- Page 1 VAIS TECHNOLOG Y www.vaistech.com Owner’s Manual Model :SL2Vi Model :SL2Vi Apple® Video iPod™ audio/video interface AVGateway AVGateway Powered by Copyright (C) 2003-2007 VAIS Technology Published July 7, 2008...
-
Page 2: Before You Start
Before You Start WARNING DO NOT DISASSEMBLE OR ALTER Doing so may result in an accident, fire or electric shock. Do not block your view Do not mount product or any added audio and/or video equipment where it can block your view through the windshield or your view of dashboard indicators and displays. - Page 3 If the iPod is disconnected from the unit, it will begin normal operation within one minute. VAIS Technology accepts no responsibility for loss of data on the iPod, even if that data is lost while using this unit This unit is equipped with: Built-in Electronic Ground Noise Isolator to eliminate unwanted car engine noise and iPod hard drive noise.
- Page 4 This is done by your vehicle manufacture as a safety system in an effort to aid in the protection of the driver and passenger(s) of the vehicle and is something the VAIS Technology has no control over.
-
Page 5: Connecting The Units
Connections Connecting SoundLinQ2 (SL2Vi) Audio Wiring Harness Audio Y-Harness (included) To the Multi-Display (included) Unit To the Head Unit To the factory Audio harness Apple iPod™ ® (NOT INCLUDED) Apple iPod™ ® Video Interface Harness (included) Connecting the units Model :SL2Vi... - Page 6 Connections Connecting SoundLinQ2 to head unit (for Lexus vehicles) Head Unit (Radio Receiver) 20-pin connector Lexus GX 470 Radio Receiver shown. Locate connector “A” (20-pin connector) on your Radio. Plug into Connector location on the Radio may be Head Unit different from shown above.
-
Page 7: Important Please Read
Packages IMPORTANT Please refer to the application guide for appropriate “Package” installation instructions Description of Installation Packages Multi-Display Unit White Blue Connector Connector Lexus RX 350 Multi-Display Unit shown. Locate connector “1” (6-pin connector) on your Multi-Display. Connector location on the Multi-Display unit may be different from shown here. - Page 8 Package 1 IMPORTANT Please refer to application guide for correct fitment! Package 1 This package is for use with vehicles with an open 6-pin port as shown here. Connecting SL2Vi to Multi-Display unit ( PACKAGE “1” Multi-Display Unit White Blue...
- Page 9 Package 2 IMPORTANT Please refer to application guide for correct fitment! Package 2 This package is for use with vehicles with a reversed open 6-pin port as shown here. Connecting SL2Vi to Multi-Display unit ( PACKAGE “2” Multi-Display Unit White Blue...
- Page 10 Please refer to application guide for correct fitment! Package 3 Package 5 This package is for use with vehicles with an occupied 6-pin port using our Y-adapter as shown here. Connecting SL2Vi to Multi-Display unit ( PACKAGE “3” and “5” Multi-Display Unit Blue White...
- Page 11 Please refer to application guide for correct fitment! Package 4 This package is for use with vehicles with a factory DVD system using our video switching system shown here. Connecting SL2Vi to Multi-Display unit ( PACKAGE “4” Multi-Display Unit Blue...
- Page 12 Please refer to application guide for correct fitment! Package 6 Package 7 This package is for use with vehicles with an occupied 6-pin port using our reversed Y-adapter as shown here. Connecting SL2Vi to Multi-Display unit ( PACKAGE “6” and “7” Multi-Display Unit White Blue...
-
Page 13: Installation
Installation IMPORTANT We strongly recommend that you install the unit in easily accessible location. So you can later upgrade the unit or re-program it in case of incorrect programming. Installation Gain access to the back of you vehicle’s Head Unit. Find the same port as our Audio Harness (see “Connecting SoundLinQ2 to head unit”... - Page 14 Carpet or car chassis NOTE Velcro Fasteners are not included VAIS Technology strongly recomand to ground unit to the car chassis for best results Do not more the 5mm size screws. Using screws larger then 5mm may damage the PCB board.
- Page 15 Force Program Force 2 Mode programming steps: Put switches in appropriate position (CD or MD) for programming according to application guide. Put ignition switch to “ACC” position. Wait for long beep followed by a few short beeps. This may take up to one minute. Put “Both”...
- Page 16 Force Program Force 3 Mode programming steps: Put switches in appropriate position (CD or MD) for programming according to application guide. Put ignition switch to “ACC” position. Wait for long beep followed by a few short beeps. This may take up to one minute. Put “Both”...
