Congratulations on owning a Scag mower! This manual contains the operating
instructions and safety information for your Scag mower. Reading this manual
can provide you with assistance in maintenance and adjustment procedures to
keep your mower performing to maximum eff ciency. The specif c models that
this book covers are listed on the inside cover. Before operating your machine,
please read all the information enclosed.
© 2011
Scag Power Equipment
Division of Metalcraft of Mayville, Inc.
OPERATOR'S
MANUAL
Tiger Cat
Models:
STC48V-22FS
STC48V-22FS-LE
STC48V-25CV
STC48V-26BS
STC52V-24FX
STC52V-27CV
STC61V-27CV
PART NO. 03272 Rev. 2
PRINTED 2/2011
PRINTED IN USA
