O W N E R ' S M A N U A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 200 Sedan 2012 and is the answer not in the manual?

Questions and answers

Related Manuals for Chrysler 200 Sedan 2012

Summary of Contents for Chrysler 200 Sedan 2012

  • Page 1 200 Sedan 2 0 1 2 O W N E R ’ S M A N U A L...
  • Page 2 With respect to any Vehicles Sold in Canada, the name Chrysler This manual illustrates and describes the operation of features and Group LLC shall be deemed to be deleted and the name Chrysler equipment that are either standard or optional on this vehicle. This Canada Inc.

  • Page 3: Introduction 3

    TABLE OF CONTENTS SECTION PAGE ............3 INTRODUCTION .
  • Page 5 INTRODUCTION CONTENTS Introduction ......4 Vehicle Identification Number ....6 How To Use This Manual .

  • Page 6: Introduction

    4 INTRODUCTION INTRODUCTION When it comes to service, remember that your authorized Congratulations on selecting your new Chrysler Group dealer knows your vehicle best, has factory-trained tech- LLC vehicle. Be assured that it represents precision nicians and genuine MOPAR parts, and cares about workmanship, distinctive styling, and high quality - all your satisfaction.
  • Page 7 INTRODUCTION 5...

  • Page 8: Warnings And Cautions

    6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.

  • Page 9: Vehicle Modifications/Alterations

    INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a accident resulting in serious injury or death. Stamped VIN Location NOTE: It is illegal to remove or alter the VIN.

  • Page 11: Table Of Contents

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Rearming The System ....19 Ignition Key Removal .
  • Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Programming Additional Transmitters ..25 Auto Window Up With Anti-Pinch Protection — If Equipped ..... . . 36 Transmitter Battery Replacement .
  • Page 13 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 Automatic Locking Retractor Mode (ALR) — Air Bag Deployment Sensors And Controls . . . 63 If Equipped ......49 Event Data Recorder (EDR) .

  • Page 14: Things To Know Before Starting Your Vehicle 9

    12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The authorized dealer that sold you your vehicle has the key code numbers for your vehicle locks. These numbers can be used to order duplicate keys from your authorized dealer.
  • Page 15 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 occurs, rotate the key to the right slightly, then remove the key as described. If a malfunction occurs, the system will trap the key in the ignition switch lock cylinder to warn you that this safety feature is inop- erable.
  • Page 16 14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The time for this feature is programmable. Refer to WARNING! (Continued) “Electronic Vehicle Information Center (EVIC)/ • Allowing children to be in a vehicle unattended is Personal Settings (Customer-Programmable Fea- dangerous for a number of reasons. A child or tures)”...

  • Page 17: Key-In-Ignition Reminder

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 Key-In-Ignition Reminder SENTRY KEY Opening the driver’s door when the key is in the ignition The Sentry Key Immobilizer System prevents unauthor- sounds a signal to remind you to remove the key. ized vehicle operation by disabling the engine.

  • Page 18: Replacement Keys

    16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE seconds for a bulb check. If the light remains on after the All of the keys provided with your vehicle have been bulb check, it indicates that there is a problem with the programmed to the vehicle electronics.

  • Page 19: Customer Key Programming

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 authorized dealer or by using the Customer Key Pro- three seconds, but no longer than 15 seconds. Then, turn gramming procedure. This procedure consists of pro- the ignition switch to the LOCK position and remove the gramming a blank key to the vehicle electronics.

  • Page 20: General Information

    18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • This device must accept any interference that may be The new Sentry Key is programmed. The Remote Keyless Entry (RKE) transmitter will also be pro- received, including interference that may cause unde- sired operation.

  • Page 21: Rearming The System

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 Rearming The System Security Alarm is arming. During this period, if a door is If something triggers the alarm, and no action is taken to opened, the ignition switch is turned to ON/RUN, or the disarm it, the Vehicle Security Alarm will turn off the power door locks are unlocked in any manner, the horn after three minutes, turn off all of the visual signals...

  • Page 22: Illuminated Entry - If Equipped

    20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If the Vehicle Security Alarm is armed and the battery • The driver’s door key cylinder and the trunk button on becomes disconnected the Vehicle Security Alarm will the RKE transmitter cannot arm or disarm the Vehicle remain armed when the battery is reconnected.

  • Page 23: Remote Keyless Entry (Rke) - If Equipped

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 The interior lights will fade to off after approximately NOTE: • The line of transmission must not be blocked with 30 seconds or they will immediately fade to off once the ignition switch is turned to ON/RUN from the OFF metal objects.

  • Page 24: To Unlock The Doors

    22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • For vehicles not equipped with the EVIC, perform the To Unlock The Doors Press and release the UNLOCK button on the RKE following procedure: transmitter once to unlock the driver’s door, or twice to 1.
  • Page 25 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 cause the alarm to sound. Press the UNLOCK button to 1. Press and hold the UNLOCK button on a programmed deactivate the Vehicle Security Alarm system. RKE transmitter for at least four seconds, but not longer than 10 seconds.

  • Page 26: To Lock The Doors

    24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • For vehicles equipped with EVIC, refer to “Electronic Illuminated Approach — If Equipped This feature activates the headlights for up to 90 seconds Vehicle Information Center (EVIC)/Personal Settings when the doors are unlocked with the RKE transmitter. (Customer-Programmable Features)”...

  • Page 27: To Unlatch The Trunk

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 NOTE: If there is no key in the ignition switch, pressing The Panic Alarm will stay on for three minutes unless the LOCK button on the RKE transmitter while you are in you turn it off by pressing the PANIC button a second the vehicle will activate the Vehicle Security Alarm.

  • Page 28: General Information

    26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. With the RKE transmitter buttons facing down, use a 2. Remove and replace the battery. Avoid touching the flat blade screwdriver to pry the two halves of the RKE new battery with your fingers. Skin oils may cause transmitter apart.

  • Page 29: Remote Start System - If Equipped

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 If your RKE transmitter fails to operate from a normal How To Use Remote Start distance, check for these two conditions. All of the following conditions must be met before the engine will remote start: 1.
  • Page 30 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Remote Start Aborted — Hood Ajar WARNING! • Remote Start Aborted — Trunk Ajar • Do not start or run an engine in a closed garage or • Remote Start Aborted — Fuel Low confined area.
  • Page 31 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 • For security, power window operation is disabled To Exit Remote Start Mode Without Driving The when the vehicle is in the Remote Start mode. Vehicle Press and release the REMOTE START button one time or •...

  • Page 32: Door Locks

    30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE DOOR LOCKS WARNING! Manual Door Locks • For personal security and safety in the event of an To lock each door, push the door lock knob on each door accident, lock the vehicle doors as you drive as trim panel downward.

  • Page 33: Power Door Locks

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 CAUTION! An unlocked vehicle is an invitation to thieves. Always remove the key from the ignition and lock all of the doors when leaving the vehicle unattended. Power Door Locks A door lock switch is located on the driver and passenger door panel.

  • Page 34: Automatic Unlock Doors On Exit

    32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Auto Unlock On Exit Auto Unlock On Exit Programming The doors will unlock automatically on vehicles with The Automatic Unlock Doors On Exit feature can be power door locks if: enabled or disabled as follows: •...

  • Page 35: Child-Protection Door Lock System - Rear Doors

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 4. A single chime will indicate the completion of the programming. 5. Repeat these steps if you want to return this feature to its previous setting. NOTE: Use the Automatic Unlock Doors On Exit feature in accordance with local laws.

  • Page 36: Power Windows

    34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Child-Protection Door Locks are located inside the WARNING! rear edge of the door. Insert the tip of the ignition key or similar flat-bladed object into the lock and rotate approxi- Avoid trapping anyone in a vehicle in a collision. mately one-quarter turn to the lock or unlock position (as Remember that the rear doors can only be opened indicated by the stamped icons).

  • Page 37: Auto Window Down - If Equipped

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 WARNING! Never leave children in a vehicle, with the keys in the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the win- dows while operating the power window switches. Such entrapment may result in serious injury or death.

  • Page 38: Auto Window Up With Anti-Pinch Protection - If Equipped

    36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To cancel the Auto-Down movement, operate the switch Auto Window Up With Anti-Pinch Protection — If either in the up or down direction and release the switch. Equipped Lift the window switch fully upward to the second For vehicles not equipped with the Electronic Vehicle detent, release, and the window will go up automatically.

  • Page 39: Window Lockout Switch

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 • Any impact due to rough road conditions may trigger Window Lockout Switch the auto reverse function unexpectedly during auto- The window lockout switch on the driver’s door allows closure. If this happens, pull the switch lightly to the you to disable the window control on the other doors.

  • Page 40: Wind Buffeting

    38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Wind Buffeting NOTE: The shift lever must be in PARK for this button Wind buffeting can be described as the perception of to operate. pressure on the ears or a helicopter-type sound in the To unlatch the trunk lid from outside the vehicle, press ears.

  • Page 41: Trunk Safety Warning

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 TRUNK SAFETY WARNING WARNING! Do not allow children to have access to the trunk, either by climbing into the trunk from outside, or through the inside of the vehicle. Always close the trunk lid when your vehicle is unattended.
  • Page 42 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Advanced Front Air Bags for driver and front passen- • All seat belt systems (except the driver’s) include Automatic Locking Retractors (ALRs), which lock the seat belt webbing into position by extending the belt •...
  • Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 NOTE: The Advanced Front Air Bags have a multistage secured in the rear seat in child restraints or belt- inflator design. This allows the air bag to have different positioning booster seats. Older children who do not use rates of inflation based on the severity and type of child restraints or belt-positioning booster seats should collision.
  • Page 44 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Do not lean against the door or window. If your WARNING! (Continued) vehicle has side air bags, and deployment occurs, the • Being too close to the steering wheel or instrument side air bags will inflate forcefully into the space panel during Advanced Front Air Bag deployment between you and the door.

  • Page 45: Lap/Shoulder Belts

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 Buckle up even though you are an excellent driver, even conditions. However, in an accident the belt will lock and on short trips. Someone on the road may be a poor driver reduce your risk of striking the inside of the vehicle or and cause an accident that includes you.
  • Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the belt. Slide the latch plate up the webbing as far as WARNING! (Continued) necessary to allow the belt to go around your lap. • Wearing your belt in the wrong place could make your injuries in an accident much worse.
  • Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 WARNING! • A belt that is buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal injuries. Always buckle your belt into the buckle nearest you.
  • Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE tilt the latch plate and pull on the lap belt. A snug belt WARNING! reduces the risk of sliding under the belt in an accident. • A belt that is worn under your arm is dangerous. Your body could strike the inside surfaces of the vehicle in an accident, increasing head and neck injury.

  • Page 49: Lap/Shoulder Belt Untwisting Procedure

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 6. To release the belt, push the red button on the buckle. WARNING! The belt will automatically retract to its stowed position. • A lap belt worn too high can increase the risk of If necessary, slide the latch plate down the webbing to allow the belt to retract fully.

  • Page 50: Adjustable Upper Shoulder Belt Anchorage

    48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Position the latch plate as close as possible to the anchor point. 2. At about 6 to 12 in (15 to 30 cm) above the latch plate, grasp and twist the belt webbing 180 degrees to create a fold that begins immediately above the latch plate.

  • Page 51: Rear Seat Belts

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 Rear Seat Belts If the passenger seating position is equipped with an The shoulder belt anchorages of the rear three-point belts ALR and is being used for normal usage: are nonadjustable for outboard and center rear passen- Only pull the belt webbing out far enough to comfortably gers on sedans.

  • Page 52: Energy Management Feature

    50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE position that has a belt with this feature. Children WARNING! 12 years old and under should always be properly • The belt and retractor assembly must be replaced restrained in the rear seat. if the seat belt assembly Automatic Locking Re- How To Engage The Automatic Locking Mode tractor (ALR) feature or any other seat belt func-...

  • Page 53: Seat Belt Pretensioners

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 Seat Belt Pretensioners Supplemental Active Head Restraints (AHR) — If The seat belts for both front seating positions are Equipped equipped with pretensioning devices that are designed to These head restraints are passive, deployable compo- remove slack from the seat belt in the event of an nents, and vehicles with this equipment cannot be readily accident.
  • Page 54 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE This system is designed to help prevent or reduce the extent of injuries to the driver and front passenger in certain types of rear impacts. NOTE: The Active Head Restraints (AHR) may or may not deploy in the event of a front or side impact.
  • Page 55 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 1. Grasp the deployed AHR from the rear seat. CAUTION! All occupants, including the driver, should not oper- ate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of an accident.
  • Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Pull down then rearward towards the rear of the vehicle then down to engage the locking mechanism. 3 — Final Downward Movement To Engage Locking Mecha- nism 1 — Downward Movement 2 —...

  • Page 57: Enhanced Seat Belt Use Reminder System (Beltalert )

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 • For safety reasons, have the Active Head Restraints 4. The AHR front soft foam and trim half should lock into the back decorative plastic half. checked by a qualified specialist at an authorized dealer.

  • Page 58: Seat Belts And Pregnant Women

    BeltAlert can be enabled or disabled by your authorized Seat Belt Extender dealer. Chrysler Group LLC does not recommend deac- If a seat belt is too short, even when fully extended and tivating BeltAlert .

  • Page 59: Supplemental Restraint System (Srs) - Air Bags

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 extender should be used only if the existing belt is not instrument panel, above the glove compartment. The long enough. When it is not required, remove the ex- words SRS AIRBAG are embossed on the air bag covers. tender, and store it.
  • Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Advanced Front Air Bags have a multistage inflator vehicle is equipped with SABIC, they are located above design. This allows the air bag to have different rates of the side windows. The trim covering the side air bags is inflation that are based on the severity and type of labeled SRS AIRBAG.

  • Page 61: Air Bag System Components

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 • Front and Side Impact Sensors Air Bag System Components Your vehicle may be equipped with the following air bag • Front Seat Belt Pretensioners, Seat Belt Buckle Switch, system components: and Seat Track Position Sensors •...
  • Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Seat-Mounted Side Air Bags (SAB) WARNING! Supplemental Seat-Mounted Side Air Bags (SAB) may • No objects should be placed over or near the air provide enhanced protection to help protect an occupant during a side impact.
  • Page 63 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 When the air bag deploys, it opens the seam between the front and side of the seat’s trim cover. Each air bag deploys independently; a left side impact deploys the left air bag only and a right-side impact deploys the right air bag only.
  • Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The system includes side impact sensors that are cali- WARNING! (Continued) brated to deploy the side air bags during impacts that • If your vehicle is equipped with SABIC air bags, require air bag occupant protection. do not have any accessory items installed which will alter the roof, including adding a sunroof to WARNING!

  • Page 65: Air Bag Deployment Sensors And Controls

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 Along with seat belts and pretensioners, Advanced Front Advanced Front Air Bags are designed to provide addi- Air Bags work with the knee bolsters to provide im- tional protection by supplementing the seat belts in proved protection for the driver and front passenger.
  • Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Because air bag sensors measure vehicle deceleration Also, the ORC turns on the Air Bag Warning over time, vehicle speed and damage by themselves are Light in the instrument panel for approxi- not good indicators of whether or not an air bag should mately four to eight seconds for a self-check have deployed.
  • Page 67 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 are possible, based on the collision type and severity. The WARNING! steering wheel hub trim cover and the upper right side of the instrument panel separate and fold out of the way as Ignoring the Air Bag Warning Light in your instru- the air bags inflate to their full size.
  • Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Based on the severity and type of collision, the side air A quantity of non-toxic gas is generated to inflate the side bag inflator on the crash side of the vehicle may be curtain air bag.
  • Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 Enhanced Accident Response System NOTE: Front and/or side air bags will not deploy in all In the event of an impact causing air bag deployment, if collisions. This does not mean something is wrong with the communication network remains intact, and the the air bag system.
  • Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE bag inflation. These airborne particles may irritate the Maintaining Your Air Bag System skin, eyes, nose, or throat. If you have skin or eye WARNING! irritation, rinse the area with cool water. For nose or throat irritation, move to fresh air.
  • Page 71 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 Air Bag Warning Light WARNING! (Continued) You will want to have the air bags ready to • Do not attempt to modify any part of your air bag inflate for your protection in a collision. The system.

  • Page 72: Event Data Recorder (Edr)

    70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • How various systems in your vehicle were operating; NOTE: If the speedometer, tachometer, or any engine related gauges are not working, the Occupant Restraint • Whether or not the driver and passenger safety belts Controller (ORC) may also be disabled.