-
Page 17: Special Feature
Special Feature IMPORTANT Important Please Read! (1) After a delay of five seconds, this product will automatically bypass the automobile manufacturer's on-screen warnings concerning use of the onboard navigation system. These warnings are: ”Caution, Drive safely and obey traffic rules. Watching this screen while vehicle is in motion can lead to a serious accident. -
Page 18: Dvd Controls
DVD Controls IMPORTANT Functionality Description To ensure video playback please set the “TV OUT” option on your Video iPod to “ON”. Applies only to Gen 5 & 5.5 ipod Using your “Disc” button to cycle through your playback options selection will be as follows... iPod™... - Page 19 DVD Controls When you are in DVD mode you can push the “Audio” button to get the DVD option screen to appear. (shown below) Pressing the “Picture”button will return you to the video playback screen. In some vehicles the “Disc” and/or “Audio” buttons will also cause the screen to revert to video playback.
- Page 20 Head Unit Controls CD/MD Changer Emulation Functionality Description Audio/Video input dedicated for Apple iPod can only be used for Apple iPod integration. Control of Apple iPod is done through your head unit or the steering wheel controls (explained below). This unit supports: This unit can be programmed in CD changer emulation mode , MD changer emulation mode and CD-MP3 Emulation Please see attached chart to determine which emulation mode is compatible with your vehicle.
-
Page 21: Ipod Controls
iPod controls CD/MD Changer Emulation TRACK+ TRACK- Select the desired track (Maximum number of tracks is 99 for CD changer Emulation mode, 999 for MD changer Emulation mode). You can fast switch through tracks by repeatedly pressing the [TRACK+] / [TRACK-] button. - Page 22 Head Unit Controls CD-MP3 Changer Emulation Functionality Description Audio/Video input dedicated for Apple iPod can only be used for Apple iPod integration. Control of Apple iPod is done through your head unit or the steering wheel controls (explained below). This unit supports: This unit can be programmed in CD changer emulation mode , MD changer emulation mode and CD-MP3 Emulation Please see attached chart to determine which emulation mode is compatible with your vehicle.
- Page 23 iPod controls CD-MP3 Changer Emulation TRACK+ TRACK- Select the desired track (Maximum number of tracks is 99 for CD -MP3 changer Emulation mode). You can fast switch through tracks by repeatedly pressing the [TRACK+] / [TRACK-] button. The track will change after a brief pause when you stop pressing the button. NOTE: If a playlist only contains one track, the [TRACK+] / [TRACK-]...
- Page 24 iPod controls Simple Mode Enable/Disable “Simple mode” - press the [SCAN] button 8 times ( MUST BE DONE within 1-2 seconds) You will hear a short beep. This feature will allow you to control the iPod™ manually. [Track+], [Track-] on your Head Unit will still select the desired Track, but all other control can only be done through the iPod.
-
Page 25: License Agreement
For Most Toyota/Lexus Vehicles 2001-2006; (hereinafter collectiv ely referred to as ‘PRODUCTS’). THIS IS A LEGAL AGREEMENT BETWEEN YOU, AS THE END USER, AND VAIS TECHNOLOGY, LLC (“VAIS”). PLEASE CAREFULLY READ THE TERMS AND CONDITIONS OF THIS AGREEMENT BEFORE USING THE VAIS PRODUCTS. BY USING THE VAIS PRODUCTS AND SOFTWARE INSTALLED ON THE VAIS PRODUCTS, YOU ARE AGREEING TO BE BOUND BY THE TERMS OF THIS AGREEMENT. - Page 26 A COPY OF THE ‘OPERATIONAL WARNINGS AND SAFETY INSTRUCTIONS’ IS TO BE KEPT WITH THE VEHICLE AT ALL TIMES. 3.DISCLAIMER AND LIMITATION OF WARRANTIES . (A) EXCEPT AS OTHERWISE CONTAINED HEREIN , the PRODUCTS and related documentation are provided to you, “AS IS”. IN NO EVENT SHALL VAIS BE LIABLE FOR ANY DAMAGES, CLAIM OR LOSS INCURRED BY YOU (INCLUDING WITHOUT LIMITATION, COMPENSATORY, INCIDENTAL, INDIRECT , SPECIAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES, LOST PROFITS, LOST SALES OR BUSINESS, EXPENDITURES, INVESTMENTS, OR COMMITMENTS IN CONNECTION WITH ANY BUSINESS, LOSS OF...
-
Page 27: Limited Warranty
B. WHAT YOU MUST DO. To obtain warranty performance, you must take the PRODUCTS, or deliver the PRODUCTS freight prepaid, to a VAIS Technology Authorized Service Center. If shipped, the PRODUCTS must be packaged so that it is protected from possible shipping damage. VAIS Technology will ship the PRODUCTS to you when warranty performance is completed. -
Page 28: Other Provisions
VAIS Technology, concerning the Products, and your purchase hereund er, and supercede all statements or other agreements, whether oral or written, between you and VAIS Technology. No change in this Agreement shall be effective, unless agreed to in writing by bot h, you, the end-user and VAIS.
