- Page 1 Fridge--Freezer / Kühl--Gefrierkombination / Réfrigérateur--Congélateur Frigorifero--Congelatore / Koel--Vriescombinatie / Køle--Fryseskab INSTRUCTION BOOK GEBRAUCHSANWEISUNG NOTICE D’UTILISATION ISTRUZIONI D’USO GEBRUIKSAANWIJZING BRUGSANVISNING ER8313B 818 17 44--00/7...
-
Page 2: Table Of Contents
Safety instructions Your new fridge/freezer may have other functions compared to your previous one. Carefully read these instructions to learn how the appliance works and how to care for it. Keep the instruction booklet. It will come in handy if you later sell the cabinet or give it to somebody else. These warnings are provided in the interests of your safety. -
Page 3: Description Of The Appliance
Description of the Appliance Model ER8313B Glass shelf Bottle shelf Vegetable drawer Butter compartment Door shelf Egg holder Sliding shelf Freezer plate + accumulator Freezer drawer Ventilation grille Freezer calendar Control Panel B C D E F A. Thermometer F. Green indicator lamp Displays the warmest temperature inside the freezer. -
Page 4: Before Use
Before use Position and clean the cabinet as explained in the section "Installation". Check that the drain hose at the rear of the cabinet discharges into the drip tray. Before inserting the power plug into the outlet and switching on the cabinet for the first time, leave it standing upright for about 30 minutes, or for 4 hours if it was transported horizontally. -
Page 5: Switching Off
Hints: · Distribute foodstuffs to allow cold air to circulate freely between the products. · Do not place food products directly against the cooling plate on the rear wall since they may freeze in this case. · Also never put warm products into the cabinet. Wait until they have cooled down. -
Page 6: Temperature Inside The Freezer
Temperature inside the freezer To ensure that foodstuff will keep for a long time, be sure that the temperature inside the freezer is -18°C or below. Please note, however, that the energy consumption increases as the temperature decreases. The built-in temperature display shows the warmest temperature inside the freezer. -
Page 7: Suitable Storage Periods
· Do not freeze too much food at the same time. The freezing capacity of the unit is indicated in the specifications section. Check that the cabinet is operating and keeps the set temperature one day after switching it on for the first time. Only after then should the freezer be used to freeze fresh foodstuff. -
Page 8: Hints And Tips
Hints and Tips Saving energy · Make sure the door gasket is complete and always clean. · Pay careful attention to where the cabinet is placed. See the section "Installation". When Food Storage installed correctly, the cabinet will consume less ·... -
Page 9: Defrosting The Freezer
Internal Cleaning Clean the inside and accossories with warm water and bicarbonate of soda (5ml to 0,5 litre water) Rinse and dry thoroughly. Regularly check the door seals and wipe clean to ensure they are clean and free from debris. Clean out the drip channel inside the fridge at regular intervals and ensure that the drip channel is clear at all times. -
Page 10: Defrosting The Fridge
Defrosting the fridge The fridge is defrosted automatically every time the compressor stops. Frost formation can be prevented · not putting warm foodstuff inside the cabinet. · avoiding frequently opening the door or keeping it open too long. · do not place foodstuffs directly against the cold cooling plate. - Page 11 Water is running inside the refrigerator. Clean the water drain and drain hole inside the refrigerator using e.g. cotton swabs or a bottle cleaner brush. Some food products could have been placed near the rear of the appliance prevetung the water from running into the drain. Water comes out on the floor.