  • Page 73: Child Restraints

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 To read data recorded by an EDR, special equipment is WARNING! required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, In a collision, an unrestrained child, even a tiny baby, such as law enforcement, that have the special equip- can become a projectile inside the vehicle.
  • Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Infants And Child Restraints held in the vehicle by the lap/shoulder belt or the Safety experts recommend that children ride rearward- LATCH child restraint anchor system. Refer to “Lower facing in the vehicle until they are two years old or until Anchors and Tether for CHildren (LATCH)”.
  • Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 remain in a forward-facing child seat with a harness for WARNING! as long as possible, up to the highest weight or height • Improper installation can lead to failure of an allowed by the child seat. These child seats are also held in the vehicle by the lap/shoulder belt or the LATCH infant or child restraint.
  • Page 76 Safety lap/shoulder belt on the child restraint because the Standards. Chrysler Group LLC also recommends that buckle or latch plate is too close to the belt path you make sure that you can install the child restraint in opening on the restraint.
  • Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 around, and insert the latch plate into the buckle Lower Anchors and Tether for CHildren (LATCH) again. If you still can’t make the child restraint secure, Your vehicle is equipped with the child restraint anchor- try a different seating position.
  • Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE belts. For typical installation instructions, refer to “In- stalling LATCH-Compatible Child Restraint System”. Rear Seat LATCH Anchors Child restraints systems having attachments designed to connect to the lower anchorages are now available. Child restraints having tether straps and hooks for connection to the top tether anchorage, have been available for some time.
  • Page 79 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 have tether straps, and you are urged to take advantage Installing The LATCH-Compatible Child Restraint of all of the available attachments provided with your System child restraint in any vehicle. We urge you to carefully follow the directions of the manufacturer when installing your child restraint.
  • Page 80 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE window. These tether strap anchorages are under a provide the most direct path between the anchor and the plastic cover with this symbol on it. child restraint. Finally, tighten all three straps as you push the child restraint rearward and downward into the Many, but not all, restraint systems will be equipped with seat, removing slack in the straps according to the child...
  • Page 81 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 the child restraint belt path and then buckle it. This should stow the seat belt out of the reach of an inquisitive child. Remind all children in the vehicle that the seat belts are not toys and should not be played with, and never leave your child unattended in the vehicle.
  • Page 82 80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE route the tether strap under the head restraint and Installing Child Restraints Using The Vehicle Seat between the two posts. If not possible, lower the head Belts restraint and pass the tether strap around the outboard The seat belts in the passenger seating positions are side of the head restraint.
  • Page 83 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 2. Finally, pull on any excess webbing to tighten the lap Driver Center Passenger portion around the child restraint. Any seat belt system CRS Lock CRS Lock CRS Lock will loosen with time, so check the belt occasionally, and First Row pull it tight if necessary.

  • Page 84: Transporting Pets

    82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Children Too Large For Booster Seats Transporting Pets Children who are large enough to wear the shoulder belt Air Bags deploying in the front seat could harm your pet. comfortably, and whose legs are long enough to bend An unrestrained pet will be thrown about and possibly over the front of the seat when their back is against the injured, or injure a passenger during panic braking or in...

  • Page 85: Safety Tips

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83 The engine oil installed in the engine at the factory is a SAFETY TIPS high-quality energy conserving type lubricant. Oil Transporting Passengers changes should be consistent with anticipated climate NEVER TRANSPORT PASSENGERS IN THE CARGO conditions under which vehicle operations will occur.

  • Page 86: Exhaust Gas

    84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If it is necessary to sit in a parked vehicle with the engine WARNING! (Continued) running, adjust your heating or cooling controls to force • Be sure everyone in your vehicle is in a seat and outside air into the vehicle.

  • Page 87: Safety Checks You Should Make Inside The Vehicle

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 85 inspect the exhaust system each time the vehicle is raised authorized dealer. If the light stays on, flickers, or comes for lubrication or oil change. Replace as required. on while driving, have the system checked by an autho- rized dealer.
  • Page 88 86 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • Check mounting of mats on a regular basis. Al- Pedals that cannot move freely can cause loss of ways properly reinstall and secure floor mats that vehicle control and increase the risk of serious per- have been removed for cleaning.

  • Page 89: Periodic Safety Checks You Should Make Outside The Vehicle

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 87 Periodic Safety Checks You Should Make Outside Door Latches The Vehicle Check for positive closing, latching, and locking. Tires Fluid Leaks Examine tires for excessive tread wear and uneven wear Check area under vehicle after overnight parking for fuel, patterns.

  • Page 91: Understanding The Features Of Your Vehicle

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......93 Uconnect™ Phone — If Equipped ... 97 Inside Day/Night Mirror .
  • Page 92 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Command — If Equipped ... 128 Fold-Flat Passenger Seatback ... . 144 Voice Command System Operation .
  • Page 93 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 Fog Lights — If Equipped ....151 To Activate ......160 Daytime Running Lights —...
  • Page 94 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Security ......169 Electrical Power Outlets ....174 Troubleshooting Tips .

  • Page 95: Mirrors

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 MIRRORS Inside Day/Night Mirror A two-point pivot system allows for horizontal and vertical mirror adjustment. Adjust the mirror to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle).

  • Page 96: Power Mirrors

    94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE to the left of the button will illuminate to indicate when CAUTION! the dimming feature is activated. The sensor to the right of the button does not illuminate. To avoid damage to the mirror during cleaning, never spray any cleaning solution directly onto the mirror.
  • Page 97 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 Power Mirror Switch Mirror Directions To adjust a mirror, turn the control wand toward the left When you are finished adjusting the mirror, turn the or right mirror positions indicated. Tilt the control wand control to the center position to prevent accidentally in the direction you want the mirror to move.

  • Page 98: Adjusting Sideview Mirrors

    96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Adjusting Sideview Mirrors WARNING! Outside Mirror — Driver Side Vehicles and other objects seen in the passenger side Adjust the outside mirror to center on the adjacent lane of convex mirror will look smaller and farther away traffic, with a slight overlap of the view obtained on the than they really are.

  • Page 99: Heated Mirrors - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 Heated Mirrors — If Equipped These mirrors are heated to melt frost or ice. This feature is activated whenever you turn on the rear window defroster. Refer to “Rear Window Features” in “Under- standing the Features of Your Vehicle”...
  • Page 100 Uconnect™ Phone works no matter where you stow your • www.chrysler.com/uconnect mobile phone (be it your purse, pocket, or briefcase), as long as your phone is turned on and has been paired to •...
  • Page 101 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99 Voice Command Button WARNING! Actual button location may vary with the ra- dio. The individual buttons are described in the Any voice commanded system should be used only “Operation” section. in safe driving conditions following local laws and phone use.

  • Page 102: Operation

    100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Operation example, you can use the compound form voice Voice commands can be used to operate the Uconnect™ command “Phonebook New Entry”, or you can break Phone and to navigate through the Uconnect™ Phone the compound form command into two voice com- menu structure.
  • Page 103 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 • When prompted, after the beep, say “Pair a Device” Cancel Command At any prompt, after the beep, you can say “Cancel” and and follow the audible prompts. you will be returned to the main menu. However, in a •...
  • Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The Uconnect™ Phone will confirm the phone number phone to use if multiple mobile phones are in the vehicle at the same time. For example, if priority three and then dial. The number will appear in the display and priority five phones are present in the vehicle, the of certain radios.
  • Page 105 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 • The Uconnect™ system will confirm the name and • When prompted, enter the number designation (e.g., then dial the corresponding phone number, which “Home”, “Work”, “Mobile”, or “Other”). This will may appear in the display of certain radios. allow you to store multiple numbers for each phone- book entry, if desired.
  • Page 106 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Depending on the maximum number of entries down- Phonebook Download – Automatic Phonebook Transfer From Mobile Phone loaded, there may be a short delay before the latest If equipped and specifically supported by your phone, downloaded names can be used.
  • Page 107 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 Edit Uconnect™ Phonebook Entries After you are finished editing an entry in the phonebook, you will be given the opportunity to edit another entry in NOTE: the phonebook, call the number you just edited, or return •...
  • Page 108 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After you enter the Phonebook Delete menu, you will Delete/Erase “All” Uconnect™ Phonebook Entries then be asked for the name of the entry that you wish • Press the button to begin. to delete.

  • Page 109: Phone Call Features

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 List All Names In The Uconnect™ Phonebook Phone Call Features The following features can be accessed through the • Press the button to begin. Uconnect™ Phone if the feature(s) are available on your •...
  • Page 110 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Answer Or Reject An Incoming Call — Call in progress. To go back to the first call, refer to “Toggling Currently In Progress Between Calls” in this section. To combine two calls, refer If a call is currently in progress and you have another to “Conference Call”...
  • Page 111 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 Conference Call Call Termination When two calls are in progress (one active and one on To end a call in progress, momentarily press the hold), press and hold the button until you hear a button.

  • Page 112: Uconnect™ Phone Features

    110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Call Continuation Uconnect™ Phone Features Call continuation is the progression of a phone call on the Language Selection Uconnect™ Phone after the vehicle ignition key has been To change the language that the Uconnect™ Phone is switched to OFF.
  • Page 113 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 Emergency Assistance Canada and 060 for Mexico). The number dialed may If you are in an emergency and the mobile phone is not be applicable with the available mobile service and reachable: area. •...
  • Page 114 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Towing Assistance Paging If you need towing assistance: To learn how to page, refer to “Working with Automated Systems”. Paging works properly except for pagers of • Press the button to begin. certain companies, which time out a little too soon to •...
  • Page 115 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 When calling a number with your Uconnect™ Phone that The Uconnect™ Phone will then send the corresponding normally requires you to enter in a touch-tone sequence phone number associated with the phonebook entry, as on your mobile phone keypad, you can press the tones over the phone.
  • Page 116 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turning Confirmation Prompts ON/OFF Dialing Using The Mobile Phone Keypad Turning confirmation prompts off will stop the system You can dial a phone number with your mobile phone from confirming your choices (e.g., the Uconnect™ keypad and still use the Uconnect™...

  • Page 117: Advanced Phone Connectivity

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 Mute/Un-Mute (Mute OFF) from your Uconnect™ Phone paired mobile phone to the When you mute the Uconnect™ Phone, you will still be Uconnect™ Phone or vice versa, press the button able to hear the conversation coming from the other and say “Transfer Call”.
  • Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When prompted, say “List Phones”. • The selected phone will be used for the next phone call. If the selected phone is not available, the • The Uconnect™ Phone will play the phone names of Uconnect™...

  • Page 119: Things You Should Know About Your Uconnect™ Phone

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 Things You Should Know About Your Uconnect™ You can either press the Uconnect™ Phone button to Phone restore the factory setting or repeat the words and phrases when prompted by the Uconnect™ Phone. For Uconnect™...
  • Page 120 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • fully closed windows, Voice Command • For best performance, adjust the rearview mirror to • dry weather condition. provide at least ⁄ in (1 cm) gap between the overhead • Even though the system is designed for users speaking console (if equipped) and the mirror.
  • Page 121 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 • Numbers must be spoken in single digits. “800” must • fully closed windows, be spoken “eight-zero-zero” not “eight hundred”. • dry weather conditions, and • You can say “O” (letter “O”) for “0” (zero). •...
  • Page 122 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Send Messages: Uconnect™ Phone can read or send new messages on You can send messages using Uconnect™ Phone. To send your phone. a new message: • Press the Read Messages: button. If you receive a new text message while your phone is •...
  • Page 123 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 List of Preset Messages: 14. Are you there yet? 1. Yes 15. Where are we meeting? 2. No 16. Can this wait? 3. Where are you? 17. Bye for now 4. I need more direction. 18.
  • Page 124 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Bluetooth Communication Link Power-Up Mobile phones have been found to lose connection to the After switching the ignition key from OFF to either the Uconnect™ Phone. When this happens, the connection ON or ACC position, or after a language change, you can generally be reestablished by switching the phone must wait at least fifteen seconds prior to using the off/on.
  • Page 125 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123...
  • Page 126 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
  • Page 127 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125...
  • Page 128 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) zero call cancel confirmation prompts three continue four delete five dial download seven edit eight emergency nine English star (*) erase all plus (+) Espanol pound (#) Francais add location...
  • Page 129 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) language return to main menu return or main menu list names select phone select list phones send mobile set up phone settings or phone set up mute towing assistance mute off...

  • Page 130: General Information

    128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information NOTE: Take care to speak into the Voice Interface This device complies with Part 15 of the FCC rules and System as calmly and normally as possible. The ability of RSS 210 of Industry Canada. Operation is subject to the the Voice Interface System to recognize user voice com- following conditions: mands may be negatively affected by rapid speaking or a...

  • Page 131: Commands

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 NOTE: If you do not say a command within a few When using this system, you should speak clearly and at seconds, the system will present you with a list of a normal speaking volume. options.
  • Page 132 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • “Memo” (to switch to the memo recorder) Changing the Volume • “Setup” (to switch to system setup) 1. Start a dialogue by pressing the Voice Command button. Radio AM 2. Say a command (e.g., “Help”). To switch to the AM band, say “AM”...
  • Page 133 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 • “Previous Channel” (to select the previous channel) Radio FM To switch to the FM band, say “FM” or “Radio FM”. In • “List Channel” (to hear a list of available channels) this mode, you may say the following commands: •...
  • Page 134 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Memo − “Previous” (to play the previous memo) To switch to the voice recorder mode, say “Memo”. In − “Delete” (to delete a memo) this mode, you may say the following commands: • “Delete All” (to delete all memos) •...

  • Page 135: Voice Training

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 • “Language Spanish” session should be completed when the vehicle is parked, engine running, all windows closed, and the blower fan • “Tutorial” switched off. This procedure may be repeated with a new •...

  • Page 136: Power Seats - If Equipped

    134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • Do not allow people to ride in any area of your vehicle that is not equipped with seats and seat belts. In a collision, people riding in these areas are more likely to be seriously injured or killed. •...
  • Page 137 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 Adjusting The Seat Up Or Down WARNING! The height of the seats can be adjusted up or down. Pull • Adjusting a seat while driving may be dangerous. upward or push downward on the rear of the seat switch, the seat will move in the direction of the switch.

  • Page 138: Heated Seats - If Equipped

    136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Press the switch once to select HIGH-level CAUTION! heating. Press the switch a second time to select LOW-level heating. Press the switch a third Do not place any article under a power seat or time to shut the heating elements OFF.

  • Page 139: Manual Front Seat Adjustment

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 WARNING! • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, ex- haustion or other physical condition must exercise care when using the seat heater.

  • Page 140: Driver Seat Manual Height Adjuster - If Equipped

    138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust the seat only while the vehicle is parked.
  • Page 141 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 WARNING! • Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust the seat only while the vehicle is parked.

  • Page 142: Lumbar Support - If Equipped

    140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lumbar Support — If Equipped Head Restraints This feature allows you to increase or decrease the Head restraints are designed to reduce the risk of injury amount of lumbar support. The control lever is located by restricting head movement in the event of a rear on the outboard side of the driver’s seatback.
  • Page 143 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 identified by any markings, only through visual inspec- To raise the head restraint, pull upward on the head tion of the head restraint. The head restraint will be split restraint. To lower the head restraint, press the push in two halves, with the front half being soft foam and button, located at the base of the head restraint, and push trim, the back half being decorative plastic.
  • Page 144 142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For comfort the Active Head Restraints can be tilted forward and rearward. To tilt the head restraint closer to the back of your head, pull forward on the bottom of the head restraint. Push rearward on the bottom of the head restraint to move the head restraint away from your head.
  • Page 145 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 • In the event of deployment of an Active Head Re- WARNING! (Continued) straint, refer to “Occupant Restraints/Resetting Active • Active Head Restraints may be deployed if they Head Restraints (AHR)” in “Things to Know Before are struck by an object such as a hand, foot or loose Starting Your Vehicle”...

  • Page 146: Fold-Flat Passenger Seatback

    144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fold-Flat Passenger Seatback The hard seatback features a work surface and a molded The recline handle on the front passenger seat also rim for retaining items stored on the seatback panel. releases the seatback to fold forward. Fold-Flat Front Passenger Seat Seatback Adjustment...

  • Page 147: Folding Rear Seat

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 Folding Rear Seat WARNING! To provide additional storage area, the rear seatback can be folded forward. Pull on the loops shown in the picture The rear cargo area of the vehicle (with the rear to fold down either or both seatbacks.

  • Page 148: Folding Rear Seat Center Armrest

    146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Folding Rear Seat Center Armrest TO OPEN AND CLOSE THE HOOD The rear seat is equipped with a folding armrest with To open the hood, two latches must be released. cupholders. 1. Pull the hood release lever located under the left side of the instrument panel.
  • Page 149 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 2. Then lift the secondary latch located under the front Use the hood prop rod to secure the hood in the open edge of the hood, near the center and raise the hood. position.

  • Page 150: Lights

    148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE passing light, fog lights, instrument panel light dimming CAUTION! and turn signals. The multifunction lever is located on the left side of the steering column. To prevent possible damage, do not slam the hood to close it.

  • Page 151: Headlights And Parking Lights

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 Headlights And Parking Lights Automatic Headlights — If Equipped Turn the end of the multifunction lever to the first detent Turning the end of the multifunction lever to the third for parking light operation. Turn to the second detent for detent (AUTO), will activate the automatic headlight headlight operation.

  • Page 152: Headlight Time Delay

    150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE With the engine running and the multifunction lever in the AUTO position, the headlights will turn on and turn off based on the surrounding light levels. Headlight Time Delay There is also a feature that delays turning off the vehicle lights for 30, 60 or 90 seconds after the ignition switch is turned OFF.

  • Page 153: Lane Change Assist

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 Lane Change Assist Fog Lights — If Equipped Tap the lever up or down once, without moving beyond The front fog light switch is on the multifunction the detent, and the turn signal (right or left) will flash lever.

  • Page 154: Daytime Running Lights - If Equipped

    152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The front fog lights will only operate with the Instrument Panel Dimmer headlights on low beam. Selecting high beam headlights Rotate the center portion of the lever to the extreme will turn off the front fog lights. bottom position to fully dim the instrument panel lights and prevent the interior lights from illuminating when a Daytime Running Lights —...

  • Page 155: Map/Reading/Interior Lights

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 will remain on until the switch is pressed a second time, so be sure they have been turned off before leaving the vehicle. They will not turn off automatically. Interior lighting also comes on when a door is opened or the dimmer control is turned fully upward, past the second detent.

  • Page 156: Windshield Wipers And Washers

    154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE There is a second light located midway back in the headliner. To protect the battery, the interior lights will turn off automatically 10 minutes after the ignition switch is moved to the LOCK position. This will occur if the interior lights were switched on manually or are on because a door is open.

