- Page 1 OWNER’S MANUAL IES Quicksilver Electric Bicycle Copyright 2004 IES...
-
Page 2: Record Of Serial Number
’ – IMPORTANT! Congratulations on selecting the IES Quicksilver. In order to use and enjoy your bicycle safely and to get the best performance and durability from this product, please read this manual before riding. Warning! Even on the best days, riding or operating any sort of vehicle is hazardous. -
Page 3: Photo Of Quicksilver
’ – ’ – QUICKSILVER-BUTTER YELLOW... -
Page 4: Table Of Contents
’ – ’ – Table of Contents Page • Record of serial number • Photo of Quicksilver • Table of Contents • Cautions and Warnings • Inspection • Illustration of bike • Assembly Instructions • Adjusting the Brakes • Operational Instructions / Electric Bike components •... -
Page 5: Cautions And Warnings
’ – ’ – CAUTIONS AND WARNINGS Please read this section! It is very important for your safety and satisfaction that you read these cautions and warnings. Thanks! Warning! Always wear your helmet, obey local laws, and exercise caution when riding. Warning! If you are not certain that your bike is safe to ride, take it to an authorized dealer and ask for a safety inspection. -
Page 6: Inspection
’ – ’ – INSPECTION The following is a list of all the necessary parts and components of your new Quicksilver. Please make sure everything is enclosed in the box and in good working condition. Bicycle 1 Comfort Saddle 2 Pedals Power Source (charger) Took Kit Battery... -
Page 7: Illustration Of Bike
’ – ’ – Figure 1 – Parts of your Quicksilver Figure 1 – Parts of your Quicksilver QUICKSILVER-BUTTER YELLOW 1 – Brake Lever 10 – Battery Indicator 19 – Saddle 2 – Handlebar 11 – Battery (under seat) 20 – Rear Shocks 3 –... -
Page 8: Assembly Instructions
’ – ’ – ASSEMBLY INSTRUCTIONS Tools Required For Assembly This bicycle can be assembled with the tools supplied in the bike’s shipping carton. For this bike, a set of metric Allen wrenches, an 8” crescent wrench, a standard screwdriver, slip joint pliers, a Phillips screwdriver, and a tire pump are needed for assembly. -
Page 9: Adjusting The Brakes
’ – ’ – ADJUSTING THE BRAKES Adjust the brakes by turning the adjusting nuts located at the junction of the brake cable and brake lever. When you have determined the proper setting, turn the knurled knob at the shaft of the adjusting bolt all the way down to the brake lever to lock the brake setting in place. -
Page 10: Operational Instructions / Electric Bike Components
’ – ’ – OPERATIONAL INSTRUCTIONS Before You Ride Make sure all of your quick releases are locked and secure. Make sure all parts, components and accessories are in good working order. Check all fittings and be sure that they are tight and secure. Inspect your bike completely. BICYCLE COMPONENTS Wheels Wheels should be centered in fork or dropouts. - Page 11 ’ – ’ – BICYCLE COMPONENTS (continued) Tires Inflate your tires up to a maximum pressure of 40 PSI. Every time you ride, make sure that the tires are inflated according to pressure indicated on tire sidewall. Improper tire pressure will cause excessive wear, causing premature replacement.
- Page 12 ’ – ’ – BICYCLE COMPONENTS (continued) Computer/Display Your bike is equipped with a display unit that will inform you of the battery charge state, and other functions. Power On/Off Your Power On/Off switch is a key switch located near the bicycle frame. Some models use the same key to lock the battery box and accessory box.
-
Page 13: Recharging Your Battery
’ – ’ – RECHARGING THE BATTERIES It is important that you charge your batteries after every use. This will extend the total life of your battery. Once the charger has indicated that the battery is fully charged, unplug the power source from the bicycle and from the electrical outlet and store in a cool (59°-86°... -
Page 14: Pre-Cautions While Recharging Your Battery
’ – ’ – PRE-CAUTIONS WHILE RECHARGING THE BATTERY 1. Using your power source incorrectly or leaving the power source connected to the bicycle and plugged into an AC power source for extended periods of time can result in a fire. 2. -
Page 15: Bicycle Care
’ – ’ – BICYCLE CARE We recommend having your Quicksilver serviced once a year by a bicycle mechanic for regular bicycle maintenance in order to ensure safety and keep components in proper working order. Throughout the year, there are simple steps you can take to inspect and maintain your Quicksilver: 1. -
Page 16: Safety Responsibility
’ – ’ – SAFETY RESPONSIBILITY Know the laws of your state. It is your responsibility to know and obey the laws of your local area concerning the operation of an electric bicycle. In most cases, cyclists must obey the same laws that apply to motorists. This may include the use of proper protective equipment –... -
Page 17: Warranty
’ – ’ – WARRANTY Electric Bike Limited Warranty With normal care and recommended maintenance, this electric bicycle is warranted to be free of defects in materials and workmanship for a stated period of six months from the date of purchase. We will repair or replace, at our option, any product or part that is defective in material or workmanship, without charge, if the product is presented to us via our authorized service center, with dated proof of purchase, inside the warranty... -
Page 18: Troubleshooting
’ – ’ – TROUBLESHOOTING Problem Possible Cause Correction Turn the power switch to 1. Fuse has melted 1. Replace the fuse “ignition” position. 2. Power switch 2. Contact the nearest Indicator light does not trouble authorized dealer work. 3. Electrical fault 3. -
Page 19: Specifications
’ – ’ – QUICKSILVER SPECIFICATIONS Description Specification Size(Mm) 1500x600x1060 Highest Speed 22~26km/min Mileage Per Charge 45~50km Noise <60dB(A) Consumption Per 100km 0.6kWh Loading 85kg Battery 36V/12Ah Motor Brushless motor Motor Power <240w Rated Rotation Speed 175r/min Rated Rotation Torque 16N.m Wheel Size 18”...
