- Page 1 EtherWe-1000U USB 2.0 Ethernet Adapter User’s Manual...
-
Page 2: Declaration Of Conformity
OvisLink Corp. 5F., NO.6, Lane 130, Min-Chuan Rd., Hsin-Tien City, Taipei County, Taiwan Declare that the product USB2.0 Ethernet Adapter AirLive EtherWe-1000U is in conformity with In accordance with 89/336 EEC-EMC Directive and 1999/5 EC-R & TTE Directive Clause Description ■... - Page 3 1999/5/EY oleellisten vaatimusten ja sitä koskevien pertinenti stabilite dalla direttiva 1999/5/CE. direktiivin muiden ehtojen mukainen Ar šo OvisLink Corp. deklarē, ka AirLive Hér með lýsir OvisLink Corp yfir því að AirLive Latviski [Latvian] EtherWe-1000U atbilst Direktīvas 1999/5/EK Íslenska [Icelandic] EtherWe-1000U er í samræmi við grunnkröfur og būtiskajām prasībām un citiem ar to saistītajiem...
-
Page 4: Safety Instructions
All trademarks, trade names and copyrights are properties of their respective owners. AirLive EtherWe‐1000U User’s Manual 1 ... -
Page 5: Table Of Contents
On MAC OS X 10.x ...................... 7 Chapter 3: Specification .............. 11 Chapter 4: Regulatory Compliance ..........12 AirLive EtherWe‐1000U User’s Manual 2 ... -
Page 6: Chapter 1: Introduction
USB2.0 Ethernet Adapter x1 Driver CD Quick Installation Guide 1-3 System Requirements IBM compatible Pentium-233MHz or faster PC or Mac 64 MB RAM or more One available USB port Windows® 2000, XP, Vista 32/64-bit; Mac OS X 10.x AirLive EtherWe‐1000U User’s Manual 3 ... -
Page 7: Led Status
1-4 LED Status Color Description Power Green On for connection to a 100Mbps network. Off for connection to a 10Mbps or not connected. Link Green LAN activity. Blinking when there is data flow between LAN and the host computer. AirLive EtherWe‐1000U User’s Manual 4 ... -
Page 8: Chapter 2: Installation
Actual strings depend on your operation system. These screen shots are from Windows Vista and might vary slightly for each operation system. When the installation is done, click Finish. (On Windows 2000, you will need to restart your computer as prompted.) AirLive EtherWe‐1000U User’s Manual 5 ... -
Page 9: Verifying The Driver Installation On Windows
On Windows XP/2000: Right-click My Computer on the desktop and click Properties > (Hardware) > Device Manager. In the Network adapters group, an item named EtherWe-1000U USB2.0 to Fast Ethernet Adapter should be displayed. If there is a question or exclamation mark next to that item, then the driver is not properly installed. Please delete the item, select the Delete the driver software for this device option (if provided), unplug the adapter from your computer and then repeat the installation steps. -
Page 10: On Mac Os X 10.X
Insert the provided driver CD into your CD-ROM drive. Double-click the CD and navigate to the directory of \Driver\Mac10.x. In the directory of Mac10.x, select and copy the folder named EtherWe-1000U.kext. On the desktop, double-click the start-up drive. Paste the EtherWe-1000U.kext to the root directory of the disk. - Page 11 If there is one old driver in the Extensions directory, please remove it first by executing the command: sudo rm –R /System/Library/Extensions/EtherWe-1000U.kext You will need to enter your password as prompted. Paste the driver to the Extensions folder by the command line below: sudo cp –R //EtherWe-1000U.kext /System/Library/Extensions/EtherWe-1000U.kext AirLive EtherWe‐1000U User’s Manual 8 ...
- Page 12 To verify the installation, you can go to /System/Library/Extensions to check if EtherWe-1000U.kext is present. Connect the Ethernet adapter to a free USB port. Reboot your Mac. Start System Preferences and select Network. You will find that a new Ethernet network interface is available. It’s usually named Ethernet Adapter (en1) or Ethernet Adapter (en2).
- Page 13 Now you are ready to configure the network settings for network access. You must use the command line to install the driver as instructed above. Simply copy and paste EtherWe-1000U.kext to the Extensions folder will lead to an improper installation as the warning message below: Now the installation is complete.
-
Page 14: Chapter 3: Specification
Windows 2000, XP, Vista 32/64-bit; Mac OS X 10.x Dimensions 72 x 52x 26 mm (L x W x H) Weight 0℃ to 70℃ Operating Temperature Certifications FCC, CE * Specification is subject to change without further notice. AirLive EtherWe‐1000U User’s Manual 11 ... -
Page 15: Chapter 4: Regulatory Compliance
AirLive EtherWe‐1000U User’s Manual 12 ...