  • Page 157: Intermittent Wiper System

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 CAUTION! • Turn the windshield wipers off when driving through an automatic car wash. Damage to the windshield wipers may result if the wiper control is left in any position other than off. •...

  • Page 158: Windshield Washers

    156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE regulate the wipe interval from a minimum of one cycle Windshield Washers every second to a maximum of approximately 18 seconds To use the washer, pull the windshield wiper/washer between cycles. control lever toward you and hold it for as long as washer spray is desired.

  • Page 159: Mist Feature

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 WARNING! Sudden loss of visibility through the windshield could lead to a collision. You might not see other vehicles or other obstacles. To avoid sudden icing of the windshield during freezing weather, warm the windshield with defroster before and during wind- shield washer use.

  • Page 160: Tilt/Telescoping Steering Column

    158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE column) is placed in the AUTO position. In addition, the headlights will turn off when the wipers are turned off if they were turned on by this feature. The headlights with wipers feature can be turned on or off through the Electronic Vehicle Information Center (EVIC) —...

  • Page 161: Electronic Speed Control - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 outward or push it inward as desired. To lock the steering The Electronic Speed Control buttons are located on the column in position, pull the lever upward until fully right side of the steering wheel. engaged.

  • Page 162: To Activate

    160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the same time. If this occurs, the Electronic Speed Control To Set A Desired Speed System can be reactivated by pushing the Electronic Turn the Electronic Speed Control ON. When the vehicle Speed Control ON/OFF button and resetting the desired has reached the desired speed, press the SET (-) button vehicle set speed.

  • Page 163: To Resume Speed

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 To Resume Speed decrease until the button is released. Release the button To resume a previously set speed, push the RES (+) when the desired speed is reached, and the new set speed button and release.

  • Page 164: Garage Door Opener - If Equipped

    162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE On steep hills, a greater speed loss or gain may occur so The HomeLink buttons, located on either the overhead it may be preferable to drive without Electronic Speed console, headliner or sunvisor, designate the three differ- Control.

  • Page 165: Before You Begin Programming Homelink

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 For more efficient programming and accurate transmis- sion of the radio-frequency signal it is recommended that a new battery be placed in the hand-held transmitter of the device that is being programmed to the HomeLink system.

  • Page 166: Programming A Rolling Code

    164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Programming A Rolling Code For programming garage door openers that were manu- factured after 1995. These garage door openers can be identified by the “LEARN” or “TRAIN” button located where the hanging antenna is attached to the garage door opener.
  • Page 167 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 3. Simultaneously press and hold both the Homelink NOTE: You have 30 seconds in which to initiate the next button you want to program and the hand-held transmit- step after the LEARN button has been pressed. ter button.

  • Page 168: Programming A Non-Rolling Code

    166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Press and hold the desired HomeLink button until 4. Continue to hold both buttons and observe the indi- the indicator light begins to flash after 20 seconds. Do not cator light. The Homelink indicator will flash slowly and then rapidly after Homelink has received the fre- release the button.

  • Page 169: Canadian/Gate Operator Programming

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 Reprogramming A Single HomeLink Button to pick up the signal during programming. Similar to this To reprogram a channel that has been previously trained, Canadian law, some U.S. gate operators are designed to follow these steps: time-out in the same manner.

  • Page 170: Using Homelink

    168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Watch for the HomeLink indicator to change flash Reprogramming A Single HomeLink Button rates. When it changes, it is programmed. It may take up To reprogram a channel that has been previously trained, to 30 seconds or longer in rare cases.

  • Page 171: Security

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 Security Troubleshooting Tips It is advised to erase all channels before you sell or turn If you are having trouble programming HomeLink , here in your vehicle. are some of the most common solutions: •...

  • Page 172: General Information

    170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information WARNING! This device complies with FCC rules Part 15 and Industry • Your motorized door or gate will open and close Canada RSS-210. Operation is subject to the following two conditions: while you are programming the universal trans- ceiver.

  • Page 173: Power Sunroof - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 POWER SUNROOF — IF EQUIPPED WARNING! The sunroof controls are mounted between the dome/ • Never leave children in a vehicle with the key in reading lights. the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch.

  • Page 174: Opening Sunroof - Express

    172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Opening Sunroof — Express position. The sunroof will close fully and stop automati- Press the switch rearward and release it within one-half cally. This is called “Express Close”. During Express second and the sunroof will open automatically from any Close operation, any movement of the switch will stop position.

  • Page 175: Venting Sunroof - Express

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 NOTE: Pinch protection is disabled while the switch is Wind Buffeting pressed. Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the Venting Sunroof — Express ears.

  • Page 176: Ignition Off Operation

    174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Ignition Off Operation ELECTRICAL POWER OUTLETS For vehicles not equipped with the Electronic Vehicle There are two 12 Volt (13 Amp) electrical power outlets Information Center (EVIC), the power sunroof switch on this vehicle. Both of the power outlets are protected by will remain active for 45 seconds after the ignition switch a fuse.
  • Page 177 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 Instrument Panel Power Outlet Center Console NOTE: To preserve the heating element, do not hold the The center console power outlet is powered directly from lighter in the heating position. the battery (power available at all times). Items plugged into this power outlet may discharge the battery and/or A second power outlet is located inside the center con- prevent the engine from starting.
  • Page 178 176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! • Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power rating is exceeded the fuse protecting the system will need to be replaced. •...
  • Page 179 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177 WARNING! CAUTION! • Many accessories that can be plugged in draw To avoid serious injury or death: • Only devices designed for use in this type of power from the vehicle’s battery, even when not in use (i.e., cellular phones, etc.).

  • Page 180: Cigar Lighter And Ash Receiver - If Equipped

    178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CIGAR LIGHTER AND ASH RECEIVER — IF EQUIPPED An optional ash receiver is available from your autho- rized dealer and will fit in the center console front cupholder. The optional ash receiver also comes with a cigar lighter that can be used with the power outlets.
  • Page 181 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179 Rear Cupholders Rear Bottle Holder Rear Seat Bottle Holder WARNING! There are built-in bottle holders located in both rear door trim panels. If containers of hot liquid are placed in the bottle holder, they can spill when the door is closed, burn- ing the occupants.

  • Page 182: Storage

    180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE STORAGE CONSOLE FEATURES Glovebox Storage Compartment Storage The glovebox storage compartment is located on the right The center console is located between the front driver side of the instrument panel. To open the glovebox, pull and passenger seats.
  • Page 183 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181 Center Console Center Console Storage Two separate storage compartments are also located The top compartment holds small items, such as a pen underneath the armrest. and note pad, while the larger bottom compartment will hold CDs and alike.

  • Page 184: Cargo Area Features

    182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: CARGO AREA FEATURES • A notch in the front of the console base allows for use The 60/40 split-folding rear seat provides cargo-carrying of a cellular phone while it is plugged into the power versatility.
  • Page 185 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183 Always place cargo evenly on the cargo floor. Put heavier WARNING! (Continued) objects as low and as far forward as possible. Place as • The cargo area in the rear of the vehicle (with the much cargo as possible in front of the rear axle.

  • Page 186: Ski Pass-Through

    184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Ski Pass-Through REAR WINDOW FEATURES There is a ski pass-through door located behind the rear Rear Window Defroster seat armrest that allows longer items, such as snow skis, The rear window defroster button is located on the to be stored in the rear cargo area.
  • Page 187 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185 CAUTION! Failure to follow these cautions can cause damage to the heating elements: • Use care when washing the inside of the rear window. Do not use abrasive window cleaners on the interior surface of the window. Use a soft cloth and a mild washing solution, wiping parallel to the heating elements.
  • Page 189 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....190 EVIC Main Menu ....213 Compass Display .
  • Page 190 188 UNDERSTANDING YOUR INSTRUMENT PANEL Setting The Analog Clock ....221 Media Center 730N/430/430N (RHR/RER/ RBZ/RHB) CD/DVD/HDD/NAV — If Media Center 230 (REQ) — AM/FM Stereo Equipped .
  • Page 191 UNDERSTANDING YOUR INSTRUMENT PANEL 189 Operating Instructions — Radio Mode ..250 Play Mode ......268 Operation Instructions —...

  • Page 192: Instrument Panel Features

    190 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Air Outlet 6 — Radio 11 — Storage Compartment 2 — Side Window Demister Outlet 7 — Passenger Airbag 12 — Climate Control 3 — Instrument Cluster 8 — Glove Compartment 13 —...

  • Page 193: Instrument Cluster

    UNDERSTANDING YOUR INSTRUMENT PANEL 191 INSTRUMENT CLUSTER...

  • Page 194: Instrument Cluster Descriptions

    192 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS removes this heat. You can also turn the Temperature control to maximum heat, the Mode control to Floor and 1. Temperature Gauge the Fan control to High. This allows the heater core to act The temperature gauge shows engine coolant tempera- as a supplement to the radiator and aids in removing heat ture.
  • Page 195 UNDERSTANDING YOUR INSTRUMENT PANEL 193 5. Low Fuel Light If jump starting is required, refer to “Jump Starting When the fuel level drops to approximately 2.0 gal- Procedures” in “What To Do In Emergencies”. lons (7.6 Liters), the fuel symbol will light and a 7.
  • Page 196 194 UNDERSTANDING YOUR INSTRUMENT PANEL flash or remain on continuously. Refer to “Occupant 10. Engine Temperature Warning Light Restraints” in “Things To Know Before Starting Your This light warns of an overheated engine condi- Vehicle” for further information. tion. As engine coolant temperatures rise and the gauge approaches H , this indicator will illuminate 9.
  • Page 197 UNDERSTANDING YOUR INSTRUMENT PANEL 195 11. Brake Warning Light If brake failure is indicated, immediate repair is neces- This light monitors various brake functions, sary. including brake fluid level and parking brake WARNING! application. If the brake light turns on it may indicate that the parking brake is applied, that Driving a vehicle with the brake light on is danger- the brake fluid level is low, or that there is a problem with...
  • Page 198 196 UNDERSTANDING YOUR INSTRUMENT PANEL off unless the parking brake is applied or a brake fault is NOTE: You must apply the brakes before shifting from detected. If the light does not illuminate, have the light PARK. inspected by an authorized dealer. 14.
  • Page 199 UNDERSTANDING YOUR INSTRUMENT PANEL 197 The two trip odometers show individual trip mileage. To NOTE: If the instrument cluster is equipped with the switch from odometer to trip odometers, press and optional Electronic Vehicle Information Center (EVIC), release the Trip Odometer button. To reset a trip odom- then warnings such as ”Low Tire,”...
  • Page 200 198 UNDERSTANDING YOUR INSTRUMENT PANEL gASCAP means the engine oil change interval may fluctuate If the vehicle diagnostic system detects a leak or change dependent upon your personal driving style. in the evaporative system, or the fuel filler cap is loose, Unless reset, this message will continue to display each improperly installed, or damaged, the words “gASCAP”...
  • Page 201 UNDERSTANDING YOUR INSTRUMENT PANEL 199 4. For vehicles equipped with the Electronic Vehicle 17. Electronic Throttle Control (ETC) Indicator Light Information Center (EVIC), refer to “Electronic Vehicle This light informs you of a problem with the Information Center (EVIC)”. Electronic Throttle Control (ETC) system. If a problem is detected, the light will come on 15.

  • Page 202: Understanding Your Instrument Panel 187

    200 UNDERSTANDING YOUR INSTRUMENT PANEL 18. Park/Headlight ON Indicator — If Equipped 21. Front Fog Light Indicator — If Equipped This indicator will illuminate when the park This indicator will illuminate when the front fog lights or headlights are turned on. lights are on.
  • Page 203 UNDERSTANDING YOUR INSTRUMENT PANEL 201 the conventional brake system will continue to operate engine running. If the “ESC Activation/Malfunction In- normally provided that the BRAKE warning light is not dicator Light” comes on continuously with the engine running, a malfunction has been detected in the ESC system.
  • Page 204 202 UNDERSTANDING YOUR INSTRUMENT PANEL • The ESC system will make buzzing or clicking sounds Accordingly, when the low tire pressure telltale illumi- when it is active. This is normal; the sounds will stop nates, you should stop and check your tires as soon as when ESC becomes inactive following the maneuver possible, and inflate them to the proper pressure.
  • Page 205 UNDERSTANDING YOUR INSTRUMENT PANEL 203 illuminated. This sequence will continue upon subse- CAUTION! quent vehicle start-ups as long as the malfunction exists. When the malfunction indicator is illuminated, the sys- The TPMS has been optimized for the original tem may not be able to detect or signal low tire pressure equipment tires and wheels.
  • Page 206 204 UNDERSTANDING YOUR INSTRUMENT PANEL the bulb does not come on when turning the key from WARNING! LOCK to ON/RUN, have the condition checked promptly. A malfunctioning catalytic converter, as referenced above, can reach higher temperatures than in normal Certain conditions, such as a loose or missing gas cap, operating conditions.

  • Page 207: Mini-Trip Computer - If Equipped

    UNDERSTANDING YOUR INSTRUMENT PANEL 205 29. Electronic Vehicle Information Center (EVIC) CAUTION! Display — If Equipped This display shows the EVIC messages when the appro- Continuous driving with the Transmission Tempera- priate conditions exist. Refer to “Electronic Vehicle Infor- ture Warning Light illuminated will eventually cause mation Center (EVIC)”...

  • Page 208: Control Buttons

    206 UNDERSTANDING YOUR INSTRUMENT PANEL Control Buttons RESET Button To reset the display shown, turn the ignition switch to the ON position, then press and hold the RESET button located on the steering wheel. The following displays can be reset or changed: •...

  • Page 209: Electronic Vehicle Information Center (Evic) - If Equipped

    UNDERSTANDING YOUR INSTRUMENT PANEL 207 Trip B Shows the total distance traveled for Trip B since the last reset. ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) — IF EQUIPPED The Electronic Vehicle Information Center (EVIC) fea- tures a driver-interactive display that is located in the instrument cluster.
  • Page 210 208 UNDERSTANDING YOUR INSTRUMENT PANEL • Low Tire Information (Tire Pressure Monitor System (TPMS) Displays) — if equipped • Timer • Units • System Warnings (Door Ajar, etc.) • Personal Settings (Customer-Programmable Features) • Outside Temperature Display (°F or °C) •...

  • Page 211: Electronic Vehicle Information Center (Evic) Displays

    UNDERSTANDING YOUR INSTRUMENT PANEL 209 Press and release the DOWN button to advance Electronic Vehicle Information Center (EVIC) the display through the various Trip Functions Displays or Personal Settings. When the appropriate conditions exist, the EVIC displays the following messages: DOWN Button •...
  • Page 212 210 UNDERSTANDING YOUR INSTRUMENT PANEL • Personal Settings Not Avail – Vehicle in Motion • Remote start disabled — System fault • Door Ajar (with vehicle graphic showing which door • Oil Change Required (with a single chime) is open. A single chime sounds if the vehicle is in •...
  • Page 213 UNDERSTANDING YOUR INSTRUMENT PANEL 211 • Shift To Neutral - Then D Or R — Refer to Automatic • Trans. Getting Hot Press Brake — Refer to Automatic Transmission/Six-Speed Automatic Transmission Transmission/Six-Speed Automatic Transmission (C635) – If Equipped in Starting and Operating for (C635) –...

  • Page 214: Oil Change Required - If Equipped

    212 UNDERSTANDING YOUR INSTRUMENT PANEL • Engage Park Brake — Refer Automatic indicator system is duty cycle based, which means the Transmission/Six-Speed Automatic Transmission engine oil change interval may fluctuate dependent upon (C635) – If Equipped in Starting and Operating for your personal driving style.

  • Page 215: Evic Main Menu

    UNDERSTANDING YOUR INSTRUMENT PANEL 213 • Personal Settings EVIC Main Menu To step to each main menu feature press and release the NOTE: For features in the EVIC that can be reset MENU button once for each step. A step from the last (Average Fuel Economy and Elapsed Time), the EVIC item in the list will cause the first item in the feature list prompts a reset with a SELECT button graphic and the...
  • Page 216 214 UNDERSTANDING YOUR INSTRUMENT PANEL and audio information (if the radio is on) if the EVIC NOTE: A good calibration requires a level surface and display is not already displaying this screen. an environment free from large metallic objects such as buildings, bridges, underground cables, railroad tracks, NOTE: The system will display the last known outside etc.
  • Page 217 UNDERSTANDING YOUR INSTRUMENT PANEL 215 5. Drive the vehicle slowly (under 5 mph / 8 km/h), completing one or more circles (in an area free from large metal or metallic objects) until the “CAL” indicator turns off. The compass will now function normally. Compass Variance Compass Variance is the difference between Magnetic North and Geographic North.

  • Page 218: Average Fuel Economy

    216 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Press and release the DOWN button until “Compass Distance To Empty (DTE) Variance” and the current Variance Value displays in the Shows the estimated distance that can be traveled with EVIC. the fuel remaining in the tank. This estimated distance is 4.

  • Page 219: Tire Psi

    UNDERSTANDING YOUR INSTRUMENT PANEL 217 Tire PSI Elapsed Time Press and release the MENU button until Tire PSI is Shows the total elapsed time of travel since the last reset. displayed. Elapsed time will increment when the ignition switch is Tire pressure information is displayed as follows: in the RUN or START position.

