equipment from the mains supply
5
Television
AC 230V
5 0 H z
Television
AC 230V
5 0 H z
Television
AC 230V
5 0 H z
Aerial
Video
Satellite
Hi-fi
Video
L
R
Hi-fi
Video
You can use this connection
if your video has two scart
sockets. This will improve
sound and picture quality
when you are recording
from satellite.
To use this function, see
page 9
Aerial
Plug a phono cable into the
'Audio L/R' socket on the
back panel and into the
audio socket on any audio
amplifier, if needed. If your
video does not have this
conection, see below
(Option 2).
Aerial
Plug a scart to phono cable
into the 'AVI' socket on the
back panel and into the
audio socket on any audio
amplifier, if needed.