-
Page 12: Guarantee Conditions
Phone: 08705 950950 * PROD.NO (model number):........* calls to this number may be recarded for training purposes SER:NO (serial number):........Service and Spare Parts Purchase date............Technical specification ER8313B Model 178 l Volume fridge 124 l Volume freezer 595 mm Width... -
Page 13: Remove The Transport Supports
Remove the transport supports Remove the tape and the transport supports from · the door sides · inside the door hinges · the shelves Remove the transport support on the glass shelf by pushing the support forward along the edge of the shelf until it stops. -
Page 14: Door Reversal
Door Reversal 1. Close the cabinet and remove the plug from the electrical socket. 2. Remove the ventilation grille. There is a part on the grille that can be removed. Reposition it and put it on the other side. 3. Put the cabinet on a wooden board when it is laid down. - Page 15 qÜÉ=bäÉÅíêçäìñ=dêçìé=áë=íÜÉ=ïçêäÇDë=ä~êÖÉëí=éêçÇìÅÉê=çÑ=éçïÉêÉÇ=~ééäá~åÅÉë=Ñçê=âáíÅÜÉåI=ÅäÉ~åáåÖ=~åÇ=çìíÇççê=ìëÉK jçêÉ=íÜ~å=RR=ãáääáçå=bäÉÅíêçäìñ=dêçìé=éêçÇìÅíë=EëìÅÜ=~ë=êÉÑêáÖÉê~íçêëI=ÅççâÉêëI=ï~ëÜáåÖ=ã~ÅÜáåÉëI=î~Åììã=ÅäÉ~åÉêëI ÅÜ~áå=ë~ïë=~åÇ=ä~ïå=ãçïÉêëF=~êÉ=ëçäÇ=É~ÅÜ=óÉ~ê=íç=~=î~äìÉ=çÑ=~ééêçñK=rpa=NQ=Äáääáçå=áå=ãçêÉ=íÜ~å=NRM=ÅçìåíêáÉë ~êçìåÇ=íÜÉ=ïçêäÇK aáÉ=bäÉÅíêçäìñJdêìééÉ=áëí=ÇÉê=ïÉäíïÉáí=Öê∏≈íÉ=eÉêëíÉääÉê=îçå=Ö~ëJ=ìåÇ=ëíêçãÄÉíêáÉÄÉåÉå=dÉê®íÉå=ÑΩê=ÇáÉ=hΩÅÜÉI=òìã oÉáåáÖÉå=ìåÇ=ÑΩê=cçêëí=ìåÇ=d~êíÉåK=gÉÇÉë=g~Üê=îÉêâ~ìÑí=ÇáÉ=bäÉÅíêçäìñJdêìééÉ=áå=ΩÄÉê=NRM=i®åÇÉêå=ÇÉê=bêÇÉ=ΩÄÉê=RR jáääáçåÉå=mêçÇìâíÉ=EhΩÜäëÅÜê®åâÉI=eÉêÇÉI=t~ëÅÜã~ëÅÜáåÉåI=pí~ìÄë~ìÖÉêI=jçíçêë®ÖÉå=ìåÇ=o~ëÉåã®ÜÉêF=ãáí=ÉáåÉã tÉêí=îçå=êìåÇ=NQ=jêÇK=rpaK fä=dêìééç=bäÉÅíêçäìñ==ÉD=áä=éáìD=Öê~åÇÉ=éêçÇìííçêÉ=ãçåÇá~äÉ=Çá=~éé~êÉÅÅÜá~íìêÉ=éÉê=ä~=ÅìÅáå~I=éÉê=ä~=éìäáòá~=É=Çá ~ííêÉòò~íìêÉ==éÉê=áä=Öá~êÇáå~ÖÖáç=É=éÉê=ìëç=ÑçêÉëí~äÉK=läíêÉ=RR=ãáäáçåá=Çá=éêçÇçííá=ÇÉä=dêìééç=bäÉÅíêçäìñ==E=èì~äá=ÑêáÖçêáÑÉêáI ÅìÅáåÉI=ä~î~Äá~åÅÜÉêá~I=ä~î~ëíçîáÖäáÉI=~ëéáê~éçäîÉêÉI=ãçíçëÉÖÜÉ=É=ê~ë~ÉêÄ~=F=îÉåÖçåç=îÉåÇìíÉ=çÖåá=~ååç=áå=éáìD=Çá=NRM m~Éëá=ÇÉä=ãçåÇç=éÉê=ìå=î~äçêÉ=Çá=ÅáêÅ~=NQ=ãáäá~êÇá=Çá=Ççää~êáK Le Groupe Electrolux est le premier fabricant mondial d'appareils domestiques, d'entretien et pour l'extérieur. Plus de 55 millions de produits du Groupe Electrolux (tels que réfrigérateurs, cuisinières, lave-linge, aspirateurs, tronçonneuses, tondeuses à...