  • Page 220: System Status

    218 UNDERSTANDING YOUR INSTRUMENT PANEL System Status Press and release the DOWN button to display the following programmable features: Displays SYSTEM OK if there are no active Warning Messages stored. Pressing and releasing the DOWN Language button when SYSTEM OK is displayed will do nothing. When in this display you may select different languages Displays SYSTEM WARNINGS PRESENT if there are for all display nomenclature, including the trip functions.
  • Page 221 UNDERSTANDING YOUR INSTRUMENT PANEL 219 Driver Door 1st Press is selected, you must press the RKE without the Sound Horn on lock feature selected. To transmitter UNLOCK button twice to unlock the passen- make your selection, press and release the SELECT ger’s doors.
  • Page 222 220 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Turning the headlights on during the daytime Display Units In causes the instrument panel lights to dim. To increase the The EVIC and odometer can be changed between English brightness, refer to “Lights” in “Understanding The and Metric units of measure.

  • Page 223: Setting The Analog Clock

    UNDERSTANDING YOUR INSTRUMENT PANEL 221 SETTING THE ANALOG CLOCK MEDIA CENTER 230 (REQ) — AM/FM STEREO RADIO AND 6–DISC CD/DVD CHANGER To set the analog clock, located at the top center of the (MP3/WMA AUX JACK) instrument panel, press and hold the button in until the setting is correct.

  • Page 224: Operating Instructions - Radio Mode

    222 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Radio Mode to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make NOTE: The ignition switch must be in the ON or ACC another selection.
  • Page 225 UNDERSTANDING YOUR INSTRUMENT PANEL 223 If your vehicle is not equipped with or this feature is not Clock Setting Procedure available on your vehicle, a “Not Equipped With 1. Press and hold the TIME button until the hours blink. Uconnect Phone” message will display on the radio screen.
  • Page 226 224 UNDERSTANDING YOUR INSTRUMENT PANEL INFO Button Push the rotary TUNE/SCROLL control knob a second Press the INFO button for an RDS station (one with call time and MID will display. Turn the TUNE/SCROLL letters displayed). The radio will return a Radio Text control knob to the right or left to increase or decrease the message broadcast from an FM station (FM mode only).
  • Page 227 UNDERSTANDING YOUR INSTRUMENT PANEL 225 Push the rotary TUNE/SCROLL control knob again to 16-Digit Character Program Type exit setting tone, balance, and fade. Display Classic Rock Cls Rock MUSIC TYPE Button College College Pressing this button once will turn on the Music Type mode for five seconds.
  • Page 228 226 UNDERSTANDING YOUR INSTRUMENT PANEL SETUP Button 16-Digit Character Program Type Pressing the SETUP button allows you to select between Display the following items: Soft Soft Soft Rock Soft Rck NOTE: Turn the TUNE/SCROLL control knob to scroll through the entries. Push the AUDIO/SELECT button to Soft Rhythm and Blues Soft R &...
  • Page 229 UNDERSTANDING YOUR INSTRUMENT PANEL 227 • DVD Play Options - Selecting the DVD Play Options • VES™ Power - Allows you to turn VES™ ON and will display the following: OFF (if equipped). • Subtitle – Repeatedly pressing SELECT will switch •...
  • Page 230 228 UNDERSTANDING YOUR INSTRUMENT PANEL Menu Language — If Equipped the disc). You can select a language not listed by scrolling Selecting this item will allow the user to choose the down and selecting other. Enter the country code using default startup DVD menu language (effective only if the TUNE/SCROLL control knob to scroll up and down language supported by disc).
  • Page 231 UNDERSTANDING YOUR INSTRUMENT PANEL 229 AutoPlay — If Equipped and press and release that button. If a button is not When this is set to On and a DVD video is inserted, it will selected within five seconds after pressing the SET but- bypass the DVD menu screen and automatically play the ton, the station will continue to play but will not be movie.

  • Page 232: Operation Instructions - (Disc Mode For Cd And Mp3/Wma Audio Play, Dvd-Video)

    230 UNDERSTANDING YOUR INSTRUMENT PANEL Buttons 1 - 6 CAUTION! These buttons tune the radio to the stations that you commit to pushbutton memory {12 AM, 12 FM, and 12 The radio may shut down during extremely hot Satellite (if equipped) stations}. conditions.
  • Page 233 UNDERSTANDING YOUR INSTRUMENT PANEL 231 Radio display will show LOADING DISC when the disc The disc can be ejected with the radio and ignition OFF. is loading and “READING DISC” when the radio is SEEK Button (CD MODE) reading the disc. Press the right SEEK button for the next selection on the CD.

  • Page 234: Notes On Playing Mp3/Wma Files

    232 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF (CD MODE) Supported Medium Formats (File Systems) Press and hold FF (Fast Forward) and the CD player will The medium formats supported by the radio are ISO 9660 begin to fast forward until FF is released, or RW or Level 1 and Level 2 and includes the Joliet extension.
  • Page 235 UNDERSTANDING YOUR INSTRUMENT PANEL 233 Multisession disc formats are supported by the radio. frequencies in the following table are supported. In Multisession discs may contain combinations of normal addition, variable bit rates (VBR) are also supported. The CD audio tracks and computer files (including MP3/ majority of MP3/WMA files use a 44.1 kHz sampling rate WMA files).

  • Page 236: List Button (Disc Mode For Mp3/Wma Play)

    234 UNDERSTANDING YOUR INSTRUMENT PANEL • Number of files and folders - Loading times will ID3 Tag information for artist, song title, and album title are supported for ID3 version 1 tags. ID3 version 2 is not increase with more files and folders supported by the radios.

  • Page 237: Info Button (Disc Mode For Mp3/Wma Play)

    UNDERSTANDING YOUR INSTRUMENT PANEL 235 INFO Button (DISC Mode for MP3/WMA Play) Pressing the AUX button will change the mode to auxil- Pressing the INFO button repeatedly will scroll through iary device if the AUX jack is connected. the following TAG information: Song Title, Artist, File NOTE: The AUX device must be turned on and the Name, and Folder Name (if available).
  • Page 238 236 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button (Auxiliary Mode) Operating Instructions - Video Entertainment Press the TIME button to change the display from System (VES)™ (If Equipped) elapsed playing time to time of day. The time of day will Refer to “Video Entertainment System (VES)™” for fur- display for five seconds.

  • Page 239: Uconnect™ Multimedia (Satellite Radio) - If Equipped

    UNDERSTANDING YOUR INSTRUMENT PANEL 237 DTS™ radio system in your vehicle. Sirius will supply a wel- DTS™ and DTS™ 2.0 are trademarks of Digital The- come kit that contains general information, including ater Systems, Inc. how to setup your on-line listening account. For further information, call the toll-free number 888-539-7474, or Uconnect™...
  • Page 240 238 UNDERSTANDING YOUR INSTRUMENT PANEL using the TUNE/SCROLL control knob until Sirius ID is Reception Quality selected. Press the TUNE/SCROLL control knob and the Satellite reception may be interrupted due to one of the Sirius ID number will display. The Sirius ID number following reasons: display will time out in two minutes.
  • Page 241 UNDERSTANDING YOUR INSTRUMENT PANEL 239 SEEK Buttons additional three seconds will make the radio display the Press and release the SEEK buttons to search for the next Song Title all of the time (press and hold again to return channel in Satellite mode. Press the right switch to seek to normal display).
  • Page 242 240 UNDERSTANDING YOUR INSTRUMENT PANEL Toggle the MUSIC TYPE button again to select the music SET Button – To Set the Pushbutton Memory type. When you are receiving a channel that you wish to commit to pushbutton memory, press the SET button. By pressing the SEEK button when the Music Type The symbol SET 1 will now show in the display window.

  • Page 243: Media Center 730N/430/430N

    UNDERSTANDING YOUR INSTRUMENT PANEL 241 Buttons 1 - 6 MEDIA CENTER 130 (SALES CODE RES) These buttons tune the radio to the channels that you NOTE: The radio sales code is located on the lower right commit to pushbutton memory (12 Satellite stations). side of the radio faceplate.

  • Page 244: Operating Instructions - Radio Mode

    242 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions — Radio Mode to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make NOTE: The ignition switch must be in the ON or ACC another selection.
  • Page 245 UNDERSTANDING YOUR INSTRUMENT PANEL 243 4. Adjust the minutes using the right side TUNE/ Push the rotary TUNE/SCROLL control knob a second SCROLL control knob. Press the TUNE/SCROLL control time and MID will display. Turn the TUNE/SCROLL knob to save time change. control knob to the right or left to increase or decrease the mid-range tones.
  • Page 246 244 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob again to SET 2 in both AM and FM. This allows a total of 12 AM exit setting tone, balance, and fade. and 12 FM stations to be stored into pushbutton memory. The stations stored in SET 2 memory can be selected by AM/FM Button pressing the pushbutton twice.

  • Page 247: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play

    UNDERSTANDING YOUR INSTRUMENT PANEL 245 Operation Instructions — CD MODE For CD And If you insert a disc with the ignition ON and the radio MP3 Audio Play ON, the unit will switch from radio to CD mode and begin to play when you insert the disc. The display will NOTE: show the track number, and index time in minutes and •...
  • Page 248 246 UNDERSTANDING YOUR INSTRUMENT PANEL EJECT Button - Ejecting a CD the current selection. Pressing and holding the SEEK Press the EJECT button to eject the CD. button will allow faster scrolling through the tracks in CD and MP3 modes. TIME Button Press this button to change the display from a large CD If you have ejected a disc and have not removed it within...

  • Page 249: Notes On Playing Mp3 Files

    UNDERSTANDING YOUR INSTRUMENT PANEL 247 SET/RND Button (Random Play Button) Supported Medium Formats (File Systems) Press this button while the CD is playing to activate The medium formats supported by the radio are ISO 9660 Random Play. This feature plays the selections on the Level 1 and Level 2 and includes the Joliet extension.
  • Page 250 248 UNDERSTANDING YOUR INSTRUMENT PANEL • Maximum number of characters in file/folder names: extension may cause playback problems. The radio is designed to recognize the file as an invalid MP3 and will • Level 1: 12 (including a separator . and a three- not play the file.

  • Page 251: Operation Instructions - Auxiliary Mode

    UNDERSTANDING YOUR INSTRUMENT PANEL 249 • Number of files and folders - Loading times will ID3 Tag information for artist, song title, and album title are supported for version 1 ID3 tags. ID3 version 2 is not increase with more files and folders supported by the radios.

  • Page 252: Media Center 130 With Satellite Radio (Sales Code Res+Rsc)

    250 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button (Auxiliary Mode) Press this button to change the display to time of day. The time of day will display for five seconds (when ignition is OFF). MEDIA CENTER 130 WITH SATELLITE RADIO (SALES CODE RES+RSC) NOTE: The radio sales code is located on the lower right side of the radio faceplate.
  • Page 253 UNDERSTANDING YOUR INSTRUMENT PANEL 251 Power Switch/Volume Control (Rotary) Voice Command System (Radio) — If Equipped Push the ON/VOLUME control knob to turn on the Refer to “Voice Command” in “Understanding The Fea- radio. Push the ON/VOLUME control knob a second tures Of Your Vehicle”.
  • Page 254 252 UNDERSTANDING YOUR INSTRUMENT PANEL If your vehicle is not equipped with or this feature is not 4. Adjust the minutes using the right side TUNE/ available on your vehicle, a “Not Equipped With SCROLL control knob. Press the TUNE/SCROLL control Uconnect Phone”...
  • Page 255 UNDERSTANDING YOUR INSTRUMENT PANEL 253 RW/FF Push the rotary TUNE/SCROLL control knob a third Pressing the RW (Rewind) or FF (Fast Forward) buttons time and TREBLE will display. Turn the TUNE/SCROLL causes the tuner to search for the next frequency in the control knob to the right or left to increase or decrease the direction of the arrows.
  • Page 256 254 UNDERSTANDING YOUR INSTRUMENT PANEL seconds will allow the program format type to be se- 16-Digit Character Program Type lected. Many radio stations do not currently broadcast Display Music Type information. Nostalgia Nostalga Toggle the MUSIC TYPE button to select the following Oldies Oldies format types:...
  • Page 257 UNDERSTANDING YOUR INSTRUMENT PANEL 255 By pressing the SEEK button when the Music Type icon the minutes using the right side TUNE/SCROLL is displayed, the radio will be tuned to the next frequency control knob. Press the TUNE/SCROLL control knob station with the same selected Music Type name.

  • Page 258: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play

    256 UNDERSTANDING YOUR INSTRUMENT PANEL display window. Each button can be set for SET 1 and Operation Instructions — CD MODE for CD and SET 2 in both AM and FM. This allows a total of 12 AM MP3 Audio Play and 12 FM stations to be stored into pushbutton memory.
  • Page 259 UNDERSTANDING YOUR INSTRUMENT PANEL 257 If you insert a disc with the ignition ON and the radio EJECT Button - Ejecting a CD ON, the unit will switch from radio to CD mode and Press the EJECT button to eject the CD. begin to play when you insert the disc.

  • Page 260: Notes On Playing Mp3 Files

    258 UNDERSTANDING YOUR INSTRUMENT PANEL the current selection. Pressing and holding the SEEK SET/RND Button (Random Play Button) button will allow faster scrolling through the tracks in Press this button while the CD is playing to activate CD and MP3 modes. Random Play.
  • Page 261 UNDERSTANDING YOUR INSTRUMENT PANEL 259 Supported Medium Formats (File Systems) exceeding 20 folders will result in this display. With The medium formats supported by the radio are ISO 9660 200 files, exceeding 50 folders will result in this Level 1 and Level 2 and includes the Joliet extension. display.) When reading discs recorded using formats other than •...
  • Page 262 260 UNDERSTANDING YOUR INSTRUMENT PANEL Supported MP3 File Formats MPEG Sampling Fre- Bit Rate (kbps) The radio will recognize only files with the *.MP3 exten- Specification quency (kHz) sion as MP3 files. Non-MP3 files named with the *.MP3 160, 128, 144, extension may cause playback problems.

  • Page 263: List Button (Cd Mode For Mp3 Play)

    UNDERSTANDING YOUR INSTRUMENT PANEL 261 Loading times for playback of MP3 files may be affected begin playing the files contained in that folder (or the by the following: next folder in sequence if the selection does not contain playable files). •...

  • Page 264: Uconnect™ Multimedia (Satellite Radio) - If Equipped

    262 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - Auxiliary Mode Uconnect™ Multimedia (Satellite Radio) — If The auxiliary (AUX) jack is an audio input jack which Equipped allows the user to plug in a portable device such as an Satellite radio uses direct satellite-to-receiver broadcast- MP3 player or cassette player and utilize the vehicle’s ing technology to provide clear digital sound, coast to audio system to amplify the source and play through the...
  • Page 265 UNDERSTANDING YOUR INSTRUMENT PANEL 263 information, call the toll-free number 888-539-7474, or Sirius ID number will display. The Sirius ID number visit the Sirius web site at www.sirius.com, or at display will time out in two minutes. Press any button on www.siriuscanada.ca for Canadian residents.
  • Page 266 264 UNDERSTANDING YOUR INSTRUMENT PANEL Reception Quality SEEK Buttons Satellite reception may be interrupted due to one of the Press and release the SEEK buttons to search for the next following reasons: channel in Satellite mode. Press the right switch to seek up and the left switch to seek down.
  • Page 267 UNDERSTANDING YOUR INSTRUMENT PANEL 265 additional three seconds will make the radio display the Toggle the MUSIC TYPE button again to select the music Song Title all of the time (press and hold again to return type. to normal display). By pressing the SEEK button when the Music Type RW/FF function is active, the radio will be tuned to the next...

  • Page 268: Ipod /Usb/Mp3 Control - If Equipped

    266 UNDERSTANDING YOUR INSTRUMENT PANEL SET Button – To Set the Pushbutton Memory Every time a preset button is used, a corresponding When you are receiving a channel that you wish to button number will display. commit to pushbutton memory, press the SET button. Buttons 1 - 6 The symbol SET 1 will now show in the display window.

  • Page 269: Connecting The Ipod Or External Usb Device

    UNDERSTANDING YOUR INSTRUMENT PANEL 267 This feature allows an iPod or external USB device to be Connecting The iPod Or External USB Device plugged into the USB port, located in the center of the Use the connection cable to connect an iPod or external instrument panel below the climate controls.

  • Page 270: Using This Feature

    268 UNDERSTANDING YOUR INSTRUMENT PANEL • The audio device can be controlled using the radio Once the audio device is connected and synchronized to the vehicle’s iPod /USB/MP3 control system (iPod or buttons to Play, Browse, and List the iPod contents. external USB device may take a few minutes to connect), •...
  • Page 271 UNDERSTANDING YOUR INSTRUMENT PANEL 269 • A single press backward << RW or forward FF >> will mode. In Play mode, the following buttons on the radio faceplate may be used to control the iPod or external jump backward or forward respectively, for five USB device and display data: seconds.

  • Page 272: List Or Browse Mode

    270 UNDERSTANDING YOUR INSTRUMENT PANEL • Press the SCAN button to use iPod /USB/MP3 de- List Or Browse Mode vice scan mode, which will play the first 10 seconds of During Play mode, pressing any of the buttons described each track in the current list and then forward to the below, will bring up List mode.
  • Page 273 UNDERSTANDING YOUR INSTRUMENT PANEL 271 • During all List modes, the iPod displays all lists in • Pressing a PRESET button will display the current “wrap-around” mode. So if the track is at the list on the top line and the first item in that list on bottom of the list, just turn the wheel backward the second line.

