Giant TCR Advanced SL 2 Specifications

TCR Advanced SL 2
All new. All race. All conquering. That's the TCR Advanced SL. Developed for the pro ranks,
tested in the world's toughest races from the Spring Classics to the Tour de France and the
choice of High Road's Team Columbia. Ready to ride. Ready to rip. Ready to win.
Specifications
SIZES XS,S,M,M/L,L,XL
Composite/Charcoal
COLORS
Advanced SL-Grade Composite
FRAME
Advanced SL-Grade Composite,
FORK
Full Composite OverDrive Steerer
SHOCK N / A
Race Face Revolution, 31.8
HANDLEBAR
STEM Race Face Revolution
SEATPOST Giant Vector Composite Seatpost
Fi'zi:k Arione w/ k:ium rails
SADDLE
PEDALS Not Included
SHIFTERS Shimano Ultegra
Shimano Ultegra
FRONT DERAILLEUR
Shimano Ultegra
REAR DERAILLEUR
BRAKES Shimano Ultegra
BRAKE LEVERS Shimano Ultegra
Shimano Ultegra 12/25, 10-speed
CASSETTE
CHAIN Shimano Ultegra
CRANKSET Shimano Ultegra, 39/53
Shimano Dura-Ace, Internal Press
BOTTOM BRACKET
Fit
RIMS Mavic Ksyrium Elite
Mavic Ksyrium Elite
HUBS
SPOKES Mavic Ksyrium Elite
TIRES Michelin Pro Race3, 700x23
EXTRAS
Specifications and availability subject to change without notice.
Frame Technology
Giant's lightest, stiffest, fastest road racer ever. Handcrafted, engineered precision creates the new
benchmark for pedaling stiffness and efficiency. From its sleek seatpost to the massive MegaDrive
rectangular downtube and oversized toptube, this is pure Advanced SL-grade composite performance.
Without compromise.
features
— Full Shimano Ultegra component group
— Race Face Revolution handlebar and stem, Giant Vector seatpost
— Mavic Ksyrium Elite wheelset
frame geometry
Actual
Part Number Head Angle Seat Angle*
Frame Size
centimeters degrees degrees
XS/43.0 cm 386642 71.0 74.5
S/46.5 cm 386643 72.0 73.5
M/50.0 cm 386644 73.0 73.0
M/L/53.5 cm 386645 73.0 72.0
L/55.5 cm 386646 73.0 72.0
XL/58.5 cm 386647 73.0 72.0
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
COMPETITION
Toptube** Headtube Chainstay Wheelbase
centimeters centimeters centimeters centimeters
52.0 12.0 40.5 97.7
53.5 13.5 40.5 97.4
55.5 15.0 40.5 98.0
57.0 17.0 40.5 98.6
58.5 18.5 40.5 100.1
60.5 20.0 40.5 102.1
21 giantbicycle.com
road
Standover
Height***
inches
28.5
29.2
30.1
31.0
31.7
32.4
