This manual conTains The illusTraTed parTs lisT for models:
sTc48V-22fs
sTc48V-23cV
sTc52V-22fX
sTc52V-25cV
sTc52V-25cV-efi
sTc61V-23fX
sTc61V-25cV
sTc61V-26cV-efi
sTc61V-27Bs
© 2013
Scag Power Equipment
Division of Metalcraft of Mayville, Inc.
30
29
35
with a serial number of J8700001 to J8799999
with a serial number of J8800001 to J8899999
with a serial number of J9000001 to J9099999
with a serial number of J9100001 to J9199999
with a serial number of K4300001 to K4399999
with a serial number of J9200001 to J9299999
with a serial number of J9300001 to J9399999
with a serial number of J9400001 to J9499999
with a serial number of J9500001 to J9599999
ILLUSTRATED
PARTS
MANUAL
Model STC
Tiger Cat
Part No. 06274
Printed 12/13
Printed in USA
Advertisement
Table of Contents
Related Manuals for Scag Power Equipment STC Tiger Cat
Summary of Contents for Scag Power Equipment STC Tiger Cat
- Page 1 J9300001 to J9399999 sTc61V-26cV-efi with a serial number of J9400001 to J9499999 sTc61V-27Bs with a serial number of J9500001 to J9599999 © 2013 Part No. 06274 Scag Power Equipment Printed 12/13 Division of Metalcraft of Mayville, Inc. Printed in USA...
-
Page 3: Table Of Contents
Table of contents Table of contents 48V & 52V cuTTer decKs ..........................2 61V cuTTer decK ............................4 cuTTer decK conTrols ..........................6 sheeT meTal componenTs ........................8 sTc foldaBle roll-oVer proTecTion sYsTem ................10 sTc suspension seaT ..........................12 sTc sofT ride seaT W/BlacK armresTs .....................13 driVe sYsTem componenTs ........................14 enGine &... -
Page 4: 48V & 52V Cutter Decks
section 8 48V & 52V cuTTer decKs 64 60 62 61 59 58 66 63 6 7 8 5 25 STC 2012 CD4852 * 52" cutter deck has a notch for anti-scalp roller... - Page 5 section 8 48V & 52V cuTTer decKs ref. ref. part no. description 48 52 part no. description 48 52 43689 Idler Pivot 461854 Cutter Deck Velocity Plus 462359 Belt Cover Weldment RH (incl. #91) 461858 Cutter Deck Velocity Plus 462358 Belt Cover Weldment LH (incl.
-
Page 6: 61V Cutter Deck
section 8 61V cuTTer decK 64 60 62 61 "A" 59 58 66 63 "A" 2 80 6 7 8 5 25 STC 2012 CD61... - Page 7 section 8 61V cuTTer decK ref. ref. part no. description part no. description 461862 Cutter Deck Velocity Plus 483210 Idler Pulley, 5” Dia. 43687 Boss, Spring Anchor 48181 Idler Pulley, 5” Dia. 424371 Bracket, LH Spring Anchor 61V 424575 Belt Cover (61V) 481625-01 Wing Nut, 3/8-16 48926...
-
Page 8: Cutter Deck Controls
section 8 cuTTer decK conTrols CUTTER DECK STC 2006 CDC... - Page 9 section 8 cuTTer decK conTrols ref. part no. description 482624 Rod, Deck Lift Linkage 04020-28 Nut, Jam 1/2-20 LH Thread 481766 Rod End, 1/2-20 Female Thread 04050-10 Retaining Ring, 1/2” External “E” 483062 Slide, Deck Height Adjust 43487 Pin, Deck Lift 423463 Bracket, Cutting Height Adjustment 04001-22...
-
Page 10: Sheet Metal Components
section 8 sheeT meTal componenTs 18 19 7 8 20 STC 2011 SMC... - Page 11 Pin Retainer, Spring 451658 Yoke, Front Caster Wheel (61”) 481389 Spring 04001-134 Bolt, Hex Head 1/2-13 x 7-1/2” Battery (not available through Scag) 04001-167 Bolt, Hex Head 1/2-13 x 9-1/2” (61”) 423571 Battery Cover 43581 Sleeve - 48” & 52”...