  • Page 274: Bluetooth Streaming Audio (Btsa)

    272 UNDERSTANDING YOUR INSTRUMENT PANEL Bluetooth Streaming Audio (BTSA) CAUTION! Music can be streamed from your cellular phone to the • Leaving the iPod or external USB device (or any Uconnect™ phone system. supported device) anywhere in the vehicle in Controlling BTSA Using Radio Buttons extreme heat or cold can alter the operation or To get into the BTSA mode, press either “AUX”...

  • Page 275: Steering Wheel Audio Controls - If Equipped

    UNDERSTANDING YOUR INSTRUMENT PANEL 273 2. After the Ready prompt and the following beep, say STEERING WHEEL AUDIO CONTROLS — IF Setup , then Select Audio Devices . EQUIPPED 3. Say the name of the audio device or ask the Uconnect™...

  • Page 276: Radio Operation

    274 UNDERSTANDING YOUR INSTRUMENT PANEL The right-hand rocker switch has a pushbutton in the The button located in the center of the left-hand switch center, and controls the volume and mode of the sound will tune to the next preset station that you have pro- system.

  • Page 277: Cd/Dvd Disc Maintenance

    UNDERSTANDING YOUR INSTRUMENT PANEL 275 CD/DVD DISC MAINTENANCE NOTE: If you experience difficulty in playing a particu- To keep a CD/DVD in good condition, take the following lar disc, it may be damaged (i.e., scratched, reflective precautions: coating removed, a hair, moisture or dew on the disc) oversized, or have protection encoding.

  • Page 278: Climate Controls

    276 UNDERSTANDING YOUR INSTRUMENT PANEL CLIMATE CONTROLS Blower Control The air conditioning and heating system is designed to Rotate this control to regulate the make you comfortable in all types of weather. amount of air forced through the ven- tilation system in any mode. The Manual Heating And Air Conditioning blower speed increases as you move the control to the right from the “O”...
  • Page 279 UNDERSTANDING YOUR INSTRUMENT PANEL 277 Temperature Control Mode Control (Air Direction) Rotate this control to regulate the tem- Rotate this control to choose from sev- perature of the air inside the passenger eral patterns of air distribution. You compartment. Rotating the dial left can select either a primary mode as into the blue area of the scale indicates identified by the symbols on the con-...
  • Page 280 278 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: For all settings, except full cold or full hot, there Defrost is a difference in temperature between the upper and Air is directed through the windshield and side lower outlets. The warmer air flows to the floor outlets. window demist outlets.
  • Page 281 UNDERSTANDING YOUR INSTRUMENT PANEL 279 the LED in the control button to illuminate. After ten several times then go out. Recirculation will be dis- minutes, the system will return to normal mode function abled automatically is these modes are selected. and the LED will turn off.

  • Page 282: Automatic Temperature Control (Atc) - If Equipped

    280 UNDERSTANDING YOUR INSTRUMENT PANEL • MAX A/C Automatic Temperature Control (ATC) — If For maximum cooling use the A/C and recirculation Equipped buttons at the same time. • ECONOMY MODE If economy mode is desired, press the A/C button to turn OFF the indicator light and the A/C compressor.
  • Page 283 UNDERSTANDING YOUR INSTRUMENT PANEL 281 Operation of the system is quite simple. the “O” (OFF) position on the blower control stops the system completely and closes the outside air intake. 1. Turn the Mode Control knob (on the right) and the Blower Control knob (on the left) to AUTO.
  • Page 284 282 UNDERSTANDING YOUR INSTRUMENT PANEL the radiator and through the condenser. Fabric front Manual Operation fascia protectors may reduce airflow to the condenser, This system offers a full complement of manual override reducing air conditioning performance. features, which consist of Blower Preferred Automatic, Mode Preferred Automatic, or Blower and Mode Pre- •...
  • Page 285 UNDERSTANDING YOUR INSTRUMENT PANEL 283...
  • Page 286 284 UNDERSTANDING YOUR INSTRUMENT PANEL • Floor The operator can override the AUTO mode setting to change airflow distribution by rotating the Mode Control Air is directed through the floor outlets with a knob (on the right) to one of the following positions. small amount flowing through the defrost and side window demist outlets.
  • Page 287 UNDERSTANDING YOUR INSTRUMENT PANEL 285 • Air Conditioner Control the LED in the control button to illuminate. After ten Press this button to turn on the air minutes, the system will return to normal AUTO mode conditioning during manual operation function and the LED will turn off.

  • Page 288: Operating Tips

    286 UNDERSTANDING YOUR INSTRUMENT PANEL Recirculation to be selected while in floor, defrost, or Operating Tips Mix mode. Attempting to use the recirculation while in NOTE: Refer to the chart at the end of this section for these modes will cause the LED in the control button suggested control settings for various weather condi- to blink and then turn off.
  • Page 289 UNDERSTANDING YOUR INSTRUMENT PANEL 287 Winter Operation provide sufficient heating. If side window fogging be- Use of the air Recirculation Mode during winter months comes a problem, increase blower speed. Vehicle win- is not recommended because it may cause window dows tend to fog on the inside in mild but rainy or humid fogging.
  • Page 290 288 UNDERSTANDING YOUR INSTRUMENT PANEL Outside Air Intake A/C Air Filter — If Equipped Make sure the air intake, located directly in front of the The A/C Filter prevents most dust and pollen from windshield, is free of obstructions such as leaves. Leaves entering the cabin.
  • Page 291 UNDERSTANDING YOUR INSTRUMENT PANEL 289 Control Setting Suggestions for Various Weather Conditions...

  • Page 293: Starting And Operating

    STARTING AND OPERATING CONTENTS Starting Procedures ....296 Automatic Transmission ....300 Automatic Transmission .
  • Page 294 292 STARTING AND OPERATING Gear Ranges ......310 Power Steering ..... . . 331 Six-Speed Automatic Transmission (C635) —...
  • Page 295 STARTING AND OPERATING 293 Tire Identification Number (TIN) ..346 Tread Wear Indicators ....358 Tire Terminology And Definitions ..347 Life Of Tire .
  • Page 296 294 STARTING AND OPERATING E-85 Usage In Non-Flex Fuel Vehicles ..374 Replacement Parts ....380 MMT In Gasoline ....375 Maintenance .
  • Page 297 STARTING AND OPERATING 295 Trailer Hitch Classification ....388 Recreational Towing (Behind Motorhome, Etc.) ....396 Trailer Towing Weights (Maximum Trailer Weight Ratings) .

  • Page 298: Starting Procedures

    296 STARTING AND OPERATING STARTING PROCEDURES Automatic Transmission Before starting your vehicle, adjust your seat, adjust the The shift lever must be in the PARK or NEUTRAL inside and outside mirrors, fasten your seat belt, and if position before you can start the engine. Apply the brakes present, instruct all other occupants to buckle their seat before shifting to any driving gear.

  • Page 299: Extreme Cold Weather

    STARTING AND OPERATING 297 For vehicles equipped with Tip Start (Six-Speed Trans- If Engine Fails To Start mission), turn the ignition switch to the START position WARNING! and release it as soon as the starter engages. The starter motor will continue to run, and it will disengage auto- •...
  • Page 300 298 STARTING AND OPERATING the way to the floor and hold it there while cranking the WARNING! (Continued) engine. This should clear any excess fuel in case the • Do not attempt to push or tow your vehicle to get engine is flooded.

  • Page 301: After Starting

    STARTING AND OPERATING 299 With Tip Start ENGINE BLOCK HEATER — IF EQUIPPED If the engine fails to start after you have followed the The engine block heater warms the engine, and permits “Normal Starting” or “Extreme Cold Weather” proce- quicker starts in cold weather.

  • Page 302: Automatic Transmission

    300 STARTING AND OPERATING AUTOMATIC TRANSMISSION WARNING! • It is dangerous to move the shift lever out of PARK CAUTION! or NEUTRAL if the engine speed is higher than Damage to the transmission may occur if the follow- idle speed. If your foot is not firmly pressing on ing precautions are not observed: the brake pedal, the vehicle could accelerate •...

  • Page 303: Automatic Transmission Ignition Interlock

    STARTING AND OPERATING 301 Key Ignition Park Interlock WARNING! (Continued) This vehicle is equipped with a Key Ignition Park Inter- • Unintended movement of a vehicle could injure lock which requires the shift lever to be placed in PARK those in and near the vehicle. As with all vehicles, before the ignition switch can be turned to the LOCK/ you should never exit a vehicle while the engine is OFF position.

  • Page 304: Four-Speed Automatic Transmission - If Equipped

    302 STARTING AND OPERATING be turned to the ON/RUN or START position (engine vehicle is stopped. Be sure to keep your foot on the brake running or not) and the brake pedal must be pressed. pedal when moving the shift lever between these gears. Four-Speed Automatic Transmission —...
  • Page 305 STARTING AND OPERATING 303 move the shift lever out of PARK. As an added precau- WARNING! (Continued) tion, turn the front wheels toward the curb on a downhill • It is dangerous to move the shift lever out of PARK grade and away from the curb on an uphill grade.
  • Page 306 304 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • Unintended movement of a vehicle could injure • When leaving the vehicle, always remove the key those in or near the vehicle. As with all vehicles, fob from the ignition and lock your vehicle. Never you should never exit a vehicle while the engine is leave children alone in a vehicle, or with access to running.
  • Page 307 STARTING AND OPERATING 305 • Look at the shift lever position display and verify that CAUTION! it indicates the PARK position. • Before moving the shift lever out of PARK, you • With brake pedal released, verify that the shift lever must turn the ignition switch from the LOCK/OFF will not move out of PARK.
  • Page 308 306 STARTING AND OPERATING DRIVE WARNING! This range should be used for most city and highway driving. It provides the smoothest upshifts and down- Do not coast in NEUTRAL and never turn off the shifts, and the best fuel economy. The transmission ignition to coast down a hill.
  • Page 309 STARTING AND OPERATING 307 modify the DRIVE and “3” range shift points. This is Shifts into third may be delayed to provide second gear done to prevent transmission damage due to overheat- operation at higher speeds. Using the 3 range while ing.
  • Page 310 308 STARTING AND OPERATING selected. PARK, REVERSE, and NEUTRAL will continue NOTE: Even if the transmission can be reset, it is to operate. The Malfunction Indicator Light (MIL) may be recommended that you visit your authorized dealer at illuminated. Limp Home Mode allows the vehicle to be your earliest possible convenience.

  • Page 311: Six-Speed Automatic Transmission (62Te) - If Equipped

    STARTING AND OPERATING 309 • vehicle speed is sufficiently high, and when the transmission is sufficiently warm, will demon- strate that the transmission is able to shift into and out of • the driver is not heavily pressing the accelerator. Overdrive.

  • Page 312: Gear Ranges

    310 STARTING AND OPERATING Shifting from DRIVE to PARK or REVERSE should be done only after the accelerator pedal is released and the vehicle is stopped. Be sure to keep your foot on the brake pedal when moving the shift lever between these gears. The transmission shift lever has PARK, REVERSE, NEU- TRAL, DRIVE, and AutoStick shift positions.
  • Page 313 STARTING AND OPERATING 311 Never attempt to use PARK while vehicle is in motion. WARNING! Apply the parking brake when leaving vehicle in this • Never use the PARK position as a substitute for range. the parking brake. Always apply the parking When parking on a level surface, you may place the shift brake fully when parked to guard against vehicle lever in the PARK position first, and then apply the...
  • Page 314 312 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • It is dangerous to move the shift lever out of PARK • Unintended movement of a vehicle could injure or NEUTRAL if the engine speed is higher than those in or near the vehicle. As with all vehicles, idle speed.
  • Page 315 STARTING AND OPERATING 313 WARNING! (Continued) CAUTION! • When leaving the vehicle, always remove the key • Before moving the shift lever out of PARK, you fob from the ignition and lock your vehicle. Never must turn the ignition switch from the LOCK/OFF leave children alone in a vehicle, or with access to position to the ON/RUN position, and also press an unlocked vehicle.
  • Page 316 314 STARTING AND OPERATING The following indicators should be used to ensure that in this range. Set the parking brake and shift the trans- you have engaged the shift lever into the PARK position: mission into PARK if you must leave the vehicle. •...
  • Page 317 STARTING AND OPERATING 315 DRIVE During cold temperatures, transmission operation may This range should be used for most city and highway be modified depending on engine and transmission driving. It provides the smoothest upshifts and down- temperature as well as vehicle speed. This feature im- shifts, and the best fuel economy.
  • Page 318 316 STARTING AND OPERATING PARK, REVERSE, and NEUTRAL will continue to oper- NOTE: Even if the transmission can be reset, we recom- ate. The Malfunction Indicator Light (MIL) may be illu- mend that you visit an authorized dealer at your earliest minated.

  • Page 319: Six-Speed Automatic Transmission (C635) - If Equipped

    STARTING AND OPERATING 317 • vehicle speed is sufficiently high, and transmission is sufficiently warm, will demonstrate that the transmission is able to shift into and out of Overdrive. • the driver is not heavily pressing the accelerator. Six-Speed Automatic Transmission (C635) — If Torque Converter Clutch Equipped A feature designed to improve fuel economy has been...
  • Page 320 318 STARTING AND OPERATING vehicle is stopped. Be sure to keep your foot on the brake pedal when moving the shift lever between these gears. The transmission shift lever has PARK, REVERSE, NEU- TRAL, DRIVE, and AutoStick shift positions. Manual shifts can be made using the AutoStick shift control (refer to “AutoStick ”...

  • Page 321: Gear Ranges

    STARTING AND OPERATING 319 Gear Ranges WARNING! DO NOT race the engine when shifting from PARK or • Never use the PARK position as a substitute for NEUTRAL into another gear range. the parking brake. Always apply the parking PARK brake fully when parked to guard against vehicle This range supplements the parking brake by locking the movement and possible injury or damage.
  • Page 322 320 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • It is dangerous to move the shift lever out of PARK • Unintended movement of a vehicle could injure or NEUTRAL if the engine speed is higher than those in or near the vehicle. As with all vehicles, idle speed.
  • Page 323 STARTING AND OPERATING 321 WARNING! (Continued) CAUTION! • When leaving the vehicle, always remove the key • Before moving the shift lever out of PARK, you fob from the ignition and lock your vehicle. Never must turn the ignition switch from the LOCK/OFF leave children alone in a vehicle, or with access to position to the ON/RUN position, and also press an unlocked vehicle.
  • Page 324 322 STARTING AND OPERATING • With brake pedal released, verify that the shift lever CAUTION! will not move out of PARK. Towing the vehicle, coasting, or driving for any other REVERSE reason with the transmission in NEUTRAL can result This range is for moving the vehicle backward. Shift into in severe transmission damage.
  • Page 325 STARTING AND OPERATING 323 while towing heavy trailers), use the AutoStick mode MESSAGE DESCRIPTION (refer to “AutoStick ” in “Starting And Operating” for SHIFT NOT The gear position requested by the further information) to select a lower gear range. Under ALLOWED driver is currently blocked.
  • Page 326 324 STARTING AND OPERATING MESSAGE DESCRIPTION MESSAGE DESCRIPTION SHIFT TO The transmission has shifted itself into REDUCE The transmission pump is overheat- NEUTRAL – NEUTRAL (due to a fault condition, GEAR ing. In AutoStick mode, try to drive THEN D or R or overheat due to excessive idling CHANGES in one specific gear as much as pos-...
  • Page 327 STARTING AND OPERATING 325 Transmission Limp Home Mode MESSAGE DESCRIPTION Transmission function is monitored electronically for TRANS. HOT The transmission driving clutch has abnormal conditions. If a condition is detected that could STOP overheated. Pull over and shift the result in transmission damage, Transmission Limp Home SAFELY transmission into PARK and allow the Mode is activated.

  • Page 328: Autostick - If Equipped

    326 STARTING AND OPERATING 3. Turn the ignition switch to the LOCK/OFF position. vehicle. AutoStick allows you to maximize engine brak- ing, eliminate undesirable upshifts and downshifts, and 4. Wait approximately 10 seconds. improve overall vehicle performance. This system can 5.

  • Page 329: General Information

    STARTING AND OPERATING 327 • The transmission will automatically shift up when AutoStick is deactivated when the shift lever is moved from the AutoStick (+/-) position into the DRIVE maximum engine speed is reached while AutoStick is position. engaged. • Transmission shifting will be more noticeable when General Information AutoStick is engaged.

  • Page 330: Traction

    328 STARTING AND OPERATING 2. Slow down if the road has standing water or puddles. WARNING! 3. Replace the tires when tread wear indicators first Rapid acceleration on slippery surfaces is dangerous. become visible. Unequal traction can cause sudden pulling of the 4.

  • Page 331: Flowing/Rising Water

    STARTING AND OPERATING 329 Flowing/Rising Water CAUTION! • Always check the depth of the standing water WARNING! before driving through it. Never drive through Do not drive on or across a road or path where water standing water that is deeper than the bottom of is flowing and/or rising (as in storm run-off).
  • Page 332 330 STARTING AND OPERATING CAUTION! (Continued) WARNING! • Driving through standing water may cause dam- • Driving through standing water limits your vehi- age to your vehicle’s drivetrain components. Al- cle’s traction capabilities. Do not exceed 5 mph ways inspect your vehicle’s fluids (i.e., engine oil, (8 km/h) when driving through standing water.

  • Page 333: Power Steering

    STARTING AND OPERATING 331 POWER STEERING system. This noise should be considered normal, and it The standard power steering system will give you good does not in any way damage the steering system. vehicle response and increased ease of maneuverability WARNING! in tight spaces.

  • Page 334: Parking Brake

    332 STARTING AND OPERATING checked if a leak is suspected, abnormal noises are If necessary, add fluid to restore to the proper indicated apparent, and/or the system is not functioning as antici- level. With a clean cloth, wipe any spilled fluid from all pated.
  • Page 335 STARTING AND OPERATING 333 NOTE: • When the parking brake is applied and the transmis- sion is placed in gear, the “Brake Warning Light” will flash. If vehicle speed is detected, a chime will sound to alert the driver. Fully release the parking brake before attempting to move the vehicle.
  • Page 336 334 STARTING AND OPERATING WARNING! WARNING! (Continued) • Be sure the parking brake is fully disengaged • Never use the PARK position as a substitute for before driving; failure to do so can lead to brake the parking brake. Always apply the parking failure and a collision.

  • Page 337: Anti-Lock Brake System (Abs)

    STARTING AND OPERATING 335 ANTI-LOCK BRAKE SYSTEM (ABS) WARNING! (Continued) The Anti-Lock Brake System (ABS) provides increased • The ABS cannot prevent collisions, including vehicle stability and brake performance under most those resulting from excessive speed in turns, braking conditions. The system operates with a separate following another vehicle too closely, or hydro- computer to modulate the hydraulic pressure to prevent planing.
  • Page 338 336 STARTING AND OPERATING service is required. However, the conventional brake properly. This self check occurs each time the vehicle is system will continue to operate normally if the “Brake started and accelerated past 7 mph (11 km/h). Warning Light” is not on. ABS is activated during braking under certain road or If the “Anti-Lock Brake Warning Light”...

  • Page 339: Electronic Brake Control System

    STARTING AND OPERATING 337 vehicle stability and control in various driving conditions WARNING! and are commonly referred to as ESC. The Anti-Lock Brake System contains sophisticated Anti-Lock Brake System (ABS) electronic equipment that may be susceptible to This system aids the driver in maintaining vehicle control interference caused by improperly installed or high under adverse braking conditions.

  • Page 340: Brake Assist System (Bas)

    338 STARTING AND OPERATING brake of the spinning wheel. This will allow more engine WARNING! torque to be applied to the wheel that is not spinning. • The BAS cannot prevent the natural laws of phys- This feature remains active even if TCS and ESC are in the “Partial Off”...

  • Page 341: Electronic Stability Control (Esc)

    STARTING AND OPERATING 339 Electronic Stability Control (ESC) WARNING! This system enhances directional control and stability of Electronic Stability Control (ESC) cannot prevent the the vehicle under various driving conditions. ESC cor- natural laws of physics from acting on the vehicle, rects for over/under steering of the vehicle by applying nor can it increase the traction afforded by prevailing the brake of the appropriate wheel to assist in counter-...
  • Page 342 340 STARTING AND OPERATING ESC Operating Modes reduction. This mode is intended to be used if the vehicle All ESC equipped vehicles can choose the following ESC is in deep snow, sand, or gravel conditions and more operating modes: wheel spin than ESC would normally allow is required to gain traction.

  • Page 343: Esc Activation/Malfunction Indicator Light And Esc Off Indicator Light

    STARTING AND OPERATING 341 To turn ESC on again, momentarily press the “ESC Off” ESC Activation/Malfunction Indicator Light And switch. This will restore the normal “ESC On” mode of ESC OFF Indicator Light operation. The “ESC Activation/Malfunction Indicator Light” in the instrument cluster will come on WARNING! when the ignition switch is turned to the ON position.

  • Page 344: Tire Safety Information

    342 STARTING AND OPERATING Malfunction Indicator Light” begins to flash during ac- TIRE SAFETY INFORMATION celeration, ease up on the accelerator and apply as little Tire Markings throttle as possible. Be sure to adapt your speed and driving to the prevailing road conditions. NOTE: •...
  • Page 345 STARTING AND OPERATING 343 • Temporary spare tires are spares designed for tempo- NOTE: • P (Passenger) - Metric tire sizing is based on U.S. rary emergency use only. Temporary high pressure design standards. P-Metric tires have the letter “P” compact spare tires have the letter “T”...
  • Page 346 344 STARTING AND OPERATING Tire Sizing Chart EXAMPLE: Size Designation: P = Passenger car tire size based on U.S. design standards ..blank..= Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T or S = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
  • Page 347 STARTING AND OPERATING 345 EXAMPLE: Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...

  • Page 348: Tire Identification Number (Tin)

    346 STARTING AND OPERATING Tire Identification Number (TIN) Look for the TIN on the outboard side of black sidewall tires as mounted on the vehicle. If the TIN is not found on The TIN may be found on one or both sides of the tire, the outboard side, then you will find it on the inboard however, the date code may only be on one side.

  • Page 349: Tire Terminology And Definitions

    STARTING AND OPERATING 347 Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold Tire Inflation Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least 3 hours, or driven less than 1 mile (1.6 km) after sitting for a three hour period.

  • Page 350: Tire Loading And Tire Pressure

    348 STARTING AND OPERATING Tire Loading And Tire Pressure Tire And Loading Information Placard Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door.
  • Page 351 STARTING AND OPERATING 349 Loading The combined weight of occupants, cargo/luggage and The vehicle maximum load on the tire must not exceed trailer tongue weight (if applicable) should never exceed the load carrying capacity of the tire on your vehicle. You the weight referenced here.
  • Page 352 350 STARTING AND OPERATING available cargo and luggage load capacity is 650 lbs NOTE: • The following table shows examples on how to calcu- (295 kg) (since 5 x 150 = 750, and 1400 – 750 = 650 lbs [295 kg]). late total load, cargo/luggage, and towing capacities of your vehicle with varying seating configurations 5.
  • Page 353 STARTING AND OPERATING 351...

  • Page 354: Tires - General Information

    352 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.

  • Page 355: Tire Inflation Pressures

    STARTING AND OPERATING 353 Tire Inflation Pressures WARNING! (Continued) The proper cold tire inflation pressure is listed on the • Unequal tire pressures from one side of the ve- driver’s side B-Pillar or rear edge of the driver’s side hicle to the other can cause the vehicle to drift to door.
  • Page 356 354 STARTING AND OPERATING Tire pressures change by approximately 1 psi (7 kPa) per CAUTION! 12°F (7°C) of air temperature change. Keep this in mind when checking tire pressure inside a garage, especially in After inspecting or adjusting the tire pressure, al- the winter.

  • Page 357: Radial-Ply Tires

    STARTING AND OPERATING 355 loading may be required for high-speed vehicle opera- Radial-Ply Tires tion. Refer to original equipment or an authorized tire WARNING! dealer for recommended safe operating speeds, loading and cold tire inflation pressures. Combining radial ply tires with other types of tires on your vehicle will cause your vehicle to handle WARNING! poorly.

  • Page 358: Compact Spare Tire - If Equipped

    356 STARTING AND OPERATING vehicle. If your vehicle has this option refer to an Compact Spare Tire – If Equipped authorized tire dealer for the recommended tire rotation The compact spare is for temporary emergency use only. pattern. You can identify if your vehicle is equipped with a compact spare by looking at the spare tire description on If your vehicle is not equipped with an original equip- the Tire and Loading Information Placard located on the...

  • Page 359: Full Size Spare - If Equipped

    STARTING AND OPERATING 357 your original equipment tire, replace (or repair) the WARNING! original equipment tire and reinstall on the vehicle at the first opportunity. Compact spares are for temporary emergency use only. With these spares, do not drive more than Limited-Use Spare –...

  • Page 360: Tire Spinning

    358 STARTING AND OPERATING Refer to “Freeing A Stuck Vehicle” in “What To Do In WARNING! Emergencies” for further information. Limited-use spares are for emergency use only. In- WARNING! stallation of this limited-use spare tire affects vehicle handling. With this tire, do not drive more than the Fast spinning tires can be dangerous.

  • Page 361: Life Of Tire

    STARTING AND OPERATING 359 Life Of Tire The service life of a tire is dependent upon varying factors including but not limited to: • Driving style • Tire pressure • Distance driven WARNING! Tires and spare tire should be replaced after six years, regardless of the remaining tread.

  • Page 362: Replacement Tires

    360 STARTING AND OPERATING Replacement Tires It is recommended to replace the two front tires or two The tires on your new vehicle provide a balance of many rear tires as a pair. Replacing just one tire can seriously characteristics. They should be inspected regularly for affect your vehicle’s handling.

  • Page 363: Tire Chains

    STARTING AND OPERATING 361 WARNING! WARNING! (Continued) • Failure to equip your vehicle with tires having • Do not use a tire, wheel size or rating other than adequate speed capability can result in sudden tire that specified for your vehicle. Some combinations failure and loss of vehicle control.

  • Page 364: Snow Tires

    362 STARTING AND OPERATING original equipment or an authorized tire dealer for CAUTION! recommended safe operating speeds, loading and cold tire inflation pressures. Damage to the vehicle may result if tire chains are used. While studded tires improve performance on ice, skid and traction capability on wet or dry surfaces may be SNOW TIRES poorer than that of non-studded tires.

  • Page 365: Tire Pressure Monitor System (Tpms)

    STARTING AND OPERATING 363 tires. Rotation will increase tread life, help to maintain mud, snow and wet traction levels, and contribute to a smooth, quiet ride. Refer to the “Maintenance Schedule” for the proper maintenance intervals. The reasons for any rapid or unusual wear should be corrected prior to rotation being performed.
  • Page 366 364 STARTING AND OPERATING the outside temperature decreases, the tire pressure will The TPM System will continue to warn the driver of low decrease. Tire pressure should always be set based on tire pressure as long as the condition exists, and will not cold inflation tire pressure.
  • Page 367 STARTING AND OPERATING 365 pressure to approximately 23 psi (158 kPa). This tire CAUTION! pressure is sufficiently low enough to turn ON the “Tire • The TPMS has been optimized for the original Pressure Monitoring Telltale Light.” Driving the vehicle may cause the tire pressure to rise to approximately equipment tires and wheels.

  • Page 368: Base System

    366 STARTING AND OPERATING • Seasonal temperature changes will affect tire pressure, NOTE: • The TPMS is not intended to replace normal tire care and the TPMS will monitor the actual tire pressure in and maintenance, or to provide warning of a tire the tire.
  • Page 369 STARTING AND OPERATING 367 Tire Pressure Monitoring Low Pressure Warnings sound a chime. If the ignition key is cycled, this sequence The “Tire Pressure Monitoring Telltale Light” will will repeat, providing the system fault still exists. The illuminate in the instrument cluster, a LOW TIRE “Tire Pressure Monitoring Telltale Light”...

  • Page 370: Premium System - If Equipped

    368 STARTING AND OPERATING NOTE: 5. Once you repair or replace the original road tire, and 1. The compact spare tire (if equipped) does not have a reinstall it on the vehicle in place of the compact spare, tire pressure monitoring sensor. Therefore, the TPMS will the TPMS will update automatically and the “Tire Pres- not monitor the pressure in the compact spare tire.
  • Page 371 STARTING AND OPERATING 369 The TPMS consists of the following components: Electronic Vehicle Information Center (EVIC) will display a graphic showing the pressure values of each tire with • Receiver Module the low tire pressure values flashing. • Four Tire Pressure Monitoring Sensors •...
  • Page 372 370 STARTING AND OPERATING updated tire pressures, the system will automatically update, the graphic display in the EVIC will stop flash- ing, and the “Tire Pressure Monitoring Telltale Light” will turn off. The vehicle may need to be driven for up to 20 minutes above 15 mph (24 km/h) in order for the TPMS to receive this information.
  • Page 373 STARTING AND OPERATING 371 1. Jamming due to electronic devices or driving next to The system still needs to be serviced as long as the facilities emitting the same Radio Frequencies as the TPM CHECK TPM SYSTEM message is displayed. sensors.

  • Page 374: General Information

    372 STARTING AND OPERATING CHECK TPM SYSTEM message for a minimum of five active road tires. The vehicle may need to be driven for seconds and then display dashes (- -) in place of the up to 20 minutes above 15 mph (24 km/h) in order for the pressure value.

  • Page 375: Fuel Requirements

    STARTING AND OPERATING 373 FUEL REQUIREMENTS Over 40 auto manufacturers worldwide have issued and This engine is designed to meet all emis- endorsed consistent gasoline specifications (the World- sions regulations and provide excellent wide Fuel Charter, WWFC) which define fuel properties fuel economy and performance when us- necessary to deliver enhanced emissions, performance, ing high-quality unleaded “regular”...

  • Page 376: Gasoline/Oxygenate Blends

    374 STARTING AND OPERATING Gasoline/Oxygenate Blends E-85 Usage In Non-Flex Fuel Vehicles Some fuel suppliers blend unleaded gasoline with oxy- Non-FFV vehicles are compatible with gasoline contain- genates such as Ethanol. Fuels blended with oxygenates ing 10% ethanol (E10). Gasoline with higher ethanol may be used in your vehicle.

  • Page 377: Mmt In Gasoline

    STARTING AND OPERATING 375 To fix a Non-FFV vehicle inadvertently fueled once with therefore, you should ask your gasoline retailer whether E-85 perform the following: the gasoline contains MMT. It is even more important to look for gasoline without MMT in Canada, because MMT •...

  • Page 378: Fuel System Cautions

    376 STARTING AND OPERATING Fuel System Cautions CAUTION! (Continued) • The use of fuel additives, which are now being CAUTION! sold as octane enhancers, is not recommended. Follow these guidelines to maintain your vehicle’s Most of these products contain high concentra- performance: tions of methanol.

  • Page 379: Carbon Monoxide Warnings

    STARTING AND OPERATING 377 Carbon Monoxide Warnings WARNING! (Continued) • Guard against carbon monoxide with proper WARNING! maintenance. Have the exhaust system inspected Carbon monoxide (CO) in exhaust gases is deadly. every time the vehicle is raised. Have any abnor- Follow the precautions below to prevent carbon mal conditions repaired promptly.

  • Page 380: Ethanol Fuel (E-85)

    378 STARTING AND OPERATING the other sections of this manual for information on CAUTION! features that are common between Flexible Fuel and gasoline-only powered vehicles. Only vehicles with the E-85 fuel filler door label can operate on E-85. Ethanol Fuel (E-85) E-85 is a mixture of approximately 85% fuel ethanol and 15% unleaded gasoline.

  • Page 381: Fuel Requirements

    Observing these precautions will avoid possible hard in MOPAR engine oils, and in equivalent oils meeting starting and/or significant deterioration in driveability Chrysler Specification MS-6395. The manufacturer re- during warm up. quires engine oils that are API Certified and meet the...

  • Page 382: Starting

    Because E-85 fuel contains less energy per gallon/liter tensive fleet testing, to provide additional protection to than gasoline, you will experience an increase in fuel Chrysler Group LLC engines. Use MOPAR or an consumption. You can expect your miles per gallon equivalent oil meeting the specification MS-6395.

  • Page 383: Maintenance

    STARTING AND OPERATING 381 Maintenance CAUTION! Do not use ethanol mixture greater than 85% in your vehicle. It will cause difficulty in cold starting and may affect driveability. ADDING FUEL Fuel Filler Cap (Gas Cap) The gas cap is behind the fuel filler door, on the left rear quarter panel of the vehicle.
  • Page 384 382 STARTING AND OPERATING After removing the gas cap, place the gas cap tether cable CAUTION! over a hook on the inside of the fuel door. This keeps the • Damage to the fuel system or emission control gas cap suspended away from and protects the vehicle’s surface.

  • Page 385: Loose Filler Cap Message

    STARTING AND OPERATING 383 Loose Filler Cap Message WARNING! (Continued) If the vehicles diagnostic system determines that the fuel • Never add fuel when the engine is running. This is filler cap in loose, improperly installed, or damaged, a in violation of most state and federal fire regula- “gASCAP”...

  • Page 386: Vehicle Loading

    384 STARTING AND OPERATING VEHICLE LOADING The bar code allows a computer scanner to read the Vehicle Identification Number (VIN). Vehicle Certification Label Your vehicle has a certification label attached to the rear Gross Vehicle Weight Rating (GVWR) of the driver’s door. The GVWR is the total allowable weight of your vehicle.

  • Page 387: Overloading

    STARTING AND OPERATING 385 Figure out the weight on the front and rear of the vehicle WARNING! separately. It is important that you distribute the load evenly over the front and rear axles. Because the front wheels steer the vehicle, it is important that you do not exceed the maximum front Overloading can cause potential safety hazards and or rear GAWR.

  • Page 388: Trailer Towing

    386 STARTING AND OPERATING TRAILER TOWING Common Towing Definitions In this section, you will find safety tips and information The following trailer towing related definitions will assist on limits to the type of towing you can reasonably do you in understanding the following information: with your vehicle.
  • Page 389 STARTING AND OPERATING 387 Gross Combination Weight Rating (GCWR) WARNING! The GCWR is the total permissible weight of your vehicle and trailer when weighed in combination. It is important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition NOTE: The GCWR rating includes a 150 lbs (68 kg) can result if either rating is exceeded.

  • Page 390: Trailer Hitch Classification

    388 STARTING AND OPERATING Weight-Carrying Hitch Trailer Hitch Classification Definitions A weight-carrying hitch supports the trailer tongue Class Max. Trailer Hitch Industry weight, just as if it were luggage located at a hitch ball or Standards some other connecting point of the truck. These kinds of Class I - Light Duty 2,000 lbs (907 kg) hitches are the most popular on the market today and...

  • Page 391: Trailer Towing Weights

    STARTING AND OPERATING 389 Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Maximum Trailer Weight Ratings Max. GTW Max. Trailer Tongue Wt. Engine/Transmission Max. Frontal Area (Gross Trailer Wt.) (See Note 1) 2.4L/Auto See Note 2...