-
Page 12: Stc Foldable Roll-Over Protection System
section 8 sTc foldaBle roll-oVer proTecTion sYsTem 2011 STC ROPS... - Page 13 section 8 sTc foldaBle roll-oVer proTecTion sYsTem ref. part no. description 462209 STC Foldable ROPS 484168 Pin Assembly (incl. #3 & #4) 484170 Spring, ROPS 484169 Clip, ROPS 04001-90 Bolt, Hex Head 1/2-13 x 3-1/4" 04021-19 Nut, Center Lock 1/2-13 484167 Spring Clip, ROPS 04021-19...
-
Page 14: Stc Suspension Seat
section 8 sTc suspension seaT ref. part no. description 922B Suspension Seat Assembly w/seat belt 484709 Armrest Kit, LH 484717 Seat Belt Kit 484711 Recliner Knob Kit 484710 Armrest Kit, RH 484712 Back Cover 481638 Seat Switch 484713 Track Kit 484714 Suspension Knob Kit 43572... -
Page 15: Stc Soft Ride Seat W/Black Armrests
section 8 sTc sofT ride seaT W/BlacK armresTs used on sTc48V-22fs & sTc61V-27Bs models ref. part no. description 484752 Seat Assembly 484754 Armrest Kit, LH 484527 Seat Belt Kit 484528 Back Cover 484755 Armrest Kit, RH 484529 Cushion Cover 481638 Seat Switch 482937 Track Kit, 6”... -
Page 16: Drive System Components
section 8 driVe sYsTem componenTs STC 2005 DSC... - Page 17 section 8 driVe sYsTem componenTs ref. part no. description 04021-09 Nut, Elastic Stop 3/8-16 04019-04 Nut, Serrated Flange 3/8-16 483087 Spring, Pump Idler 43286 Spacer 04001-22 Bolt, Hex Head 3/8-16 x 2-3/4” 461603 Idler Arm Assy., Pump Drive 04063-14 Key, 5 x 5 x 25mm 483172 Belt, Transmission 483415...
-
Page 18: Engine & Attaching Parts
section 8 enGine & aTTachinG parTs 2014 STC EAP... - Page 19 section 8 enGine & aTTachinG parTs ref. no. part no. description 484419 Engine, Kawasaki 22FS 484225 Engine, Kawasaki 22FX 484226 Engine, Kohler Command 484227 Engine, Kohler Command 484415 Engine, Kawasaki 23FX 485031 Engine, Kohler 25CV-EFI 484727 Engine, Kohler 26CV-EFI 484456 Engine, Briggs &...
-
Page 20: Steering Components
section 8 sTeerinG componenTs 29, 29A To Pump STC 2002 SSC... - Page 21 section 8 sTeerinG componenTs ref. part no. description 484376 Grip, Control Lever 462401 Handle Bar (Includes item 1) 04001-32 Bolt, Hex Head 3/8-16 x 1-1/4” 04030-04 Lockwasher, 3/8” 04041-07 Flatwasher, 3/8-.391 x .938 x .105" 04040-15 Flatwasher, 5/16-.375 x .875 x .083" 04060-01 Roll Pin, Spring 5/32 x 3/4”...
-
Page 22: Brake Components
section 8 BraKe componenTs 40 16 17 35 31 11 3 15 14 13 12 STC 2002 BSC... - Page 23 section 8 BraKe componenTs ref. part no. description 04019-06 Nut, Serr. Flange 1/2-13 48807 Spring 04001-08 Bolt, Hex Head 5/16-18 x 3/4” 04001-163 Bolt, Hex Head 1/2-13 x 3-3/4” 04001-52 Bolt, Hex Head 1/2-13 x 2-1/2” 04021-19 Nut, 1/2-13 Center Lock 482639 Wheel Motor, Parker 04063-25...
-
Page 24: Hydraulic System
section 8 hYdraulic sYsTem 3 45 20 19 STC 2011 HS... - Page 25 section 8 hYdraulic sYsTem ref. ref. part no. description part no. description 482643 Pump, BDP-10A-316 (LH) 48136-13 Clamp, .69" Max. / .25" Min. Dia. 482644 Pump, BDP-10A-419 (RH) 482800-02 Fitting, 9/16" O-Ring x 3/8" Hose 482266-01 Elbow, 90 Degree 9/16" O-Ring x 3/8" Hose 04019-03 Nut, Serr.