  • Page 392: Trailer And Tongue Weight

    390 STARTING AND OPERATING CAUTION! Towing a trailer with a larger than recommended frontal area could cause the engine to overheat or cause severe engine damage under extreme condi- tions. Trailer And Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer.

  • Page 393: Towing Requirements

    STARTING AND OPERATING 391 NOTE: Remember that everything put into or on the Towing Requirements trailer adds to the load on your vehicle. Also, additional To promote proper break-in of your new vehicle drive- factory-installed options, or authorized dealer-installed train components the following guidelines are recom- options, must be considered as part of the total load on mended: your vehicle.
  • Page 394 392 STARTING AND OPERATING WARNING! WARNING! (Continued) • Safety chains must always be used between your Improper towing can lead to a collision. Follow these vehicle and trailer. Always connect the chains to guidelines to make your trailer towing as safe as the frame or hook retainers of the vehicle hitch.
  • Page 395 STARTING AND OPERATING 393 • Check for signs of tire wear or visible tire damage WARNING! (Continued) before towing a trailer. Refer to “Tires – General 3. GAWR Information” in “Starting and Operating” for informa- 4. Trailer tongue weight rating for the trailer hitch tion on tread wear indicators and for proper inspection utilized (This requirement may limit the ability to procedure.
  • Page 396 394 STARTING AND OPERATING • An electronically actuated trailer brake controller is WARNING! required when towing a trailer with electronically • Do not connect trailer brakes to your vehicle’s actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic hydraulic brake lines.

  • Page 397: Towing Tips

    STARTING AND OPERATING 395 Towing Tips If you REGULARLY TOW a trailer for more than 45 min- Before setting out on a trip, practice turning, stopping, utes of continuous operation, then change the automatic and backing the trailer in an area located away from transmission fluid and filter according to the interval heavy traffic.

  • Page 398: Recreational Towing (Behind Motorhome, Etc.)

    396 STARTING AND OPERATING • Use speed control in flat terrain and with light loads to • Highway Driving maximize fuel efficiency. Reduce speed. • Air Conditioning Cooling System To reduce potential for engine and transmission over- Turn off temporarily. heating, take the following actions: •...

  • Page 399: Recreational Towing - All Models

    STARTING AND OPERATING 397 Recreational Towing – All Models CAUTION! Recreational towing is allowed ONLY if the front wheels • DO NOT flat tow this vehicle. Damage to the are OFF the ground. This may be accomplished using a tow dolly or vehicle trailer. If using a tow dolly, follow drivetrain will result.

  • Page 401: What To Do In Emergencies

    WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flashers ....401 Road Tire Installation ....411 If Your Engine Overheats .
  • Page 402 400 WHAT TO DO IN EMERGENCIES Dual Dry Clutch (6-Speed C635 Ddct) Without The Ignition Key ....422 Automatic Transmission ....422...

  • Page 403: Hazard Warning Flashers

    WHAT TO DO IN EMERGENCIES 401 HAZARD WARNING FLASHERS IF YOUR ENGINE OVERHEATS The Hazard Warning flasher switch is located on the In any of the following situations, you can reduce the instrument panel, below the radio. potential for overheating by taking the appropriate ac- tion.

  • Page 404: Engine Oil Overheating (2.4L Engine Only) - If Equipped

    402 WHAT TO DO IN EMERGENCIES NOTE: There are steps that you can take to slow down WARNING! an impending overheat condition: You or others can be badly burned by hot engine • If your air conditioner (A/C) is on, turn it off. The A/C coolant (antifreeze) or steam from your radiator.

  • Page 405: Jacking And Tire Changing

    WHAT TO DO IN EMERGENCIES 403 NOTE: The vehicle speed is reduced to a maximum of WARNING! (Continued) 53 mph (85 km/h). You may of course, reduce your • Never start or run the engine while the vehicle is vehicle speed further if needed. on a jack.

  • Page 406: Preparations For Jacking

    404 WHAT TO DO IN EMERGENCIES Spare Tire Removal WARNING! Lift up the load floor cover and remove the hold down. Do not attempt to change a tire on the side of the vehicle close to moving traffic, pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.

  • Page 407: Jacking Instructions

    WHAT TO DO IN EMERGENCIES 405 6. Block both the front and rear of the WARNING! (Continued) wheel diagonally opposite the jacking • Always park on a firm, level surface as far from position. For example, if changing the the edge of the roadway as possible before raising right front tire, block the left rear the vehicle.
  • Page 408 406 WHAT TO DO IN EMERGENCIES WARNING! (Continued) CAUTION! • Only use the jack in the positions indicated and Do not attempt to raise the vehicle by jacking on for lifting this vehicle during a tire change. locations other than those indicated in the Jacking •...
  • Page 409 WHAT TO DO IN EMERGENCIES 407 CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated in Step 3. Removing Jack Handle From Jack 2. Loosen, but do not remove, the wheel nuts by turning them to the left one turn while the wheel is still on the ground.
  • Page 410 408 WHAT TO DO IN EMERGENCIES 3. There is a front and rear jacking location on each side of the vehicle. Rear Jacking Location 4. Turn the jack screw to the left until the jack can be placed under the jacking location. Once the jack is Front Jacking Location positioned, turn the jack screw to the right until the jack head is properly engaged with the lift area closest to the...
  • Page 411 WHAT TO DO IN EMERGENCIES 409 WARNING! CAUTION! Raising the vehicle higher than necessary can make Be sure to mount the spare tire with the valve stem the vehicle less stable. It could slip off the jack and facing outward. The vehicle could be damaged if the hurt someone near it.
  • Page 412 410 WHAT TO DO IN EMERGENCIES 9. Remove the wheel blocks and lower the jack until it is WARNING! free. Reassemble the lug wrench to the jack assembly and • To avoid the risk of forcing the vehicle off the jack, stow it in the spare tire area.

  • Page 413: Road Tire Installation

    WHAT TO DO IN EMERGENCIES 411 Road Tire Installation Vehicles Equipped With Wheel Covers 1. Mount the road tire on the axle. 2. To ease the installation process for steel wheels with wheel covers, install two lug nuts on the mounting studs which are on each side of the valve stem.
  • Page 414 412 WHAT TO DO IN EMERGENCIES 3. Align the valve notch in the wheel cover with the 6. Finish tightening the lug nuts. Push down on the valve stem on the wheel. Install the cover by hand, wrench while at the end of the handle for increased snapping the cover over the two lug nuts.

  • Page 415: Jump-Starting

    WHAT TO DO IN EMERGENCIES 413 5. After 25 miles (40 km) check the lug nut torque with a WARNING! torque wrench to ensure that all lug nuts are properly seated against the wheel. To avoid the risk of forcing the vehicle off the jack, do not tighten the wheel nuts fully until the vehicle JUMP-STARTING has been lowered.

  • Page 416: Preparations For Jump-Start

    414 WHAT TO DO IN EMERGENCIES CAUTION! Do not use a portable battery booster pack or any other booster source with a system voltage greater than 12 Volts or damage to the battery, starter motor, alternator or electrical system may occur. WARNING! Do not attempt jump-starting if the battery is frozen.
  • Page 417 WHAT TO DO IN EMERGENCIES 415 3. Remove the protective cover over the remote positive WARNING! (+) battery post. To remove the cover, press the locking • Take care to avoid the radiator cooling fan when- tab and pull upward on the cover. ever the hood is raised.

  • Page 418: Jump-Starting Procedure

    416 WHAT TO DO IN EMERGENCIES 1. Connect the positive (+) end of the jumper cable to the WARNING! remote positive (+) post of the discharged vehicle. Do not allow vehicles to touch each other as this 2. Connect the opposite end of the positive (+) jumper could establish a ground connection and personal cable to the positive (+) post of the booster battery.
  • Page 419 WHAT TO DO IN EMERGENCIES 417 5. Start the engine in the vehicle that has the booster 10. Reinstall the protective cover over the remote posi- battery, let the engine idle a few minutes, and then start tive (+) battery post of the discharged vehicle. the engine in the vehicle with the discharged battery.

  • Page 420: Freeing A Stuck Vehicle

    418 WHAT TO DO IN EMERGENCIES FREEING A STUCK VEHICLE NOTE: If your vehicle is equipped with Electronic If your vehicle becomes stuck in mud, sand, or snow, it Stability Control (ESC), turn the system to Partial OFF can often be moved by a rocking motion. Turn your before attempting to “rock”...

  • Page 421: Shift Lever Override

    WHAT TO DO IN EMERGENCIES 419 3. Turn the ignition to the ON/RUN position without WARNING! starting the engine. Fast spinning tires can be dangerous. Forces gener- 4. Press and maintain firm pressure on the brake pedal. ated by excessive wheel speeds may cause damage, or 5.

  • Page 422: Towing A Disabled Vehicle

    420 WHAT TO DO IN EMERGENCIES TOWING A DISABLED VEHICLE Towing Condition Wheels OFF the 4-SPEED, 6-SPEED (62TE) 6-SPEED (C635 DDCT) Ground TRANSMISSIONS TRANSMISSION Flat Tow NONE If transmission is operable: NOT ALLOWED • Transmission in NEUTRAL • 25 mph (40 km/h)max speed Rear NOT ALLOWED Wheel Lift Or Dolly...

  • Page 423: Conventional Automatic Transmission

    WHAT TO DO IN EMERGENCIES 421 If flatbed equipment is not available, and the transmis- CAUTION! (Continued) sion is operable, the vehicle may be flat towed (with all • When securing the vehicle to a flatbed truck, do four wheels on the ground) under the following condi- not attach to front or rear suspension components.
  • Page 424 422 WHAT TO DO IN EMERGENCIES Without The Ignition Key CAUTION! Special care must be taken when the vehicle is towed with the ignition in the LOCK position. Flatbed towing is Towing faster than 25 mph (40 km/h) or farther than the preferred towing method.
  • Page 425 MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 2.4L ... . . 425 Engine Oil ......431 Engine Compartment —...
  • Page 426 424 MAINTAINING YOUR VEHICLE Exhaust System ..... 441 Bulb Replacement ..... 467 Cooling System .

  • Page 427: Engine Compartment - 2.4L

    MAINTAINING YOUR VEHICLE 425 ENGINE COMPARTMENT — 2.4L 1 — Engine Coolant Reservoir 7 — Air Cleaner Filter 2 — Power Steering Fluid Reservoir 8 — Engine Oil Fill 3 — Automatic Transmission Dipstick 9 — Coolant Pressure Cap 4 — Brake Fluid Reservoir 10 —...

  • Page 428: Engine Compartment - 3.6L

    426 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 3.6L 1 — Engine Coolant Reservoir 5 — Air Cleaner Filter 2 — Power Steering Fluid Reservoir 6 — Engine Oil Dipstick 3 — Brake Fluid Reservoir 7 — Engine Oil Fill 4 — Totally Integrated Power Module (Fuses) 8 —...

  • Page 429: Onboard Diagnostic System - Obd Ii

    MAINTAINING YOUR VEHICLE 427 ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic further damage to the emission control system.

  • Page 430: Emissions Inspection And Maintenance Programs

    428 MAINTAINING YOUR VEHICLE persists, the message will appear the next time the Normally, the OBD II system will be ready. The OBD II vehicle is started. This might indicate a damaged cap. If system may not be ready if your vehicle was recently the problem is detected twice in a row, the system will serviced, recently had a dead battery or a battery replace- turn on the “Malfunction Indicator Light (MIL).”...

  • Page 431: Replacement Parts

    MAINTAINING YOUR VEHICLE 429 4. Approximately 15 seconds later, one of two things will Regardless of whether your vehicle’s OBD II system is happen: ready or not, if the MIL is illuminated during normal vehicle operation you should have your vehicle serviced a.

  • Page 432: Maintenance Procedures

    Immediately have potential malfunctions examined by an authorized Chrysler Group LLC dealership or qualified repair center. (Continued)

  • Page 433: Engine Oil

    MAINTAINING YOUR VEHICLE 431 fully warmed engine is shut off. Do not check oil level CAUTION! (Continued) before starting the engine after it has sat overnight. • Your vehicle has been built with improved fluids Checking engine oil level when the engine is cold will that protect the performance and durability of give you an incorrect reading.
  • Page 434 API Certified and meet the will cause oil aeration, which can lead to loss of oil requirements of Chrysler Material Standard MS-6395. pressure and an increase in oil temperature. This could damage your engine. Also, be sure the oil fill American Petroleum Institute (API) Engine Oil cap is replaced and tightened after adding oil.
  • Page 435 MAINTAINING YOUR VEHICLE 433 Lubricants which do not have both the engine oil certi- CAUTION! fication mark and the correct SAE viscosity grade num- ber should not be used. Do not use chemical flushes in your engine oil as the chemicals can damage your engine.

  • Page 436: Engine Oil Filter

    434 MAINTAINING YOUR VEHICLE Lubricants which do not have both, the engine oil certi- station, or governmental agency for advice on how and fication mark and the correct SAE viscosity grade num- where used oil and oil filters can be safely discarded in ber should not be used.

  • Page 437: Engine Air Cleaner Filter

    MAINTAINING YOUR VEHICLE 435 Engine Air Cleaner Filter Engine Air Cleaner Filter Selection The quality of replacement engine air cleaner filters WARNING! varies considerably. Only high quality filters should be used to assure most efficient service. MOPAR engine air The air induction system (air cleaner, hoses, etc.) can cleaner filters are high quality and are recommended.
  • Page 438 436 MAINTAINING YOUR VEHICLE WARNING! CAUTION! • Battery fluid is a corrosive acid solution and can • It is essential when replacing the cables on the burn or even blind you. Do not allow battery fluid battery that the positive cable is attached to the to contact your eyes, skin, or clothing.

  • Page 439: Air Conditioner Maintenance

    MAINTAINING YOUR VEHICLE 437 Air Conditioner Maintenance WARNING! For best possible performance, your air conditioner • Use only refrigerants and compressor lubricants should be checked and serviced by an authorized dealer at the start of each warm season. This service should approved by the manufacturer for your air condi- include cleaning of the condenser fins and a performance tioning system.

  • Page 440: A/C Air Filter - If Equipped

    438 MAINTAINING YOUR VEHICLE Protection Agency and is an ozone-saving product. How- 1. Open the glove box and remove all contents. ever, the manufacturer recommends that air conditioning 2. Push in on the sides of the glove box and lower the service be performed by authorized dealers or other door.

  • Page 441: Body Lubrication

    MAINTAINING YOUR VEHICLE 439 CAUTION! The A/C Air Filter is identified with an arrow to indicate airflow direction through the filter. Failure to install the filter properly will result in the need to replace it more often. 8. Reinstall the glove box door dampener and glove box. Body Lubrication Locks and all body pivot points, including such items as seat tracks, door hinge pivot points and rollers, liftgate,...

  • Page 442: Windshield Wiper Blades

    440 MAINTAINING YOUR VEHICLE hood latching components to ensure proper function. Operation of the wipers on dry glass for long periods When performing other underhood services, the hood may cause deterioration of the wiper blades. Always use latch, release mechanism and safety catch should be washer fluid when using the wipers to remove salt or dirt cleaned and lubricated.

  • Page 443: Adding Washer Fluid

    MAINTAINING YOUR VEHICLE 441 Adding Washer Fluid Exhaust System The fluid reservoir for the windshield washers is located The best protection against carbon monoxide entry into in the engine compartment. Be sure to check the fluid the vehicle body is a properly maintained engine exhaust level in the reservoir at regular intervals.
  • Page 444 442 MAINTAINING YOUR VEHICLE WARNING! CAUTION! • Exhaust gases can injure or kill. They contain • The catalytic converter requires the use of un- carbon monoxide (CO), which is colorless and leaded fuel only. Leaded gasoline will destroy the odorless. Breathing it can make you unconscious effectiveness of the catalyst as an emissions con- and can eventually poison you.
  • Page 445 MAINTAINING YOUR VEHICLE 443 Under normal operating conditions, the catalytic con- To minimize the possibility of catalytic converter dam- verter will not require maintenance. However, it is im- age: portant to keep the engine properly tuned to assure • Do not shut off the engine or interrupt the ignition, proper catalyst operation and prevent possible catalyst when the transmission is in gear and the vehicle is in damage.

  • Page 446: Cooling System

    444 MAINTAINING YOUR VEHICLE Cooling System rusty in appearance, the system should be drained, flushed, and refilled with fresh engine coolant (anti- WARNING! freeze). Check the front of the A/C condenser for any accumulation of bugs, leaves, etc. If dirty, clean by gently •...
  • Page 447 MAINTAINING YOUR VEHICLE 445 Selection Of Coolant CAUTION! (Continued) Use only the manufacturer’s recommended coolant. Re- • Do not use water alone or alcohol-based engine fer to “Fluids, Lubricants, and Genuine Parts” in “Main- coolant (antifreeze) products. Do not use addi- taining Your Vehicle”...
  • Page 448 446 MAINTAINING YOUR VEHICLE replacement. To prevent reducing this extended mainte- (antifreeze) solution. The use of lower quality water nance period, it is important that you use the same will reduce the amount of corrosion protection in the engine coolant (antifreeze) throughout the life of your engine cooling system.
  • Page 449 MAINTAINING YOUR VEHICLE 447 rules for your community. To prevent ingestion by ani- WARNING! mals or children, do not store ethylene glycol based • The warning words “DO NOT OPEN HOT” on engine coolant (antifreeze) in open containers or allow it to remain in puddles on the ground.
  • Page 450 448 MAINTAINING YOUR VEHICLE The radiator normally remains completely full, so there is If an examination of your engine compartment shows no no need to remove the radiator cap unless checking for evidence of radiator or hose leaks, the vehicle may be engine coolant (antifreeze) freeze point or replacing cool- safely driven.

  • Page 451: Brake System

    MAINTAINING YOUR VEHICLE 449 • Make sure that the radiator and coolant recovery WARNING! bottle overflow hoses are not kinked or obstructed. Riding the brakes can lead to brake failure and • Keep the front of the radiator clean. If your vehicle is possibly a collision.
  • Page 452 450 MAINTAINING YOUR VEHICLE Clean the top of the master cylinder area before removing WARNING! the cap. If necessary, add fluid to bring the fluid level up • Use only manufacturer’s recommended brake to the requirements described on the brake fluid reser- voir.

  • Page 453: Automatic Transmission

    MAINTAINING YOUR VEHICLE 451 WARNING! (Continued) WARNING! (Continued) • To avoid contamination from foreign matter or • Do not allow petroleum based fluid to contami- moisture, use only new brake fluid or fluid that nate the brake fluid. Brake seal components could has been in a tightly closed container.
  • Page 454 452 MAINTAINING YOUR VEHICLE Parts” in “Maintaining Your Vehicle” for further informa- Special Additives tion. It is important that the transmission fluid be main- Automatic Transmission Fluid (ATF) is an engineered tained at the prescribed level using the recommended product and its performance may be impaired by supple- fluid.
  • Page 455 MAINTAINING YOUR VEHICLE 453 Fluid Level Check – Four-Speed Automatic driven at least 15 miles (24 km). Hot fluid cannot be held Transmission comfortably between the fingertips. Cold fluid is at a Use the following procedure to check the automatic temperature below 80°...

  • Page 456: Appearance Care And Protection From Corrosion

    454 MAINTAINING YOUR VEHICLE Fluid Level Check – Six-Speed Automatic CAUTION! Transmission • Using a transmission fluid other than the manu- The automatic transmission has no dipstick and is dealer serviced only. facturer’s recommended fluid may cause deterio- ration in transmission shift quality and/or torque Transmission Fluid And Filter Changes converter shudder.
  • Page 457 MAINTAINING YOUR VEHICLE 455 road surfaces on which the vehicle is operated, extreme Washing hot or cold weather and other extreme conditions will • Wash your vehicle regularly. Always wash your ve- have an adverse effect on paint, metal trim, and under- hicle in the shade using MOPAR Car Wash or equiva- body protection.
  • Page 458 456 MAINTAINING YOUR VEHICLE • If you detect any stone chips or scratches in the paint, CAUTION! touch them up immediately. The cost of such repairs is • Do not use abrasive or strong cleaning materials considered the responsibility of the owner. such as steel wool or scouring powder, which will •...
  • Page 459 MAINTAINING YOUR VEHICLE 457 Wheel And Wheel Trim Care Cleaning Headlights Your vehicle has plastic headlights that are lighter and • All wheels and wheel trim, especially aluminum and less susceptible to stone breakage than glass headlights. chrome plated wheels, should be cleaned regularly with a mild soap and water to prevent corrosion.
  • Page 460 458 MAINTAINING YOUR VEHICLE • Blot any remaining stain with a clean, damp towel. Cleaning Interior Trim Interior Trim should be cleaned starting with a damp • For tough stains, apply MOPAR Total Clean or cloth, a damp cloth with MOPAR Total Clean or equiva- equivalent, or a mild soap solution to a clean, damp lent, then MOPAR Spot &...
  • Page 461 MAINTAINING YOUR VEHICLE 459 solvents, detergents, or ammonia-based cleaners to clean When cleaning the rear view mirror, spray cleaner on the your leather upholstery. Application of a leather condi- towel or rag that you are using. Do not spray cleaner tioner is not required to maintain the original condition.

  • Page 462: Cleaning Center Console Cupholders

    460 MAINTAINING YOUR VEHICLE Seat Belt Maintenance the liner from the water and dip it back into the water Do not bleach, dye, or clean the belts with chemical about six times. This will loosen any remaining debris. solvents or abrasive cleaners. This will weaken the fabric. Rinse the liner thoroughly under warm running water.
  • Page 463 MAINTAINING YOUR VEHICLE 461 Cartridge Cavity Mini Fuse Description Fuse Center High 10 Amp Mounted Stop — Light (CHMSL)/ Brake Switch 10 Amp — Ignition Switch 20 Amp Trailer Tow – If — Yellow Equipped Power Mirror 10 Amp — Switch/Climate Totally Integrated Power Module Controls...
  • Page 464 462 MAINTAINING YOUR VEHICLE Cartridge Cartridge Cavity Mini Fuse Description Cavity Mini Fuse Description Fuse Fuse Battery Feed – 40 Amp — Radiator Fan Relay Power Seats – If Green 40 Amp Equipped/PZEV Cigar Lighter/ Green 15 Amp Air Pump – If —...
  • Page 465 MAINTAINING YOUR VEHICLE 463 Cartridge Cartridge Cavity Mini Fuse Description Cavity Mini Fuse Description Fuse Fuse 10 Amp Ignition Run – Oc- — Siren – If Equipped cupant Classifica- 10 Amp tion Module Ignition Run – Cli- — (OCM)/Occupant 10 Amp mate Controls/Hot —...
  • Page 466 464 MAINTAINING YOUR VEHICLE Cartridge Cartridge Cavity Mini Fuse Description Cavity Mini Fuse Description Fuse Fuse 10 Amp Headlamp Washer Anti-Lock Brakes — – If Equipped (ABS) Module – If Equipped/ 30 Amp Auto Shutdown 40 Amp — — Electronic Stability Pink (ASD) Relay 1 Green...

  • Page 467: Vehicle Storage

    MAINTAINING YOUR VEHICLE 465 VEHICLE STORAGE CAUTION! If you will not be using your vehicle for more than • When installing the Totally Integrated Power 21 days, you may want to take steps to preserve your battery. Module cover, it is important to ensure the cover is properly positioned and fully latched.

  • Page 468: Replacement Bulbs

    466 MAINTAINING YOUR VEHICLE REPLACEMENT BULBS LIGHT BULBS – Exterior Bulb No. All the inside bulbs are brass or glass wedge base. Bi-Halogen Headlamp ....HIR2 Aluminum base bulbs are not approved and should not Front Turn Signal Lamp.

  • Page 469: Bulb Replacement

    MAINTAINING YOUR VEHICLE 467 BULB REPLACEMENT Headlamp 1. Raise and prop open the hood. Locate the connector behind the headlamp. NOTE: It may be necessary to remove the air cleaner filter housing and position the totally integrated power module aside prior to replacing the low beam headlamp on the driver’s side of the vehicle.
  • Page 470 468 MAINTAINING YOUR VEHICLE 3. Rotate bulb and connector one-quarter turn and pull 4. Pull the bulb out of the socket and replace the bulb. outward from assembly. 5. If the bulb comes in contact with any oily surface, clean the bulb with rubbing alcohol. CAUTION! 6.

  • Page 471: Front Turn Signal

    MAINTAINING YOUR VEHICLE 469 Front Turn Signal 1. Rotate the bulb’s electrical connector one-quarter turn counterclockwise and remove it from the fog lamp hous- 1. Raise and prop open the hood. ing. 2. Rotate the bulb’s electrical connector one-quarter turn 2.

  • Page 472: Backup Lamps

    470 MAINTAINING YOUR VEHICLE Backup Lamps NOTE: Placing a small flat head screwdriver or similar tool between the lamp outboard ball stud and plastic 1. Open the trunk and gently pull back the trunk liner grommet from inside the trunk can help to disengage the behind the tail lamp (requires removal of a push pin outboard edge of the tail lamp.

  • Page 473: License Plate Lamp

    MAINTAINING YOUR VEHICLE 471 License Plate Lamp 1. Using a small screwdriver, press inward the locking tab on the side of the lamp assembly and pull down on the lamp assembly for removal. 2. Pull bulb from socket, replace, and reinstall the lamp assembly into place ensuring the locking tab is secure.

  • Page 474: Fluid Capacities

    472 MAINTAINING YOUR VEHICLE FLUID CAPACITIES U.S. Metric Fuel (Approximate) All Engines — (Except 2.4L PZEV) 16.9 Gallons 64 Liters 2.4L PZEV (Partial Zero Emissions Vehicle) 18.5 Gallons 70 Liters Engine Oil with Filter 2.4L Engine (SAE 5W-20, API Certified) 4.5 Quarts 4.4 Liters 3.6L Engine (SAE 5W-30, API Certified)

  • Page 475: Fluids, Lubricants, And Genuine Parts

    Use API Certified SAE 5W-20 Engine Oil, meeting the requirements of Engine Oil – 2.4L Engine Chrysler Material Standard MS-6395. Refer to your engine oil filler cap for correct SAE grade. Use API Certified SAE 5W-30 Engine Oil, meeting Chrysler Material Stan- Engine Oil –...

  • Page 476: Chassis

    474 MAINTAINING YOUR VEHICLE Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transmission – Four- MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed Speed ATF+4 product. Automatic Transmission – Six- MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed Speed (62TE Only) ATF+4 product.
  • Page 477 MAINTENANCE SCHEDULES CONTENTS Maintenance Schedule ....476 Required Maintenance Intervals ..478...
  • Page 478 476 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULE Based on engine operation conditions the oil change The Scheduled Maintenance services listed in this indicator message will illuminate, this means that service manual must be done at the times or mileages specified is required for your vehicle. Have your vehicle serviced to protect your vehicle warranty and ensure the best as soon as possible, within the next 500 miles (805 km).
  • Page 479 MAINTENANCE SCHEDULES 477 scheduled oil change is performed by someone other Once A Month than your authorized dealer, the message can be reset by • Check tire pressure and look for unusual wear or referring to the steps described under “Electronic Vehicle damage.
  • Page 480 478 MAINTENANCE SCHEDULES At Each Oil Change Required Maintenance Intervals Refer to the Maintenance Schedules on the following • Change the engine oil filter. pages for the required maintenance intervals. • Inspect the brake hoses and lines. CAUTION! Failure to perform the required maintenance items may result in damage to the vehicle.
  • Page 481 MAINTENANCE SCHEDULES 479 8,000 Miles (13,000 km) or 16,000 Miles (26,000 km) or 12 Months Maintenance Service 6 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...

  • Page 482: Service Schedule

    480 MAINTENANCE SCHEDULES 24,000 Miles (39,000 km) or 32,000 Miles (52,000 km) or 24 Months Maintenance Service 18 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
  • Page 483 MAINTENANCE SCHEDULES 481 40,000 Miles (65,000 km) or 48,000 Miles (78,000 km) or 36 Months Maintenance Service 30 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
  • Page 484 482 MAINTENANCE SCHEDULES 56,000 Miles (91,000 km) or 64,000 Miles (104,000 km) or 48 Months Maintenance Service 42 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
  • Page 485 MAINTENANCE SCHEDULES 483 72,000 Miles (117,000 km) or 80,000 Miles (130,000 km) or 60 Months Maintenance Service 54 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
  • Page 486 484 MAINTENANCE SCHEDULES 88,000 Miles (143,000 km) or 96,000 Miles (156,000 km) or 72 Months Maintenance Service 66 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
  • Page 487 MAINTENANCE SCHEDULES 485 104,000 Miles (169,000 km) or 112,000 Miles (182,000 km) or 84 Months Maintenance Service 78 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
  • Page 488 486 MAINTENANCE SCHEDULES 120,000 Miles (195,000 km) or 128,000 Miles (208,000 km) or 96 Months Maintenance Service 90 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
  • Page 489 MAINTENANCE SCHEDULES 487 136,000 Miles (221,000 km) or 144,000 Miles (234,000 km) or 108 Months Maintenance Service 102 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
  • Page 490 488 MAINTENANCE SCHEDULES 152,000 Miles (247,000 km) or WARNING! 114 Months Maintenance Service • You can be badly injured working on or around a Schedule motor vehicle. Do only service work for which you ❏ Change the engine oil and engine oil filter. ❏...

  • Page 491: If You Need Consumer Assistance

    If You Need Assistance ....491 Reporting Safety Defects ....494 Chrysler Group LLC Customer Center ..492 In The 50 United States And Washington, D.C.
  • Page 492 490 IF YOU NEED CONSUMER ASSISTANCE Department Of Transportation Uniform Tire Traction Grades ..... 497 Quality Grades ......497 Temperature Grades .

  • Page 493: Suggestions For Obtaining Service For Your

    IF YOU NEED CONSUMER ASSISTANCE 491 SUGGESTIONS FOR OBTAINING SERVICE FOR the service advisor and list the items in order of priority. YOUR VEHICLE At many authorized dealers, you may obtain a rental vehicle at a minimal daily charge. If you need a rental, it Prepare For The Appointment is advisable to make these arrangements when you call If you’re having warranty work done, be sure to have the...

  • Page 494: Chrysler Group Llc Customer Center

    492 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized Chrysler Group LLC Customer Center dealer’s service manager first. Most matters can be re- P.O. Box 21–8004 solved with this process. Auburn Hills, MI 48321–8004 Phone: (800) 247–9753...

  • Page 495: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)

    IF YOU NEED CONSUMER ASSISTANCE 493 Customer Assistance For The Hearing Or Speech the manufacturer’s service contracts. If you purchased a Impaired (TDD/TTY) manufacturer’s service contract, you will receive Plan To assist customers who have hearing difficulties, the Provisions and an Owner Identification Card in the mail manufacturer has installed special TDD (Telecommuni- within three weeks of the vehicle delivery date.

  • Page 496: Warranty Information

    See the Warranty Information Booklet, located on the has also made a major investment in facilities, tools, and DVD, for the terms and provisions of Chrysler Group training to assure that you are absolutely delighted with LLC warranties applicable to this vehicle and market.

  • Page 497: In Canada

    Customer Service Department imme- need in diagnosing/troubleshooting, problem solving, diately. Canadian customers who wish to report a safety maintaining, servicing, and repairing Chrysler Group defect to the Canadian government should contact LLC vehicles. A complete working knowledge of the...
  • Page 498 • Diagnostic Procedure Manuals acquaint you with specific Chrysler Group LLC ve- hicles. Included are starting, operating, emergency Diagnostic Procedure Manuals are filled with dia- and maintenance procedures as well as specifications, grams, charts and detailed illustrations.
  • Page 499 IF YOU NEED CONSUMER ASSISTANCE 497 DEPARTMENT OF TRANSPORTATION UNIFORM significantly from the norm due to variations in driving TIRE QUALITY GRADES habits, service practices, and differences in road charac- The following tire grading categories were established by teristics and climate. the National Highway Traffic Safety Administration.
  • Page 500 498 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades WARNING! The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat The temperature grade for this tire is established for and its ability to dissipate heat, when tested under a tire that is properly inflated and not overloaded.
  • Page 501 INDEX...
  • Page 502 500 INDEX About Your Brakes ..... . . 332 Airbag, Side ..... . 60,63,65,66 ABS (Anti-Lock Brake System) .
  • Page 503 INDEX 501 Automatic Temperature Control (ATC) ..280 Body Mechanism Lubrication ....439 Automatic Transaxle ....12,296 Brake Assist System .
  • Page 504 502 INDEX Caps, Filler Clean Air Gasoline ..... . . 373 Fuel ......381 Cleaning Oil (Engine) .
  • Page 505 INDEX 503 Coolant Pressure Cap (Radiator Cap) ..446 Data Recorder, Event ..... . 70 Cooling System .
  • Page 506 504 INDEX Driving Air Cleaner ......435 On Slippery Surfaces ....327 Block Heater .
  • Page 507 INDEX 505 Oil Synthetic ......434 Automatic Transmission ....454 Overheating .
  • Page 508 506 INDEX Fluid Level Checks Filler Door (Gas Cap) ....192 Automatic Transmission ... . . 453,454 Gasoline .
  • Page 509 INDEX 507 Gauges Head Restraints ......140 Coolant Temperature ....192 Headlights .
  • Page 510 508 INDEX Ignition ....... 12 Jack Location ......403 Key .
  • Page 511 INDEX 509 LATCH (Lower Anchors and Tether for Headlight Switch ..... 149 CHildren) ......77 Headlights .
  • Page 512 510 INDEX Turn Signal ....87,150,200,469,470 Maintenance Schedule ....476 Voltage .
  • Page 513 INDEX 511 New Vehicle Break-In Period ....82 Filter Disposal ..... . . 434 Identification Logo .
  • Page 514 512 INDEX Phone, Hands-Free (Uconnect™) ....97 Radial Ply Tires ......355 Placard, Tire and Loading Information .
  • Page 515 INDEX 513 Remote Keyless Entry (Sedan) ....21 Safety, Exhaust Gas ..... . . 84 Remote Sound System (Radio) Controls .
  • Page 516 514 INDEX Seats ....... . . 133 Shoulder Belts ......43 Adjustment .
  • Page 517 INDEX 515 Wheel, Tilt ......158 Tilt Steering Column ..... 158 Steering Wheel Audio Controls .
  • Page 518 516 INDEX Pressure Warning Light ....202 Traction ......328 Quality Grading .
  • Page 519 INDEX 517 Transmitter Programming (Remote Keyless Unleaded Gasoline ..... . . 373 Entry) ....... . . 25 Untwisting Procedure, Seat Belt .
  • Page 520 518 INDEX Washer Windows ......34 Adding Fluid ..... . . 441 Power .
  • Page 521 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
  • Page 522 Chrysler Group LLC 12C41-126-AC 3rd Edition Printed in U.S.A.

Table of Contents