-
Page 26: Stc Fuel System
section 8 sTc fuel sYsTem To Fuel Pump To Engine Purge Port Tank Purge STC 2011 FS CARB TEIR 3... - Page 27 section 8 sTc fuel sYsTem ref. part no. description 484286 Fuel Cap w/ Tethered 484297 Fuel Cap w/Tethered - California Models Only (not shown) 484279-01 Tube, Fuel Tank Insert 462383 Fuel Tank RH Low Perm. (incl. #7 & #8) 04030-03 Lockwasher, 5/16"...
-
Page 28: Electrical System
section 8 elecTrical sYsTem STC 2011 ESKA... - Page 29 Throttle Control - Kohler (Qty 1) 481638 Switch, Seat 483599 Module, Interlock 04010-01 Screw, #10-32 x .5” Phillips Head 483665 Battery, 350CCA (Not Available Through Scag) 04001-44 Bolt, Hex Head 1/4-20 x .5” 04020-02 Nut, Hex 1/4-20 48029-15 Cable, Battery Black (negative) 48029-12...
-
Page 30: Electrical System - Kohler Efi
section 8 elecTrical sYsTem - Kohler efi STC 2014 ESCV-EFI... - Page 31 Voltmeter 481638 Switch, Seat 483599 Module, Interlock 04010-01 Screw, #10-32 x .5” Phillips Head 483665 Battery, 350CCA (Not Available Through Scag) 04001-44 Bolt, Hex Head 1/4-20 x .5” 04020-02 Nut, Hex 1/4-20 48029-15 Cable, Battery Black (negative) 48029-12 Cable, Battery Red (positive)
-
Page 32: Bdp-10A Hydraulic Pump Assembly
section 8 Bdp-10a hYdraulic pump assemBlY PORT "A" SIDE PORT "B" SIDE... - Page 33 section 8 Bdp-10a hYdraulic pump assemBlY ref. part no. description HG 70516 Housing Kit HG 70573 End Cap Kit HG 50641 Straight Headless Pin HG 50969 Hex Flange Bolt, M8-1.25 x 60mm HG 51232 Housing O-Ring HG 2513027 Charge Pump Kit HG 50273 Gerotor Assembly HG 9004101-1340...
-
Page 34: Replacement Decals And Information Plates
section 8 replacemenT decals and informaTion plaTes 48404 Hea vy- Duty Comm e rcial 481971 forWard 483838 reVerse WarninG 482100 WarninG insTall BelT coVer Before operaTinG machine 483900 read operaTor's manual 483402 STC 2013 RDP1... - Page 35 Decal, Front Footplate 483405 Decal, Discharge Chute 482549 Decal, Cutting Height Top Row of Holes 461983 Spanish Decal Kit, STC / STWC (not shown) 01411 DVD Video, Tips for Safe Operation of Your Scag Zero-Turn Mower 483839 482166 STC 2009 RDP2...
-
Page 36: Electrical Schematic - Briggs & Stratton / Kohler
section 8 elecTrical schemaTic - BriGGs & sTraTTon / Kohler BRIGGS & STRATTON ADAPTER HARNESS SWITCH MAIN HARNESS RELAY ENGINE WHITE SWITCH ENGINE GROUND YELLOW YELLOW 20 AMP FUSES BRAKE SOLENOID SOLENOID INTERLOCK SWITCH SOLENOID "B+" KOHLER ADAPTER HARNESS RED W/YEL STRIPE ENGINE PLUG WHITE YELLOW... -
Page 37: Electrical Schematic - Kawasaki
section 8 elecTrical schemaTic - KaWasaKi SWITCH RELAY SWITCH KAWASAKI ADAPTER HARNESS - FX ENGINE WHITE RED W/YEL STRIPE 20 AMP YELLOW FUSES BRAKE GRN W/WHT STRIPE INTERLOCK MAIN HARNESS SWITCH BLACK KAWASAKI ADAPTER HARNESS - FS ENGINE GROUND L.H. NEUTRAL SWITCH SOLENOID BLACK... -
Page 38: Electrical Schematic - Kohler Efi
section 8 elecTrical schemaTic - Kohler efi SWITCH RELAY SWITCH BRAKE 20 AMP INTERLOCK FUSE SWITCH PINK L.H. NEUTRAL SWITCH ORANGE BROWN BLACK BLACK LIGHT BLUE MODULE GROUND BLACK BLACK PLUG WHITE BLACK GRN W/BLK STRIPE ENGINE SEAT ADAPTER SWITCH HARNESS CLUTCH R.H.
